BT CONVERSE 425 Manual de usuario

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

User Guide

BT CON ERSE 425

This product is intended for connection to analogue

public switched telephone networks and private

switchboards in the United Kingdom.

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

Please open this page for an ‘At a glance’ guide

to your BT Converse 425.

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

At a glance

1 2

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

BT Converse 425

Message Waiting indicator

(for compatible switchboard users only).

Flashes when there is Voice Mail.

Call timer

Used to time the duration of a call.

Recall

For use with a switchboard/PBX, e.g. to

transfer calls and some BT Calling Features.

Redial

Redials the last number.

Repeat dials a number when the line is

engaged.

Also lets you enter a Pause in a stored

number.

Calculator button

Switches the calculator on and off.

Navigator Wheel

Quick access to the directory. Adjusts the

volume of the caller’s voice.

Displays range of calculator functions.

(Tick Button)Select

Dials telephone numbers displayed on the

screen.

Also confirms options displayed on the

screen in the directory and used to store

entries in the directory and selects

calculator functions.

Directory

Lets you store up to 75 names and numbers

including pre-set BT Calling Features:-

1471 Call Return, Call Diversion,

Reminder Call and 1571 – Call Minder/

BT Answer.

eadset (and light) button

Used when there is a headset

connected.

Display

Shows 24 hour clock, battery low

indicator, phone numbers, and names.

Call indicator light

Flashes to indicate you have an

incoming call.

andset park

When the phone is wall mounted you

can hang the handset here if you need to

leave the phone during a call.

Inserts a space in a number when storing

numbers in the memory.

Clear

Used to edit numbers when pre-dialling

or when storing or editing numbers in

the memory.

andset hook

Rotates to hold the handset in place

when wall mounted.

Volume

Used with the Navigator wheel to adjust

the volume of the dial tone and your

caller’s voice.

Secrecy button (and light)

Allows you to talk to someone in the

same room without your caller being able

to hear the conversation.

andsfree button (and light)

Allows you to talk to callers without lifting

the handset.

earing aid compatible

Your Converse handset

is hearing aid

compatible.

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

In this guide

At a glance 1

Introduction 4

Unpacking your Converse 425 4

For your records 4

Safety information 4

Setting up 5

Using the telephone 7

Secrecy 8

Last number redial 8

Handsfree talking

Directory 10

Using the calculator 13

Data port 14

Using BT Calling Features 15

1471 Call Return 15

Call Diversion 16

1571 – Call Minder/BT Answer 16

Reminder Call 17

Other services 17

General information 1

Guarantee 18

Technical information 1

Switchboard compatibility 1

R&TTE Directive 1

Wall-mounting 20

Index 21

Hints and tips boxes

In this user guide, we’ve included

helpful tips and important notes.

They are shown in boxes like this.

BT Converse 425

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

Introduction

Your Converse 425 has been designed for ease of use and made

to the high standards set by BT.

Unpacking your

Converse 425

For your records

For guarantee purposes, proof of

purchase is required, so please keep

your receipt.

Date of purchase:

Place of purchase:

Serial number

(on the underside of the base unit):

Purchase price:

Please read the instructions carefully

before use and keep this User Guide

for future reference.

INT ODUCTION

If anything is missing, please contact

your place of purchase immediately.

Converse 425 telephone

with telephone line

attached.

Screws, wall plugs and

plinth for wall-mounting.

3 x AAA batteries

Safety information

General

Simply clean your Converse 425 with a damp

(not wet) cloth, or an antistatic wipe.

Never use household polish as this may

damage the product.

Never use a dry cloth as this may cause

static shock.

Do not open the Converse 425. This could

expose you to high voltages or other risks.

Never dispose of batteries in a fire. There is

a serious risk of explosion and/or the release

of highly toxic chemicals.

Environmental

Do not expose to direct sunlight.

We recommend that you do not place the product

on antique/veneered wood to avoid damage.

Do not stand your product on carpets or other

surfaces which generate fibres, or place it in locations

preventing free flow of air over its surfaces.

Do not submerge any part of your product in water

and do not use it in damp or humid conditions,

such as in bathrooms.

Do not expose your product to fire, explosive or

other hazardous conditions.

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

1Install t e batteries

The display on your Converse 425 is

Make sure the phone is not plugged

into the phone socket. Open the battery

compartment cover.

Insert batteries as shown.

Close the lid and replace the

compartment cover.

Plan t e location

Situate your Converse 425 close

enough to a phone socket so that the

line cord will reach.

Your Converse 425 can be wall-mounted.

See ‘Wall-mounting’, on page 20.

Setting up

2Plug your Converse 425

into t e p one socket

SETTING UP

3C eck t e dialling mode

Your Converse 425 should be pre-set to

T-TB which gives you TONE dialling.

This ensures the phone will work with

all modern digital exchanges.

If your phone does not work when you

dial a number, try setting the dialling

mode to Tor P.

Note

When your batteries are within about

two weeks of total exhaustion, BATT

LOW will appear in the display. If you

do not replace the batteries and

they become totally discharged your

Converse 425 will not display anything

on the screen.

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

4Set t e time

Press and hold the Clock

button until the display shows

TIME

Release the Clock button.

Display shows

00-00

Enter the current time using

the 24 hour clock,

eg. 0 9 3 0 = 9.30am,

1 5 3 0 = 3.30pm.

Press the ✔button.

The time is set and displayed.

Your Converse 425 is now ready for use.

SETTING UP

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

To make a call

Lift the handset off the base

and wait for the dial tone.

Dial the telephone number.

The display will show the

number dialled.

Preparatory dialling.

