Bosch A10VO Manual de usuario

Instruction manual

RE 92703-01-B/04.2018

Replaces: 01.2012

English

Axial piston variable pump

A10VO, A10VSO, A10VNO,

A10VSNO

Series 52 and 53

also regarding any disposal, exploitation,

reproduction, editing, distribution, as well

as in the event of applications for industrial

property rights.

The data speciﬁed within only serves

to describe the product. No statements

concerning a certain condition or suitability

for a certain application can be derived from

our information. The information given does

not release the user from the obligation of

own judgment and veriﬁcation. It must be

remembered that our products are subject

to a natural process of wear and aging.

The cover shows an example application.

The product delivered may diﬀer from the

image on the cover.

The original instruction manual was created in

the German language.

Contents 3/60

RE 92703-01-B/04.2018, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, Bosch Rexroth AG

1 About this documentation 5

1.1 Validity of the documentation 5

1.2 Required and supplementary documentation 5

1.3 Representation of information 6

1.3.1 Safety instructions 6

1.3.2 Symbols 7

1.3.3 Designations 7

1.3.4 Abbreviations 7

2 Safety instructions 8

2.1 About this chapter 8

2.2 Intended use 8

2.3 Improper use 8

2.4 Personnel qualiﬁcations 9

2.5 General safety instructions 10

2.6 Product-speciﬁc safety instructions 11

2.7 Personal protective equipment 13

3 General notices regarding property and product damage 14

4 Scope of delivery 17

5 About this product 18

5.1 Performance description 18

5.2 Product description 18

5.2.1 Axial piston unit layout 18

5.2.2 Functional description 19

5.3 Product identiﬁcation 20

6 Transport and storage 21

6.1 Transporting the axial piston unit 21

6.1.1 Transporting by hand 21

6.1.2 Transporting with a lifting device 21

6.2 Storing the axial piston unit 23

7 Installation 25

7.1 Unpacking 25

7.2 Installation conditions 25

7.3 Installation position 26

7.3.1 Below-reservoir installation (standard) 26

7.3.2 Inside-reservoir installation 27

7.3.3 Above-reservoir installation 29

7.4 Installing the axial piston unit 30

7.4.1 Preparation 30

7.4.2 Dimensions 30

7.4.3 General instructions 30

7.4.4 Installation with a coupling 31

7.4.5 Installation on a gearbox 32

7.4.6 Installation with cardan shaft 32

7.4.7 Remove the spacer (for version with through drive) 33

Contents

4/60

Bosch Rexroth AG, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, RE 92703-01-B/04.2018

7.4.8 Completing installation 34

7.4.9 Hydraulically connecting the axial piston unit 35

7.4.10 Electrically connecting the axial piston unit 41

7.5 Performing ﬂushing cycle 42

8 Commissioning 43

8.1 Initial commissioning 43

8.1.1 Filling the axial piston unit 43

8.1.2 Testing the hydraulic ﬂuid supply 44

8.1.3 Performing a functional test 45

8.2 Running-in phase 45

8.3 Recommissioning after standstill 46

9 Operation 47

10 Maintenance and repair 47

10.1 Cleaning and care 47

10.2 Inspection 48

10.3 Maintenance 48

10.4 Repair 49

10.5 Spare parts 49

11 Removal and replacement 50

11.1 Required tools 50

11.2 Preparing for removal 50

11.3 Removal 50

11.4 Preparing components for storage or further use 50

12 Disposal 51

13 Extension and conversion 51

14 Troubleshooting 52

14.1 How to proceed for troubleshooting 52

14.2 Malfunction table 53

15 Technical data 57

16 Alphabetical index 58

Contents

About this documentation 5/60

RE 92703-01-B/04.2018, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, Bosch Rexroth AG

1 About this documentation

1.1 Validity of the documentation

This documentation applies to the following products:

•Axial piston variable pump A10VO (Series 52 and 53)

•Axial piston variable pump A10VSO (Series 52)

•Axial piston variable pump A10VNO (Series 52 and 53)

•Axial piston variable pump A10VSNO (Series 52)

This documentation is intended for machine/system manufacturers, assemblers and

service engineers.

It contains important information on the safe and appropriate transport, installation,

commissioning, operation, maintenance, removal and simple troubleshooting of the

axial piston unit.

