Broadcom SAS 9305-16e Manual de usuario

SAS 9305-16e PCI Express® to 12Gb/s SAS Host Bus

Adapter

User Guide

Version 1.0

January 27, 2016

pub-005244

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

Broadcom, the pulse logo, Connecting everything, the Connecting everything logo, and Avago Technologies are

among the trademarks of Broadcom Ltd. and/or its affiliates in the United States, certain other countries and/or the EU.

Any other trademarks or trade names mentioned are the property of their respective owners.

Broadcom Ltd. reserves the right to make changes without further notice to any products or data herein to improve

reliability, function, or design.

Information furnished by Broadcom Ltd. is believed to be accurate and reliable. However, Broadcom Ltd. does not

assume any liability arising out of the application or use of this information, nor the application or use of any product

or circuit described herein, neither does it convey any license under its patent rights nor the rights of others.

Corporate Headquarters Website

San Jose, CA www.broadcom.com

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

Table of Contents

Broadcom Ltd.

- 3 -

Table of Contents

SAS 9305-16e Host Bus Adapter User Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3 Functional Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3.1 PCI Express Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3.2 SAS-3 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3.3 LED Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4 Operating System Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5 Broadcom SAS 9305-16e HBA Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5.1 Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5.2 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5.3 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5.4 Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

5.5 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

5.6 Thermal and Atmospheric Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

6 12Gb/s SAS HBA Certifications and Safety Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

7 Hardware Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

8 Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Broadcom Ltd.

- 4 -

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

Overview

SAS 9305-16e Host Bus Adapter User Guide

1Overview

The PCI Express®(PCIe®)-to-Serial Attached SCSI (SAS) host bus adapter (HBA), referred to as the Broadcom 12Gb/s SAS

HBA, provides high-performance external storage connectivity for servers and workstations. The 12Gb/s SAS HBA

provides sixteen lanes of 12Gb/s SAS connectivity and is matched with eight lanes of PCIe 3.0 8Gb/s performance. The

low-profile design of the SAS HBA includes a full-height mounting bracket and a low-profile mounting bracket that

create a universal fit for any server. The 12Gb/s SAS HBA is developed on the Fusion-MPT-based SAS 3216 controller

that integrates the latest enhancements in PCIe 3.0 technology and 12Gb/s SAS technology.

2Features

This section lists the Broadcom 12Gb/s SAS HBA features.

Implements one SAS 3216 sixteen-port 12Gb/s SAS to PCIe 3.0 controller

Supports eight-lane, full-duplex PCIe 3.0 performance

Supports sixteen external 12Gb/s SATA+SAS ports

Supports SATA link rates of 3Gb/s and 6Gb/s

Supports SAS link rates of 3Gb/s, 6Gb/s, and 12Gb/s

Provides sixteen x4 external mini-SAS HD connectors (SFF-8644)

Supports passive copper cable, active copper cable, and optical cable

Supports up to 1024 SATA or SAS end devices

Offered with a full-height bracket and a and a low-profile vented bracket

Provides one heartbeat LED

Provides a universal asynchronous receiver/transmitter (UART) debug/diagnostic port

3 Functional Descriptions

3.1 PCI Express Interface

PCIe is a high-speed standard local bus for point-to-point interfacing of I/O components to the processor and the

memory subsystems in high-end computers and servers.

The 12Gb/s SAS HBA supports eight-lane PCIe performance up to 64Gb/s single direction and 128Gb/s dual direction.

3.2 SAS-3 Interface

The Broadcom SAS 3216 controller chip contains the SATA+SAS functionality for the 12Gb/s SAS HBA with SAS

performance of 1200 MB/s per port in each direction.

Broadcom Ltd.

- 5 -

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

Operating System Support

3.3 LED Management

The 12Gb/s SAS HBA offers enclosure LED management support for your enclosure implementation through SCSI

Enclosure Services (SES).

4 Operating System Support

The Broadcom 12Gb/s SAS HBA supports all major operating systems: Windows®, Linux®(Oracle®, SuSE®, Red Hat®),

Solaris®, VMware®, FreeBSD®, CentOS®, Canonical®, Citrix®, Fedora®, and Debian®.

Refer to http://www.avagotech.com/support/download-search for details on the software versions and device driver

support. Contact Oracle support for Oracle driver or software support.

5 Broadcom SAS 9305-16e HBA Characteristics

5.1 Memory

The 12Gb/s SAS HBA provides one a128Mb Flash ROM to store the firmware and the BIOS.

5.2 LEDs

The 12Gb/s SAS HBA has a Heartbeat LED (LED2) that blinks green to indicate the HBA is capable of general activity and

a thermal event LED (LED1) that illuminates if the IOC experiences an over temperature condition.

5.3 Connectors

UART Connectors (J1). The UART connector debug port requires a special cable and Broadcom support to gather

detailed IOC status. The UART connector uses the following layout.

