Briggs & Stratton 31D707 Manual de usuario

in any form or by any means, electronic or mechanical, including photocopying,

recording or by any information storage and retrieval system, without permission

in writing from Briggs & Stratton Corporation.

PRINTED IN U.S.A.

FORM MS−5515−11/13/2007

REPLACES FORM MS−5515−07/12/2007

FILE IN SECT. 2 OF SERVICE MANUAL

31D700

Illustrated Parts List

Model Series

31D700

TYPE NUMBERS

0035 through 0601.

TABLE OF CONTENTS

Air Cleaner 5. . . . . . . . . . . . . . . . . . . . . . . . .

Alternator 7. . . . . . . . . . . . . . . . . . . . . . . . . .

Blower Housing 5. . . . . . . . . . . . . . . . . . . . .

Camshaft 2. . . . . . . . . . . . . . . . . . . . . . . . . . .

Carburetor 4. . . . . . . . . . . . . . . . . . . . . . . . . .

Controls 7. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Crankshaft 2. . . . . . . . . . . . . . . . . . . . . . . . .

Cylinder 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cylinder Head 3. . . . . . . . . . . . . . . . . . . . . .

Electric Starter 7. . . . . . . . . . . . . . . . . . . . . .

Engine Sump 2. . . . . . . . . . . . . . . . . . . . . . .

Flywheel 6. . . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Supply 5. . . . . . . . . . . . . . . . . . . . . . . . .

Governor Spring 7. . . . . . . . . . . . . . . . . . . .

Ignition 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Kit −Carburetor Overhaul 4. . . . . . . . . . . .

Gasket Set −Engine 2. . . . . . . . . . . . . . . . .

Gasket Set −Valve 3. . . . . . . . . . . . . . . . . .

Lubrication 3. . . . . . . . . . . . . . . . . . . . . . . . .

Operator’s Manual 2. . . . . . . . . . . . . . . . . .

Piston, Rings, Connecting Rod 2. . . . . . .

Valves 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Warning Label 2. . . . . . . . . . . . . . . . . . . . . .

31D700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−2Assemblies include all parts shown in frames. 11/13/2007

1017

415

1032

29 32

307

306

718

691

552

358 ENGINE GASKET SET

584

1263

1264

1270

758

759

757

524

1022

943

868

842

691

617

1266

741

146

883

16 46

1058 OPERATOR’S MANUAL 1319 WARNING LABEL

REQUIRED when replacing parts

with warning labels affixed.

850

239

31D700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−3Assemblies include all parts shown in frames. 11/13/2007

617

830

1034

1022

238 36

868

1029

534

192

1027

383

337

635

1026

1022

868

1095 VALVE GASKET SET

847

523

842

525

524

750

943

965

883

1022

1023

914

850

54 654

1024

1024A

31D700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−4Assemblies include all parts shown in frames. 11/13/2007

133

276

137

104

105

142 1091

634

987

130

947

975

125 141

131

LMT / PART

NUMBER

LOCATIONS

108

117

106

121 CARBURETOR OVERHAUL KIT

977 CARBURETOR GASKET SET

51 137 276

104

105

106

137

142

987

634

276

127

1266A

1266

617

950

431 1266A

1266

240

692

187B

601

118

121A CARBURETOR OVERHAUL KIT

95A

104A

105A

127A

617

987A

634B

1266

1266A

WALBRO

187B

601

104A

105A

634B

987A

95A

130A

NIKKI

98A

133A

94A

117A

141B

131A

127A

108B 118A

344

135

137A

1127

975A

137A

947A

276A

125A

141C

1146

31D700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−5Assemblies include all parts shown in frames. 11/13/2007

1267

967

305

643

968

304

305A

1036 EMISSIONS LABEL

1040

445

31D700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−6Assemblies include all parts shown in frames. 11/13/2007

783

1051

363 1044

1070

1005

1005A 415A

1070A

73A

1005B

31D700

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−7Assemblies include all parts shown in frames. 11/13/2007

851

334

333

1054

216 202

232

268

269

271

270

267

265

209

222

188

616

404

614

562

505

227

697

1051

510

513

783

802

462

579

503

310

803

544

801

309

1090 311

797

789A

521

NOTE: All stators use a No. mounting screw.

