Bradford White 50T65 Guía de aplicación

RESIDENTIAL & LIGHT DUTY

COMMERCIAL REPLACEMENT PARTS LIST

“M

”, “M(1,2)XR”, “M4” and

Light Duty 50T65, 65T65 Models

Includes Hydrojet

Total Performance System

Effective: July 31, 2008

ECO 7291-2

NOTE: BOTH MODEL AND SERIAL

NUMBERS ARE REQUIRED FOR

ORDERING REPLACEMENT PARTS

Dimensions and specifications

subject to change without notice.

Parts Book #238-46639-00C

Page 2

Item Description Model Model Model Model Model

MI30T*F(BN,CX,SX) MI30S*F(BN,CX,SX) MI303T*F(BN,CX,SX) MI40T*F(BN,CX,SX) MI403S*F(BN,CX,SX)

1 Draft Hood 243-45787-00 243-45787-00 243-45787-00 243-45787-00 243-45787-00

2 Hot Water Outlet Anode MagnesiumŸ224-32731-95 224-32731-97 224-32731-82 224-32731-95 224-32731-81

Hot Water Outlet AluminumŸ224-32999-24 224-32999-25 224-32999-06 224-32999-24 224-32999-31

Hot Water Outlet A420 AluminumŸ224-45147-02 224-45147-02 224-45147-03 224-45147-02 224-45147-04

3 Cold Water Inlet Dip Tube PolypropyleneŸŸ 229-39625-23 229-39625-24 229-39625-07 229-39625-25 229-39625-03

Cold Water Inlet Polysulfone (NC Code)ŸŸ 229-39628-26 229-39628-27 229-39628-07 229-39628-28 229-39628-03

4 Flue Baffle 243-44639-00 243-45226-00 243-45224-00 243-42283-00 243-45223-00

5 T&P Relief Valve 265-32920-01 265-32920-01 265-32920-01 265-32920-01 265-32920-01

6 Gas Valve Natural Gas 265-46181-01 265-46181-01 265-46181-01 265-46181-01 265-46181-01

Gas Valve LP Gas 265-46182-01 265-46182-01 265-46182-01 265-46182-01 265-46182-01

7 Piezo Igniter 239-43448-00 239-43448-00 239-43448-00 239-43448-00 239-43448-00

7A Piezo Bracket (White Rodgers) 239-46157-02 239-46157-02 239-46157-02 239-46157-02 239-46157-02

Piezo Bracket (Robertshaw) 239-43449-00 239-43449-00 239-43449-00 239-43449-00 239-43449-00

8 Brass Drain Valve 265-42351-02 265-42351-02 265-42351-02 265-42351-02 265-42351-02

9 Screw-#8-18 x 3/4 HWH 239-44195-00 239-44195-00 239-44195-00 239-44195-00 239-44195-00

10 Screw-#10-12 x 3/4 HWH 239-44113-00 239-44113-00 239-44113-00 239-44113-00 239-44113-00

11 Left Side Inner Door Complete 239-43968-14 239-43968-16 239-43968-14 239-43968-16 239-43968-18

12 Nat. Gas Right Side Inner Door Complete 239-43963-02 239-43963-03 239-43963-02 239-43963-05 239-43963-07

LP Gas Right Side Inner Door Complete 239-43963-02 239-43963-03 239-43963-01 239-43963-03 239-43963-07

13 Nat. Gas Resettable Thermal Switch 239-43676-03 239-43676-01 239-43676-03 239-43676-03 239-43676-02

LP Gas Resettable Thermal Switch 239-43676-03 239-43676-01 239-43676-02 239-43676-01 239-43676-02

14 Screw-#6-20 x 3/8 PHCR 239-43967-00 239-43967-00 239-43967-00 239-43967-00 239-43967-00

15 Outer Door 243-43962-00 243-43962-00 243-43962-00 243-43962-00 243-43962-00

Natural Gas (BN) Burner Assembly

16 Nat Gas Burner Assembly Complete*** 265-47439-02-36 265-47439-04-38 265-47439-02-32 265-47439-04-32 265-47439-07-32

17 Nat. Gas (BN) Burner** 228-42506-00 228-42506-00 228-42506-00 228-42506-00 228-42506-00

18 Nat. Gas (BN) Main Burner Orifice** 234-41034-36 234-41034-38 234-41034-32 234-41034-32 234-41034-32

Nat. Gas (BN) High Altitude 2001 Ft. to 5000 Ft.** 234-41034-39 234-41034-41 234-41034-36 234-41034-36 234-41034-36

