Buffalo CP821 Manual de usuario
Model • Modèle • Modell • Modello • Modelo • Malli:
CP821
Spiral Dough
Mixer
Instruction manual
UK Spiral Dough Mixer
Instruction manual
4DE Spiral-Teigkneter
Bedienungsanleitung
19
NL Spiraal deegmenger
Handleiding
9IT Impastatrice a spirale
Manuale di istruzioni
24
FR Pétrin à spirale
Mode d'emploi
14ES Amasadora Espiral
Manual de instrucciones
29
CP821_ML_A5_v3_20211125.indb 1CP821_ML_A5_v3_20211125.indb 1 2021/11/25 14:172021/11/25 14:17
SPARE PARTS LIST OF CP821
CP821_ML_A5_v3_20211125.indb 2CP821_ML_A5_v3_20211125.indb 2 2021/11/25 14:172021/11/25 14:17
NO. Description QTY. NO. Description QTY.
1. Small chain wheel of main
shaft 1 29. Chain 06B-1-70L 2
2. Big chain wheel 3 30. Control panel 1
3. Spindle Sprocket Flange 4 31. Motor belt wheel 1
4. Bearing 6205-Z 2 32. Belt A630 2
5. Main shaft 1 33. Motor seat 1
6. Hook 1 34. Motor 1
7. Bowl 1 35. Plate 1
8. Bowl shaft 1 36. Chain wheel 1
9. Bearing 6205-Z 2 37. Chain wheel lining ring 1
10. Shaft ring 25 1 38. Chain wheel shaft 1
11. Flanges of bowl shaft 1 39. Frame 1
12. Chain 06B-1-92L 1 40. Switch seting board 1
13. Flanges of drive shaft 1 41. Fixed block 1
14. Shaft ring 30 1 42. Down bearing seat 1
15. Shaft Sleeve 2 1 43. Housing 1
16. Bearing 6204-Z 2 44. Cover 1
17. Bearing Spacer 1 45. Brand 1
18. Shaft Sleeve 1 1 46. Up bearing seat 1
19. Ring 20 1 47. Back cover 1
20. Shaft ring 20 1 48. Lateral board 2
21. Bearing 1204-Z 2 49. Grounding mark 1
22. Drive shaft 1 50. Protect sets 4
23. Small chain wheel of drive
shaft 1 51. Anchor rubber pad 4
24. Clamp plate 34 1 52. Screw M8 4
25. Cover of fixed shaft 2 53. Bottom cover board 1
26. Protect cover 1 54. Small chain wheel of drive
shaft 1
27. Left fixed shaft 1 55. Drive pulley 1
28. Right fixed shaft 1
CP821_ML_A5_v3_20211125.indb 3CP821_ML_A5_v3_20211125.indb 3 2021/11/25 14:172021/11/25 14:17
4
UK
Safety Instructions
THE MIXER IS A DANGEROUS APPLIANCE AND
MUST ONLY BE USED BY TRAINED PERSONNEL
IN ACCORDANCE WITH THESE INSTRUCTIONS.
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• Always stand BEHIND the safety guard when operating the
appliance.
• DO NOT place hands near the rotating attachments when in
use. This can result in severe injury.
• DO NOT remove food from the appliance until the mixing
attachments have come to a complete stop.
• DO NOT immerse the appliance in water.
• DO NOT attempt to mix items that this machine is not
designed for. This can damage the mixing attachments.
• DO NOT use with a damaged mixing attachment.
• DO NOT bypass the safety interlocks.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• NEVER leave the appliance unattended when in use.
• The appliance is heavy. Take care when moving.
CP821_ML_A5_v3_20211125.indb 4CP821_ML_A5_v3_20211125.indb 4 2021/11/25 14:172021/11/25 14:17
5
UK
• This appliance must only be used in accordance with these
instructions and by persons competent to do so.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by an
BUFFALO agent or a recommended qualified technician in
order to avoid a hazard.
• Never use accessories which are not recommended by the
manufacturer. They could pose a safety risk to the user and
might damage the appliance. Only use original parts and
accessories.
• BUFFALO recommends that this appliance should be
periodically tested (at least annually) by a Competent Person.
Testing should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
• BUFFALO recommend that this product is connected to a
circuit protected by an appropriate RCD (Residual Current
Device).