▶ Read this documentation completely, in particular chapter2 “Safety instructions”

on page8 and chapter3 “General notices regarding property and product

damage” on page14 before you start work with the axial piston unit.

1.2 Required and supplementary documentation

▶ Only commission the axial piston unit if the documentation marked with the book

symbol is available to you and you have understood and observed it.

Table 1: Required and supplementary documentation

Title Document number Document type

Order conﬁrmation

Contains the order-based technical data of your axial piston variable pump

A10VO, A10VSO, A10VNO and A10VSNO.

– Order conﬁrmation

Installation drawing

Contains the outer dimensions, all connections and the hydraulic circuit diagram

for your axial piston variable pump A10VO, A10VSO, A10VNO and A10VSNO.

Please request the

installation drawing

from your contact at

Bosch Rexroth.

Installation drawing

Axial piston variable pump A10VO (Series 52 and 53), sizes 18 to 100

Contains the permissible technical data.

92703 Data sheet

Axial piston variable pump A10VSO (Series 52), size 10

Contains the permissible technical data.

92703 Data sheet

Axial piston variable pump A10VNO (Series 52 and 53), sizes 28 to 85

Contains the permissible technical data.

92735 Data sheet

Axial piston variable pump A10VSNO (Series 52), size 15

Contains the permissible technical data.

92741 Data sheet

Hydraulic ﬂuids based on mineral oils and related hydrocarbons

Describes the requirements on a hydraulic ﬂuid based on mineral oil and related

hydrocarbons for operation with Rexroth hydraulic components, and assists you in

selecting a hydraulic ﬂuid for your system.

90220 Data sheet

Environmentally acceptable hydraulic ﬂuids

Describes the requirements on an environmentally acceptable hydraulic ﬂuid

for operation with Rexroth hydraulic components and assists you in selecting a

hydraulic ﬂuid for your hydraulic system.

90221 Data sheet

Information on the use of hydrostatic drives at low temperatures

Contains additional information on the use of Rexroth axial piston units at low

temperatures.

90300-03-B Manual

6/60 About this documentation

Bosch Rexroth AG, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, RE 92703-01-B/04.2018

Table 1: Required and supplementary documentation

Title Document number Document type

Storage and preservation of axial piston units

Contains additional information on storage and preservation.

90312 Data sheet

Axial piston variable pump A10V(S)O, A10VO series 3x and 5x with electro-

proportional diﬀerential pressure control EF

92709 Data sheet

1.3 Representation of information

Standardized safety instructions, symbols, terms and abbreviations are used

throughout this documentation so that you can work quickly and safely with your

product. For clariﬁcation, they are explained in the sections below.

1.3.1 Safety instructions

This documentation contains safety instructions in chapter2.6 “Product-speciﬁc

safety instructions” on page11 and in chapter3 “General notices regarding

property and product damage” on page14, as well as before a sequence of

actions or an instruction for action involving a risk of personal injury or property

damage. Always follow the instructions on avoiding the dangers associated with the

use of this product.

Safety instructions are set out as follows:

SIGNAL WORD

Type and source of danger!

Consequences of noncompliance

▶ Measures to prevent danger

•Warning sign: draws attention to the danger

•Signal word: identiﬁes the degree of the danger

•Type and source of danger: indicates the type and source of the danger

•Consequences: describes what occurs if safety instructions are disregarded

•Precautions: states how the danger can be avoided

Table 2: Danger classes as deﬁned in ANSI Z535.6

Warning sign, signal word Meaning

DANGER Identiﬁes a dangerous situation that will result in death

or serious injury if it is not avoided.

WARNING Identiﬁes a dangerous situation that may result in death

or serious injury if it is not avoided.

CAUTION Identiﬁes a dangerous situation that may result in minor

to moderate injury if it is not avoided.

NOTICE Property damage: The product or surrounding area may

be damaged.

About this documentation 7/60

RE 92703-01-B/04.2018, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, Bosch Rexroth AG

1.3.2 Symbols

The following symbols indicate information that is not safety-relevant but increases

understanding of the documentation.

Table 3: Meaning of symbols

Symbol Meaning

If this information is disregarded, the product cannot be used and/or

operated to its full extent.

