Make it your own with

optional interchangeable grilles,

a Boston exclusive.

Boston Horizon HS Floorstanding Speakers

play strong. play smart.

Muscular audio doesn’t have to be bulky. Tall, slim and elegant, the HS series

oorstanding loudspeakers make a positive impression even before they start to

perform. But with soft-dome tweeters for crystalline high-frequency sound, and

dual woofers coupled with dual passive radiators for improved bass response,

rest assured, they sound as good as they look.

Boston Horizon HS Floorstanding Speakers

(Left) HS 450 in mist

with Silver grille

(Right) HS 460 in Midnight

with Onyx grille

HS 460

newlitideas_fin8 1newlitideas_fin8 1 12/11/07 1:00:52 AM12/11/07 1:00:52 AM

Boston Horizon Floorstanding speakers

300 Jubilee Drive, Peabody, MA 01960 bostonacoustics.com

© 2007. All rights reserved. Boston, Boston Acoustics, Deep Channel, and Kortec are registered trademarks, and the B/A ellipse symbol and Play Smart are trademarks of Boston Acoustics, Inc.

Specications HS 460 HS 450

Frequency Response 44Hz – 25kHz (±3dB) 46Hz – 25kHz (±3dB)

Recommended Amplier 15 – 200 watts 15 – 200 watts

Sensitivity 89dB [2.8v at 1m] 89dB [2.8v at 1m]

Nominal Impedance 8 ohms 8 ohms

Crossover Frequency 2,800Hz 2,600Hz

Woofer Dual 6½”(165mm) copolymer Dual 5¼” (133mm) plus

DCD with Phase Plugs DCD with Phase Plugs

MBOS Dual 7” (178mm) Dual 6½” (165mm)

(Maximum Bass Output System) passive radiators plus passive radiators plus

MBOS Rear Port MBOS Rear Port

Tweeter 1” (25mm) Kortec®1” (25mm) Kortec

Soft Dome Soft Dome

Dimensions (H x W x D) 43⁄ x 11⁄ x 9⁄” 39⁄ x 10⁄ x 8⁄”

(1096 x 302 x 242 mm) (999 x 275 x 221 mm)

Weight 28.2 lbs (12.9kg) 23.2 lbs (10.6kg)

Finish Soft touch nish in Midnight with Onyx grille or Mist with Silver grille

What it means to be from Boston.

Many manufacturers design speaker systems around third-party, o-the-shelf parts.

Boston Acoustics engineers every component of every system to meet the highest performance

standards (our own). Of course, performance is only one measure of value. So we’re careful to

build all our products with strict attention to everything from the choice of materials to the

details of t and nish. It’s how we’ve been exceeding the expectations of serious listeners for

nearly thirty years.

May we have your full attention?

HS Series oorstanding speakers pack a lot of technology into their trim ABS exteriors.

MBOS (Maximum Bass Output System) uses passive radiators and a rear port to improve bass

performance — without the audible noise of a port alone. Proprietary Deep Channel® Design

(DCD) poly cones with phase plugs deliver smooth, consistent response at any output level.

Front baes are gently curved. And the cabinets themselves are heavily braced to reduce

unwanted resonances. The combined result is the natural, captivating sound you expect from

Boston, with clean, contemporary style.

MBOS (Maximum Bass Output System)

includes rear port and passive radiators

Integral carrying handle

5-way gold-plated binding posts

HS 460 HS 450

newlitideas_fin8 2newlitideas_fin8 2 12/11/07 1:00:54 AM12/11/07 1:00:54 AM