Introduction
This BUFFALO Spiral Dough Mixer is intended mainly to mix doughs. With the spiral hook and bowl, it
is capable of versatile actions of pushing, pulling, kneading and pressing to make fast dough in hotels,
restaurants and other catering units for making bread and cakes.
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your BUFFALO product.
CP821_ML_A5_v3_20211125.indb 5CP821_ML_A5_v3_20211125.indb 5 2021/11/25 14:172021/11/25 14:17
6
UK
Pack Contents
The following is included:
• BUFFALO Spiral Dough Mixer • Instruction Manual
BUFFALO prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your BUFFALO dealer immediately.
Installation
• Ensure the location of the spiral mixer is capable of supporting its weight.
• WARNING: The mixer is very heavy, care must be taken when moving it.
• If the appliance is intended to be positioned on a worktop, please ensure it is secured in position.
Operation
Mixing
WARNING: Always
ensure the appliance
is turned off before
placing hands in the
mixing bowl.
1. Lift the safety guard.
2. Fill the bowl.
3. Close the guard.
Note: Ensure the
safety guard is fully
closed or the mixer
will not work.
4. Select the desired mixing time with
the Timer knob.
5. Press the Start button to begin
mixing.
Mixing bowl
Safety guard
Control panel
Top cover
Overload
switch
If the appliance is straining to mix:
1. Turn the appliance Off by pressing down the Stop button;
2. Remove some of the contents from the bowl and close the guard;
3. Rotate the Stop button clockwise to release it;
4. Press the Start button to resume working.
CP821_ML_A5_v3_20211125.indb 6CP821_ML_A5_v3_20211125.indb 6 2021/11/25 14:172021/11/25 14:17
7
UK
Overload Switch
The Overload switch is situated at the back of the machine. If the appliance becomes too hot the
Overload switch will stop the machine automatically. If this happens:
1. Turn Off the mixer.
2. Reduce the load in the mixing bowl.
3. Push the Overload switch back in to reset it.
4. Allow the appliance to cool for 30 minutes.
Note:
• In the event of a power cut the Overload switch will cut in to prevent the
appliance from restarting automatically when power is restored.
• Always disconnect the Mixer from the mains powers supply when not in use.
Cleaning, Care & Maintenance
• Always turn off the mixer and disconnect from the power supply before cleaning.
• Use warm soapy water to clean the bowl and mixing attachments. Do not use abrasive cleaning
chemicals as these can leave harmful residues.
• Clean the exterior of the appliance with a damp cloth.
• Do not use jet/pressure washers to clean the appliance.
• Clean the appliance regularly.
• Dry all parts thoroughly after cleaning.
Troubleshooting
If your BUFFALO appliance develops a fault, please check the following table before making a call to the
Helpline or your BUFFALO dealer.
Fault Probable Cause Solution
The appliance is
not working The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Call BUFFALO agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Mains power supply fault Check mains power supply
The Stop button not released Turn Stop button clockwise to release
The overload switch has activated See overload switch information in the
Operation section of this manual
Safety Guard not closed Close Safety Guard fully
The appliance is
overheating The mixing bowl is overloaded Turn off the appliance and empty some of the
contents
The appliance has been operating
for too long Turn off the appliance and allow to cool down
for 30 minutes
The appliance is
noisy Poor lubrication Call BUFFALO agent or qualified Technician
Loose chain Call BUFFALO agent or qualified Technician
Spiral hook hitting
bowl Hook or bowl deformation Call BUFFALO agent or qualified Technician
CP821_ML_A5_v3_20211125.indb 7CP821_ML_A5_v3_20211125.indb 7 2021/11/25 14:182021/11/25 14:18
8
UK
Technical Specifications
Model Voltage Power Current Dimensions
H x W x D mm
Rotating speed
(RPM) Max flour
for each
kneading Weight Bowl
Volume
Bowl Hook
CP821 220-240V~
50/60Hz 1100W 7.2A 695 x 380 x 690 20 185 ≤ 8kg 78kg 20L
Electrical Wiring
This appliance is supplied with a 3 pin BS1363 plug and lead.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
BUFFALO parts have undergone strict product testing in order to comply
with regulatory standards and specifications set by international,
independent, and federal authorities.
BUFFALO products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of BUFFALO.
Every effort is made to ensure all details are correct at the time of going to press, however, BUFFALO reserve the right to
change specifications without notice.
