Brother MFC-T4500DW Manual de usuario
1
Secure Network Access
Your machine’s default password is initpass. We
recommend you change it to protect your machine
from unauthorised access.
Operation Videos
http://www.95105369.com
Installation
& Using
Videos
NOTE
• The Reference Guide for this model is available on the enclosed
installation disc. Visit at the installation disc: \document\userguide\
simplied_chinese\pdf
• Save all packing materials and the box in case you must ship your
machine.
• For a network connection you must purchase a network
interface cable. A USB cable is included with your machine.
USB cable
We recommend using a USB 2.0 cable (Type A/B) that is 2 metres
long.
Ethernet (Network) cable
Use a straight-through Category 5 (or greater) twisted-pair cable
for 10BASE-T or 100BASE-TX Fast Ethernet Network.
2Load plain A4 paper
1Unpack the machine and check the components
Remove the protective tape or film covering the machine.
Quick Setup Guide
MFC-T4500DW
Read the Product Safety Guide first, then read this Quick Setup Guide
for the correct installation procedure.
CHN-ENG
Version A
Inbox Ink Bottles
• [BTD60BK] Black
• [BT5009Y] Yellow
• [BT5009C] Cyan
• [BT5009M] Magenta
Quick Setup Guide
Product Safety Guide
Power Cord
USB Interface Cable
Maintenance Sheet
Brother Installation Disc
Telephone Line Cord
7Connect the telephone line cord
If you are not using your machine as a fax, go to 8.
For more information on using the fax feature, see the Online User’s Guide.
5Fill the ink tanks with the inbox ink
Point the nozzle upward so
that the ink does not spill,
and then remove the nozzle
from the ink tank.
When the machine has finished the initial cleaning process,
follow the touchscreen instructions to configure the machine
settings.
• Check print quality
• Congurethetrayorpapersizesettings
• Set Firmware Update Notice
6Machine settings
Push down on the cap of the
ink tank to close it tightly.
Repeat step 5for the three
other ink tanks.
Close the ink tank cover. The
machine will prepare the ink
tube system for printing.
Open the ink tank cover aand pull
the tab bdownwards to open the
cap of the ink tank.
1
2
Pull the paper tray completely out of
the machine as shown by the arrow. Adjust the paper guides.
Do not exceed this
mark (bbb).
Pull out the paper support
until it locks into place.
Slowly push the paper tray
completely into the machine.
Fan the paper well and load it in the tray.
Connect the power cord. The machine will power
on automatically.
3Connect the power
cord
4Set the date and
time
Follow the touchscreen instructions to set the date and
time.
Remove the tip of the ink bottle.
Insert the nozzle of the ink bottle
firmly so that the ink does not
spill. Fill the ink tank by gently
squeezing the bottle as shown.
Empty the entire bottle into the
ink tank.
Remove the cap and protective
film from the ink bottle, and then
replace the cap.
NOTE
Fasten the ink bottle cap tightly to
avoid leakage.
Connect the telephone line cord.
Use the socket marked LINE and guide
the cord out the back of the machine.
Lift the scanner cover. Close the scanner cover.
Adjust the control
panel angle to read the
touchscreen more easily.
2
© 2018 Brother Industries, Ltd. All rights reserved.For FAQs, Troubleshooting, and to download software and manuals, visit www.95105369.com. For product specifications, see the Online User’s Guide.
8Select a device to connect to your machine
9Connect your computer
10 Alternative wireless setup
11 Print or scan using your mobile device
Your mobile device must be connected to the same wireless network as your Brother machine.
Put the installation disc into your CD/DVD drive, or
download the Full Driver & Software Package at:
www.95105369.com
If you are using a recently released operating
system on your computer, visit the above websites
for updated driver and software information.
Follow the on-screen instructions and prompts.
For Windows®:
If the Brother screen does not appear
automatically, go to Computer (My
Computer/This PC). Double-click the
CD/DVD-ROM icon, and then double-click
start.exe.
For Mac:
For full driver functionality, we recommend
choosing the CUPS driver when adding a
printer.
If you cannot find this information, ask your network
administrator or wireless access point/router manufacturer.
If setup is not successful, restart
your Brother machine and your
wireless access point/router, and
repeat 10 .
Find your SSID (Network Name) and Network Key (Password) on your
wireless access point/router and write them in the table provided below.
Select the SSID (Network Name) for
your access point/router and enter the
Network Key (Password).
When the wireless setup is
successful, the touchscreen displays
[Connected].
Go to 9to install software.
Go to 11 to install apps.
SSID (Network Name)
Network Key (Password)
Computer Mobile Device
Go to 9and follow the instructions. Go to 10 and follow the instructions.
For Computer
For Mobile Device
Can’t Connect? Check the following:
Brother regularly updates firmware to add features and apply bug fixes.
To check for the latest firmware, visit support.brother.com/up7.
Wireless network
Wired network
USB connection
Restart your wireless access point/router
(if possible). If still not successful, go to 10 .
Disconnect the cable. If still not successful, visit www.95105369.com
for FAQs and Troubleshooting.
Restart your machine and computer,
and then go to 9.
Download
SSID: XXXXXXX
Network key: XXXX
Finished
AirPrint is available for all supported iOS devices including iPhone, iPad, and iPod touch. You do not need to
download any software to use AirPrint. For more information, see the Online User’s Guide.
Search Mopria from the search engine you use, then download and install the Mopria®Print Service app
using your Android™ device.
Download and install our free application Brother iPrint&Scan.
Go to your machine, and
press > [S etu p
Wizard] > [Yes].
For Wired Network Connection and USB
Connection:
Locate the correct port (based on the
cable you are using) inside the machine
as shown.
Read the two-dimensional code (or visit http://www.95105369.com), click iPrint&Scan from the
mobile application menu on the right-lower corner to enter the download page.
*We suggest Android users using a mobile browser to scan and download our product.