Nat. Gas (BN) High Altitude 5001 Ft. to 8000 Ft.** 234-41034-41 234-41034-43 234-41034-38 234-41034-38 234-41034-38

Nat. Gas (BN) High Altitude Over 8000 Ft.** 234-41034-43 234-41034-43 234-41034-38 234-41034-38 234-41034-38

19 Nat. Gas Pilot Assembly** 233-46277-04 233-46277-04 233-46277-04 233-46277-04 233-46277-04

20 Nat. Gas Pilot Orifice** 234-46502-05 234-46502-05 234-46502-05 234-46502-05 234-46502-05

21 Thermocouple** 233-46501-15 233-46501-15 233-46501-15 233-46501-15 233-46501-15

LP Gas (SX) Titanium Stabilized Stainless Steel Burner Assembly (Replacement for LP Gas (CX) Cast Iron Burner)

22 LP Gas Burner Assembly Complete*** 265-47440-02-60 265-47440-05-54 265-47440-02-52 265-47440-05-52 265-47440-11-50

23 LP Gas (SX) Burner** 228-46964-00 228-46964-00 228-46964-00 228-46964-00 228-46964-00

24 LP Gas (SX) Main Burner Orifice** 234-47064-60 234-47064-54 234-47064-52 234-47064-52 234-47064-50

LP Gas (SX) High Altitude 2001 Ft. to 5000 Ft.** 234-47064-54 234-47064-54 234-47064-53 234-47064-53 234-47064-51

LP Gas (SX) High Altitude 5001 Ft. to 8000 Ft.** 234-47064-54 234-47064-54 234-47064-54 234-47064-54 234-47064-52

LP Gas (SX) High Altitude Over 8000 Ft.** 234-47064-54 234-47064-54 234-47064-54 234-47064-54 234-47064-53

25 LP Gas Pilot Assembly** 233-46278-03 233-46278-03 233-46278-03 233-46278-03 233-46278-03

26 LP Gas Pilot Orifice** 234-46502-02 234-46502-02 234-46502-02 234-46502-02 234-46502-02

27 Thermocouple** 233-46501-15 233-46501-15 233-46501-15 233-46501-15 233-46501-15

28 ASSE Approved Mixing Valve (Optional) 239-43740-01 239-43740-01 239-43740-01 239-43740-01 239-43740-01

29 3/4 NPT Plug --- --- --- --- ---

30 Inner Door Gasket Kit 239-44078-00 239-44078-00 239-44078-00 239-44078-00 239-44078-00

31 Wire Tie 239-44328-00 239-44328-00 239-44328-00 239-44328-00 239-44328-00

32 Heat Trap Insert (Outlet) 239-45167-00 239-45167-00 239-45167-00 239-45167-00 239-45167-00

33 Heat Trap Insert (Inlet) 239-45073-00 239-45073-00 239-45073-00 239-45073-00 239-45073-00

34 Kit-Heat Trap Insert 265-45420-00 265-45420-00 265-45420-00 265-45420-00 265-45420-00

- LP to Natural Gas Conversion Kit (Norm Alt.) 265-45712-01 265-45712-02 265-45712-03 265-45712-04 265-45712-05

- LP to Natural Gas Conversion Kit (High Alt.) 265-45712-13 265-45712-14 265-45712-15 265-45712-16 265-45712-17

*Applies to all warranties

**Inner door gasket kit recommended

***Ordering a complete burner assembly may increase delivery time. Please order the specific component required for the quickest delivery.

