OWNER’S / OPERATOR’S
MANUAL
INTRODUCTION
CONGRATULATIONS! You are now the owner of a Brown
EdgeMasterTM.
READ THIS MANUAL CAREFULLY! This manual will help you learn
how to operate and service your EdgeMasterTM correctly. Fail-
ure to read and follow the instructions of this manual could result
in personal injury or equipment damage. This manual should be
considered a permanent part of your EdgeMasterTM. All operators
should read and follow these instructions prior to operating the
EdgeMasterTM.
TABLE OF CONTENTS
SAFETY............................................................................. 1
OPERATION....................................................................... 5
TROUBLESHOOTING........................................................... 7
WARRANTY........................................................................ 8
SERVICE........................................................................... 11
PARTS LIST....................................................................... 12
ASSEMBLY INSTRUCTIONS.................................................. 16
All information, including illustrations and speci-
fications, contained in this manual are based on the
latest information available at the time of publica-
tion. The right is reserved to make changes, when
deemed necessary, without notice.
PAGE LEFT BLANK INTENTIONALLY
RECOGNIZE SAFETY INFORMATION
This is the safety-alert symbol. When you see
this symbol in this manual or on your
EdgeMasterTM, be alert to the potential for
personal injury.
SAFETY
UNDERSTAND SIGNAL WORDS
CAUTION is used for general reminders of
good safety practices
WARNING denotes a specific potential
hazard.
DANGER is the most serious specific
potential hazard.
These signal words are used in conjunction
with the safety-alert symbol.
FOLLOW SAFETY INSTRUCTIONS
Read owner/operator manual.
Replace missing or damaged safety decals.
Safety decals and this manual must be consid-
ered a permanent part of your EdgeMasterTM.
Keep your EdgeMasterTM in proper repair. Safety
decals, manuals and replacement parts are avail-
able through your BROWN dealer. Unauthorized
modifications to the BROWN EdgeMasterTM are
not recommended. This could impair the func-
tion, safety, and machine life. For any part of this
manual that you do not understand, contact your
BROWN dealer.
PAGE 1
OPERATE EDGER SAFELY
Do not let anyone operate edger without reading this manual.
Keep edging area clear of people and pets.
Wear protective clothing and eye and footwear.
Do not use edger unless all guards are in place.
Reduce ground speed on slopes, rough ground, and corners.
Operate edger from handle bar position only.
Disengage blade prior to starting engine.
Do not run engine indoors.
Do not put hands or feet near or under blade.
Do not touch muffler or other hot parts.
Do not lift edger when engine is running.
Do not leave edger unattended when engine is running.
Operate edger only in daylight.
-------------------------------------------------------------------------
WEAR PROTECTIVE CLOTHING
Wear close-fitting clothing appropriate for the job.
Wear a hearing protective device to protect from loud or
uncomfortable noise.
Wear proper eye protection. Safety goggles are supplied with each
BROWN EdgeMasterTM.
Wear appropriate foot wear.
Wear gloves when changing or replacing blades.
PAGE 2
HANDLE FUEL SAFELY
Fuel is highly flammable. Handle with care.
Stop engine before refueling.
Do not refuel while smoking or near open flames.
Always fill fuel tank outdoors.
Keep edger clean of oil, grease, and dirt.
Clean up spilled fuel immediately.
Never store machine where fumes may reach flame or spark.
AVOID INJURY FROM THROWN OBJECTS
Before operating edger:
Be sure all guards are in place.
Clear all objects and debris that may be thrown by
blade from edging area.
Clear area of people and pets.
PAGE 3
PAGE 4
AVOID ROTATING BLADE
Be sure blade guard is in place.
Do not adjust curb depth while blade is turning.
Do not put hands or feet near blade while engine is running.
READ AND FOLLOW SAFETY SIGNS
PAGE 5
OPERATING INSTRUCTIONS
NOTICE: NEW ENGINES SHIPPED WITH MACHINES ARE NOT
SERVICED. ADD OIL TO CRANKCASE BEFORE STARTING.
WARNING: GASOLINE IS EXTREMELY FLAMMABLE AND
IS EXPLOSIVE UNDER CERTAIN CONDITIONS.
NOTE: FOR FURTHER INFORMATION CONCERNING THE SAFETY,
OPERATING, MAINTENANCE, ETC. OF THE PARTICULAR ENGINE
SUPPLIED WITH YOUR BROWN EdgeMasterTM, SEE THE EN-
GINE OWNER’S MANUAL THAT IS SUPPLIED TO YOU WITH THE
EdgeMasterTM.
BEFORE STARTING ENGINE
1. CHECK MACHINE
A. Read and be familiar with equipment operating instructions.
B. Be sure you have the proper blade for your edging purpose. The
E-104H will accommodate blades up to 10” long. The blade must
have a 1/2” arbor hole.
C. Check blade retaining nut for tightness. Tighten blades hand tight
with an eight inch wrench. Do not overtighten nut if an impact
wrench is used.
D. Be sure belt and pulleys are properly aligned and adjusted. Be sure
belt stops are properly adjusted.
E. Check blade guard for proper alignment and tightness.
F. Check all other nuts and bolts for tightness.
2. CHECK ENGINE
A. Read and be familiar with manufacturer’s operating and safety
instructions for engine.
B. Check oil level and add if necessary. Do not over-fill.
C. Check air filter and clean frequently.
D. Use only clean fuel. Unleaded fuel is recommended in all engines.
E. Be sure muffler and exhaust deflector are installed, are in proper
position, and are in good operating condition.
PAGE 6
3. START ENGINE
A. Be sure belt tensioner is in disengaged position and that no tension
is on the belt.
B. Turn ignition to “ON” position.
C. Close choke if engine is cold.
D. Pull start cord rapidly.
E. As the engine warms, gradually move the choke lever to the
“OPEN” position.
WARNING: Do not operate the machine until area is cleared of
people, pets, automobiles, etc. that might be damaged
by projectiles.
WARNING! Do not operate machine without blade guard in place.
WARNING! Operator must wear eye protection when operating the
Edge Mastertm. (Eye goggles are provided with each
machine.)
4. ENGAGE BLADE / SET CUTTING DEPTH
CAUTION! Blade will begin to turn when the belt tensioner lever is
moved forward.
A. Move belt tensioner lever forward to tighten belt and set cutting
depth.
B. Insert locking pin into appropriate hole for desired cutting depth.
5. ADJUST CURB HEIGHT
CAUTION! adjust curb height before starting engine.
A. Place left rear tire of edger on the curb.
B. Loosen adjustment handle on front wheel assembly and right rear
wheel assembly.
C. Lift edger frame to level position by pushing the handle to the left
until frame is level.
D. Re-tighten wheel adjusting handles (The edger will work on curbs
up to 10” high.)
E. Proceed with operating procedures.
