Breville Bakery Boss BEM823 Manual de usuario

the Bakery Boss™

Instruction Book - BEM823

BREVILLE

RECOMMENDS

SAFETY FIRST

At Breville we are very safety

conscious. We design and

manufacture consumer

products with the safety of you,

our valued customer, foremost

in mind. In addition we ask

that you exercise a degree of

care when using any electrical

appliance and adhere to the

following precautions.

IMPORTANT

SAFEGUARDS

READ ALL INSTRUCTIONS

BEFORE USE AND SAVE

FOR FUTURE REFERENCE

• Carefully read all instructions

before operating the appliance

for the ﬁrst time and save

for future reference.

• Remove and safely discard

any packaging material and

promotional labels before

using the appliance for

the ﬁrst time.

• To eliminate a choking

hazard for young children,

remove and safely discard the

protective cover ﬁtted to the

power plug of this appliance.

• Do not place the appliance

near the edge of a bench

or table during operation.

Ensure the surface is level,

clean and free of water and

other substances. Vibration

during operation may cause

the appliance to move.

• Do not use the appliance

on a sink drain board.

• Do not place the appliance

on or near a hot gas or

electric burner, or where it

could touch a heated oven.

• Always ensure the appliance

is completely assembled

before operating. Follow the

instructions provided in

this book.

• Ensure the speed control dial

is in the OFF position and

the appliance is switched off

at the power outlet and the

power cord is unplugged

before attaching the beater,

whisk or dough hook.

• Do not use attachments

other than those provided

with the appliance.

• Do not operate the appliance

continuously on heavy loads

for more than 3 minutes.

• Handle the appliance and

attachments with care.

Never place your ﬁngers

inside the mixing bowl or near

the beaters, whisk or dough

hook during operation.

• Keep hands, hair, clothing,

as well as, spatulas and other

utensils away from moving

beaters, whisk or dough hook

during operation.

• Should an object such as

a spoon or spatula fall into

the bowl while mixing,

immediately ensure the speed

control dial is in the OFF

position, turn the appliance

off, unplug at the power outlet

and remove the object.

• Do not place hands in the

mixing bowl unless the

appliance is disconnected

from the power outlet.

Ensure the speed control dial

is in the OFF position, the

appliance is switched off and

unplugged from the power

outlet before removing the

beater, whisk or dough hook.

• Ensure the motor and beater,

whisk or dough hook have

completely stopped before

disassembling.

• Always remove the beater,

whisk or dough hook from

the appliance before cleaning.

• Care should be taken when

removing the food from the

mixer bowl by ensuring the

motor and the beater, whisk, or

dough hook have completely

stopped before disassembling.

Ensure the speed control dial

is in the OFF position, the

appliance is switched off at the

power outlet and unplugged

before unlocking the mixer

motor head and moving

into the upright position.

The beater, whisk or dough

hook should be released from

the mixer motor head before

removing the processed food

from the mixer bowl and the

beater, whisk or dough hook.

• Ensure the mixer motor head

is locked into the horizontal

(closed) position when not

in use and before storing.

• Always ensure the speed

control dial is in the OFF

position, the power is

switched off at the power

outlet and the power cord is

unplugged from the power

outlet before attempting to

move the appliance, before

assembling or disassembling,

when it is left unattended and

before cleaning or storing.

• Do not move the appliance

whilst in operation.

• Do not leave the appliance

unattended when in use.

• Do not place any part

of the appliance in the

dishwasher other than the

bowl, splash guard, beater,

dough hook and whisk.

• Do not place any part

of the appliance in the

microwave oven.

• Keep the appliance clean.

Follow the cleaning

instructions provided in

this book.

• Authorised Breville Service

Centres can be found on our

website www.Breville.com.au

Alternatively, you can contact

the Breville Customer Care

Centre by phone on

1300 139 798 or email

AskUs@breville.com.au

IMPORTANT

SAFEGUARDS

FOR ALL

ELECTRICAL

APPLIANCES

• It is recommended to

regularly inspect the appliance.

To avoid a hazard do not use

the appliance if power cord,

power plug or appliance

becomes damaged in any way.

Return the entire appliance

to the nearest authorised

Breville Service Centre for

examination and/or repair.

• Any maintenance other

than cleaning should be

performed at an authorised

Breville Service Centre.

• This appliance is for

household use only.

Do not use this appliance

for anything other than its

intended use. Do not use in

moving vehicles or boats.

• Do not use outdoors.

Misuse may cause injury.

• Children shall not play

with the appliance.

• This appliance shall not be

used by children. Cleaning

and user maintenance shall

not be made by children

without supervision.

• Keep the appliance and its

cord out of reach of children.

Appliances can be used by

persons with reduced physical,

sensory or mental capabilities

or lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and if they understand

the hazards involved.

• The installation of a residual

current device (safety switch)

is recommended to provide

additional safety protection

when using electrical

appliances. It is advisable that

a safety switch with a rated

residual operating current

not exceeding 30mA be

installed in the electrical circuit

supplying the appliance.

