HRVBBLHU

HRVBBSVC

HRVBBLVU

Heat Recovery Ventilators

Form No. PDS HRV.71.1

The Heat RecoveryVentilation (HRV) system offered by Bryant

is the ﬁnest unit on the market today.

The HRVB provides efﬁcient and cost-effective heat recovery

during the heating season when needed most.

As temperatures drop below 23°F (–5°C), indoor air is

recirculated periodically through the heat exchanger core to

prevent frost from forming. Competitors’methods of

supplementary electric defrost waste energy.Unlike rotary

wheel heat exchangers which mix air streams, these cross ﬂow

or counterﬂow heat exchangers ensure that there is no mixing

of the stale air stream with the fresh outdoor air stream.

A ﬁlter installed on the incoming outdoor air stream removes

large airborne particles from the intake air stream before they

enter the heat exchanger and reduces the maintenance

required.

The units’acoustically engineered design makes them the

quietest on the market and ensures that comfort is felt, not

heard.

Unlatching 2 suitcase style latches allows easy removal of the

ﬁlters and core for cleaning.

FEATURES

• Energy saving defrost cycle

• Cross ﬂow, counterﬂow heat exchangers

• Two ﬁlters on incoming outdoor air stream to protect the HRV

core

• Acoustical design

• No-tools maintenance

• Polypropylene heat exchanger core

HRVBBSVC

HRVBBLHU

HRVBBLVU

—2—

Model number nomenclature

HRV BB LHU 1 150

Maximum Capacity

(CFM)

150 CFM

200 CFM

250 CFM

330 CFM

Electrical Supply:

1 — 115 volts

Descriptor:

LHU — Large Horizontal Unit

SVU — Small Vertical Unit

LVU — Large Vertical Unit

Brand:

Bryant

Equipment Type:

Heat Recovery

Ventilator

Climate Map for Energy and Heat Recovery Ventilators

ERV Recommended w/HRV or ERV Wall Control

ERV Recommended

HRV Recommended

Honolulu

Sacramento Salt Lake

City

Boise

Salem

Vancouver

Helena

Edmonton

Calgary Regina Winnipeg

Bismark

Topeka

Denver

Oklahoma City

Austin Baton Rouge

Orlando

Atlanta Columbia

Raleigh

Washington D.C.

Nashville

Indianapolis

Springfield

Chicago

Des Moines

Minneapolis

Green Bay

Milwaukee

Detroit

Madison

Harrisburg Hartford

Boston

Syracuse

Montreal

Ottawa

Timmins

A00099

TESTED/CERTIFIED

HOME VENTILATING INSTITUTE

DIVISION OF AMCA

—3—

Controls and accessories part no. nomenclature

ACCESSORIES

K V B CN 01 01 BAU

CONTROL DESCRIPTION

BAU — Bryant Automatic Control

BBS — Bryant Basic Control

BST — Bryant Standard Control

ACCESSORY DESCRIPTION

6FM — 6 in. Flowmeters (2)

7FM — 7 in. Flowmeters (2)

8FM — 8 in. Flowmeters (2)

EXH — Exhaust Hood

HOD — Intake Hood

KIT — Balancing Kit

FIR — Interlock Relay

TIMER DESCRIPTION

20C — 20-Minute Timer Kit Carrier

60M — 60 Minute Adjustable Timer Kit

FILTER DESCRIPTION

112 — 11-1/2 x 12-3/4

116 — 11-7/8 x 16-5/8

123 — 12-15/16 x 13-1/2

145 — 14-3/8 x 15-1/2

713 — 7-13/16 x 13-1/2

810 — 8-1/8 x 10-3/4

812 — 8-7/8 x 12-3/4

916 — 9 x 16-5/8

01 — Single Pack

01 — Part Number

AC — Accessory

CN — Control

FL — Filter Media

TM — Timer

A — Original Series

B — Second Series

V — Heat Recovery Ventilator (HRV)

K — Accessory Kit

Kit Number Description Where Used

KVBCN0101CBS

Basic HRV Control Used with all HRVs

KVBCN0101CST

Standard HRV Control Used with all HRVs

KVBCN0101CAU

Automatic HRV Control HRVBLSVU, HRVBBLVU

KVAAC0101FIR

Interlock Relay When combining an HRV with a Furnace or Fan Coil

KVATM010120C

20 Minute Push ButtonTimer Used with all HRVs when 20 minute manual operation is required

KVATM010160M

60 Minute Timer Used with all HRVs, time is adjustable between 10 and 60 minutes

KVAAC0101HOD

Exterior Intake and Exhaust Hood 2 Required

KVAAC0101KIT

Start up Balancing Kit Start up Balancing Kit, includes (2) 6 in.Flow Meter Collars & Magnehelic Gage