▶ Single, independent action

Numbered instruction:

The numbers indicate that the actions must be completed in order.

1.3.3 Designations

This documentation uses the following designations:

Table 4: Designations

Designation Meaning

A10VO Axial piston variable pump, open circuit, maximum pressure 315 bar, for

mobile applications

A10VSO Axial piston variable pump, open circuit, maximum pressure 315 bar, for

stationary applications

A10VNO Axial piston variable pump, open circuit, maximum pressure 250 bar, for

mobile applications

A10VSNO Axial piston variable pump, open circuit, maximum pressure 250 bar, for

stationary applications

Threaded plug Metal screw, pressure-resistant

Protective plug Made out of plastic, not pressure-resistant, only for transportation

As an umbrella term for “axial piston variable pump A10VO”, “A10VSO”, “A10VNO”

and/or “A10VSNO” the designation “axial piston unit” is used in the following.

1.3.4 Abbreviations

This documentation uses the following abbreviations:

Table 5: Abbreviations

Abbreviation Meaning

ATEX EC directive on explosion protection (Atmosphère explosible)

DIN Deutsches Institut für Normung (German Institute for Standardization)

EF Electro-proportional diﬀerential pressure control

ISO International Organization for Standardization

JIS Japan Industrial Standard

RE Rexroth document in the English language

VDI2230 Standard for the systematic calculation of heavy-duty threaded connections

and cylindrical screw joints from the VDI (VereinDeutscherIngenieure -

Association of German Engineers)

8/60 Safety instructions

Bosch Rexroth AG, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, RE 92703-01-B/04.2018

2 Safety instructions

2.1 About this chapter

The axial piston unit has been manufactured to generally accepted engineering

standards. There is still, however, a risk of personal injury or property damage if this

chapter and the safety instructions in this documentation are not observed.

▶ Read this documentation completely and thoroughly before working with the axial

piston unit.

▶ Keep it in a location where it is accessible to all users at all times.

▶ Always include the required documentation when you pass the axial piston unit

on to third parties.

2.2 Intended use

Axial piston units are hydraulic components, meaning that in their application

area they are classiﬁed neither as complete nor as partly completed machinery as

deﬁned in the EC Machinery Directive 2006/42/EC. The component is exclusively

intended to form partly completed machinery or complete machinery together with

other components. The component should only be commissioned after it has been

installed in the machine/system for which it is intended and the safety of the entire

system has been established in accordance with the Machinery Directive.

This product is intended for the following use:

The axial piston unit is only approved as a pump for hydrostatic drives in an open

circuit.

▶ Observe the technical data, application and operating conditions and

performance limits as speciﬁed in data sheet92703, 92735, 92741 and in the

order conﬁrmation. Information about approved hydraulic ﬂuids can be found in

data sheet92703, 92735 and 92741.

The axial piston unit is only intended for commercial use and not for private use.

Intended use includes having fully read and understood this documentation,

especially chapter2 “Safety instructions” on page8.

2.3 Improper use

Any use other than that described as intended use is considered improper.

Bosch Rexroth AG is not liable for damages resulting from improper use. The user is

solely responsible for any risks arising from improper use.

The following foreseeable misuses are also considered improper (this list is not

exhaustive):

•Use outside the operating parameters approved in the data sheet or in the order

conﬁrmation (unless speciﬁcally approved by the customer)

•Use of non-approved ﬂuids, e.g. water or polyurethane components

•Changes to factory settings by unauthorized persons

•Use of assembled parts (e.g. attachment ﬁlter, control unit, valves) other than

speciﬁed Rexroth components

•Use of the axial piston unit with assembled parts under water at a depth of

more than 10meters without the necessary additional measures, e.g. pressure

equalization. Units with electrical components (e.g. sensors) generally cannot

Safety instructions 9/60

RE 92703-01-B/04.2018, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, Bosch Rexroth AG

come into contact with water. Axial piston units may only be used on a case-to-case

basis for this application.

•The maximum permissible case pressure speciﬁed in the data sheet must not be

exceeded.

•Use of the axial piston unit in explosive environments unless the component

or machine/system has been certiﬁed as compliant with the ATEX Directive

2014/34/EU

•Use of the axial piston unit in a corrosive atmosphere

•Use of the axial piston unit in aircraft or spacecraft

2.4 Personnel qualiﬁcations

The activities described in this manual require a basic understanding of mechanics,

electricity and hydraulics, as well as familiarity with associated technical terms.

