Braun 5491 Manual de usuario

3210

7570

Syncro System

7570

Type 5491

Modèle 5491

Modelo 5491

NA-09.02.00-KURTZ DESIGN

5491451_S 1 Seite 1 Freitag, 18. August 2000 11:15 11

English 4

Français 14

Español 22

Internet

www.Braun.com

5-491-451/01/III-00

USA / CDN / Mex.

Printed in Germany

Imprimé en Allemagne

Impreso en Alemania

Thank you for purchasing a Braun product.

We hope you are completely satisfied with

your new Braun shaver.

If you have any questions, please call:

US residents 1-800-BRAUN-11

1-800-272-8611

Canadian residents (905) 712-5400

Merci d’avoir fait l’achat d’un produit Braun.

Nous espérons que vous serez pleinement

satisfait de votre nouveau rasoir Braun.

Si vous avez des questions, veuillez appeler

Braun Canada : (905) 712-5400

Gracias por haber comprado un producto

Braun.

Esperamos que Ud. completamente

satisfecha con su nueva afeitadora Braun.

Si Ud. tiene alguna duda, por favor llame al:

Cd. de México 387-1941

Interior del país 01(800) 508-5800

The world’s # 1 selling foil shavers

Le rasoir à grille le plus vendu au monde

Fabricante mundial # 1 en la venta de

rasuradoras de lámina

5491451_S 2 Seite 4 Freitag, 18. August 2000 11:17 11

Syncro 7570

No. 7000

KURTZ DESIGN 16.08.99

Syncro

5491451_S 3 Seite 1 Freitag, 18. August 2000 11:18 11

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions should always be

followed, including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1. Do not reach for an appliance that has fallen into water.

Unplug immediately.

2. Do not use while bathing or in a shower.

3. Do not place, store or charge the appliance where it can fall or be pulled

into a tub or sink. Do not place in or drop into water or other liquid.

4. Except when charging, always unplug this appliance from the electrical

outlet immediately after using.

5. Unplug this appliance before cleaning.

FOR HOUSEHOLD USE

SAVE THESE INSTRUCTIONS

English

5491451_S 4-29 Seite 4 Freitag, 18. August 2000 11:19 11

WARNING

To reduce the risk of burns, fire, electric shock, or injury to persons:

1. Close supervision is necessary when this appliance is used by, on,

or near children.

2. Use this appliance only for its intended use as described in this manual.

Do not use attachments not recommended by the manufacturer.

3. The shaver should never be exposed to temperatures of less

than 32 ºF / 0 ºC and more than 105 ºF/+40ºC for longer than a few hours.

Keep the shaver and cord dry at all times. Do not handle with wet hands.

Do not store in a damp environment. To avoid damage do not wind

the cord around the appliance. It is important to check the cord for damage

periodically particularly at each end where the cord enters the plug.

4. Never operate this appliance if it has a damaged cord or plug, if it is not

working properly, if it has been dropped or damaged, or dropped into water.

Return the appliance to a service center for examination and repair.

5. Keep the cord away from heated surfaces.

6. Never drop or insert any object into any opening.

7. Do not use outdoors or operate where aerosol (spray) products are being

used or where oxygen is being administered.

8. Do not use this appliance with a damaged or broken foil, as serious

facial injuries may occur.

9. Always attach plug to appliance first, then to outlet.

To disconnect, turn all controls to «off», then remove plug from outlet.

5491451_S 4-29 Seite 5 Freitag, 18. August 2000 11:19 11

Your Braun Syncro is supplied with a

Braun Clean&Charge (please see separate

use instructions).

Important

Only use the power supply cord set provided.

A damaged cord must be replaced immediately.

Description

1 Foil protection cap 6 Switch

2 Shaver foil 7 Display

3 Cutter block 8 Info key

4 Foil release button 9 Pilot light

5 Long hair trimmer 10 Shaver socket

Technical specifications:

•

Wattage via cord set: 7 W

•

Power supply via cord set:

100-240 V

/ 50 or 60 Hz (automatic adaptation)

•

Shaver input voltage: 12-24 V

Charging the shaver

•

First charging: Using the power supply cord set,

plug the shaver into an electrical outlet with the switch

on position «0» and charge it for at least 4 hours

(plug might get warm).

