Britax B-SCENE Manual de usuario
B-SCENE™ Stroller
User Guide
IMPORTANT: To ensure your child is as safe as possible, read all
instructions thoroughly before using this stroller. Store this manual for
future reference.
©2010 Britax Child Safety, Inc. All rights reserved. Printed in China. P409400_R3:09.10
This product and its components are subject to change without notice.
Warnings..2
Features..4
In.the.Box.5
Assembly..6
Operating.Instructions
Parking Brake 10
Attaching the Seat 10
Detaching the Seat 11
Folding 12
Swivel Wheels 12
Leg Rest 13
Reclining 13
Handle Angle 13
Securing.Your.Child.14
Infant.Car.seat.Mode
Attaching Britax Infant Car Seat Adapters 16
Removing Britax Infant Car Seat Adapters 16
Attaching a Britax Infant Car Seat 17
Removing a Britax Infant Car Seat 18
Accessories.19
Other.Available.Accessories . 20
B-SCENE™.Stroller.Configurations. 21
Care.and.Maintenance.23
Warranty.24
Table of Contents
2
Section Title
WARNING!
DEATH or SERIOUS INJURY can occur:
•
Never leave child unattended.
•
Avoid serious injury from falling or sliding out. Always use harness to
secure child.
•
Do not use stroller for an infant younger than 6 months without an
infant car seat or bassinet.
•
Do not use stroller with a child who weighs more than 55 lbs (25
kg).
•
Do not use stroller with a child taller than 44 inches (111.8 cm).
•
Do not overload basket – Maximum weight in basket is 10 lbs (4.5
kg). Overloading the basket may cause the stroller to become
unstable.
• Do not overload the seat-back storage pockets. Maximum weight in
storage pockets is 1 lb (0.45 kg).
•
Always make certain that the stroller is fully open and locked before
use.
•
Assembly of this stroller must be performed only by an adult.
•
Do not hang or place items on the stroller handle or frame except
for those approved by Britax. They may cause the stroller to become
unstable.
•
Only use Britax approved child restraints or car seats with this stroller
without the use of the Infant Car Seat Adapter Frame.
•
Do not allow children to climb on or play with the stroller.
•
Never use stroller on stairs or escalators.
•
To avoid entrapment or pinching, do not fold or unfold stroller when
child is in or near stroller.
3
Section Title
WARNING!
DEATH or SERIOUS INJURY can occur:
•
Stroller is intended for walking speed only. Do not use while jogging,
skating, etc.
•
Always set the parking brake when stroller is not moving.
•
Only use accessories and replacement parts approved by Britax
Child Safety, Inc.
• Do not lift the stroller by the arm bar of the seat when the seat is
occupied.
•
Read and understand these instructions before using this product.
To ensure proper use, store this user guide in a convenient place
so it can be consulted often. Failure to follow all warnings and
instructions could result in serious injury or death.
• When using an infant car seat with this product, refer to the product’s
user guide for maximum weights and other instructions.
• Do not exceed the manufacturer’s maximum weight limit when using
an infant car seat with this product.
4• Actual product may vary from images.
Canopy
Chassis.
Lock
On.right.side.
of.frame
Arm.Bar
Harness
Buckle
Leg.Rest
Front.Wheel
Rear.Wheels
Rear.Wheel.
Release.Button
Frame.
Release.
Lever
Handle.
Height.
Adjuster
Seat.Locking.Latch
Chassis.Socket
Release.Lever
Under-Seat.
Storage.
Basket
Front.
Wheel.
Release
Swivel.
Lock
Features
5
Front.Wheel
Rear.Wheels
Seat
Arm.Bar
Stroller.Frame
Rain.Cover
Britax.Infant.Car.
seat.Adapters
In the Box
6
• Lift chassis lock lever and
open the frame
• Lift handle until frame locks
into upright position as
shown
• Slide mounting pin into the
housing on the frame until it
locks into place
Unfolding
Front Wheel
NOTE: Always make sure the front
and rear wheels are locked into place
and that the brake functions properly
before each use
Assembly
7
NOTE: Left and right wheels are
marked with an L or R and are from
the perspective of standing behind
the stroller
• Hold in the release button in
the center of the wheel and
slide the mounting pin into
the housing on the rear axle
Rear Wheels
• Attaching: slide the pins into
the mounts on the seat until
they lock into place
• Removing: push the release
button on the bottom of the
mounts and pull arm bar out
NOTE: Armbar or cup holders must
always be used to avoid finger
entrapment in the open connectors
Arm Bar
Assembly
8
• Press and hold the release
button in the center of the
wheel and pull away from
the wheel housing
Removing Front Wheel
Removing Rear Wheels
• To remove, pull the wheel
release lever on the
front hub until the wheel
assembly releases
Assembly
