PARTS REFERENCE LIST

MODEL: MFC-P2500 / HL-P2500

Read this list thoroughly before maintenance work.

Keep this list in a convenient place for quick and easy reference at all times.

Dec., 1999

PL-PRN003

NOTE FOR USING THIS PARTS REFERENCE LIST

1. In the case of ordering parts, it needs mentioning the following items:

(1) Code

(2) Q'ty

(3) Description

(4) Symbol ( PCB No., Revision , and Parts location mounted on the PCB.)

Note : No orders without Parts Code or Tool No. can be accepted.

REF.NO. CODE Q’TY DESCRIPTION SYMBOL REMARK

Revision No.: marked on the main printed circuit board.

B48K056 - 201A

Revision No.: marked on the power supply printed circuit board.

Rev. A

2. Design-changed parts :

If the parts are changed, any one of the following symbols is indicated in the REMARKS column.

#A : compatible between old and new

#B : replaceable from old to new

#D : incompatible

# : newly established

3. The original of this list was made based on the information available in December, 1999.

4. Parts are subject to change in design without prior notice.

(1) (4)

(3)

(2)

Design change indication

Specification No .

Pattern alteration No.

Circuit board No.

Design change indication

(The first version has no sign.)

CONTENTS

1. FRAME / DRIVE UNIT..........................................................................1

2. LASER UNIT.........................................................................................1

3. DOCUMENT SCANNER FRAME ......................................................... 3

4. PAPER FEEDER..................................................................................5

5. FIXING UNIT.........................................................................................7

6. PAPER CASSETTE......................................................................... 9AB

7. COVER...............................................................................................11

8. CONTROL PANEL.............................................................................. 13

9. MAIN PCB........................................................................................... 15

10. ENGINE PCB......................................................................................15

11. LOW-VOLTAGE POWER SUPPLY PCB............................................17

12. HIGH VOLTAGE POWER SUPPLY PCB...........................................17

13. AC CORD ........................................................................................... 19

14. ACCESSORIES..................................................................................19

15. DOCUMENTS.....................................................................................21

16. PACKING MATERIALS ......................................................................21

17. ADJUSTMENT TOOL.........................................................................23

1. FRAME / DRIVE UNIT

REF.NO.

CODE Q'TY DESCRIPTION SYMBOL REMARK

1UL9311001 1MAIN MOTOR ASSY

2 087320616 4 TAPTITE, CUP S M3X6

3LJ4069001 1SOLENOID ASSY

4 000300415 1 SCREW, BIND M3X4

5LJ4432001 1TAPE 32X12

6UL8984001 1LINK

7LJ4745001 1FAN MOTOR UNIT

8UL9099001 1TONER EMPTY PCB UNIT (LIGHT EMISSION) B512038

10 087320616 3 TAPTITE, CUP S M3X6

11 LJ7403001 4RUBBER FOOT chg

12 UL9104001 1TONER EMPTY PCB UNIT (LIGHT RECEPTION) B512037

13 087320616 2 TAPTITE, CUP S M3X6

14 LJ8031001 1LT RELAY PCB ASSY B512060

15 087320616 1 TAPTITE, CUP S M3X6

16 LE1169001 1USB GROUND PLATE

17 UL8970001 1SOLENOID RELEASE SPRING 30/99

18 LJ5591001 1PLANET GEAR ASSY (SP)

19 UL8985001 1GEAR 59

20 LJ5705001 1GEAR 21 PRESSURE PLATE

21 087320616 1 TAPTITE, CUP S M3X6

22 UG3005000 1FERRITE CORE: 16X8X10

23 UL8972001 1P/R CLUTCH LEVER

24 UL8971001 1F/R CLUTCH LEVER

25 UL8982001 1DEVELOP JOINT

26 UL8983001 1JOINT SPRING

27 UL8959001 1FRICTION SPRING delete

28 LJ5838001 1PLANET GEAR ASSY B (SP) Ref.No.CHG

MODEL MFC-P2500/HL-P2500 84U-Z11-010

T/I NO. PR2000014 / PR2000073 / PR2000132 / PR2000152 / PR2001023 / PR2001049 / PR2001061

/ PR2001100 / PR2002013 / PR2002098 / PR2002139 / PR2002157

2. LASER UNIT

REF.NO.

