Page 1 BrickHouse Security User’s Guide
Black Box Micro
User’s Guide
Black Box Micro
The Black Box Micro is a fully functional and customizable
video recording system in a compact case. Use one of the 2
preset recording modes, or program custom settings to record
based on motion or vibration, change video quality, video
orientation and more. Record for up to 8 hours on a single
charge, or use the AC adapter and eliminate power concerns.
All video is recorded to a micro SD card. Use the DVR
Conguration Tool to customize your settings from your
Windows PC, and view your videos using your PC’s media
player (Windows Media Player, VLC, etc.).
Page 2 BrickHouse Security User’s Guide
In the box you will nd the
Black Box Micro DVR, a USB
cord, AC power adaptor, and
this user’s guide.
Page 3BrickHouse Security User’s Guide
Page 4 BrickHouse Security User’s Guide
Page 5BrickHouse Security User’s Guide
Getting Started
The rst step in using your device is charging it. Connect the
device to a USB port on your PC or plug it into AC power with
the included adapter. While charging, the LED indicator will
glow red and will turn off when the battery is full. Before rst
use, we suggest charging the device for 8 hours
This device does not have internal memory and relies on a
micro SD card for recording. The micro SD card should be
inserted with the gold contacts facing up in the direction of the
BrickHouse Security logo. Before inserting a micro SD card,
make sure the card is formatted correctly. The device can re-
cord in the FAT 16/32 format. If you aren’t sure how to format
an SD card, you can nd instructions here:
Page 6 BrickHouse Security User’s Guide
http://www.ehow.com/how_2112408_format-memory-card.
html. The Black Box Micro is compatible with micro SD cards
up to 32GB capacity.
To change settings on your device, you will need to download
and install the DVR Conguration Tool. This can be down-
loaded from http://l.bhs.net/blackbox. Once downloaded,
double-click on Setup.exe and follow the prompts on your
screen to complete installation.
Videos can be played using Windows Media Player (version 9
or higher) or VLC Player. The most recent version of VLC can
be downloaded at no cost from http://www.videolan.org.
Page 7BrickHouse Security User’s Guide
Page 8 BrickHouse Security User’s Guide
The DVR Conguration Tool is broken up into 3 sections. When the DVR is plugged
into your PC via USB, the icon along the top will say “DVR Connected”. If it says
“DVR Disconnected”, you may need to power your computer off and on and plug
the device back in.
Date Time: in the Date Time section, you can adjust the time stamp on
your videos. Choose PC Date Time to program the device using the time and date
saved to your computer.
Click the Custom Date Time radio button to manually program the time stamp using
the dropdown boxes.
DVR Date Time SnapShot displays the time stamp programmed into your Black
Box Micro when it was connected to your PC.
To load any time changes, click on Sync Date Time to DVR. You should see a
notication that reads, “Date Time Updated” when complete.
If the device runs out of power it will hold its time settings for up to 5 days. If more
time passes between charges, the time will have to be reset.
Page 9BrickHouse Security User’s Guide
Settings: in the Settings section you can create custom re-
cording settings for your Black Box Micro.
Video Quality: High, Medium, or Low. The higher the video quality,
the more memory it will use.
Resolution: 640 x 480 or 320 x 240
Circular Recording: Enable or Disable circular recording. When
enabled, the device will automatically delete the oldest le on the
memory card if it reaches capacity, and replace it with a new le.
Timestamp: Enable or Disable to turn the timestamp on and off.
Frame Rate: High is 18 FPS. Low is 6 FPS.
