BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

User

Guide

BT Freelance

XD 100 / 100 Twin

Digital Cordless Telephone

This product is not DECT

AP compatible. It cannot

be registered to any other

DECT AP telephone and

it is not possible to register

additional handsets.

This equipment is not designed for making emergency telephone calls

when the power fails. Alternative arrangements should be made for

access to emergency services.

This product is intended for connection to analogue public switched

telephone networks and private switchboards in the United Kingdom.

Please open this page for an ‘At a glance’

guide to your BT Freelance XD 100

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832 BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

1 2

Handset display

Displays the status

of your handset.

Red light

Indicates that the phone

is ringing or in use.

Talk button

Use to make, receive and

end calls.

Int button

Use to make an internal call or to

transfer a call to the BT Freelance XD

100 additional handset (feature only

available if you have purchased the

BT Freelance XD 100 Twin).

Recall button

For use with a switchboard/PBX

and some BT Select Services.

Also use to exit the Calls list.

Quickdial button

Use to store up to 10 numbers

that can then be dialled at the

touch of two buttons.

Keypad

Delete/Secrecy button

Use to delete digits entered

incorrectly and numbers in the

Calls list. Also used to mute a call

so the caller cannot hear you talk

to someone close by.

Calls list button

Press to enter the Calls list, to

view the last 10 calls/most recent

calls. Also use to scroll up and

down through the Calls list.

Volume button

In idle mode use to adjust the

handset ringer volume.

During a call, use to adjust the

earpiece speech volume.

Redial/ ause button

Press to redial the last number

called. Also, press to dial or

store a pause in a number.

At a glance

Secrecy

ABC

DEF

MNO

WXYZ

TUV

PQRS

GHI

Redial Volume

Del





123

456

789

R Int

Quickdial

BT Freelance XD 100 Handset

Page

Charging Power/

In Use

Page

Charging

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

Additionally if you have purchased the BT Freelance XD 100 Twin

Charging light

Red light comes on

when the batteries are

being recharged.

Charging

light

Red light

comes on

when the

batteries

are being

recharged.

Use to page

a handset(s).

BT Freelance XD 100 Base

BT Freelance XD 100 Charger

Secrecy

ABC

JKL

DEF

MNO

WXYZ

TUV

PQRS

Redial Volume

Del





123

456

789

RInt

Quickdial

ote

When batteries are fully charged the charging light will

remain lit.

Power/In use light

Green light comes on to

indicate mains power.

Flashes when the line is in use.

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

Quick guide to the handset

display icons

Batteries are charged

Batteries are exhausted and require charging

Batteries are being charged

Switches off when batteries are fully charged

Handset is in use

Flashes to indicate an external incoming call

Steady during an external call

Flashes to indicate an internal call

Indicates you are dialling or storing a

number in the Quickdial memory

Secrecy feature is switched on

Steady when viewing the Calls list

Flashes when a new call has been received

in the Calls list

Steady when handset is in range of the base

Flashes when the handset is out of range of

the base

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

n this guide

At a glance 1

ntroduction 6

Unpacking 7

For your records 8

Safety information 9

Setting up 11

Using the telephone 18

Making and receiving calls 18

Secrecy 20

Last number redial 20

aging 21

Quickdial memory 22

Caller Display 24

Handset settings 26

Using the BT Freelance XD 100

additional handset 27

Internal calls 27

Transferring calls 28

Help 29

General information 31

Guarantee 31

Technical information 32

Switchboard compatibility 32

Switchboard external line access code 33

Setting pauses 33

Recall 33

ndex 34

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

ntroduction

Your BT Freelance XD 100 is designed for ease of use and

made to the high standards set by BT.

You can expect your BT Freelance XD 100 to provide many

years of quality service. Please read the instructions

carefully before use and keep this user guide for future

reference.

DECT

By purchasing the BT Freelance XD 100 you now own a

product which combines the advantages of cordless

operation with the performance of a high quality corded

telephone. It complies with the Digitally Enhanced

Cordless Telecommunications (DECT) standard and offers

unparalleled quality and features.

This user guide applies to both the BT Freelance XD 100

and BT Freelance XD 100 Twin telephones. Please note the

BT Freelance XD 100 range of telephones are non GAP

compatible. Please refer to page 27 for further information.

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

Unpacking your BT Freelance XD 1

or BT Freelance XD 1 Twin

Check that your BT Freelance XD 100 is complete.

If anything is missing, please contact your place of

purchase immediately.

BT Freelance XD 100 handset

BT Freelance XD 100 base

Power supply for the base

Telephone line cord

2 x AAA rechargeable batteries (NiMH)

(Item code 872260)

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

Additionally if you have purchased the BT Freelance XD 100 Twin:

BT Freelance XD 100 Twin additional handset

BT Freelance XD 100 Twin charger

Power supply for the charger

2 x AAA rechargeable batteries (NiMH)

For your records

For guarantee purposes proof of purchase is required, so

please keep your receipt.

Date of purchase:

Place of purchase:

Serial number:

(on the underside of the base)

Helpline

If you have problems with your phone, please call the BT

Freelance XD 100 Helpline on 08706 058 047.

(Item code 003313)

BT Freelance XD ~ 3rd Edition ~ 2nd August ’02 ~ 4832

General

Only use the power supply included with the product.

Using an unauthorised power supply will invalidate your

guarantee and may damage the telephone. The item

number for the base is 872260. The item number for the

charger is 003313 (only applicable if you have purchased

the BT Freelance 100 XD Twin).

For the handset use only approved Nickel Metal

Hydride (NiMH) rechargeable batteries. Never use

other batteries or conventional alkaline batteries. They

could lead to a short circuit or destroy the battery

casing. Recommended batteries should have a power

rating of 550mAh 1.2V. Batteries are available from the

BT Freelance XD 100 Helpline 08706 058 047.

Do not open the handset or base. This could expose you

to high voltages or other risks. Contact the helpline for

all repairs.

Radio signals transmitted between the handset and base

may cause interference to hearing aids.

It is recommended that advice from a qualified expert

be sought before using this product in the vicinity of

emergency/intensive care medical equipment.

It is recommended that if you have a pacemaker fitted

you check with a medical expert before using this

product.

Never dispose of batteries in a fire. There is a serious

risk of explosion and/or the release of highly toxic

chemicals.

Safety information