1119

NOTE: The proper flywheel part number and/or the alternator magnet size will

determine the alternator type or output. See repair instruction manual

for additional information.

559

356

729A

878

474A

877

DUAL

CIRCUIT

878A

474B

877B

TRI

CIRCUIT

526A

REGULATED

1059

501A

1059

5/9 AMP

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

31D700

KIncluded in Engine Gasket Set−Ref. No. 358.

DIncluded in Carburetor Overhaul Kit−Ref. No. 121 or 121A.

zIncluded in Carburetor Gasket Set−Ref. No. 977.

ΔIncluded in Valve Gasket Set−Ref. No. 1095.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−8Assemblies include all parts shown in frames. 11/13/2007

1 793987 Cylinder Assembly

2 399265 Kit−Bushing/Seal

(Magneto Side)

3K391086S Seal−Oil

(Magneto Side)

4 697106 Sump−Engine

Used on Type No(s).

0193, 0232, 0419,

0458, 0567, 0601.

4A 697188 Sump−Engine

Used on Type No(s).

0035, 0233, 0235,

0236, 0339.

5 793989 Head−Cylinder

7KΔ699168 Gasket−Cylinder Head

9K697109 Gasket−Breather

(Used Before Code

Date 07071900).

(After Date Code Use

Liquid Sealant

Reference 850)

10 697157 Screw

(Breather Assembly)

11 794683 Tube−Breather

(Used After Code Date

07071800).

−−−−−− Note −−−−−−

697113 Tube−Breather

(Used Before Code

Date 07071900).

12 K697110 Gasket−Crankcase

(.015” Thick)

(Standard)

13 793988 Screw

(Cylinder Head)

(Used After Code Date

07011400).

−−−−−− Note −−−−−−

690360 Screw

(Cylinder Head)

(Used Before Code

Date 07011500).

15 690946 Plug−Oil Drain

(3/8” Diameter)

16 697127 Crankshaft

20 K791892 Seal−Oil

(PTO Side)

22 692125 Screw

(Crankcase

Cover/Sump)

23 693557 Flywheel

−−−−−− Note −−−−−−

693556 Flywheel

Used on Type No(s).

0419.

24 222698S Key−Flywheel

25 792507 Piston Assembly

(Standard)

−−−−−− Note −−−−−−

792648 Piston

Assembly

(.020” Oversize)

26 791936 Ring Set

(Standard)

−−−−−− Note −−−−−−

792649 Ring Set

(.020” Oversize)

27 698469 Lock−Piston Pin

28 697099 Pin−Piston

(Standard)

29 791631 Rod−Connecting

(Standard)

32 791118 Screw

(Connecting Rod)

33 791934 Valve−Exhaust

(Used After Code Date

06021200).

−−−−−− Note −−−−−−

695760 Valve−Exhaust

(Used Before Code

Date 06021300).

34 791935 Valve−Intake

(Used After Code Date

06021200).

−−−−−− Note −−−−−−

695761 Valve−Intake

(Used Before Code

Date 06021300).

35 691279 Spring−Valve

(Intake)

36 691279 Spring−Valve

(Exhaust)

37 697352 Guard−Flywheel

42 499586 Keeper−Valve

43 691968 Slinger−Governor/Oil

45 690564 Tappet−Valve

46 793880 Camshaft

50 690193 Manifold−Intake

51KΔD692137 Gasket−Intake

53 690227 Stud

(Carburetor)

54 691148 Screw

(Intake Manifold)

73 697133 Screen−Rotating

(Used Before Code

Date 07040900).