Without lifting the handset,

dial the telephone number

you want. The number is

displayed.

Press the ✔button.

The displayed number is

dialled in ‘handsfree’mode.

To end a call

Replace the handset.

To receive a call

When the telephone rings, the

Call indicator light will flash to

indicate that there is an

incoming call. Simply pick up

the handset.

Using the telephone

Note

There are three ways to make a call

on your Converse 425: by lifting the

handset, using the Handsfree button

or by using the ✔button.

Note

If you make a mistake, use

the Clear button to delete

the last digit you have entered.

USING

Hearing Aid Compatibility

As this telephone is fitted with an

Inductive Coupler, Hearing Aid

wearers may benefit from switching

their hearing aid to the middle T

position and holding the earpiece up

to the aid, not their ear.

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

Using a eadset

Plug the headset into the

socket marked HEADSET on

the underside of the base.

To make a call, press the

Headset button.

Dial the telephone number.

To end the call, press the

Headset button.

Note

Converse headsets (RJ11 jack)

are available separately

from BT shops or by calling

0870 240 5522.

Secrecy

When on a call you can talk to someone

in the same room, without your caller

hearing.

To switc Secrecy on and off

During a call, press and release

the Secrecy button.

The red Secrecy light will

come on. Your caller cannot

hear you.

To resume your conversation,

press and release the Secrecy

button again. The Secrecy

light will go off.

USING

To set t e call timer

You can time the duration of

each call.

During a call, press the Clock

button. The time of the

previous call will be displayed.

Press the Clock button again

to start the timer. You can stop

the time by pressing the Clock

button once more.

When you replace the handset

or press the Handsfree button

to end the call, the display shows

the final duration of the call for

a few seconds before returning

to the normal clock setting.

To redial t e last number called

Press the Handsfree button.

Press the edial button.

The last number you called is

redialled.

Last number redial

Your Converse 425 stores the last

number called which enables quick and

easy redialling. A redial number can be

no longer than 32 digits.

BT Converse 425 ~ Issue 3 ~ 2nd Edition ~ 23rd July ’03 ~ 5528

Handsfree talking

The handsfree feature allows you to

make and receive calls without lifting

the handset.

To make a andsfree call

Press the Handsfree button.

You will hear the dial tone.

Dial the telephone number.

The number will be shown on

the display.

When your call is answered

you can either speak in

handsfree mode or pick up the

handset if you wish to speak to

your caller privately.

Note

To cancel repeat dial before your call

is answered, lift the handset or press

the Handsfree button or press the

Headset button.

USING

To repeat dial a number

If the number you call is

engaged, you can set your

Converse 425 to dial a number

repeatedly, saving you from

continually having to press the

edial button.

When you hear the engaged

tone, press the edial button

and replace the handset (or

press the Handsfree button).

The display shows

BUSY

10 seconds after the handset

is replaced, your Converse 425

automatically picks up the line,

switches on the loudspeaker

and redials the number.

If it is still engaged, you need

do nothing, your phone will wait

for 45 seconds before repeating

the procedure.

This will be repeated every

45 seconds up to a maximum

of 15 times or until the call is

answered.

When your call is answered,

you can speak to your caller by

pressing Handsfree or lift the

handset or press the Headset

button and speak.

Note

This feature works in handset,

handsfree and headset modes.

To receive a call in

andsfree mode

When the phone rings, press

the Handsfree button and speak

to answer the call.

Otros manuales para CONVERSE 425

Tabla de contenidos

Otros manuales de Teléfono de BT

BT Payphone Contour 400 Manual de usuario

BT DIVERSE X10 Manual de usuario

BT DECOR 1500 Manual de usuario

BT In Touch 2000c Carer Manual de usuario

BT PARAGON 500 Manual de usuario

BT Decor 1300 Manual de usuario

BT BT DECOR 310 USER GUIDE 310 Manual de usuario

BT Inspiration Manual de usuario

BT Converse 2300 Manual de usuario

BT Duet Mini Manual de usuario

BT Inspiration Manual de instrucciones

BT PARAGON 650 Manual de usuario

BT DIVERSE 5210 Manual de usuario

BT DECOR 210 Manual de usuario

BT YOUR PHONE Manual de usuario

BT CALYPSO 120 Manual de usuario

BT RESPONSE 115 Manual de usuario

BT CALLER DISPLAY 1000 Manual de usuario

BT Converse 2300 Manual de usuario

BT Featureline Manual de usuario

BT Paragon 550 Manual de usuario

BT Big Button 200 Manual de usuario

BT Contour 200 Manual de usuario

BT Converse 2200 Manual de usuario

Manuales populares de Teléfono de otras marcas

GE 2-9480 Manual de usuario

Geemarc

Geemarc PHOTOPHONE 155 Manual de usuario

D-Link

D-Link DWR-720/PW Manual de usuario

Interquartz

Interquartz Gemini IQ333 Manual de usuario

SSS Siedle

SSS Siedle HT 840-0 Manual de usuario

Motorola

Motorola TITANIUM Manual de usuario

Panasonic

Panasonic ICX Manual de usuario

LG H870DS Manual de usuario

Samsung

Samsung GT-I9500 Manual de usuario

AT&T

AT&T Trimline 205 Manual de usuario

Selta

Selta zenyth 600 Manual de usuario

Doro

Doro AFTI 20 Manual de usuario

UNIQCELL

UNIQCELL A1 Manual de usuario

Panasonic

Panasonic KX Series Manual de usuario

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manual de usuario

NEC

NEC SV8500 Manual de usuario

Teledex

Teledex PEARL Manual de usuario

Ericsson

Ericsson Dialog 3213 Manual de usuario