KVAAC01016FM

6 in. Flow Meter Collar At start up, when 6 in. duct work is connected to HRV

KVAAC01017FM

7 in. Flow Meter Collar At start up, when 7 in. duct work is connected to HRV

KVAAC01018FM

8 in. Flow Meter Collar At start up, when 8 in. duct work is connected to HRV

KVAFK0101150

Internal Filter Used with HRVBBLHU 1150 Unit 11 3/4 x 12 7/8 x 3/4 (2)

KVAFK0201200

Internal Filter Used with HRVBBLHU 1250 Unit 11 3/4 x 16 3/4 x 3/4 (2)

KVAFL0101713

Internal Filter Used with HRVBBSVU 1150 Unit 7 13/16 x 13 1/2 (2)

KVAFL0101123

Internal Filter Used with HRVBBSVU 1200 Unit 12 15/16 x 13 1/2 (2)

KVAFL0101123

Internal Filter Used with HRVBBLVU 1200 Unit 12 15/16 x 13 1/2 (2)

KVAFL0101145

Internal Filter Used with HRVBBLVU 1200 Unit 14 3/8 x 15 1/2

KVAFL0101810

Internal Filter Used with HRVBBLVU 1330 Unit 8 1/8 x 10 3/4 (1)

KVAFL0101145

Internal Filter Used with HRVBBLVU 1330 Unit 14 3/8 x 15 1/2 (1)

KVAFL0101810

Internal Filter Used with HRVBBLVU 1200 Unit 8 1/8 x 10 3/4 (1)

—4—

CONTROL FEATURES

Basic Control:

Allows the user to manually set fan speed to low or high as required to maximize comfort.

Standard Control:

Offers automatic dehumidistat control and the option to select continuous or intermittent fan

operation.Setting the wall control to low will activate the continuous mode.

Automatic Control:

In addition to the features found with standard control, this package offers a recirculation mode.

These controls may only be used to operate stand-alone units with the defrost option which enables the recirculation

feature.

* Air exchange with outside.

† No air exchange with outside.

‡ Use only on units with defrost.

CONTROL DESCRIPTION AND USAGE

Fan Speed Control

— Enables user to modulate fan speed from low to high air exchange with outside.

Dehumidistat Control

— Allows the user to select the relative humidity level at which the unit would change fan speed

for dehumidiﬁcation in the winter months.

Continuous Mode

— If the relative humidity inside the building is lower than selected, air exchange occurs with the

outside at low speed.If the relative humidity inside the house is higher than selected, air exchange occurs with the

outside at high speed. Ensures continuous air exchange for constant air quality.

Intermittent Mode

— If the relative humidity inside the building is lower than selected, no air exchange occurs and the

system turns off. If the relative humidity inside the house is higher than selected, air exchange occurs with the outside

at high speed. Ensures minimum air exchange level when the building is unoccupied to minimize operating costs.

Circulation Mode

—Ifthe relativehumidity insidethebuildingislowerthanselected,the ambient airwouldbe circulated

and ﬁltered at high speed.If the relative humidity inside the house is higher than selected, air exchange would occur with

the outside at high speed. Ensures continuous movement and ﬁltration of air for maximum comfort. Available with

automatic control only.

AUTOMATIC DEFROST CYCLE FEATURES

All models offer a non-electric defrost cycle feature which prevents frost and ice buildup within the heat recovery core.

When the outside air temperature falls below 23°F (–5°C) it is electronically sensed and the dampers close the outside

air ports.This allows warm indoor air to recirculate within the heat recovery core.The frequency of this cycle increases

as the outside air temperature decreases.

