9
and a new calculation of the time when the
next cleaning is required will be started.
During the cleaning process in the
Clean&Renew™ the yellow light will flash and
will go off after approx. 4 hours when cleaning
is finished.
Automatic cleaning
Once the shaver is put into the
Clean&Renew™, it is cleaned automatically
(see separate instructions). Manual cleaning is
recommended only when the Clean&Renew™
is not available, e.g. when travelling.
Manual cleaning
This appliance is suitable for cleaning
under an open water tap.
Warning: Detach the hand-held part
from the power supply before cleaning it in
water.
Regular cleaning ensures better shaving
performance. Rinsing the shaving head after
each shave under running water is an easy and
fast way to keep it clean:
• Switch the shaver on (cordless) and rinse
the shaving head under hot running water.
A natural based soap may also be used
provided it contains no particles or abrasive
substances. Rinse off all foam and let the
shaver run for a few more seconds.
• Next, switch off the shaver, remove the
shaver foil and the cutter block. Then leave
the disassembled shaving parts to dry.
Alternatively, you may clean the shaver using
the brush provided:
• Switch off the shaver. Remove the shaver
foil.
• Using the brush, clean the cutter block and
the inner area of the shaver head. However,
do not clean the shaver foil with the brush as
this may damage the foil.
Replacement light for shaving parts / Reset
To maintain 100% shaving performance,
replace your foil and cutter block, when the
replacement light for shaving parts (9) comes
on (after about 18 months) or when worn.
Change both parts at the same time for a
closer shave with less skin irritation.
(Shaver foil (2) and cutter block (3):
5000 series)
The replacement light will remind you during
the next 7 shaves to replace the shaving parts.
Then the shaver will automatically reset the
display.
After you have replaced the shaving parts (foil
and cutter block), use a ball-pen to push the
reset button (10) for at least 3 seconds to reset
the display manually.
While doing so, the replacement light blinks
and goes off when the reset is complete. The
manual reset can be done at any time.
Preserving the batteries
In order to maintain the optimum capacity
of the rechargeable batteries, the shaver has
to be fully discharged (by shaving) every
6 months approximately. Then recharge the
shaver to full capacity. Do not expose the
shaver to temperatures higher than 50 °C for
extended periods of time.
Environmental notice
This product contains rechargeable
batteries. In the interest of protecting
the environment, please do not dispose
of the product in the household waste at the
end of its useful life. Disposal can take place
at a Braun Service Centre or at appropriate
collection points provided in your country.
Clean&Renew™
Braun Clean&Renew™ has been developed
for cleaning, charging and storing your shaver.
Clean your shaver daily in the Clean&Renew™.
During the automated cleaning process,
the shaver is switched on and off at intervals
to obtain best cleaning results. Since the
specially formulated cleaning fluid contains a
