Broadcom BCM95396 Manual de usuario

16215 Alton Parkway • P.O. Box 57013 • Irvine, CA 92619-7013 • Phone: 949-450-8700 • Fax: 949-450-8710

Quick Start Guide

for the BCM95389/BCM95396

Reference Board

04/29/05

Broadcom®, the pulse logo, Connecting everything®, and the Connecting everything logo are among the trademarks of

Broadcom Corporation and/or its affiliates in the United States, certain other countries and/or the EU. Any other

trademarks or trade names mentioned are the property of their respective owners.

Broadcom Corporation

P.O. Box 57013

16215 Alton Parkway

Irvine, CA 92619-7013

Printed in the U.S.A.

REVISION HISTORY

Revision Date Change Description

95389_95396-QS100-R 04/29/05 Initial release.

Broadcom Corporation

Document 95389_95396-QS100-R Page iii

TABLE OF CONTENTS

Overview ..........................................................................................................1

Block Diagram ................................................................................................2

Connector Settings .........................................................................................3

Setting Up a WebSmart™ Console Connection .......................................4

Terminal-to-WebSmart™ Connection .................................................4

Configuring the HyperTerminal Utility ................................................5

Setting Up a WebSmart™ Web-Based Connection ..................................8

BCM95389/BCM95396

Broadcom Corporation

Page iv Document 95389_95396-QS100-R

Broadcom Corporation

Document 95389_95396-QS100-R Page v

LIST OF FIGURES

1: BCM95389 Block Diagram...............................................................................2

2: BCM95396 Block Diagram...............................................................................2

3: Terminal-to-WebSmart Connection................................................................4

4: WebSmart Web-Based Connection.................................................................8

Broadcom Corporation

Document 95389_95396-QS100-R Page vi

LIST OF TABLES

Table 1: BCM95389 Connector Settings ............................................................3

Table 2: BCM95396 Connector Settings ............................................................3

BCM95389/BCM95396 Overview

Broadcom Corporation

Document 95389_95396-QS100-R Page 1

Overview

This document discusses how to bring up the Broadcom BCM95389/

BCM95396 reference board system using WebSmart™ software. It describes

steps required to set up and configure the WebSmart program.

The WebSmart program allows you to manage the Broadcom BCM95389/

BCM95396 reference board and monitor its performance. This program can

be accessed by either of the following:

• A direct connection between a management console and the console port

of the Broadcom BCM95389/BCM95396 reference board. The

management console used for the connection can be a VT-100 terminal or

PC-running terminal emulation software. The user has access to the

WebSmart common language infrastructure (CLI).

• A network connection from one of the ports of the BCM95389/

BCM95396 reference board to a client Web browser. The user has access

to the WebSmart web-based GUI interface.

BCM95389/BCM95396

Broadcom Corporation

Page 2 Document 95389_95396-QS100-R

Block Diagram

Figure 1 and Figure 2 are generalized block diagrams for the BCM95389 and

BCM95396 reference boards.

Figure 1: BCM95389 Block Diagram

Figure 2: BCM95396 Block Diagram

Magnetics Magnetics

BCM5464 BCM5464

J1 J2

U12

BCM5389

BCM5464

5396

Magnetics Magnetics Magnetics Magnetics

BCM5464 BCM5464 BCM5464

Taifatech

J31

J32

J16

J28

J29

J30

J34

J33

SW2

U46

U47

SK2

SK3

J10

U11 U15 U19 U23

J12

J14

SK6

SK5 SK4

BCM95389/BCM95396 Connector Settings

Broadcom Corporation

Document 95389_95396-QS100-R Page 3

Connector Settings

Table 1: BCM95389 Connector Settings

Number Settings

J2 CPU_EPROM_SEL strap pin setting.

1–2: SPI Mode

2–3: EEPROM mode

J3 Mux components connecting to SPI/EEPROM pins.

1–2: EEPROM (U12)/ 6-pin jumper (J4)

2–3: Microcontroller (U7)

Power

Connector

5V/300A DC power source

Table 2: BCM95396 Connector Settings

Number Settings

J10 SPI header/6-pins

OPEN: For Websmart/microcontroller (8051) mode

CLOSE: For SPI mode

J12 CPU_EPROM_SEL strap pin setting.

OPEN: For SPI mode

CLOSE: For EEPROM mode

J14 OPEN: For nonmanagement mode

CLOSE: For management mode

J16 Mux components connecting to SPI/EEPROM pins.

1–2: 8051 mode

2–3: Websmart mode

J28 Mux components connecting to SPI/EEPROM pins.

1–2: 8051 mode

2–3: Websmart mode

J29 Mux components connecting to SPI/EEPROM pins.

1–2: 8051 mode

2–3: websmart mode

J30 Mux components connecting to SPI/EEPROM pins.

1–2: 8051 mode

2–3: websmart mode

J31 UART

1–2: 8051 mode

2–3: websmart mode

J32 UART

1–2: 8051 mode

2–3: Websmart mode

BCM95389/BCM95396

Broadcom Corporation

Page 4 Document 95389_95396-QS100-R

Setting Up a WebSmart™ Console Connection

Terminal-to-WebSmart™Connection

Connect a terminal or a PC with terminal emulation software to the console

port using a RS-232 straight cable.

Figure 3: Terminal-to-WebSmart Connection

Note:

The console port on the demo system is a DB-9 connector.

J33 Mux components connecting to SPI/EEPROM pins.

1–2: 8051 mode

2–3: Websmart mode

J34 Mux components connecting to SPI/EEPROM pins.

1–2: 8051 mode

2–3: Websmart mode

J13 AL-A250ATX MAX250W power source

Table 2: BCM95396 Connector Settings (Continued)

Number Settings

RS-232 Cable

9-pin Female

Connector

9-pin Male

Connector 9-pin Female to

9-pin Male Cable

Broadcom Switch
