Breville TR52 Manual de usuario
super clean
toastie maker
instruction booklet
2
product safety
PLEASE READ THESE INSTRUCTIONS AND
RETAIN THEM FOR FUTURE USE.
This product can be used by children aged 8 years and above,
and persons who require supervision, provided:
• they are familiar with the hazards associated with the
product, and,
• they receive instruction by a competent person on how to
safely use the product.
Children must not play with the product. Cleaning and user
maintenance must not be done by children unless they are
aged 8 or older and are supervised.
Keep the appliance and its cord out of reach of children less
than 8 years old.
Bread can burn therefore do not use the appliance near or
below combustible materials such as curtains. Never use the
appliance below wall cupboards or shelves.
Never operate the appliance by means of an external timer or
separate remote-control system.
Do not touch the metal parts of the appliance during use as
they may become very hot.
If the supply cord is damaged, it must be replaced by the
manufacturer,itsserviceagentorsimilarlyqualiedpersons
in order to avoid a hazard.
3
product safety
!Never use this appliance for anything other than its intended use. This appliance is for
household use only. Do not use this appliance outdoors.
!Always ensure that hands are dry before handling the plug or switching on the
appliance.
!Always use the appliance on a stable, secure, dry and level surface.
!Do not touch the external surfaces of the appliance during use as they may become
very hot.
!Care is required when using the appliance on surfaces that may be damaged by heat.
The use of an insulated pad is recommended.
!This appliance must not be placed on or near any potentially hot surfaces (such as a
gas or electric hob).
!Never let the power cord hang over the edge of a worktop, touch hot surfaces or
become knotted, trapped or pinched.
!Do not use the appliance if it has been dropped or if there are any visible signs of
damage.
!Ensure the appliance is switched off and unplugged from the supply socket after use
and before cleaning.
!Always allow the appliance to cool before cleaning or storing.
!Never immerse any part of the appliance or power cord and plug in water or any other
liquid.
!Never leave the appliance unattended when in use.
4
features
Due to our policy of continuous improvement, the actual product may differ slightly from the one illustrated in these instructions.
e
r
t
y
w
1 Latch-holdsthelidrmlyclosedduringcooking
2 Carrying handle
3 Greenready-to-cooklight
4 Red power on light
5 Non-stickcookingplateswiththeoriginalBrevillecut-and-sealaction.Suitable
for large or small slices of bread.
6 Cord storage around feet
q
5
5
using your sandwich toaster
Beforerstuse
Note that the rst time you use your sandwich toaster, you may notice a slight burning
smell and a little smoke. This is completely normal and will soon disappear.
• Unpack your sandwich toaster. You may wish to keep the packaging for future use.
• Remove and clean the plates in warm soapy water. Dry thoroughly and ret.
Using your sandwich toaster
1. Plug your toaster in to the mains supply socket and switch the socket on if required.
The red ‘power on’ light will light up and your sandwich toaster will start heating up.
Pre-heating will take about 6 minutes.
2. When your sandwich toaster is fully heated the green ready-to-cook light will light up.
This light will go on and off as your sandwich toaster maintains the right temperature.
3. Lightly brush the cooking plates with sunower oil or spread the OUTSIDE of the
bread with butter or a spread suitable for cooking. Don’t use a low fat spread or one
which has a high water content.
4. Place the lower slice of bread onto the bottom plate ‘buttered’ side down. Form a
hollow with the back of a spoon and add 1-2 tbsp of the prepared lling. Don’t overl
the sandwich or the lling will leak out Add the top slice of bread buttered side up and
close the lid gently and latch it. Take care because your sandwich toaster will be hot!
5. Allow the sandwich to toast for approximately 4-5 minutes. Leave the sandwich in the
toaster for more or less time according to taste.
6. Unlatch and open the lid. Watch out for escaping steam—use a tea towel or wear
oven gloves. Remove the cooked sandwich with a non-metallic spatula. Don’t use a
metal blade as this will damage the non-stick surface of the plates.
7. Once cooked, take care when eating, as llings, especially fruit or tomato, can be
very hot.