ŸOrder with item 32

ŸŸOrder with item 33

Page 3

Page 4

Item Description

1 Draft Hood

2 Hot Water Outlet Anode MagnesiumŸ

Hot Water Outlet AluminumŸ

Hot Water Outlet A420 AluminumŸ

3 Cold Water Inlet Dip Tube PolypropyleneŸŸ

Cold Water Inlet Polysulfone (NC Code)ŸŸ

4 Flue Baffle

5 T&P Relief Valve

6 Gas Valve Natural Gas

Gas Valve LP Gas

7 Piezo Igniter

7A Piezo Bracket (White Rodgers)

Piezo Bracket (Robertshaw)

8 Brass Drain Valve

9 Screw-#8-18 x 3/4 HWH

10 Screw-#10-12 x 3/4 HWH

11 Left Side Inner Door Complete

12 Nat. Gas Right Side Inner Door Complete

LP Gas Right Side Inner Door Complete

13 Nat. Gas Resettable Thermal Switch

LP Gas Resettable Thermal Switch

14 Screw-#6-20 x 3/8 PHCR

15 Outer Door

Natural Gas (BN) Burner Assembly

16 Nat Gas Burner Assembly Complete***

17 Nat. Gas (BN) Burner**

18 Nat. Gas (BN) Main Burner Orifice**

Nat. Gas (BN) High Altitude 2001 Ft. to 5000 Ft.**

Nat. Gas (BN) High Altitude 5001 Ft. to 8000 Ft.**

Nat. Gas (BN) High Altitude Over 8000 Ft.**

19 Nat. Gas Pilot Assembly**

20 Nat. Gas Pilot Orifice**

21 Thermocouple**

LP Gas (SX) Titanium Stabilized Stainless Steel Burner Assembly

22 LP Gas Burner Assembly Complete***

23 LP Gas (SX) Burner**

24 LP Gas (SX) Main Burner Orifice**

LP Gas (SX) High Altitude 2001 Ft. to 5000 Ft.**

LP Gas (SX) High Altitude 5001 Ft. to 8000 Ft.**

LP Gas (SX) High Altitude Over 8000 Ft.**

25 LP Gas Pilot Assembly**

26 LP Gas Pilot Orifice**

27 Thermocouple**

28 ASSE Approved Mixing Valve (Optional)

29 3/4 NPT Plug

30 Inner Door Gasket Kit

31 Wire Tie

32 Heat Trap Insert (Outlet)

33 Heat Trap Insert (Inlet)

34 Kit-Heat Trap Insert

- LP to Natural Gas Conversion Kit (Norm Alt.)

- LP to Natural Gas Conversion Kit (High Alt.)

Model Model Model Model Model

MI404T*F(BN,CX,SX) MI503*F(BN,CX,SX) MI50L*F(BN,CX,SX) MI504S*F(BN,CX,SX) MI60T*F(BN,CX,SX)