* All defrost times are in the standard mode (as shipped)

† Time between defrost when within speciﬁed temperature range

CONTROL

DESCRIPTION

FAN

SPEED

CONTROL DEHUMIDISTAT

CONTROL CONTINUOUS

MODE* INTERMITTENT

MODE* CIRCULATION

MODE†

Basic

Yes No Yes No No

Standard

Yes Yes Yes Yes No

Automatic‡

Yes Yes Yes Yes Yes

MODEL 23°FTO 55°F (–5°CTO –15°C) 4°FTO –17°F (–15.6°CTO –27.3°C) BELOW –18°F (–27.8°C)

DEFROST* EXCHANGE† DEFROST* EXCHANGE† DEFROST* EXCHANGE†

HRVBBLHU

6 Minutes 60 Minutes 6 Minutes 32 Minutes 6 Minutes 20 Minutes

HRVBBSVU

6 Minutes 60 Minutes 6 Minutes 32 Minutes 6 Minutes 20 Minutes

HRVBBLVU

6 Minutes 60 Minutes 6 Minutes 32 Minutes 6 Minutes 20 Minutes

—5—

20"

(508.0)

15"

(381.0)

(120.6)

(768.3)

(58.7)

(460.4)

(428.6)

NOTES:

1.FRESH AIR FROM OUTSIDE

2.FRESH AIR FROM HRV TO HOUSE

3.STALE AIR FROM HOUSE TO HRV

4.STALE AIR FROM HR TO OUTSIDE

" DIA

(149.2)

4 PLCS

(56.2)

4 PLCS 1"

(25.4)

2 PLCS

DIMENSIONS

MODEL NO. ABCDEFG

in. mm in. mm in. mm in. mm in. mm in. mm in. mm

HRVBBLHU1150

15-1/8 384.2 4-1/16 104 5/58 143.3 14-1/2 368.9 10-3/8 288.9 4-3/8 111.3 7-3/4 196.9

HRVBBLHU1250

19 483 5-13/16 147.7 5-1/16 128.1 14-1/2 368.9 11-3/16 283.9 4-3/8 111.3 10-1/16 255.6

A98002

—6—

5 3⁄4″

[146.0] D

27″

[685.8]

22 1/16″

[560.4]

1″

[25.4]

2 PLCS

15 11⁄16″

[398.5]

1 15⁄16″

[23.8]

3 3⁄16″

[81.0]

4 9⁄16″

[115.9)]

F DIA

2 PLCS

19 3⁄4″

[501.7]

5 7⁄8″DIA

[149.2]

2 PLCS

WALL

CONTROL

WIRING

3⁄8″DIA

[9.5]

DRAINS

11⁄16″ DIA.

[17.5]

2 PLCS

2 3⁄16″

[55.6]

4 PLCS

POWER

CORD

NOTES:

1. FRESH AIR FROM OUTSIDE TO HRV

2. FRESH AIR FROM HRV TO HOUSE

3. STALE AIR FROM HOUSE TO HRV

4. STALE AIR FROM HRV TO OUTSIDE

DIMENSIONS (continued)

A98003

MODEL NO. ABCDEFG

in. mm in. mm in. mm in. mm in. mm in. mm in. mm

HRVBBSVU1150

18-1/2 469.9 4-11/16 119.1 13-5/16 388.2 15-7/16 392.1 13-9/16 344.5 5-7/8 149.2 19-15/16 506.2

HRVBBSVU1200

24-1/2 622.2 8-3/16 208.0 19-5/16 490.6 14-9/16 369.9 16-15/16 430.2 6-7/8 174.6 19-15/16 506.2

—7—

HRVBBLVU1200 or HRVBBLVU1330

A98001

17 9⁄16″

[446.9]

4 3⁄4″

[120.6]

8 1⁄8″ DIA

[206.4]

2 PLCS

5 13⁄16″

[147.6]

5 7⁄8″ DIA

[148.2]

2 PLCS

6 15⁄16″

[176.2]

7 1⁄8″

[181.0]

18 5⁄16″

[465.1] 2 3⁄16″

[55.6]

2 PLCS

12 3⁄4″

[323.9]

23 15⁄16″

[608.0]

43″

(1092.2)

19 1⁄16″

[484.2] 8 3⁄16″

[208.0]

7 3⁄16″

[182.6]

DRAIN

11⁄16″DIA.

[17.5]

2 PLCS

24 1⁄16″

[611.2]

1 1⁄2″

[38.1]

2 PLCS

22 3⁄8″

[568.3]

41″

[1041.4]

1″ [25.4]

2 PLCS

15 1⁄2″

[393.7]

NOTES:

1. FRESH AIR FROM OUTSIDE TO HRV

2. FRESH AIR FROM HRV TO HOUSE

3. STALE AIR FROM HOUSE TO HRV

4. STALE AIR FROM HRV TO OUTSIDE

WALL

CONTROL

WIRING

3⁄8″DIA

[9.5]

POWER

CORD

DIMENSIONS (continued)

—8—

PHYSICAL DATA

PERFORMANCE DATA

ELECTRICAL DATA

MODEL DESCRIPTION CONVENTIONAL COMPACT HIGH EFFICIENCY

Model No.