CP821_ML_A5_v3_20211125.indb 8CP821_ML_A5_v3_20211125.indb 8 2021/11/25 14:182021/11/25 14:18
9
NL
Veiligheidstips
DE MENGER IS EEN GEVAARLIJK APPARAAT
EN MAG ALLEEN WORDEN GEBRUIKT DOOR
OPGELEID PERSONEEL IN OVEREENSTEMMING
MET DEZE INSTRUCTIES.
• Plaatsen op een vlakke en stabiele ondergrond.
• De installatie en eventuele reparaties dienen door een
gekwalificeerde onderhoudsmonteur/vakman uitgevoerd te
worden. Verwijder geen componenten of servicepanelen van
dit product.
• Raadpleeg en volg de plaatselijke en nationale regelgeving op
m.b.t. tot het volgende:
- Wetgeving van gezondheid en veiligheid op de werkplaats
- Werkregels
- Brandpreventie
- IEE-bedradingsvoorschriften
- Bouwvoorschriften
• Ga altijd ACHTER de veiligheidsscherm staan wanneer u het
apparaat gebruikt.
• Bij gebruik, plaats uw handen NIET in de buurt van draaiende
componenten. Dit kan ernstig letsel veroorzaken.
• Verwijder GEEN voedsel uit het apparaat voordat alle
mengcomponenten volledig tot stilstand zijn gekomen.
• Dit apparaat NIET in water dompelen.
• Probeer NIET items te mengen waarvoor dit apparaat niet
ontworpen is. Dit kan de mengcomponenten beschadigen.
• Gebruik het apparaat NIET met een beschadigd
mengcomponent.
• Veiligheidsvergrendelingen NIET overbruggen.
• Schakel altijd uit en koppel de stroomtoevoer naar de apparaat
wanneer het niet in gebruik is.
• Laat het apparaat NOOIT zonder toezicht achter wanneer het
in gebruik is.
CP821_ML_A5_v3_20211125.indb 9CP821_ML_A5_v3_20211125.indb 9 2021/11/25 14:182021/11/25 14:18
10
NL
• Het apparaat is zwaar. Wees voorzichtig bij het verhuizen.
• Het apparaat is zwaar. Wees zeer voorzichtig bij het
verplaatsen van het apparaat.
• Dit apparaat is niet bedoeld voor gebruik door personen met
lichamelijke, zintuiglijke of mentale beperkingen (inclusief
kinderen) of met gebrek aan ervaring of kennis, tenzij zij
hierin worden begeleid of zijn opgeleid in het gebruik van het
apparaat door een persoon, die verantwoordelijk is voor hun
veiligheid.
• Men dient er toezicht op te houden dat kinderen niet met het
apparaat spelen.
• Laat verpakkingsmateriaal niet binnen handbereik van
kinderen. Verpakkingsmateriaal in overeenstemming met
de regelgeving van de plaatselijke overheden als afval laten
verwerken.
• Indien de stroomkabel beschadigd raakt, dient men deze
door een BUFFALO-monteur of aanbevolen vakman te laten
vervangen om gevaarlijke situaties te voorkomen.
• Gebruik nooit accessoires die niet door de fabrikant worden
aangeraden. Zij zouden een veiligheidsrisico kunnen vormen
en het apparaat kunnen beschadigen. Gebruik alleen originele
onderdelen en accessoires.
• BUFFALO beveelt aan dat dit apparaat periodiek (minstens
jaarlijks) door een bevoegde persoon wordt getest. Tests moeten
omvatten, maar zijn niet beperkt tot: visuele inspectie, polariteit,
aardings continuïteit, isolatie continuïteit en functionele test.
Invoering
De BUFFALO Spiraal Deegmenger is voornamelijk bedoeld om deeg te mengen. Met de spiraalhaak en
kom is het in staat tot veelzijdige acties van duwen, trekken, kneden en persen om snel deeg te maken in
hotels, restaurants en andere cateringeenheden voor het maken van brood en gebak.
Neem de tijd om deze handleiding aandachtig door te lezen. Correct gebruik en onderhoud van deze
machine waarborgt de beste prestatie van uw Buffalo product.
CP821_ML_A5_v3_20211125.indb 10CP821_ML_A5_v3_20211125.indb 10 2021/11/25 14:182021/11/25 14:18
Otros manuales para CP821
1
Tabla de contenidos
Idiomas:
Otros manuales de Mezclador de Buffalo
