Breville TF40 Manual de usuario

Avance Cookware

Designed with an easy clean non-stick cooking surface

Model TF40

Instructions for use

Includes recipes

Contents

age

Introduction 3

Breville recommends safety first 4

Know your Breville Avance Cookware 6

Operating your Breville Avance Cookware 8

Care and cleaning 9

Cooking techniques 11

Recipes R2

Congratulations

on the purchase of your new Breville Avance Cookware

Breville recommends safety first

We at Breville are very safety conscious. We design and manufacture consumer products with the safety of you,

our valued customer, foremost in mind. In addition, we ask that you exercise a degree of care when using any

electrical appliance and adhere to the following precautions:

ead all instructions before operating and save for

future reference

•If using plastic utensils, do not leave in cooking

vessel when hot.

•Never immerse cord and/or temperature probe in

water or any other liquid.

•Avoid using on metal surfaces eg sink, hotplate.

•Always switch off, unplug and then remove

temperature control probe before cleaning

the appliance.

•Extreme caution must be used when the appliance

is filled with hot oil or other liquid. Do not move

the appliance during cooking and allow it to cool

before removing oil or other liquid.

•Always insert temperature control probe into probe

socket before inserting power plug into power

outlet and switching on appliance. Ensure the probe

socket is completely dry before inserting the

temperature control probe.

•Place frypan at least 200mm away from walls

and curtains.

•Do not touch hot surfaces.

•Do not leave the appliance unattended when in use.

•Always use the appliance on a dry, level surface.

•The appliance is not intended for use by young

children or infirm persons without supervision.

•Young children should be supervised to ensure that

they do not play with the appliance.

•Do not let the cord hang over the edge of a table

or counter, touch hot surfaces or become knotted.

•Do not place this appliance on or near a hot

gas or electric burner, or where it could touch a

heated oven.

•Always turn the temperature control probe to ‘MIN’,

then switch off at the power outlet, then unplug

the appliance when not in use, before attempting

to move appliance and before cleaning or storing.

•This appliance is for household use only. Do not use

this appliance for other than its intended use. Do

not use outdoors.

•Any maintenance, other than cleaning, should be

performed at an authorised Breville Service Centre.

•Regularly inspect the supply cord, plug and actual

appliance for any damage. If found damaged in any

way, immediately cease use of the appliance and

return the entire appliance to the nearest

authorised Breville Service Centre for examination,

replacement or repair.

•The installation of a residual current device (safety

switch) is recommended to provide additional safety

protection when using electrical appliances. It is

advisable that a safety switch with a rated residual

operating current not exceeding 30mA be installed

in the electrical circuit supplying the appliance. See

your electrician for professional advice.

Dishwasher safe

The Avance Cookware element is fully sealed, so the

frypan base is dishwasher safe and can be fully

immersed in water for easy cleaning

Non-skid feet

Know your Breville Avance Cookware

Three position lid tilt

The high dome metal lid can be placed in two

positions to obtain optimum cooking performance.

(see below)

High dome metal lid with steam vent

With the high dome lid in place, the Avance

Cookware can be used as an oven. It allows you to

bake cakes, roast larger pieces of lamb, beef or

chicken. The lid also retains heat and moisture

when slow cooking foods such as curries. Simply

place the lid on the frypan and adjust the steam

vent while cooking

1800 watt element

The element in your Avance Cookware is butterfly

shaped, providing a more even distribution of heat over

the entire cooking surface. The heavy die cast

construction of the frypan is designed to retain even heat

and save energy

Non-stick cooking surface

The non-stick cooking surface on your

Avance Cookware means food won't stick

and less oil can be used when cooking. It

also means that cleaning your frypan is a

breeze. As with all non-stick surfaces only

plastic or wooden utensils should be used

to avoid scratching the surface. Regular high

heat cooking may discolour the non-stick

surface. This is normal and will not affect

the performance or life of the

non-stick coating

Quick release removable base

Your Avance Cookware has a quick

release removable base for easy cleaning.

This also allows the frypan to fit easily

into a dishwasher or sink

Removable temperature control probe

The temperature probe is

thermostatically controlled providing

accurate cooking temperatures with

14 heat settings plus 'High Sear'

an tilt lever

The Pan Tilt Lever is positioned under the

socket where the temperature probe is

inserted. When the lever is pushed down

the Avance Cookware will tilt, allowing fat

and juices to drain from the food. The Pan

Tilt Lever also makes it easier to baste food

and serve gravies or sauces

Operating your Breville Avance Cookware

Before the first use

It is recommended you remove any promotional

labels and wash your frypan and lid in hot, soapy

water. Rinse and dry thoroughly.

Do not immerse the cord and/or temperature control

probe in water or any other liquid.

1. Insert the temperature control probe into the

probe socket on the appliance. then plug into a

230/240v power outlet and switch ‘ON’. Always

insert the probe into the appliance first, then

plug into main power outlet.

2. Turn the dial on the temperature probe

anti-clockwise to the desired setting. The heating

‘ON’ light will illuminate.

Before inserting the temperature probe into the

frypan socket, ensure the interior of the socket is

fully dry. To do this, shake out excess water then

wipe the interior of the socket with a dry cloth.

Note

3. The red temperature control light will be on until

the frypan reaches the desired temperature. Once

the temperature has been reached, the red light

will cycle ‘ON’ and ‘OFF’ during cooking to retain

the desired temperature.