73A 794436 Screen−Rotating

(Used After Code Date

07040800).

74 697897 Screw

(Rotating Screen)

78 691003 Screw

(Flywheel Guard)

93 D690602 Bushing−Throttle Shaft

(Walbro)

94 498030 Kit−Idle Mixture

(Walbro)

94A 695425 Kit−Idle Mixture

(Nikki)

95 D691636 Screw

(Throttle Valve)

(Walbro)

95A D690718 Screw

(Throttle Valve)

(Nikki)

98 495800 Kit−Idle Speed

(Walbro)

98A 695408 Kit−Idle Speed

(Nikki)

104 D690525 Pin−Float Hinge

(Walbro)

104A D694918 Pin−Float Hinge

(Nikki)

105 D231855S Valve−Float Needle

(Walbro)

105A D696136 Valve−Float Needle

(Nikki)

106 D690577 Seat−Inlet

(Walbro)

108 692344 Valve−Choke

(Walbro)

108B 695419 Valve−Choke

(Nikki)

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

31D700

KIncluded in Engine Gasket Set−Ref. No.358.

DIncluded in Carburetor Overhaul Kit−Ref. No. 121, or 121A.

zIncluded in Carburetor Gasket Set−Ref. No. 977.

ΔIncluded in Valve Gasket Set−Ref. No 1095.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−9Assemblies include all parts shown in frames. 11/13/2007

117 D694352 Jet−Main

(Standard)

(Walbro)

117A 792296 Jet−Main

(Standard)(Carburetor

Part No. 791722 and

792060)

−−−−−− Note −−−−−−

699457 Jet−Main

(Standard)(Carburetor

Part No. 697203)

118 697228 Jet−Main

(High Altitude)

(Walbro)

118A 699458 Jet−Main

(High Altitude)

(Nikki)

121 697241 Kit−Carburetor

Overhaul

(Walbro Carburetor)

121A 699521 Kit−Carburetor

Overhaul

(Nikki Carburetor)

125 793224 Carburetor

(Walbro)(Gravity Feed)

125A 792358 Carburetor

(Nikki)(Gravity Feed)

127 695005 Plug−Welch

(Walbro)

127A D690727 Plug−Welch

(Nikki)

130 691750 Valve−Throttle

(Walbro)

130A 699500 Valve−Throttle

(Nikki)

131 790901 Kit−Throttle Shaft

(Walbro)

131A 699501 Kit−Throttle Shaft

(Nikki)

133 494381 Float−Carburetor

(Walbro)

133A 694914 Float−Carburetor

(Nikki)

135 698780 Tube−Fuel Transfer

(Walbro)

137 D281165S Gasket−Float Bowl

(Walbro)

137A D698781 Gasket−Float Bowl

(Nikki)

141 790902 Kit−Choke Shaft

(Walbro)

141B 695420 Kit−Choke Shaft

(Nikki)

141C 793386 Kit−Choke Shaft

(Manual Choke)

142 D697140 Nozzle−Carburetor

(Standard)

(Walbro)

146 691639 Key−Timing

187B 791805 Line−Fuel

(Formed)

(10−1/4” Long)

(Cut to Required

Length)

188 691693 Screw

(Control Bracket)

192 691986 Adjuster−Rocker Arm

202 691841 Link−Mechanical

Governor

209 692208 Spring−Governor

−−−−−− Note −−−−−−

260902 Spring−

Governor

Used on Type No(s).

0236.

690576 Spring−

Governor

Used on Type No(s).

0339.

216 691840 Link−Choke

222 694042 Bracket−Control

227 691374 Lever−Governor

Control

232 691842 Spring−Governor Link

238 691843 Cap−Valve

239 694115 Switch−Oil Pressure

240 298090 Filter−Fuel

(Red, 150 Microns)

−−−−−− Note −−−−−−

394358S Filter−Fuel

(White, 75 Microns)

265 691024 Clamp−Casing

Used on Type No(s).