243-33081-02-20 243-45787-00 243-45787-00 243-12950-00 243-45787-00

224-32731-82 224-32731-107 224-32731-81 224-32731-82 224-32731-86

224-32999-06 224-32999-21 224-32999-31 224-32999-06 224-32999-30

224-45147-03 224-45147-02 224-45147-04 224-45147-03 224-45147-01

229-39625-06 229-39625-22 229-39625-05 229-39625-06 229-39625-14

229-39628-06 229-39628-21 229-39628-05 229-39628-06 229-39628-14

243-45225-00 243-44705-00 243-45223-00 243-45225-00 243-42283-00

265-32920-01 265-32920-01 265-32920-01 265-32920-01 265-32920-01

265-46181-01 265-46181-01 265-46181-01 265-46181-01 265-46181-01

265-46182-01 265-46182-01 265-46182-01 265-46182-01 265-46182-01

239-43448-00 239-43448-00 239-43448-00 239-43448-00 239-43448-00

239-46157-02 239-46157-02 239-46157-02 239-46157-02 239-46157-02

239-43449-00 239-43449-00 239-43449-00 239-43449-00 239-43449-00

265-42351-02 265-42351-02 265-42351-02 265-42351-02 265-42351-02

239-44195-00 239-44195-00 239-44195-00 239-44195-00 239-44195-00

239-44113-00 239-44113-00 239-44113-00 239-44113-00 239-44113-00

239-43968-16 239-43968-18 239-43968-20 239-43968-18 239-43968-20

239-43963-05 239-43963-07 239-43963-09 239-43963-06 239-43963-12

239-43963-05 239-43963-07 239-43963-09 239-43963-06 239-43963-13

239-43676-03 239-43676-02 239-43676-01 239-43676-01 239-43676-02

239-43676-03 239-43676-02 239-43676-01 239-43676-01 239-43676-03

239-43967-00 239-43967-00 239-43967-00 239-43967-00 239-43967-00

243-43962-00 243-43962-00 243-43962-00 243-43962-00 243-43962-00

265-47439-04-30 265-47439-07-32 265-47439-10-32 265-47439-07-30 265-47439-10-32

228-42506-00 228-42506-00 228-42506-00 228-42506-00 228-42506-00

234-41034-30 234-41034-32 234-41034-32 234-41034-30 234-41034-32

234-41034-31 234-41034-36 234-41034-36 234-41034-31 234-41034-36

234-41034-32 234-41034-38 234-41034-38 234-41034-32 234-41034-38

234-41034-33 234-41034-38 234-41034-38 234-41034-33 234-41034-38

233-46277-04 233-46277-04 233-46277-04 233-46277-04 233-46277-04

234-46502-05 234-46502-05 234-46502-05 234-46502-05 234-46502-05

233-46501-15 233-46501-15 233-46501-24 233-46501-15 233-46501-24

(Replacement for LP Gas (CX) Cast Iron Burner)

265-47440-06-47 265-47440-11-51 265-47440-17-50 265-47440-12-47 265-47440-17-50

228-47000-00 228-46964-00 228-46964-00 228-47000-00 228-46964-00

234-47064-47 234-47064-51 234-47064-50 234-47064-47 234-47064-50

234-47064-49 234-47064-53 234-47064-51 234-47064-49 234-47064-51

234-47064-50 234-47064-53 234-47064-52 234-47064-50 234-47064-52

234-47064-51 234-47064-54 234-47064-53 234-47064-51 234-47064-53

233-46278-03 233-46278-03 233-46278-03 233-46278-03 233-46278-03

234-46502-02 234-46502-02 234-46502-02 234-46502-02 234-46502-02

233-46501-15 233-46501-15 233-46501-24 233-46501-15 233-46501-24

239-43740-01 239-43740-01 239-43740-01 239-43740-01 239-43740-01

--- --- --- --- ---

239-44078-00 239-44078-00 239-44078-00 239-44078-00 239-44078-00

239-44328-00 239-44328-00 239-44328-00 239-44328-00 239-44328-00

239-45167-00 239-45167-00 239-45167-00 239-45167-00 239-45167-00

239-45073-00 239-45073-00 239-45073-00 239-45073-00 239-45073-00

265-45420-00 265-45420-00 265-45420-00 265-45420-00 265-45420-00

265-45712-06 265-45712-05 265-45712-07 265-45712-08 265-45712-27

265-45712-18 265-45712-17 265-45712-19 265-45712-20 265-45712-28

*Applies to all warranties

**Inner door gasket kit recommended

***Ordering a complete burner assembly may increase delivery time. Please order the specific component required for the quickest delivery.

ŸOrder with item 32

ŸŸOrder with item 33

Page 5

Page 6

Item Description

1 Draft Hood

2 Hot Water Outlet Anode MagnesiumŸ

Hot Water Outlet AluminumŸ

Hot Water Outlet A420 AluminumŸ

3 Cold Water Inlet Dip Tube PolypropyleneŸŸ

Cold Water Inlet Polysulfone (NC Code)ŸŸ

4 Flue Baffle

5 T&P Relief Valve

6 Gas Valve Natural Gas

Gas Valve LP Gas

7 Piezo Igniter

7A Piezo Bracket (White Rodgers)

Piezo Bracket (Robertshaw)