66
removing/refitting the plates
Unplugthetoasterandallowittofullycooldownbeforeremovingorretting
the plates.
Removal
1. To remove the top plate, slide the two latches outwards and hinge the plate
downwards and out of the sandwich toaster.
2. To remove the bottom plate, slide the two latches outwards and lift the bottom plate
out of the sandwich toaster.
Retting
3. To ret the top plates, position the two lugs on the top plate into the two recesses in
the hinge. Swing the plate upwards until the latches click into place.
4. To ret the bottom plate, position the two lugs on the bottom plate into the two
recesses in the hinge. Swing the plate downwards until the latches click into place.
7
q w
e r
8
care and cleaning
Unplug and switch off your sandwich toaster and allow it to fully cool down
before cleaning it. Do not immerse the main body, cord set or plug in water or
liquidofanykind.
Never use steel wool, scouring pads, abrasive cleaners or metallic utensils to clean
your sandwich toaster.
1. Before cleaning your sandwich toaster, switch it off and unplug it from the mains
supply. Allow it to cool down fully.
2. Wipe the cooking plates with an absorbent paper or soft damp cloth.
3. Clean the outside of your sandwich toaster with a soft damp cloth which has been
wrung almost dry in warm soapy water. The cover can be polished with a soft dry
cloth.
4. Remove the plates from your sandwich toaster. Immerse the plates in warm, soapy
water. Rinse with clean water. Wipe dry with a soft cloth. To avoid oxide forming on
the uncoated surfaces of the plate, insert the plate back into your sandwich toaster
and heat for one minute with the lid closed. The cooking plates can also be washed
in a dishwasher.
5. Clean the outside of your sandwich toaster with a soft damp cloth which has been
wrung almost dry in warm soapy water. The cover can be polished with a soft dry
cloth.
9
This appliance must be earthed.
This appliance is tted with either a moulded or rewirable BS1363, 13 amp plug. The fuse
should be rated at 5 amps and be ASTA approved to BS1362.
If the fuse in a moulded plug needs to be changed, the fuse cover must be retted. The
appliance must not be used without the fuse cover tted.
If the plug is unsuitable, it should be dismantled and removed from the supply cord
and an appropriate plug tted as detailed below. If you remove the plug it must not be
connected to a 13 amp socket and the plug must be disposed of immediately.
The wires of the mains lead are coloured in accordance with the following code:
GREEN/YELLOW = EARTH BLUE = NEUTRAL BROWN = LIVE
The wire which is coloured GREEN/YELLOW must be connected to the terminal in
your plug which is marked with an E or by the earth symbol ( ) or coloured GREEN or
GREEN /YELLOW.
The wire which is coloured BLUE must be connected to the terminal in your plug which is
marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in your plug which
is marked with the letter L or coloured RED.
If any other plug is used, a 5 amp fuse must be tted either in the plug or adaptor or at the
distributor board.
Plug should be BS1363 approved
Fit a 5 Amp Fuse
Ensure that the outer sheath of the cable
is rmly held by the clamp
BROWN
(Live)
5 Amp Fuse
BLUE
(Neutral)
GREEN/YELLOW
(Earth)
connection to the mains supply
10
after sales service
These appliances are built to the very highest of standards. There are no user serviceable
parts. Follow these steps if the unit fails to operate:
1. Check the instructions have been followed correctly.
2. Check that the fuse has not blown.
3. Check that the mains supply is functional.
If the appliance will still not operate, return the appliance to the place it was purchased for
a replacement. To return the appliance to the Customer Service Department, follow the
steps below:
1. Pack it carefully (preferably in the original carton). Ensure the unit is clean.
2. Enclose your name and address and quote the model number on all correspondence.
3. Give the reason why you are returning it.
4. If within the guarantee period, state when and where it was purchased and include
proof of purchase (e.g. till receipt).
5. Send it to our Customer Service Department at the address below:
Customer Service Department
Jarden Consumer Solutions (Europe) Limited
Middleton Road
Royton
Oldham
OL2 5LN, UK.
Telephone: 0161 621 6900 Fax: 0161 626 0391
e-mail:[email protected]
