Breville VIN210 Manual de usuario
2400W
digital steam iron
instruction booklet
2
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
This product can be used by children aged 8 years and above,
and persons who require supervision, provided:
• they are familiar with the hazards associated with the
product, and,
• they receive instruction by a competent person on how to
safely use the product.
Children must not play with the product. Cleaning and user
maintenance must not be done by children unless they are
supervised.
Keep the appliance and its cord out of reach of children less
than 8 years old when it is switched on or cooling down.
The appliance must not be left unattended when it is
connected to the mains supply.
The appliance must be unplugged from the mains supply
socketbeforellingthewatertankwithwater.
Always use the appliance on a stable, secure, dry and level
surface. When placing the appliance on its stand, ensure that
the surface on which the stand is placed is stable.
Do not use the appliance if it has been dropped, if there are
any visible signs of damage or if it is leaking.
If the supply cord is damaged, it must be replaced by the
manufacturer,itsserviceagentorsimilarlyqualiedpersonsin
order to avoid a hazard.
product safety
3
!Never use this appliance for anything other than its intended use. This appliance is for
household use only. Do not use this appliance outdoors.
!Always ensure that hands are dry before handling the plug or switching on the
appliance.
!Do not touch the metal parts of the appliance during use as they may become very hot.
!This appliance must not be placed on or near any potentially hot surfaces (such as a
gas or electric hob).
!Always allow the appliance to cool before cleaning or storing.
!Never immerse any part of the appliance or power cord and plug in water or any other
liquid.
!Never let the power cord hang over the edge of a worktop, touch hot surfaces or
become knotted, trapped or pinched.
product safety
4
features
q w e r
o
sdf
t y
u
i
g
Due to our policy of continuous improvement, the actual product may differ slightly from the one illustrated in these instructions.
1. Water tank inlet cover
2. Steam control
3. Steam burst button
4. Spray button
5. Temperature select buttons (+/-)
6. Temperature indicator display lights
7. Flexible cord protector
8. Heel rest
9. Cord wrap
10. Water tank
11. Tourmaline soleplate
12. Self clean button
13. Water level maximum indicator
14. Spray nozzle
a
5
before first use
Remove all packaging including any soleplate protection before using your iron.
General
Wipe over the soleplate with a cloth moistened with methylated spirit. Wipe off the
methylated spirit with a damp cloth then dry the soleplate thoroughly.
Before connecting your iron to the mains supply, make sure your supply voltage is the
same as the one indicated on your iron.
When you rst use your iron, there may be a slight odour and it may smoke slightly for the
rst few minutes of operation. This is quite normal and will disappear.
Cleaning your iron before use
Follow these simple steps to remove any impurities or residues inside your steam iron
that may be left over from the manufacturing process.
1. Follow the instructions under llingyouriron and ll the water tank as described.
Empty the water tank to rinse out any foreign particles then rell it.
2. Follow the instructions under steam ironing. Set the temperature to the MAX setting
and the steam control to the high steam setting.
3. Iron an old piece of cloth (cotton or towelling is ideal) for a few minutes. While ironing,
press the steam button 4 or 5 times.
4. Any impurities will be ushed from your iron by the steam and absorbed by the cloth.
5. Your iron is now ready for use.
6
filling your iron
Never add fabric conditioner, starches or any other chemicals to the water in
your iron.
1. Ensure your iron is switched off and unplugged from the mains supply socket.
2. Set the steam control to the off position (0).
3. Open the water tank inlet cover.
4. Using a jug, ll the water tank with ordinary tap water. To avoid air locks, tilt your iron
slightly while lling it.
5. Don’t ll the iron above the water level indicator MAX marking. Check the water level
by standing the iron on its heel.
6. When the iron is lled close the water tank inlet cover.
7
using your iron
We recommend that you:
• Start by ironing those items of laundry that require the lowest temperature (e.g.
synthetics). Finish by ironing fabrics which respond best to higher temperatures and
steam—such as cotton and linen.
• If you iron a fabric made of a blend of bres set the temperature of your iron to the
most delicate bre.
• Never use the burst of steam button on silks or synthetics.
• When using starch, it should be sprayed onto the reverse side of the fabric and the
soleplate cleaned more frequently.
• Do not iron over sharp or hard objects such as buttons, studs or zippers as they will
scratch the soleplate of your iron.
Important
Your iron takes time to heat up and cool down. If you change the temperature setting on
your iron, you must give it time to adjust to the new setting.