CODE Q'TY DESCRIPTION SYMBOL REMARK

1LJ4157001 1LASER UNIT (SP) (B512033)

2 087321615 3 TAPTITE, CUP S M3X16

MODEL MFC-P2500/HL-P2500 84U-Z11-020

- 1 -

- 2 -

3. DOCUMENT SCANNER FRAME

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 LE1072001 2 DOCUMENT SEPARATION ROLLER

2 UF4369000 1 PRESSURE ROLLER SHAFT

3 UF9009001 2 PRESSERE ROLLER

4 UU7032001 2 LF SPRING

5 UU2027001 1 SCANNER MOTOR

6 0A4300605 1 SCREW, PAN (S/P WASHER) M3X6

7 UU2028001 2 CIS SPRING

8 LE1160001 1 CIS UNIT ZL (SP)

9 UU2029001 1 DOCUMENT FEED ROLLER

10 LE1196001 2 ROLLER GEAR

11 UL6244002 2 EJECT PINCH ROLLER

12 UU2009001 2 EJECT PINCH ROLLER SPRING

13 UU2031001 1 DOCUMENT EJECT ROLLER

14 087311016 4 TAPTITE, CUP B M3X10

15 UU2006001 1FEED ROLLER SHAFT ASSY

16 UU2008001 1SEPARATION ROLLER SHAFT ASSY

MODEL MFC-P2500/HL-P2500 84U-Z11-015

T/I NO. PR2000063

-3-

3. DOCUMENT SCANNER FRAME

MODEL MFC-P2500/HL-P2500 84U-Z11-015

- 4 -

T/I NO. PR2000063

4. PAPER FEEDER

REF.NO.

CODE Q'TY DESCRIPTION REMARK

1UL9060001 1PAPER FEED ROLLER ASSY

2UL9066001 1PAPER PICK-UP ROLLER ASSY

3LJ4499001 1TR ELECTRODE HELICAL SPRING

4LJ4843001 1OUTER CHUTE 1 (SP)

5UL9070001 1GEAR 21

6UL9059001 1JOINT 5 add

7UL9062001 2BEARING 5 add

8UL9069001 1CONDUCTOR BEARING 5 add

9UL9053001 2TRANSFER ARM add

10 UL9052001 2TRANSFER SPRING add

11 UL9049001 1REGIST FRONT ACTUATOR ADD

12 UL9050001 1REGIST REAR ACTUATOR ADD

13 UU2042001 1ACTUATOR CASSET ADD

14 UL9051001 1REGIST REAR ACTUATOR SPRING ADD

MODEL MFC-P2500/HL-P2500 84U-Z11-040

- 5 -

4. PAPER FEEDER

- 6 -

MODEL MFC-P2500/HL-P2500 84U-Z11-040

T/I NO. PR2000051 / PR2000108 / PR2000130

5. FIXING UNIT

REF.NO.

CODE Q'TY DESCRIPTION REMARK

1LJ7759001 1FIXING UNIT, 115V (SP) CHG

1LJ7760001 1FIXING UNIT, 230V (SP) CHG

1LJ4718001 1FIXING UNIT, 230LE (SP)

1-1 UL8902001 1THERMISTOR ASSY

1-2 087311215 1 TAPTITE, CUP B M3X12

1-3 LJ4169001 1HEAT ROLLER 25 (SP)

1-3 LJ4719001 1HEAT ROLLER 25 LE (SP)

1-4 UL8908001 2HR BEARING 25

1-5 LJ4160001 1HALOGEN LAMP, 115V (SP)

1-5 LJ4163001 1HALOGEN LAMP, 230V (SP)

1-6 UL8929001 8EJECT PINCH ROLLER

1-7 LJ4431001 8PINCH SPRING

1-8 LJ4407001 2CLEANER ROLLER ASSY

1-9 LJ4409001 2CLEANER SPRING

1-10 087312015 2 TAPTITE, CUP B M3X20

1-11 Z07200001 1TAPTITE, PAN B M3X10

1-12 LJ4845001 4PICK OFF FINGER (SP)

1-13 LJ4853001 1PRESSURE ROLLER 20 (SP)

1-13 LJ4852001 1PRESSURE ROLLER 20 LE (SP)

1-14 UL8920001 1PAPER EJECT ACTUATOR

1-15 UL8921001 1EJECT ACTUATOR SPRING

1-16 UL8914001 2IDLE GEAR 13

1-17 LJ5871001 1IDLE GEAR HOLDER

1-18 UL8923001 1FU DRIVE GEAR 20/38

1-19 LJ7256001 1EJECT ROLLER SHAFT L add

1-20 LJ7257001 1EJECT ROLLER ASSY R add

1-21 LJ7259001 1EJECT ROLLER BUSHING L add

1-22 LJ7260001 1EJECT ROLLER BUSHING R add

1-23 LJ7261001 1FU FRAME LOWER 2 add

1-24 LJ7262001 1EJECT ROLLER JAM REMOVE TOOL add

1-25 UL8910001 1HR GEAR 34 ADD

2 087320815 1 TAPTITE, CUP S M3X8

3LJ4740001 2SHOULDER SCREW

MODEL MFC-P2500/HL-P2500 84U-Z11-050/051

- 7 -