•

Once the shaver is completely charged, shave without

the cord until fully discharged. Then recharge to full

capacity again (subsequent charges will take about

1 hour).

•

A full charge will give up to 50 minutes of cordless

shaving time depending on your beard growth.

However, the maximum battery capacity will only be

reached after several charging/discharging cycles.

•

Best environmental temperature range for charging

is 60°F to 95°F / 15 °C to 35°C.

+35°C

+15°C

210

7570

5491451_S 4-29 Seite 6 Freitag, 18. August 2000 11:19 11

Display

The pilot light shows that the shaver is plugged into the

outlet properly.

The display shows the operation mode and charging

conditions of the shaver: During charging the display

shows the battery capacity symbol increasing by 20%

segments and the remaining charging time (flashing):

First charging (4 h):

The display counts down in 20 min. steps.

Subsequent chargings (1 h):

The display counts down in 5 min. steps.

The battery is fully charged.

Below 10 minutes remaining shaving time, the display

shows the minutes left. The «moving»plug symbol

indicates that you should charge your shaver.

There is insufficient battery charge for a cordless shave.

Either recharge the shaver or shave with the cord

connected to the mains.

The display changes to this format when the shaver

is in the Clean&Charge.

Your shaver features an automated battery conditioning

facility which monitors the charging/discharging process. If

necessary, it will automatically recondition the battery with

a complete discharge/recharge cycle (about every

6 months).

For additional information, press the info key:

press once:

–to display the duration of the last shave

press again:

–to display the key part number for shaver foil

and cutter block

hold for 3 secs:

–to run a display demo

5491451_S 4-29 Seite 7 Freitag, 18. August 2000 11:19 11

The shaver has to be cleaned (refer to paragraph

«Manual cleaning»or to separate «Clean&Charge»use

instructions). To reset the display, push the info key.

The shaver has to be lubricated (refer to paragraph

«Manual cleaning»or to separate «Clean&Charge»use

instructions). To reset the display, push the info key.

The shaver cannot be charged if the environmental

temperature is too low (< 32 °F/0°C) or too high

(> 130 °F/55 °C).

Allow the shaver to remain for some time at room

temperature for optimal charging conditions.

No display: The rechargeable battery is completely

discharged and has to be recharged.

Shaving

Switch positions

0 = Off (switch is locked)

Press and push up the switch to operate the shaver:

1 = Shaving with the pivoting head

The pivoting cutting system automatically adjusts

to every contour of your face.

2 = Shaving with the pivoting head locked at an angle

(to permit shaving in difficult areas, e.g. under the nose)

3 = The long hair trimmer is activated

(for trimming sideburns, moustache and beard).

Shaving with the cord

If the rechargeable battery is discharged, you may also

shave with the shaver connected to the mains via the

power supply cord set.

(If the shaver does not run immediately, charge it with the

switch on position «0»for approx. 1 minute.)

Tips for the perfect shave

•

It can take 14-21 days for your beard to adjust to the

new shaving system.

•

We recommend that you shave before washing,

as the skin tends to be slightly swollen after washing.

•

Hold the shaver at right angles (90°) to the skin.

•

Stretch your skin and shave against the direction

of beard growth.

•

Replace the shaver foil and cutter block every

years, or when the parts are worn, to ensure

optimum shaving performance.

5491451_S 4-29 Seite 8 Freitag, 18. August 2000 11:19 11

Keeping your shaver in top shape

Automated cleaning

The Braun Clean&Charge automatically takes care of all

cleaning and lubrication needs of your shaver. Please refer

to the separate use instructions.

If not supplied already with your shaver, the Braun

Clean&Charge is available at your dealer or Braun Service

Centers.

Manual cleaning

For easy cleaning after each shave, switch the shaver

off. Press the release buttons to lift the shaver foil

(do not remove the foil completely). Switch on

the

shaver for approx. 5-10 seconds so that the shaved

stubbles can fall out.

