Boss Audio Systems BV9976B Manual de usuario

To ensure safety while driving

and to comply with laws,

drivers should not watch video or

operate the video device while driving.

Unit Installation

Wires Connection Description

178*50*160

85W*4

BV9976B

Cable

Screw

PM4*5mm 4pcs

Flat gasket

M5Φ10X1.0mm

2pcs

Hex nut

8.0 mmΦ5.0X1.0mm

1pc

Mounting Strap/Release Key

/Mounting Sleeve

OPEN key

Press to make the screen stretching

out or go back.

SD/USB

Short press to mute the unit.

Long press to make panel go

dark, and press any empty place,

will run the unit.

DISC/SD/USB

page

UNIT INSTALLATION

TO BOOST UP THE CAPABILITY OF

ANTI-JAMMING, PLEASE FIX THE

METAL STRAP ON THE METAL

CONNECTED TO THE BOTTOM

BRACKET OF THE CAR.

METAL STRAP

DASH BOARD

SLIDING METAL HOUSING

TO DRAW THE CHASSIS OUT OF

THE SLIDING METAL HOUSING,

INSERT THE LEFT AND RIGHT KEY

PLATES INTO THE RIGHT POSITION

OF THE 2 SIDES OF CHASSIS.

PLASTIC TRIM OUT

UNIT CHASSIS

SELECT THE PROPER TAB

FOR FIXING THE SLIDING

METAL HOUSING.

THE UNIT IS INSTALLED TO BE AN ANTI-THEFT ONE. THE CHASSIS

OF THE UNIT WEARS A SLIDING METAL HOUSING. PLEASE DO THE

CONNECTION OF THE POWER, SPEAKERS AND ANTENNA ACCORDING

TO THE REQUIREMENT OF THE INSTRUCTION BOOK , THEN INSTALL

THE SLIDING METAL HOUSING IN THE CAR AS FOLLOWS.

WIRES CONNECTION DESCRIPTION

The Description of the Input/Output Interface of the Rear Cabinet

SOCKET B

15A

YELLOW

MEMORY B+

BLUE

BLACK

RED ACC

GND

P.ANT

WHITE

WHITE/BLACK

FRONT

LEFT SPK

GREEN

GREEN/BLACK

REAR

LIGHT GREEN

BRAKE

REVERSE

GRAY

GRAY/BLACK

FRONT

RIGHT SPK

REAR

VLOLET

VLOLET/BLACK

PURPLE/WHITE

SOCKET A

YELLOW

RED

REAR

FROUT

SUB OUT1

SUB OUT2

LINE OUT

WHITE

RED

WHITE

BROWN

AV IN

CAMERA

VIDEO OUT 1 VIDEO

VIDEO OUT 2

YELLOW

SOCKET BSOCKET A

ANTENNA JACK FIXING SCREW BOLT

STEERING WHEEL KEY A GRAY

STEERING WHEEL KEY B BLUE

STEERING WHEEL KEY GND BLACK

USB JACK