0035, 0193, 0235,

0236, 0339, 0419,

0567, 0458, 0601.

267 794904 Screw

(Casing Clamp)

268 691025 Casing−Control Wire

(Cut To Required

Length)

269 691026 Wire−Control

(Cut To Required

Length)

270 691027 Nut

(Control Wire Casing)

271 691028 Lever−Control

276 D692255 Washer−Sealing

(Walbro)

276A 695410 Washer−Sealing

(Nikki)

304 698402 Housing−Blower

(Red)

305 697102 Screw

(Blower Housing)

305A 697103 Screw

(Blower Housing)

306 697107 Shield−Cylinder

307 691003 Screw

(Cylinder Shield)

309 693551 Motor−Starter

310 690323 Screw

(Starter Motor)

311 497608 Brush Set

333 795315 Armature−Magneto

334 691061 Screw

(Magneto Armature)

337 491055S Plug−Spark

−−−−−− Note −−−−−−

691043 Plug−Spark

Used on Type No(s).

0236, 0339, 0419,

0567.

344 697561 Screw

(Cable Clamp)

356 697089 Wire−Stop

358 794150 Gasket Set−Engine

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

31D700

KIncluded in Engine Gasket Set−Ref. No. 358.

DIncluded in Carburetor Overhaul Kit−Ref. No. 121 or 121A.

zIncluded in Carburetor Gasket Set−Ref. No. 977.

ΔIncluded in Valve Gasket Set−Ref. No. 1095.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5515−10 Assemblies include all parts shown in frames. 11/13/2007

363 19203 Puller−Flywheel

383 89838S Wrench−Spark Plug

404 691691 Washer

(Governor Crank)

415 690283 Plug

(Crankcase

Cover/Sump)

415A 794129 Plug

(Cover/Retainer)

431 697122 Elbow−Intake

445 698083 Filter−Air Cleaner

Cartridge

(Non Washable)

462 691261 Washer

(Starter Cable)

474A 696459 Alternator

(Dual Circuit)

Used on Type No(s).

0035, 0193, 0232,

0233, 0235, 0236,

0339, 0458, 0567,

0601.

474B 696457 Alternator

(Tri Circuit)

Used on Type No(s).

0419.

501A 691188 Regulator

Used on Type No(s).

0419.

503 691532 Strap−Starter

505 691251 Nut

(Governor Control

Lever)

510 693699 Drive−Starter

513 692024 Clutch−Drive

521 690581 Shield−Cable

523 699908 Dipstick

524 K691032 Seal−Dipstick Tube

525 697184 Tube−Dipstick

526A 697088 Screw

(Regulator)

544 692034 Armature−Starter

552 697144 Bushing−Governor

Crank

559 693675 Screw

(Remote Choke Stop)

562 691119 Bolt

(Governor Control

Lever)

579 691029 Nut

(Starter Cable)

584 794682 Cover−Breather

Passage

(Used After Code Date

07071800).

(Use With Liquid

Sealant Reference

850)

−−−−−− Note −−−−−−

697112 Cover−

Breather Passage

(Used Before Code

Date 07071900).

601 791850 Clamp−Hose

614 691620 Pin−Cotter

616 692012 Crank−Governor

617 KD692138 Seal−O Ring

(Intake Manifold)

634 D690802 Spring/Seal Assembly

(Walbro)

634B D698779 Spring/Seal Assembly

(Nikki)

635 691909 Boot−Spark Plug

643 698401 Retainer−Air Filter

654 690958 Nut

(Carburetor)

691 K692407 Seal−Governor Shaft

692 690572 Spring−Detent

697 690372 Screw

(Drive Cap)

718 690959 Pin−Locating

729A 691224 Clip−Wire

741 697128 Gear−Timing

750 790832 Screw

(Oil Pump Cover)