See your electrician for

professional advice.

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

• WARNING: Ensure the

speed dial control is in the

OFF position the appliance is

switched off at the power outlet

and unplugged from the power

outlet before attaching the

beater, whisk or dough hook.

Components

A. Tilt-release button

Button releases the motor to tilt and lock

upright. Press again to release and lock

down for storage.

B. Motor head

Powerful motor for thorough mixing results.

C. Load sensing technology

Mixer automatically senses the load

and adjusts the power to maintain the

selected speed (not shown).

D. Mixing task indicator band

E. 12 speed control dial

Adjust speed while mixing, or pause to

temporarily stop mixing and pause

the timer.

F. LCD timer

Counts up when mixing starts, or use the

arrow buttons to set timer to count down.

G. Internal cord storage

Push cord in to desired length.

H. Breville Assist™ handles

Handles on base and on motor head for

easy handling and maneuvering.

I. Handy bowl illumination

Helps you keep an eye on the mix.

J. Two-piece pouring shield

Minimises spattering when mixing and

adding ingredients.

K. Glass mixing bowl

4.7L glass mixing bowl, compatible with the

scraper beater for best results.

L. Sealing lid (not shown)

M. Spatula (not shown)

Flat beater for normal to heavy mixtures (Speed 1-9):

− Heavy cake batters and biscuit doughs

− Pastry

− Mashed potatoes

Wire whisk for incorporating air into mixtures (Speed 10-12):

− Eggs

− Egg whites

− Cream

− Sponge, chiffon or angel food cakes

− Meringues and pavlova

− Sauces and dressings

Dough hook for mixing and kneading yeast doughs (Speed 1-3):

− Breads

− Rolls

− Pizza

− Focaccia

− Yeast-raised cakes and sweet buns

Scraper beater for creaming butter & sugar,

mixing sticky ingredients or folding whipped

egg whites into mixtures (Speed 1-9):

− Frosting and icing

− Cheesecakes

− Flavoured butters

− Mufﬁn batters

− Creaming butter and sugar, mascarpone cheese, cream

cheese, sour cream

− Light cake batters and biscuit doughs

Scrapes the Bowl. So you don’t have to.

Under-mixed batters produce poorly baked results, including collapsing, unevenness of

crumb, holes, low rising, streaking and coarse textures.

The ﬂexible edge of the Scraper Beater continuously folds and scrapes the sides & bottom of

the bowl, including the dimple at the bottom, for exceptionally thorough mixing. It virtually

eliminates the need for hand scraping with a spatula, cutting mixing time by up to 60%*.

*Tested creaming butter and sugar against BEM820 ﬂat beater.

USING THE SCRAPER BEATER

The Scraper Beater can be used for a variety of mixing tasks.

Due to the efﬁcient mixing action of the Scraper Beater, the mixing time of many recipes will

be reduced. Refer to the chart below for approximate mixing times. These are a guide only.

Longer mixing times may be required for larger or double quantities.

Mixture Mixing Task Approx. Mixing Time

Butter & Sugar Creaming 3—4 minutes (or until mixture is

light and creamy)

Cake, biscuit &

mufﬁn batters

Incorporating wet and dry

ingredients

30—40 seconds (or until all

ingredients are combined)

Thin/light batters

(ie. Pancakes)

Incorporating wet and dry

ingredients

40—50 seconds

(or until batter is smooth)

Icing Incorporating wet and dry

ingredients

40—50 seconds

(or until all icing is smooth)

Frosting Creaming butter 1—2 minutes (or until butter is

smooth and creamy)

Combining icing sugar, butter &

liquid ingredients

50—60 seconds

(or until mixture is light and ﬂuffy)

NOTE

Do not use the Scraper Beater for mixing

heavy batters, doughs, whisking egg whites

or whipping potatoes.

When using the scraper beater always make

sure butter, and cream cheese, has been

softened at room temperature, and chopped

into cubes.

TIPS

• When adding ﬂour to the mixing bowl,

always use the pouring shield and ensure

the mixer is on the FOLD setting.

This will prevent ﬂour from escaping the

mixing bowl.

• The Scraper Beater can also be used as

a spatula when removing mixtures from the

mixing bowl.

Attaching the bowl

1. Place the mixer on a level, dry bench top.

The mixer motor head should be in the

horizontal (closed) position when moving.

2. When lowering or lifting the mixer, always

support the motor head with your other

hand to prevent it from free-falling.

3. To remove or insert the mixing bowl,

the mixer motor head must be raised

and locked into the open position.

Raise the mixer motor head by pressing

the RELEASE button.

4. Lift the motor head up until it tilts back and

locks into the open position.

5. Insert the bowl into the bowl locking recess

and turn clockwise until the bowl locks

securely into place.

Assembly

Before ﬁrst use

Before using your mixer for the ﬁrst time,

remove any packaging material and

promotional labels. Ensure the speed

control dial is in the OFF position, the

mixer is switched off at the power outlet

and the power cord is unplugged.

