Buffalo TeraStation Live Manual de usuario

Quick Setup Guide

TeraStation Live

Table of Contents

English.................................................................................................................................. 2

Deutsch............................................................................................................................. 12

Français.............................................................................................................................. 22

Italiano...............................................................................................................................32

Español ..............................................................................................................................42

Português..........................................................................................................................52

Nederlands.......................................................................................................................62

Svenska.............................................................................................................................. 72

Norsk.................................................................................................................................82

Dansk.................................................................................................................................92

Suomi...............................................................................................................................102

Package Contents:

• TeraStation Live

• Ethernet Cable

• Power Cable

• TeraNavigator Installation CD

• Quick Setup Guide

• Warranty Card

Quick Setup Guide

TeraStation Live

English

Step 1: Connect your Cables

Plug TeraStation’s power cord and Ethernet cable into the back of the

TeraStation.

Connect the power plug to a power outlet or surge protector. Plug the other

end of the Ethernet cable into a hub, switch, or router on the network.

Press the power button on the front panel to turn yourTeraStation on.

Check the LINK/ACT LED on the front of the TeraStation. If it’s lit, then your

TeraStation is connected to your network. Please turn to page 5 to continue

setup.

If the LINK/ACT LED on the front of TeraStation is not lit, your TeraStation is

not properly connected to your network. Make sure that:

If problems persist, contact our technical support.

• both TeraStation and the hub, switch, or PC are powered on.

• the Ethernet cable is securely fastened to both devices.

• the Ethernet cable is not damaged. To verify, try using another Ethernet cable.

Step 2: Check your Connection

Insert the TeraNavigator CD

into your computer’s CD-ROM

drive. If Setup doesn’t launch

automatically, you can launch

it manually by clicking Start,

then Run.... When the Run

dialog opens, type d:\setup.exe

(where “d” is the drive letter of

your CD-ROM). Press OK to

continue. If you are installing the software on a Mac, open the

CD and click on theTeraNavigator icon to begin installation.

If you’re installing on a Mac, skip to

the next page.

If you’re installing on a PC, click on

Connect this PC toTeraStation

(the green, lower button).

Click Next to step through the

installation.

Step 3: Installing Software

Click on Begin Installation.

Continue pressing Next to step

through the installation.

When installation is complete, you

may close the installation window.

Congratulations!Your TeraStation is ready to use.

Please see the TeraStation User Manual on yourTeraStation CD for more

help and conﬁguration options.

Step 3: Installing Software (cont’d)

The TS-Live shortcut will open the folders on your

TeraStation.

Share is the main folder that you can put ﬁles and folders

in. Info contains a copy of your user manual.

Using yourTeraStation with a Windows PC

The Buffalo NAS Navigator icon opens the

TeraStation’s client utility.This lets you easily view

system information for your TeraStation(s). If you

click Setup and choose Conﬁ guration Settings,

it will take you to the settings conﬁguration

GUI, where you may change yourTeraStation’s

settings. Until you change it, the default username

is “admin” and the password is “password”.

Consult your user manual for more information

on the Buffalo NAS Navigator and the Settings

Conﬁguration GUI.

Another way to access folders and data on your

TeraStation is through the mapped driveletter

‘T’.When the installation program ran, it added

yourTeraStation’s main “share” folder to your

“My Computer” folder as drive ‘T’. Use this

virtual hard drive like any other hard drive on

your computer.You may add additional shares and

mapped drive letters to your TeraStation and PC; consult your user manual for more

information.

If you’re using a Windows PC, two new icons will be on

your desktop: Shortcut for your TS-Live and Buffalo

NAS Navigator.

After installing the TeraNavigator software, your

Mac will have two new icons on the desktop.

The Share folder is the main folder that you can

put ﬁles and folders in. NAS Navigator is the

TeraStation’s client utility.

Using yourTeraStation with a Mac

Clicking NAS Navigator

opens the TeraStation’s client

utility.This lets you easily view

system information for your

TeraStation(s). If you click

Setup and choose Browser

Management, it will take you

to the settings conﬁguration

GUI, where you may change

yourTeraStation’s settings. Until

you change it, the GUI’s username is “admin” and the password is “password”.

Consult your user manual for more information on the Buffalo NAS Navigator

and the Settings Conﬁguration GUI.

Clicking Share opens the main

folder on the TeraStation. You

may add additional shares

to yourTeraStation; consult

your user manual for more

information.

Firmware Language -The default language for the web interface is English.

This can be changed on both PC & Mac by selecting the Basic screen, and then

choosing your desired language from the Display Language drop down.You will

also need to select the corresponding Windows Client Language. Click on Apply

to implement your changes.You must log out and log in again to view your

changes.

Technical Support

Buffalo Technology offers free technical support. See the back page of this quick

start guide for contact information. Please also visit the web site at:

http://www.buffalo-technology.com.

FCC Warning

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

Technical Speciﬁ cations

LAN Standards: IEEE 802.3u 100BASE‑TX; IEEE 802.3 10BASE‑T

Transmission: 1000/100Mbps/10 Mbps, 1000BASE‑T: 8B1Q4,

PAM5, X 4B/5B, MLT‑3; 10BASE‑T Manchester Code

Access Media: CSMA/CD

Media Interface: RJ‑45

USB Standard: USB 2.0

Hi‑Speed (HS)

Full‑Speed (FS)

Low‑Speed (LS)

USB Connector: USB A Connector (2)

Data Transmission Speed: Max: 480 Mbps (HS Mode)

Max: 12 Mbps (FS Mode)

Electric Current: 220‑240V A/C

Power Consumption: ~17W (Varies based on size)

Dimensions: 170 x 235 x 310 mm

Weight: ~7Kg. (Weight varies based on size)

Operating Temperature: 5-35˚ C; 20-80% non-condensing

Data Transmission Speed:

Max: 480 Mbps (HS Mode)

Max: 12 Mbps (FS Mode)

Power Consumption:

~17W (Varies based on size)

Access Media:

CSMA/CD

LAN Standards:

IEEE 802.3u 100BASE‑TX; IEEE 802.3 10BASE‑T