4. When cooking is completed, turn the dial

clock-wise until it is aligned with the ‘MIN’.

Switch off at the power outlet and then unplug.

5. Leave the temperature control probe connected to

the appliance until cool.

This frypan must be used with the temperature

probe provided. Do not use any other probe

or connector.

Note

ecommended heat control probe settings

Dial setting Uses

2-6 • keeping food warm

• basting

6-8 • slow cooking e.g. casseroles,

curries and soups

• cooking roasts

8-12 • browning nuts

• shallow frying

• pancakes and crepes

• rice and pasta

12-14 • sealing steaks and roasts

14-High Sear • cakes and self saucing

puddings

Care and cleaning

•Do not leave plastic cooking utensils in contact with

the hot frypan surface while cooking.

•Before cleaning, switch the frypan to ‘MIN’ and

unplug from the power outlet. Remove the

temperature probe when cooled from the socket in

the appliance.

Temperature probe

•If cleaning is necessary, wipe over the unit with a

slightly damp cloth.

Never immerse the temperature probe or cord in

water or any other liquid.

Note

Non-stick cooking surface

Cooking on a non-stick surface minimises the need

for oil, food does not stick and cleaning is easier.

Any discolouration that may occur will only detract

from the appearance of the frypan and will not affect

the cooking performance.

When cleaning the non-stick coating, do not use

metal (or other abrasive) scourers. Wash in hot soapy

water. Remove stubborn spots with a plastic washing

pad or nylon washing brush. Rinse and dry thoroughly.

emoving discolouration of the

non-stick surface

•Combine 2 tablespoons bicarbonate of soda, 1⁄4cup

household bleach, 1 cup water.

•Pour into the frypan, place lid on with the vent

closed and simmer for 5-10 minutes.

•Clean in a well-ventilated area and avoid

breathing in the vapours. Wash as directed before

re-use. In some instances this may not remove

all the staining.

emovable frypan base

To remove the base for cleaning firstly switch off at

the power outlet, unplug and remove temperature

probe from the frypan.

1. Turn the frypan upside down (see below).

Push down on the quick release knob and turn

clockwise as shown by the arrow.

2. Lift the base from the frypan, lifting over the

probe socket.

Fig. 1

Care and cleaning continued

High dome lid

Wash the lid in warm, soapy water using a soft

sponge, rinse and dry thoroughly.

Dishwasher safe

Your frypan is dishwasher safe for easy cleaning. The

recessed heating element is completely sealed so it is

safe to immerse in water. The removable frypan base

and lid are also dishwasher safe.

Before inserting the temperature probe into the

frypan socket, ensure the interior of the frypan

socket is fully dry. To do this, shake out excess

water then wipe the interior of the socket

with a dry cloth.

Note

Storage

Store the temperature probe carefully. Do not knock

or drop it as this can damage the probe. If damage is

suspected, return the temperature probe to your

nearest Breville service centre for inspection.

For convenient storage of the temperature

probe, line the frypan with 2 sheets of kitchen

paper and place the probe on the kitchen paper.

This will ensure the probe and plug don’t scratch

the non-stick surface.

That’s the idea™

THE FRYPAN SHOULD NEVER BE OPERATED WITHOUT THE FRYPAN AND BASE FULLY

ASSEMBLED AND LOC ED INTO PLACE.

Otros manuales para TF40

Otros manuales de Utensilio de cocina de Breville

Breville

Breville THE HOT WOK BEW600XL Manual de usuario

Breville

Breville EW30 Guía rápida

Breville

Breville Avance Banquet BEF400 Manual de usuario

Breville

Breville HealthSmart BEW300 Manual de usuario

Breville

Breville Gourmet Wok Manual de usuario

Breville

Breville EW30XL Manual de usuario

Breville

Breville EW40 Manual de usuario

Breville

Breville EW40 Manual de usuario

Breville

Breville Ezy Carve BEK5 Manual de usuario

Breville

Breville TF40 Manual de usuario

Breville

Breville EW30XL Manual de usuario

Manuales populares de Utensilio de cocina de otras marcas

Bourgini

Bourgini 41.0016.00.00 Manual de usuario

Hamilton Beach

Hamilton Beach 74150 Manual de usuario

Spring

Spring CBS Manual de usuario

Rohe

Rohe GP 001 Guía de configuración

Melissa

Melissa 646-035 Manual de usuario

NuWave

NuWave 31760 Manual de usuario

Miele

Miele KMTY Manual de usuario

Weston

Weston 07-0301 Manual de usuario

Westfalia

Westfalia 849372 Manual de usuario

IKEA

IKEA TROVÄRDIG Manual de usuario

IKEA

IKEA UNDERSÖKA Manual de usuario

TRFL

TRFL LoafNest Guía rápida

NEFF

NEFF T4..3.. Manual de usuario

Schulte-Ufer

Schulte-Ufer De Luxe i Series Guía de configuración

Cook's Companion

Cook's Companion IntelliBag Series Manual de usuario

Genius

Genius Nicer Dicer Chef S Manual de usuario

Swissmar

Swissmar 3-in-1 fondue set Instrucciones de funcionamiento

Livington

Livington COPPERLINE WonderCooker Manual de usuario