For a thorough cleaning (weekly), remove the shaver

foil and tap it out on a flat surface. Using the brush,

clean the cutter block and the inner area of the pivoting

head. About every four weeks, clean the cutter block

with Braun cleaning agents.

If your skin is very dry and you notice a reduced operation

time of the shaver or if the display shows «oil!»,

apply a drop of light machine oil onto the shaver foil.

Do not rinse the shaver in or under water.

Replacing the shaving parts

The shaver foil and cutter block are precision parts that,

in time, are subject to wear. Replace your foil and cutter

block every 18 months and get a 25% better shave.*

(Shaver foil and cutter block: part No. 7000)

*(Overall evaluation from Braun users comparing their

shave with new parts and those used for 18 months.)

Accessories

available at your dealer or Braun Service Centers:

•

Shaver foil and cutter block

(part No. 7000)

•

Refill cartridge (double pack) CCR 2

(#5331)

oil

7000

Syncro

5491451_S 4-29 Seite 9 Freitag, 18. August 2000 11:19 11

Environmental notice

This appliance is provided with a nickel-hydride cell unit.

This cell does not contain any harmful heavy metals.

Nevertheless, in the interest of recycling raw materials,

please do not dispose of this appliance in the household

waste at the end of its useful life. Disposal can take place

at a Braun Service Center or appropriate collection sites.

Subject to change without notice.

5491451_S 4-29 Seite 10 Freitag, 18. August 2000 11:19 11

Otros manuales para 5491

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Rasuradora eléctrica de Braun

Braun

Braun 5684 Manual de usuario

Braun

Braun 9250cc Manual de usuario

Braun

Braun Lady Braun style universal 5575 Manual de usuario

Braun

Braun Cruzer 3 2876 Manual de usuario

Braun

Braun SyncroPro 5492 Manual de usuario

Braun

Braun 5671 Manual de usuario

Braun

Braun 170 Manual de usuario

Braun

Braun PocketGo 550 Manual de usuario

Braun

Braun 5 Series Manual de usuario

Braun

Braun SilkFinish FG 1000 Manual de usuario

Braun

Braun Series 5 510 Manual de usuario

Braun

Braun FlexXPII 5775 Manual de usuario

Braun

Braun Wet & Dry 799cc-7 Manual de usuario

Braun

Braun 3080s Manual de usuario

Braun

Braun bodycruZer Manual de usuario

Braun

Braun Gillette cruZer Z20 Manual de usuario

Braun

Braun shaver Manual de usuario

Braun

Braun 5 Series Manual de usuario

Braun

Braun Series 1 Manual de usuario

Braun

Braun TriControl 4745 Manual de usuario

Braun

Braun 5090cc Manual de usuario

Braun

Braun 7 series Manual de usuario

Braun

Braun 360S-4 Manual de usuario

Braun

Braun cruZer5 Manual de usuario

Manuales populares de Rasuradora eléctrica de otras marcas

Philips

Philips MicroAction 4402LC Manual de usuario

Philips

Philips HQ7740 Manual de usuario

Philips

Philips Norelco BG2022 Bodygroom Manual de usuario

Norelco

Norelco Quadra 7610X Manual de usuario

Philips

Philips 7616X Manual de usuario

Philips

Philips HQ802 Manual de usuario

Philips

Philips HQ7363/17 Manual de usuario

Philips

Philips NORELCO S7371 Manual de usuario

Daga

Daga MT-400 Manual

Philips

Philips RQ119x Manual de usuario

Remington

Remington BHT100 Manual de usuario

Philips

Philips Bodygroom BG2000 Manual de usuario

Kompernass

Kompernass KH 5537 Manual de usuario

Remington

Remington BHT6100 Manual de usuario

Philips

Philips qc5365 Manual de usuario

MIA

MIA Aqua Body Manual de usuario

Philips

Philips NORELCO AT880 Manual de usuario

Matheo

Matheo MLR 15 Manual de usuario