HRVBBVHU1150 HRVBBVHU1260 HRVBBSVC1150 HRVBBSVC1200 HRUBBLVU1150 HRUBBLVU1200 HRUBBLVU1330

Port Locations

Sides Sides Top Top Top Top Top

CoreType

Polypropylene

Cross Flow Polypropylene

Counterﬂow Polypropylene

Counterﬂow

Weight — lb (kg)

65 (29.5) 73 (33.2) 60 (27) 80 (36.3) 80 (36.3) 120 (54.5) 120 (54.5)

ShippingWeight — lb (kg)

75 (34) 83 (37.6) 75 (34) 89 (40.4) 89 (40.4) 143 (64.9) 143 (64.9)

Shipping Dimensions (in.)

Height

Width

Depth

23 1/16

36 1/16

17 13/16

22 15/16

35 1/16

22 5/16

31.5

23.25

26.00

31.5

23.25

26.00

31.5

23.25

26.00

47.5

26.0

47.5

26.0

MODEL DESCRIPTION CONVENTIONAL COMPACT HIGH EFFICIENCY

Model No.

HRVBBLHU1150 HRVBBLHU1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330

Capacity — CFM @ 0.5–

0.3ESP (in. wc)

130–168 191–210 106–150 177–211 123–141 189–209 300–334

Efﬁciency (Sensible) —

percent

32°F (0°C)

–13°F (–25°C)

65 65

60 69

60 77

67 81

69 84

72 80

Efﬁciency (Latent) —

percent

@ all temperatures

0000000

Heat Core Exchange Area

— cu ft (cu m)

120

3.4 166

4.7 90

8.4 144

13.3 144

13.3 210

19.5 210

19.5

CONVENTIONAL COMPACT HIGH EFFICIENCY

Model

HRVBBLHU1150 HRVBBLHU1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330

Voltage

120 120 120 120 120 120 120

Max Power — watts

150 218 115 195 115 250 500

Max Amps

1.4 1.9 1.2 1.8 1.2 2.2 5.4

—9—

METHODS TO SIZE HRV’S

METHOD 1

1. Calculate cu ft of occupied space.

2. Multiply by recommended air changes per hr (AC/h).

3. Divide by 60 minutes per hr to convert to CFM.

EXAMPLE:

2000 sq ft with 8 ft ceiling

0.35 air changes per hr (AC/h)

(2000 sq ft x 8 ft ceiling x 0.35 AC/h) / 60 min/h = 93.3 CFM

METHOD 2

1. Multiply number of people times 15 CFM/person.

2. Multiply number of bath rooms 20 CFM/each.

3. Add 25 CFM for kitchen.

EXAMPLE:

2 people

2 baths

1 kitchen

(2 x 15) + (2 x 20) + 25 = 95 CFM

ADDITIONAL HEATING AND COOLING LOAD CHARTS

Although the ventilators process the outside air before it enters the home, additional heating and cooling loads need to

be considered.

HEATING LOAD BTU

The heating load chart shows the heating loads in Btuh for a range of winter design temperatures for each model of

ventilator.

EXAMPLE:

The heating design temperature for Milwaukee, WI is –4°F. At –5°F, the additional heating load of the

HRVBBLHU1250 is 8417 Btuh.This additional load should be taken into consideration when sizing the

heating equipment.

Outside

Temp °F Heat Load (Btuh) @ Inside DesignTemp 72°F

HRVBBLHU1150 HRVBBSVC1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330

–25

4,688 8,165 6,970 7,690 5,500 6,650 9,990

–20

4,466 7,744 6,470 7,090 5,030 6,070 9,310

–15

4,598 8,008 5,990 6,520 4,590 5,510 8,650

–10

4,334 7,547 5,520 5,970 4,160 4,970 8,000

–5

4,069 7,087 5,070 5,440 3,750 4,470 7,380

3,805 6,627 4,550 4,840 3,300 3,910 6,640

3,541 6,167 4,130 4,360 2,940 3,470 6,060

3,502 6,100 3,730 3,900 2,600 3,050 5,500

3,220 5,608 3,290 3,400 2,240 2,600 4,870

2,938 5,116 2,930 3,000 1,940 2,240 4,350

2,950 5,138 2,580 2,610 1,670 1,910 3,850

2,636 4,591 2,240 2,250 1,410 1,600 3,370

2,322 4,045 1,900 1,880 1,160 1,300 2,870

2,009 3,498 1,600 1,560 1,940 1,040 2,430

—10—

COOLING LOAD BTU

The cooling load chart shows loads in Btuh as well.To use the cooling load chart, ﬁrst ﬁnd the design enthalpy from a

psychrometric chart using the design dry bulb and wet bulb temperatures.(See psychrometric chart on p.11.) The

cooling load can then be found for a range of enthalpies for each ventilator.