Software Test and Debug (J5). Used by Broadcom support to assist in debugging functional issues.

SBR Recovery (J6). This port enables recovery of corrupted SBR files. Broadcom support can assist with this process.

SATA+SAS Connector (J7). The 12Gb/s SAS HBA supports SATA devices and SAS devices in an enclosure connected

by cable to SFF-8644 mini-SAS HD external connectors.

PCIe Connector (J8). The 12Gb/s SAS HBA supports a x8 interface. The PCIe host interface connection is through the

edge connector, J8. The signal definitions and pin numbers conform to the PCIe specification.

Table 1 Broadcom SAS 9305-16e HBA UART Pinout, J1 UART

Pin Function

1UART0_TX

2Gnd

3UART0_RX

41.8V

Broadcom Ltd.

- 6 -

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

Broadcom SAS 9305-16e HBA Characteristics

5.4 Physical Characteristics

The 12Gb/s SAS HBA is a 6.6 in. × 2.7 in. (167.65 mm × 68.90 mm) board. The component height on the top and bottom

of the 12Gb/s SAS HBA complies with the PCIe specification. The following figure shows the HBA board layout.

Figure 1 Broadcom SAS 9305-16e HBA Board Layout

J1– UART connector

J5– Software test and debug

J6– SBR Recovery

J7– SFF-8644 mini-SAS HD external connector

J8– PCIe x8 board edge connector

5.5 Electrical Characteristics

The power requirements for the SAS 9305 HBA under normal operation are as follows:

Power values:

—Typical = 13.0 W

Typical configuration assumes nominal silicon and voltage with all links running maximum IOs at 25C ambient

temperature. Actual power consumption may vary depending on system and environmental configurations.

5.6 Thermal and Atmospheric Limits

The atmospheric limits for the 12Gb/s SAS HBA are as follows:

Relative humidity range: 5 percent to 90 percent noncondensing

Maximum dew point temperature: 32 °C (89.6 °F)

Minimum airflow: 200 linear feet per minute at 55 °C inlet temperature

The following limits define the storage and transit environment for the 12Gb/s SAS HBA:

Temperature range: –45 °C to +105 °C (–49 °F to +221 °F) (dry bulb)

Ports 12-15 -

Ports 8 -11 -

Ports 4 - 7 -

Ports 0 -3 -

Broadcom Ltd.

- 7 -

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

12Gb/s SAS HBA Certifications and Safety Characteristics

Relative humidity range: 5 percent to 90 percent noncondensing

6 12Gb/s SAS HBA Certifications and Safety Characteristics

All Broadcom 12Gb/s SAS HBAs meet or exceed the requirements of UL flammability rating 94V-0. Each bare board is

marked with the supplier’s name or trademark, type, and UL flammability rating. Because these boards are installed in

a PCIe bus slot, all voltages are less than the SELV 42.4-V limit.

The design and implementation of the 12Gb/s SAS HBA minimizes electromagnetic emissions, susceptibility to radio

frequency energy, and the effects of electrostatic discharge.

The 12Gb/s SAS HBA meets the following integrated electromagnetic interference (EMI) compliance labels:

CE mark

RCM mark

Canadian Compliance Statement

FCC Class B, marked with the FCC Self-Certification logo

UL Listed Mark for Canada/U.S.

Japan VCCI

Korean KCC

Taiwan BSMI

The 12Gb/s SAS HBA meets the following environmental directives:

Restriction of Hazardous Substances (RoHS)

Waste of electrical and electronic equipment (WEEE)

7 Hardware Installation Instructions

To install the Broadcom 12Gb/s Serial Attached SCSI (SAS) HBA, follow these steps:

1. Unpack the HBA, and inspect it for damage. Unpack the HBA in a static-free environment. Remove the HBA from

the anti-static bag, and carefully inspect the device for damage. If you notice any damage, contact Broadcom or

your reseller support representative.

ATTENTION To avoid the risk of data loss, back up your data before you change

your system configuration.

2. Prepare the computer. Turn off the computer, and disconnect the power cord from the rear of the power supply.

CAUTION Disconnect the computer from the power supply and from any

networks to which you will install the HBA, or you risk damaging the

system or experiencing electrical shock.

3. Remove the cover from the chassis.

Broadcom Ltd.

- 8 -

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

Hardware Installation Instructions

4. Check the mounting bracket on the HBA (system- dependent) If required for your system, replace the

full-height mounting bracket that ships on the HBA with the low-profile bracket supplied. Complete the following

steps to attach the short bracket.

a. Using a #1 Phillips screwdriver that is ESD safe, remove the two Phillips screws that connect the full-profile

bracket to the board. Unscrew the two screws located at the top and bottom edges of the board. Avoid

touching any board components with the screwdriver or bracket.

b. Remove the full-profile bracket. Do not damage the HBA.

c. Place the HBA on top of the low-profile bracket. Position the bracket so that the screw holes in the tabs align

with the openings in the board.

d. Using a #1 Phillips torque screwdriver that is ESD safe, set to a maximum torque of 4.8 ± 0.5 inch-pounds.