This is especially important when you change from a high setting to a lower one. It
takes your iron longer to cool down than it does to heat up and this is the reason we
recommend that you begin ironing at lower temperatures.
If you do need to reduce the temperature of your iron, wait until the display light stops
ashing before ironing. This will ensure that your iron has reached the lower temperature
and is not too hot for the fabric being ironed.
8
using your iron
Steam ironing
If you do not allow your iron to reach the selected temperature, water may drip
from the soleplate during steam ironing.
It is recommended that for harder to iron fabrics such as cotton and linen, steam should
be used when ironing.
When ironing cotton and linen, always select the highest temperature. Steam should
never be used on delicate fabrics like nylons, acrylics and synthetics.
1. Fill your iron with water.
2. Plug your iron into the mains supply and switch on.
3. Use the temperature select +/- buttons to select the lll or MAX setting. The hotter
your iron, the more steam is generated.
4. When the lll or MAX light stops ashing, your iron is at the correct temperature
and ready to use. During use, the lll or MAX light will ash periodically as your iron
maintains the selected temperature.
5. Adjust the steam control lever to select the desired steam output.
6. Move the steam control lever to the high steam ( ) setting to increase the amount of
steam, or towards the off (0) setting to decrease the amount of steam.
7. The steam can be shut off at any time by setting the steam control to the off (0)
position.
Ironing without steam
If you intend to dry-iron fabrics there is no need to ll the water tank. However, if water is
already in the water tank, you don’t need to empty it.
1. Set the steam control to the off position (0).
2. Plug your iron in to the mains supply socket and switch the socket on. The STANDBY
and llights will illuminate.
3. Press the temperature select +/- buttons to select the temperature setting appropriate
to the fabric type being ironed. For example, if you select the lll setting, the
STANDBY, l and ll lights will illuminate and the lll light will ash as your iron
heats up. When the lll light stops ashing, your iron is at the correct temperature
and ready to use.
4. During use, the lll light will ash periodically as your iron maintains the selected
temperature.
9
using your iron
Vertical steam ironing
Never iron garments when they are being worn.
Your iron can be used for vertical steam ironing curtains, dresses on hangers etc.
1. Fill your iron with water.
2. Plug your iron into the mains supply and switch on.
3. Use the temperature select +/- buttons to select the lll or MAX setting. The hotter
your iron, the more steam is generated.
4. When the lll or MAX light stops ashing, your iron is at the correct temperature
and ready to use. During use, the lll or MAX light will ash periodically as your iron
maintains the selected temperature.
5. Hold your iron 15cm (6 inches) from the fabric.
6. Press the shot of steam button. The steam will penetrate the fabric removing the
creases. To apply more steam press the shot of steam button again. Wait several
seconds between each press of the button.
Burst of steam
Your iron must be set to either lll or MAX. Wait several seconds between each press of
the steam button.
Press the shot of steam button whenever you have a stubborn crease that needs extra
steam. Steam will burst from the holes in the soleplate of your iron into the fabric.
Spraying
The spray function will only operate when there is water in the water tank.
1. The water spray can be used to help iron heavy fabrics or difcult areas (collars,
pockets, sleeves, creases, etc). It can also be used when ironing delicate fabrics
which cannot be steam ironed.
2. Simply press the button as required to produce a spray of water. If the spray is being
used for the rst time, or if the iron has been standing for some time, you may need
to press the spray button a few times before it works correctly.
10
using your iron
Safety auto shut-off function
ALWAYS disconnect your iron from the mains supply socket after use. NEVER
leave the iron unattended with the auto shut-off function in operation.
Your iron will shut off if it has not been used for 15 minutes when resting on its heel, or 30
seconds with the soleplate face down. The STANDBY light will ash indicating that your
iron is now in auto-shut off mode. To restart your iron, either press the +/- buttons or move
your iron gently. The iron will revert back to its previous setting.
Anti-drip feature
When the temperature of your iron is insufcient to create steam, the supply of water is
cut off automatically to avoid any drips from the soleplate.
Anti-scalelter
Your iron is tted with a permanent anti-scale lter. This lter is xed and cannot be
removed for cleaning.
The lter is designed to reduce the build-up of limescale inside your iron. Limescale
occurs during steam ironing due to water hardness.
Water hardness varies from one area to another. The effectiveness of the lter will
depend on how ‘hard’ your water is.