8 Brass Drain Valve

9 Screw-#8-18 x 3/4 HWH

10 Screw-#10-12 x 3/4 HWH

11 Left Side Inner Door Complete

12 Nat. Gas Right Side Inner Door Complete

LP Gas Right Side Inner Door Complete

13 Nat. Gas Resettable Thermal Switch

LP Gas Resettable Thermal Switch

14 Screw-#6-20 x 3/8 PHCR

15 Outer Door

Natural Gas (BN) Burner Assembly

16 Nat Gas Burner Assembly Complete***

17 Nat. Gas (BN) Burner**

18 Nat. Gas (BN) Main Burner Orifice**

Nat. Gas (BN) High Altitude 2001 Ft. to 5000 Ft.**

Nat. Gas (BN) High Altitude 5001 Ft. to 8000 Ft.**

Nat. Gas (BN) High Altitude Over 8000 Ft.**

19 Nat. Gas Pilot Assembly**

20 Nat. Gas Pilot Orifice**

21 Thermocouple**

LP Gas (SX) Titanium Stabilized Stainless Steel Burner Assembly

22 LP Gas Burner Assembly Complete***

23 LP Gas (SX) Burner**

24 LP Gas (SX) Main Burner Orifice**

LP Gas (SX) High Altitude 2001 Ft. to 5000 Ft.**

LP Gas (SX) High Altitude 5001 Ft. to 8000 Ft.**

LP Gas (SX) High Altitude Over 8000 Ft.**

25 LP Gas Pilot Assembly**

26 LP Gas Pilot Orifice**

27 Thermocouple**

28 ASSE Approved Mixing Valve (Optional)

29 3/4 NPT Plug

30 Inner Door Gasket Kit

31 Wire Tie

32 Heat Trap Insert (Outlet)

33 Heat Trap Insert (Inlet)

34 Kit-Heat Trap Insert

- LP to Natural Gas Conversion Kit (Norm Alt.)

- LP to Natural Gas Conversion Kit (High Alt.)

Model Model Model Model Model

M1XR403S*F(BN,CX,SX) M2XR504T*F(BN,CX,SX) M430T*F(BN,CX,SX) M4403S*F(BN,CX,SX) M440T*F(BN,CX,SX)

243-45787-00 243-33081-02-20 243-45787-00 243-45787-00 243-45787-00

224-32731-81 224-32731-86 224-32731-95 224-32731-81 224-32731-95

224-32999-31 224-32999-30 224-32999-24 224-32999-31 224-32999-24

224-45147-04 224-45147-01 224-45147-02 224-45147-04 224-45147-02

229-39625-03 229-39625-18 229-39625-23 229-39625-03 229-39625-25

229-39628-03 229-39628-18 229-39628-26 229-39628-03 229-39628-28

243-45223-00 243-41037-00 243-44639-00 243-45223-00 243-42283-00

265-32920-01 230-40594-02 230-40594-02 230-40594-02 230-40594-02

265-46181-01 265-46181-04 265-46181-02 265-46181-02 265-46181-02

265-46182-01 265-46182-02 265-46182-02 265-46182-02 265-46182-02

239-43448-00 239-43448-00 239-43448-00 239-43448-00 239-43448-00

239-46157-02 239-46157-02 239-46157-02 239-46157-02 239-46157-02

239-43449-00 239-43449-00 239-43449-00 239-43449-00 239-43449-00

265-42351-02 265-42351-02 265-42351-02 265-42351-02 265-42351-02

239-44195-00 239-44195-00 239-44195-00 239-44195-00 239-44195-00

239-44113-00 239-44113-00 239-44113-00 239-44113-00 239-44113-00

239-43968-18 239-43968-18 239-43968-14 239-43968-18 239-43968-16

239-43963-07 239-43963-07 239-43963-02 239-43963-07 239-43963-05

239-43963-07 239-43963-07 239-43963-02 239-43963-07 239-43963-04

239-43676-02 239-43676-02 239-43676-03 239-43676-02 239-43676-03

239-43676-02 239-43676-02 239-43676-03 239-43676-02 239-43676-02

239-43967-00 239-43967-00 239-43967-00 239-43967-00 239-43967-00

243-43962-00 243-43962-00 243-43962-00 243-43962-00 243-43962-00

265-47439-07-32 265-47439-07-27 265-47439-02-36 265-47439-07-32 265-47439-04-32

228-42506-00 228-42506-00 228-42506-00 228-42506-00 228-42506-00

234-41034-32 234-41034-27 234-41034-36 234-41034-32 234-41034-32

234-41034-36 234-41034-29 234-41034-39 234-41034-36 234-41034-36

234-41034-38 234-41034-30 234-41034-41 234-41034-38 234-41034-36

234-41034-38 234-41034-31 234-41034-43 234-41034-38 234-41034-38

233-46277-04 233-46277-04 233-46277-04 233-46277-04 233-46277-04

234-46502-05 234-46502-05 234-46502-05 234-46502-05 234-46502-05

233-46501-15 233-46501-24 233-46501-15 233-46501-24 233-46501-15

(Replacement for LP Gas (CX) Cast Iron Burner)