Replace the two Phillips screws removed in step a.

ATTENTION Exceeding this torque specification can damage the board,

connectors, or screws, and can void the warranty on the board.

5. Insert the HBA into an available slot. Locate an empty x8 PCIe slot adequate for your board. Remove the blank

bracket panel on the rear of the computer that aligns with the empty PCIe slot. Save this bracket screw, if

applicable. Align the HBA to a PCIe slot. Press down gently, but firmly, to seat the HBA correctly in the slot. The

following figure shows how to insert the HBA into a PCIe slot.

NOTE The shape, size, and locations of the components on your HBA and its

bracket might vary from this illustration. The HBA requires an x8 PCIe

slot.

Figure 2 Installing the 12Gb/s 9305-16e HBA in a PCIe Slot

6. Connect SAS cables between the HBA and the SAS enclosure that contains SATA or SAS devices. The 12Gb/s

SAS HBA has four SFF-8644, external x4, mini-SAS HD connectors. Use a cable with an external mini-SAS HD

Edge of

Motherboard

PCIe Slot

BracketScrew

PressHere

3_02885

Broadcom Ltd.

- 9 -

Broadcom 9305-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide

January 27, 2016

Technical Support

connector (SFF-8644) on one end (to connect to the HBA) and the appropriate connector to attach to the enclosure

that contains SAS devices or SATA devices on the other end.

7. Make sure the system provides the required airflow for the controller. Airflow must be at least 200 linear feet

per minute (LFM) at 55 °C inlet temperature to avoid operating the Broadcom SAS 3216 processor above the

maximum junction temperature.

8. Replace the cover and reconnect any cords and cables, and power up the system. Replace the chassis’s cover,

reconnect any power cords, and reconnect any network cables. Turn on the power.

8TechnicalSupport

For assistance installing, configuring, or running the Broadcom 12Gb/s SAS HBA, contact Technical Support at

http://www.avagotech.com/support/.

Tabla de contenidos

Otros manuales de Adaptador de Broadcom

Broadcom

Broadcom 9400-8i8e Manual de usuario

Broadcom

Broadcom NetXtreme BCM57XX Manual de usuario

Broadcom

Broadcom RSVLD-0502 Manual de usuario

Broadcom

Broadcom SAS 9305-16i Manual de usuario

Broadcom

Broadcom NetXtreme BCM570 Series Manual de usuario

Broadcom

Broadcom Emulex LPe31000 Manual de usuario

Broadcom

Broadcom NetXtreme Manual de usuario

Broadcom

Broadcom Emulex Manual de usuario

Broadcom

Broadcom Emulex LPe35000 Series Manual de usuario

Broadcom

Broadcom NetXreme-C Manual de usuario

Broadcom

Broadcom Symantec PC-S200 Manual de usuario

Broadcom

Broadcom BCM92045NMD Manual de usuario

Broadcom

Broadcom Emulex LPe31000-Series Manual de usuario

Broadcom

Broadcom P411W-32P Manual de usuario

Broadcom

Broadcom Emulex LPe12000 Series Manual de usuario

Broadcom

Broadcom MegaRAID 9440-8i Manual de usuario

Broadcom

Broadcom 5720ZG Manual de usuario

Broadcom

Broadcom Emulex Manual de usuario

Broadcom

Broadcom HBA 9400-16i Manual de usuario

Broadcom

Broadcom MegaRAID 9365-28i Manual de usuario

Broadcom

Broadcom 96 Series Manual de usuario

Broadcom

Broadcom SAS 9305-24i Manual de usuario

Manuales populares de Adaptador de otras marcas

PCB Piezotronics

PCB Piezotronics 090B274 Manual de usuario

Auvidea

Auvidea J20 Manual del producto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manual de usuario

Akribis

Akribis ITF-21-BISS-MIT Manual de usuario

Tenda

Tenda W54U Manual de usuario

ROHO

ROHO AGILITY Manual de usuario

PROLiNK

PROLiNK WN2001 Manual de usuario

Hawking

Hawking HUF2 Manual de usuario

Airlink101

Airlink101 AWLC4030 Manual de usuario

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manual de usuario

Philips

Philips SWA4554S/10 Manual de usuario

JVC

JVC TS-C9D2B Manual de instrucciones

NETGEAR

NETGEAR A6100 Manual de usuario

D-Link

D-Link DWA-121 Manual de usuario

Philips

Philips SWA2037 Manual de usuario

Basalte

Basalte 0610-20 Manual de usuario

Yealink

Yealink EHS40 Manual de usuario

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manual de usuario