EXAMPLE:

The cooling design dry bulb temperature for Milwaukee, WI is 87°F and the average wet bulb at that

temperatureis73°F.Onthepsychrometric chart the enthalpyisabout37.7Btu/lbofdry air which will round

up to 38 Btu/lb of dry air.In the left column, at 38 Btu/lb the HRVBBLHU1250 would have an additional

cooling load of 6428 Btuh.This additional load should be taken into account when sizing the air cooling

equipment.

Outside

Enthalpy

Btu/lb

Cooling Load (Btuh) @ Inside DesignTemp 75°F and 50% Relative Humidity

HRVBBLHU1150 HRVBBLHU1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330

670 1,071 780 990 770 990 1,390

1,090 1,741 1,300 1,650 1,290 1,650 2,310

1,509 2,411 1,820 2,310 1,800 2,310 3,240

1,928 3,080 2,340 2,970 2,310 2,970 4,170

2,347 3,750 2,860 3,630 2,830 3,630 5,090

2,766 4,419 3,380 4,290 3,340 4,290 6,020

3,185 5,089 3,910 4,950 3,860 4,950 6,940

3,604 5,759 4,430 5,610 4,370 5,610 7,870

4,023 6,428 4,950 6,270 4,890 6,270 8,790

4,442 7,098 5,470 6,930 5,400 6,930 9,720

4,861 7,767 5,990 7,590 5,910 7,590 10,650

41 5,280 8,437 6,510 8,250 6,430 8,250 11,570

42 5,699 9,107 7,030 8,910 6,940 8,910 12,500

Otros manuales para HRVBBLHU

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de calefacción de Bryant

Bryant

Bryant ZONEBB3Z Manual de usuario

Bryant

Bryant DuraPac 580F Series Dimensiones y guía de instalación

Bryant

Bryant 39004DP230 Manual de lista de piezas

Bryant

Bryant ZONE PERFECT PLUS A96447 Guía

Bryant

Bryant DURAPAC PLUS 581A Guía rápida

Bryant

Bryant 581A Guía rápida

Bryant

Bryant 582A Series Manual de usuario

Bryant

Bryant 379A Manual de usuario

Bryant

Bryant 379 Manual operacional

Bryant

Bryant 580G Dimensiones y guía de instalación

Bryant

Bryant Legacy 677C**C Series Manual de usuario

Bryant

Bryant HRVBBLHU Instrucciones y recetas

Bryant

Bryant 551A Dimensiones y guía de instalación

Bryant

Bryant OUTDOOR HEATING AND COOLING UNIT 379H Manual de usuario

Bryant

Bryant Legacy 674D Manual de usuario

Bryant

Bryant 583B Series Guía

Bryant

Bryant DuraPac 580F Series Dimensiones y guía de instalación

Bryant

Bryant 378 Manual de usuario

Manuales populares de Sistema de calefacción de otras marcas

aerauliqa

aerauliqa QR350ABP Manual de usuario

WatchGas

WatchGas ATEX BEACON Manual de usuario

Viessmann

Viessmann Vitoligno 300-H Instrucciones de funcionamiento

Lampoassa

Lampoassa 203GT Manual de usuario

MSA

MSA SOA-1022 Manual de usuario

nilan

nilan Compact P Manual de usuario

ITR

ITR OASIS NE-S Manual de usuario

Carrier

Carrier 48LJD Dimensiones y guía de instalación

aldes

aldes EVEREST XV Manual de usuario

Kober

Kober C22SPV23MEF Manual de usuario

Oxygen

Oxygen X-Air V400 Manual de usuario

Carrier

Carrier FB4CNF Manual de usuario

Kroll

Kroll HM200 Manual

Kroll

Kroll HM200 Manual

NuAire

NuAire XBOXER XBC Series Manual de usuario

Trane

Trane VR104GD-U Series Manual de usuario

Vents

Vents VUT V mini Manual de usuario

Viessmann

Viessmann Divicon Manual de usuario