265-47440-11-50 265-47440-12-43 265-47440-02-60 265-47440-11-50 265-47440-05-52

228-46964-00 228-47000-00 228-46964-00 228-46964-00 228-46964-00

234-47064-50 234-47064-43 234-47064-60 234-47064-50 234-47064-52

234-47064-51 234-47064-46 234-47064-54 234-47064-51 234-47064-53

234-47064-52 234-47064-47 234-47064-54 234-47064-52 234-47064-54

234-47064-53 234-47064-47 234-47064-54 234-47064-53 234-47064-54

233-46278-03 233-46278-03 233-46278-03 233-46278-03 233-46278-03

234-46502-02 234-46502-02 234-46502-02 234-46502-02 234-46502-02

233-46501-15 233-46501-24 233-46501-15 233-46501-24 233-46501-15

239-43740-01 239-43740-01 239-43740-01 239-43740-01 239-43740-01

239-11638-00 239-11638-00 - - - - - - - - -

239-44078-00 239-44078-00 239-44078-00 239-44078-00 239-44078-00

239-44328-00 239-44328-00 239-44328-00 239-44328-00 239-44328-00

239-45167-00 239-45167-00 239-45167-00 239-45167-00 239-45167-00

239-45073-00 239-45073-00 239-45073-00 239-45073-00 239-45073-00

265-45420-00 265-45420-00 265-45420-00 265-45420-00 265-45420-00

265-45712-05 265-45712-12 265-45712-09 265-45712-11 265-45712-10

265-45712-17 265-45712-24 265-45712-21 265-45712-23 265-45712-22

*Applies to all warranties

**Inner door gasket kit recommended

***Ordering a complete burner assembly may increase delivery time. Please order the specific component required for the quickest delivery.

ŸOrder with item 32

ŸŸOrder with item 33

Page 7

Page 8

Item Description

1 Draft Hood

2 Hot Water Outlet Anode MagnesiumŸ

Hot Water Outlet AluminumŸ

Hot Water Outlet A420 AluminumŸ

3 Cold Water Inlet Dip Tube PolypropyleneŸŸ

Cold Water Inlet Polysulfone (NC Code)ŸŸ

4 Flue Baffle

5 T&P Relief Valve

6 Gas Valve Natural Gas

Gas Valve LP Gas

7 Piezo Igniter

7A Piezo Bracket (White Rodgers)

Piezo Bracket (Robertshaw)

8 Brass Drain Valve

9 Screw-#8-18 x 3/4 HWH

10 Screw-#10-12 x 3/4 HWH

11 Left Side Inner Door Complete

12 Nat. Gas Right Side Inner Door Complete

LP Gas Right Side Inner Door Complete

13 Nat. Gas Resettable Thermal Switch

LP Gas Resettable Thermal Switch

14 Screw-#6-20 x 3/8 PHCR

15 Outer Door

Natural Gas (BN) Burner Assembly

16 Nat Gas Burner Assembly Complete***

17 Nat. Gas (BN) Burner**

18 Nat. Gas (BN) Main Burner Orifice**

Nat. Gas (BN) High Altitude 2001 Ft. to 5000 Ft.**

Nat. Gas (BN) High Altitude 5001 Ft. to 8000 Ft.**

Nat. Gas (BN) High Altitude Over 8000 Ft.**

19 Nat. Gas Pilot Assembly**

20 Nat. Gas Pilot Orifice**

21 Thermocouple**

LP Gas (SX) Titanium Stabilized Stainless Steel Burner Assembly

22 LP Gas Burner Assembly Complete***

23 LP Gas (SX) Burner**

24 LP Gas (SX) Main Burner Orifice**

LP Gas (SX) High Altitude 2001 Ft. to 5000 Ft.**

LP Gas (SX) High Altitude 5001 Ft. to 8000 Ft.**

LP Gas (SX) High Altitude Over 8000 Ft.**

25 LP Gas Pilot Assembly**

26 LP Gas Pilot Orifice**

27 Thermocouple**

28 ASSE Approved Mixing Valve (Optional)

29 3/4 NPT Plug

30 Inner Door Gasket Kit

31 Wire Tie

32 Heat Trap Insert (Outlet)

33 Heat Trap Insert (Inlet)

34 Kit-Heat Trap Insert

- LP to Natural Gas Conversion Kit (Norm Alt.)

