Brother MFC-J2320 Manual de usuario

NOTE NOTE speciﬁes the operating environment, conditions for installation, or

special conditions of use.

WARNING WARNING indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injuries.

Unpack the machine and check the components

1. Remove the protective tape and film covering the machine, and also from the Touchscreen.

2. Make sure you have all components.

The components included in the box may differ depending on your country.

WARNING

Plastic bags are used in the packing of your machine. To avoid the danger of

suffocation, keep these plastic bags away from babies and children. Plastic

bags are not toys.

NOTE

• Save all packing materials and the box in case for any reason you must ship

your machine.

• For a network connection you must purchase a network interface cable.

Please use the supplied USB cable for a USB connection.

USB cable

We recommend using a USB 2.0 cable that is no more than 2 metres long.

Network cable

A network interface cable is not included. If you want to use a network

interface cable, please purchase one separately.

Use a straight-through Category5 (or greater) twisted-pair cable for

10BASE-T or 100BASE-TX Fast Ethernet Network.

1Load plain A4 paper

Pull the paper tray completely

out of the machine.

Connect the telephone line cord.

Use the socket marked LINE and guide

the cord out the back of the machine. Close the scanner cover.

Follow the Touchscreen instructions

to install the ink cartridges.

The machine will prepare the ink

tube system for printing.

When the machine has finished the initial cleaning process,

follow the Touchscreen instructions to configure the machine

settings.

• Check print quality

• Set date and time

• Print the installation sheet

Open the ink cartridge cover a.

Fan the paper well and load it in the tray.

Pull out the paper support a, and

unfold the paper support flap b.

Connect the power cord.

Lift the scanner cover.

Adjust the paper guides.

Do not exceed this

mark (aaa).

NOTE

If you are sharing one telephone line with an external

telephone, connect it as shown below.

You can adjust the angle of the control

panel by lifting it.

a Extension telephone

b External telephone

Quick Setup Guide

MFC-J2320

CHN-ENG

Version A

Read the Product Safety Guide first, then read this Quick Setup Guide

for the correct installation procedure.

Introductory Ink Cartridges

[x4]

Black

Yel low

Cyan

Magenta

2Connect power cord and telephone line cord

If you are not using your machine as a fax, connect the power cord and go to 3.

3Install introductory ink cartridges

4Machine Settings

Quick Setup Guide

Basic User’s Guide

Product Safety Guide

CD-ROM Maintenance Sheet

Power Cord USB Interface Cable Telephone Line Cord

5Choose your language (if needed)

1. Press (Settings).

2. Press All Settings.

3. Press aor bto display Initial Setup.

Press Initial Setup.

4. Press aor bto display Local Language.

Press Local Language.

5. Press your language.

6. Press .

For Wireless Networks

To connect additional computers, repeat Method A for each computer.

For Wired Networks

To connect additional computers, repeat this procedure for each computer.

For USB Connections

Finish

Windows®

Macintosh

■Install MFL-Pro Suite

■Connect the USB cable

■Connect the network cable

■Set up your machine

■Install MFL-Pro Suite

■Install Brother iPrint&Scan

■Install MFL-Pro Suite

■Connect the USB cable

Follow the on-screen

instructions.

Internet access is required.

Follow the on-screen instructions

to continue installation.

Follow the on-screen instructions

to continue installation.

A USB cable may be needed in

some cases.

Follow the on-screen instructions

to continue installation.

Follow the on-screen instructions

to continue installation.

You can print from and scan to mobile devices using our free application

“Brother iPrint&Scan.”

Download and install the application from www.95105369.com.

1. Write your wireless access point/router information in the area below.

This information may be hidden on the bottom of the wireless access

point/router. If you cannot find it, ask your network administrator or

wireless access point/router manufacturer.

SSID (Network Name)

Network Key (Password)

2. Press on your Brother machine’s Touchscreen, and then press

Setup Wizard.

When Switch Network interface to wireless? is displayed,

press Yes.

3. Select the SSID you wrote down in 1. Press OK.

4. If the machine prompts you to enter a Network Key, enter the key you

wrote down in 1. Press OK.

5. Press Yes to apply your settings.

Put the CD-ROM into your CD-ROM drive. If

you do not have a CD-ROM drive, download the

software at:

www.95105369.com

7Connect to your device and install software

Method A Setup from the computer

Method B Manual setup using the Setup Wizard

Make sure that you are logged on with

Administrator rights.

Make sure that you are logged on with

Administrator rights.

Make sure that you are logged on with

Administrator rights.

Follow the on-screen

instructions to continue

installation.

Make sure that you are logged on with Administrator rights.

Put the CD-ROM into your CD-ROM drive. If you do

not have a CD-ROM drive, download the software at:

www.95105369.com

Make sure that you are logged on with Administrator

rights.

Download

6Choose your method

Go to 7For Wireless Networks Method B

Mobile

Go to 7For Wireless Networks

Method A or Method B

Wireless Network

Go to 7For Wired Networks

Wired Network

Go to 7For USB Connections

USB

Download

Put the CD-ROM into your CD-ROM drive. If

you do not have a CD-ROM drive, download

the software at:

www.95105369.com

Put the CD-ROM into your

CD-ROM drive. If you do

not have a CD-ROM drive,

download the software at:

www.95105369.com

Put the CD-ROM into your CD-ROM

drive. If you do not have a CD-ROM

drive, download the software at:

www.95105369.com

Brother support website http://www.95105369.com

Download

Windows®Macintosh