757 697607 Link−Counterweight

758 697134 Counterweight

759 697392 Pin−Counterweight

783 693713 Gear−Pinion

789A 698329 Harness−Wiring

797 693167 Nut

(Brush Retainer)

801 691283 Cap−Drive

802 691286 Cap−End

803 Housing−Starter

(Not Serviced

Separately, Order

Starter Motor 693551)

830 691095 Stud−Rocker Arm

842 K691031 Seal−O Ring

(Dipstick Tube)

847 790442 Dipstick/Tube

Assembly

850 100100 Sealant−Liquid

(Rocker Cover Gasket

and Breather Gasket)

(Used After Code Date

07071800).

851 692424 Terminal−Spark Plug

868 KΔ690968 Seal−Valve

877 393456 Wire/Connector−

Alternator

(Dual Circuit)

877B 393537 Wire/Connector−

Alternator

(Tri Circuit)

878 398661 Harness−Alternator

(Dual Circuit)

878A 691955 Harness−Alternator

(Tri Circuit)

883 K692236 Gasket−Exhaust

914 691108 Screw

(Rocker Cover)

943 K690589 Seal−O Ring

(Oil Pump Cover)

947 694393 Solenoid−Fuel

(Walbro)

947A 699915 Solenoid−Fuel

(Nikki)

950 691657 Screw−Float Bowl

965 499613 Cover−Oil Pump

Used on Type No(s).

0035, 0233, 0235,

0236, 0339.

967 697015 Filter−Pre Cleaner

968 698403 Cover−Air Cleaner

(Black)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Motor de Briggs & Stratton

Briggs & Stratton

Briggs & Stratton 140000 Professional 1000 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 356400 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton 280000 Series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 276781 Manual de usuario

Briggs & Stratton

Briggs & Stratton 21B900 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 90000 series Manual de usuario

Briggs & Stratton

Briggs & Stratton 020619-00 Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Manual

Briggs & Stratton

Briggs & Stratton VANGUARD 25V000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 440000 Professional Series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 310000 VERTICAL SERIES Manual de usuario

Briggs & Stratton

Briggs & Stratton 90000 series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 20000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 82500 Manual

Briggs & Stratton

Briggs & Stratton 12H800 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton 194700 Series Instrucciones de instalación

Briggs & Stratton

Briggs & Stratton 272147 Instrucciones de funcionamiento

Briggs & Stratton

Briggs & Stratton Vanguard 130000 Manual de usuario

Briggs & Stratton

Briggs & Stratton THE POWER WITHIN 600 SERIES Manual de usuario

Briggs & Stratton

Briggs & Stratton 080000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 90000 series Manual de usuario

Manuales populares de Motor de otras marcas

Rotax

Rotax 125 senior MAX evo Manual de usuario

Kohler

Kohler K361 Manual de usuario

MTD

MTD OHV Series Manual de usuario

Kohler

Kohler COMMAND CH18-745 Manual de usuario

Mercury

Mercury D4.2L D-Tronic Manual de usuario

Selve

Selve SE Plus-RC Series Manual de usuario

Perkins

Perkins 1206E-E66TA Manual de usuario

Skov

Skov DA 174 Manual

Rossi

Rossi TX11 Series Manual de usuario

Siemens

Siemens SIMOTICS T-1FW3 Hoja de instrucciones

AL-KO

AL-KO PRO 350 Manual de usuario

MTU

MTU 12 V 4000 Lx4 Manual de usuario

Nanni

Nanni N3.30 Manual de instrucciones

Nanni

Nanni N5.160 CR2 Manual de usuario

KSB

KSB SuPreme Series Instrucciones de instalación

Hiwin

Hiwin EM1 Series Manual de usuario

Rotax

Rotax 912 i series Instrucciones de funcionamiento

Siemens

Siemens SIMOTICS XP 1MB1 Manual de usuario