Wash bowl and mixing tools in warm

soapy water with a soft cloth. Rinse and

dry thoroughly.

The bowl and the attachments may be

washed in the dishwasher.

When ﬁrst using your appliance, you may

notice an odour coming from the motor.

This is normal and will dissipate with use.

Attaching mixing and whisking tools

1. Raise the motor head by pressing the

RELEASE button.

2. Align the groove in the top of the mixing

attachment with the locking pin on the

spindle extending down from the mixer

motor head.

3. Push the attachment upwards and turn

clockwise until it locks securely onto the

locking pin on the spindle. Push up and

turn anti-clockwise to remove.

4. Lower the motor head by pressing the

RELEASE button and gently lowering until

it locks into the closed position.

5. The splatter guard can now be assembled if

required. Slide the main ring into position

on top of bowl, then assemble the

pour spout.

WARNING

Avoid contact with beater/dough hook/

whisk during operation. Keep hands, hair,

clothing, spatulas and other utensils out

of the way to prevent personal injury or

damage to the mixer.

Functions

OPERATING THE MIXER

Planetary mixing action

Planetary mixing action is similar to the

mixing action used by commercial mixers

in bakeries and patisseries for 360 degree

beater-to-bowl coverage. This is achieved

by the counter-clockwise motion of the

mixer head combined with the clockwise

sweep of the beater. The result is thoroughly

mixed ingredients without the need for

a rotating bowl.

1. Ensure the power cord is unplugged and the

speed control dial is in the OFF position.

2. Assemble the bowl and mixing / whisking

tool, as noted in the previous section.

3. Press the TILT release button and lower

the mixer head until it locks into the

closed position.

4. Attach the pouring shield, if desired.

5. Unwind the power cord completely and

insert the power plug into a grounded

wall outlet.

6. The LED’s on the speed indicator will

illuminate one-by-one all the way to the top,

then turn off one-by-one. The LCD screen

will display 0:00.

7. Always begin mixing by selecting a low

speed setting on the speed control dial.

Starting on a low speed will prevent

ingredients splattering. Increase the speed

as suited to the mixing task. The speed

setting can be adjusted during operation.

If necessary, stop the mixer during

operation and scrape any food mixture

down the sides of the mixing bowl with

a spatula.

Tabla de contenidos

Otros manuales de Mezclador de Breville

Breville

Breville HeatSoft VFM029 Manual de usuario

Breville

Breville Scraper Mixer Pro Manual de usuario

Breville

Breville twin motor Manual de usuario

Breville

Breville BEM400 Manual de usuario

Breville

Breville BHM800 Manual de usuario

Breville

Breville the Handy Mix Scraper Manual de usuario

Breville

Breville SHM2 Manual de usuario

Breville

Breville Fresh & Furious BBL620 Manual de usuario

Breville

Breville BEM800 Series Manual de usuario

Breville

Breville the Scraper Beater LEM250 Manual de usuario

Breville

Breville the Bakery Chef Hub LEM750 Manual de usuario

Breville

Breville Handy Stand Mixer BEM600XL Manual de usuario

Breville

Breville VFM031 Manual de usuario

Breville

Breville VFM031 Manual de usuario

Breville

Breville EM3 Guía rápida

Breville

Breville HeatSoft VFM027 Manual de usuario

Breville

Breville Scraper Pro BEM800XL/B Manual de usuario

Breville

Breville BBA600XL Manual de usuario

Breville

Breville BEM400 Guía rápida

Breville

Breville VFP040X Manual de usuario

Breville

Breville HeatSoft VFM027 Manual de usuario

Breville

Breville STAND BEM800XL Manual de usuario

Breville

Breville BHM800 Manual de usuario

Breville

Breville Scraper Mixer Twin BEM820 Manual de usuario

Manuales populares de Mezclador de otras marcas

Bosch

Bosch GRW 9 Manual de usuario

MULTIQUIP

MULTIQUIP Whiteman WM45E Guía

KitchenAid

KitchenAid KSM7581BZ0 Guía rápida

Jay-Lor

Jay-Lor 5050 Manual de usuario

Sunbeam

Sunbeam FPSBSM210X Manual de usuario

MULTIQUIP

MULTIQUIP Whiteman MC94S Guía

Thinky

Thinky ARE-250 Manual de usuario

Midas

Midas XL4 Manual de usuario

bianco

bianco PURO 4 Manual de usuario

Paso

Paso DAG9200 Manual de usuario

Sima

Sima SFX-9A Manual de usuario

better chef

better chef IM-815WC Instrucciones de instalación

ALLEN & HEATH

ALLEN & HEATH GR1 Manual de usuario

Lacor

Lacor 69083 Hoja de especificaciones

M-Audio

M-Audio Midiman SAM Manual de usuario

Buffalo

Buffalo CP921 Manual de usuario

Pentair

Pentair HYPRO Cleanload 3376-0870 Instrucciones de operación

Cuisinart

Cuisinart SM50WHE Manual de usuario