- LP to Natural Gas Conversion Kit (High Alt.)

Model Model Model Model Model

M4503*F(BN,CX,SX) M460T*F(BN,CX,SX) M2XR65T*F(BN,CX,SX) 50T65F(B,C,S)*(N,X) 65T65F(B,C,S)*(N,X)

243-45787-00 243-45787-00 243-33081-02-20 243-33081-02-20 243-33081-02-20

224-32731-107 224-32731-86 224-32731-83 224-32731-101 224-32731-83

224-32999-21 224-32999-30 224-32999-06 224-32999-21 224-32999-06

224-45147-02 224-45147-02 224-45147-01 224-45147-01 224-45147-01

229-39625-22 229-39625-14 229-45398-07 229-39625-19 229-39625-04

229-39628-21 229-39628-14 229-45092-04 229-39628-19 229-39628-04

243-44705-00 243-42283-00 243-46752-00 243-41037-00 243-46752-00

230-40594-02 230-40594-02 230-40594-02 230-40594-02 230-40594-02

265-46181-02 265-46181-02 265-46181-04 265-46367-02 265-46367-02

265-46182-02 265-46182-02 265-46182-02 265-46368-03 265-46368-03

239-43448-00 239-43448-00 239-43448-00 239-43448-00 239-43448-00

239-46157-02 239-46157-02 239-46157-02 239-46157-02 239-46157-02

239-43449-00 239-43449-00 239-43449-00 239-43449-00 239-43449-00

265-42351-02 265-42351-02 265-42351-02 265-42351-02 265-42351-02

239-44195-00 239-44195-00 239-44195-00 239-44195-00 239-44195-00

239-44113-00 239-44113-00 239-44113-00 239-44113-00 239-44113-00

239-43968-18 239-43968-20 239-43968-20 239-43968-18 239-43968-20

239-43963-07 239-43963-12 239-43963-09 239-43963-07 239-43963-09

239-43963-07 239-43963-13 239-43963-12 239-43963-07 239-43963-12

239-43676-02 239-43676-02 239-43676-01 239-43676-02 239-43676-01

239-43676-02 239-43676-03 239-43676-02 239-43676-02 239-43676-02

239-43967-00 239-43967-00 239-43967-00 239-43967-00 239-43967-00

243-43962-00 243-43962-00 243-43962-00 243-43962-00 243-43962-00

265-47439-07-32 265-47439-10-32 265-47439-10-27 265-47439-07-27 265-47439-10-27

228-42506-00 228-42506-00 228-42506-00 228-42506-00 228-42506-00

234-41034-32 234-41034-32 234-41034-27 234-41034-27 234-41034-27

234-41034-36 234-41034-36 234-41034-29 234-41034-29 234-41034-29

234-41034-38 234-41034-38 234-41034-30 234-41034-30 234-41034-30

234-41034-38 234-41034-38 234-41034-31 234-41034-31 234-41034-31

233-46277-04 233-46277-04 233-46277-04 233-46277-04 233-46277-04

234-46502-05 234-46502-05 234-46502-05 234-46502-05 234-46502-05

233-46501-24 233-46501-24 233-46501-24 233-46501-24 233-46501-24

(Replacement for LP Gas (CX) Cast Iron Burner)

265-47440-11-51 265-47440-17-50 265-47440-18-43 265-47440-12-43 265-47440-18-43

228-46964-00 228-46964-00 228-47000-00 228-47000-00 228-47000-00

234-47064-51 234-47064-50 234-47064-43 234-47064-43 234-47064-43

234-47064-53 234-47064-51 234-47064-46 234-47064-46 234-47064-46

234-47064-53 234-47064-52 234-47064-47 234-47064-47 234-47064-47

234-47064-54 234-47064-54 234-47064-47 234-47064-47 234-47064-47

233-46278-03 233-46278-03 233-46278-03 233-46278-03 233-46278-03

234-46502-02 234-46502-02 234-46502-02 234-46502-02 234-46502-02

233-46501-24 233-46501-24 233-46501-24 233-46501-24 233-46501-24

239-43740-01 239-43740-01 239-43740-01 239-43740-01 239-43740-01

- - - - - - 239-11638-00 239-11638-00 239-11638-00

239-44078-00 239-44078-00 239-44078-00 239-44078-00 239-44078-00

239-44328-00 239-44328-00 239-44328-00 239-44328-00 239-44328-00

239-45167-00 239-45167-00 239-45167-00 239-45167-00 239-45167-00

239-45073-00 239-45073-00 239-45073-00 239-45073-00 239-45073-00

265-45420-00 265-45420-00 265-45420-00 265-45420-00 265-45420-00

265-45712-11 265-45712-29 265-45712-47 265-45712-25 265-45712-48

265-45712-23 265-45712-30 265-45712-49 265-45712-26 265-45712-50

*Applies to all warranties

**Inner door gasket kit recommended

***Ordering a complete burner assembly may increase delivery time. Please order the specific component required for the quickest delivery.

ŸOrder with item 32

ŸŸOrder with item 33

Page 9

Este manual sirve para los siguientes modelos

Otros manuales de Calentador de agua de Bradford White

Bradford White

Bradford White UDH Series Manual de usuario

Bradford White

Bradford White TTW URG2PV75H6N Manual de usuario

Bradford White

Bradford White Kwickshot EFT-5500-4-S-10 Manual de usuario

Bradford White

Bradford White TW Series Manual de usuario

Bradford White

Bradford White GX1-55S Instrucciones de instalación

Bradford White

Bradford White Includes Hydrojet DS Manual de usuario

Bradford White

Bradford White RE2H50R10B-1NCWT Instrucciones originales

Bradford White

Bradford White Combi2 "CDW2" Series Guía de aplicación

Bradford White

Bradford White EFC-5500-4-S-10 Manual de usuario

Bradford White

Bradford White M-2-120R6DS-5500W Manual de usuario

Bradford White

Bradford White 238-46392-00G Instrucciones de instalación

Bradford White

Bradford White URG2DV40S*N Manual de usuario

Bradford White

Bradford White EFT-5500-4-S-10 Manual de usuario

Bradford White

Bradford White Defender RG130T Series Manual de usuario

Bradford White

Bradford White Everhot IGI-180 Manual de usuario

Bradford White

Bradford White THROUGH-THE-WALL GAS WATER HEATER Manual de usuario

Bradford White

Bradford White D-38T-155 Manual de usuario

Bradford White

Bradford White 6A Manual de usuario

Bradford White

Bradford White RTG 199 HEN Manual de usuario

Bradford White

Bradford White PV Series Manual de usuario

Bradford White

Bradford White URG140T10N-394 Manual de usuario

Bradford White

Bradford White Powered Direct Vent Series Manual de usuario

Bradford White

Bradford White ULG2100H805N Manual de usuario

Bradford White

Bradford White RG275H6X-506 Manual de usuario

Manuales populares de Calentador de agua de otras marcas

Kenmore

Kenmore 153.582400 Manual de usuario

Applimo

Applimo Edel AIR Manual de usuario

STIEBEL ELTRON

STIEBEL ELTRON Eltronom SHU 5 S Manual de usuario

clage

clage E-Mini Series Manual de usuario

Toyotomi

Toyotomi Oil Miser OM-180 Manual de usuario

Eccotemp

Eccotemp 40-H Manual de usuario

Dimplex

Dimplex ECSd125-580 Guía

Dux

Dux 32FCR6N Manual de usuario

Toyotomi

Toyotomi Oil Miser OM-148 (Type D) Guía de solución de problemas

Noritz

Noritz N-132M Manual de instrucciones

TESY

TESY GCV7/4S 10047 Hoja de especificaciones

A.O. Smith

A.O. Smith Gphe 50 Manual de usuario

Koryo

Koryo KWHZF15Y Manual de usuario

Pentair

Pentair PSC-14-4-02 Manual de usuario

GE 40M06AAG Instrucciones de montaje

Thermor

Thermor AEROMAX SPLIT 2 Manual de usuario

American Hometec

American Hometec AHQ-B03X Manual de usuario

PVI

PVI MAXIM Manual de usuario