For transporting and handling the product, additional familiarity with the use of

lifting devices and lifting accessories is required. In order to ensure safe use, these

activities should only be performed by skilled personnel or an instructed person

under the direction and supervision of skilled personnel.

Skilled personnel refers to persons who possess the professional training,

knowledge and experience, as well as the understanding of the regulations relevant

to the work to be done that are necessary to recognize possible hazards and take

the appropriate safety measures. Skilled personnel must follow the rules relevant to

their ﬁeld and have the necessary hydraulics expert knowledge.

Hydraulic expert knowledge includes:

•being able to read and fully understand hydraulic circuit diagrams,

•in particular, fully understanding the relationships with regard to safety devices,

•understanding how hydraulic components work and are put together.

Bosch Rexroth oﬀers training support for specialized ﬁelds. An overview of the

training contents can be found online at: www.boschrexroth.com/training.

10/60 Safety instructions

Bosch Rexroth AG, A10VO, A10VSO, A10VNO, A10VSNO Series 52 and 53, RE 92703-01-B/04.2018

2.5 General safety instructions

•Observe applicable accident prevention and environmental protection regulations.

•Observe the safety regulations of the country in which the product is used/

operated.

•Use Rexroth products only when they are in good working order.

•Observe all notices on the product.

•Do not install, operate, remove or maintain Rexroth products if under the inﬂuence

of alcohol, drugs or medication that may aﬀect your reaction time.

•Only use genuine Rexroth accessories and spare parts to make sure there is no risk

to personnel from unsuitable spare parts.

•Observe the technical data and ambient conditions speciﬁed in the product

documentation.

•If unsuitable products are installed or used in applications that are of relevance to

safety, unexpected operating conditions may occur in the application, which could

result in personal injury or property damage. For this reason, only use the product

in safety-relevant applications if this use is expressly indicated and approved in

the product documentation, e.g. in explosion protection applications or in safety-

related parts of a control system (functional safety).

•Only commission the product if it has been determined that the end product

(e.g. machinery or system) in which the Rexroth products are installed complies

with the country-speciﬁc provisions, safety regulations and standards for the

application.

•Use tools appropriate for the work being performed and wear appropriate

protective clothing to prevent punctures and cuts (e.g. when removing protective

covers, disassembly).

•There is a risk of entanglement when operating the axial piston unit with a bare

shaft end. Check whether or not your machine requires additional safety measures

for your application. If necessary, make sure these are properly implemented.

•Depending on the type of control used, electromagnetic eﬀects can be produced

when using solenoids. The use of the direct current (DC) on the electromagnet

does not produce any electromagnetic interference (EMI), nor is the electromagnet

inﬂuenced by EMI. Potential electromagnetic interference (EMI) exists if the

solenoid is energized with a modulated direct current (e.g. PWMsignal). The

machine manufacturer should conduct appropriate tests and take appropriate

measures to ensure that other components or operators (e.g.with a pacemaker)

are not aﬀected by this potentiality.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de agua de Bosch

Bosch

Bosch GardenPump 18 Manual de usuario

Bosch

Bosch VPV 16 Manual de instalación y funcionamiento

Bosch

Bosch Rexroth A7VO 63 Series Manual de usuario

Bosch

Bosch Rexroth 3 Series Manual de usuario

Bosch

Bosch VP44 Manual de usuario

Bosch

Bosch EasyPump Manual de usuario

Bosch

Bosch Rexroth 11 Series Manual de usuario

Bosch

Bosch Rexroth A10VG Instrucciones de funcionamiento

Bosch

Bosch rexroth A2FO Series Manual de usuario

Bosch

Bosch rexroth A21VG 10 Series Manual de usuario

Bosch

Bosch 7 736 504 585 Manual de usuario

Bosch

Bosch rexroth A4VSO 10 Series Manual de usuario

Bosch

Bosch Rexroth A4VG 35 Series Manual de usuario

Bosch

Bosch rexroth 10 Series Manual de usuario

Bosch

Bosch rexroth 60 Series Manual de usuario

Bosch

Bosch 2 609 390 308 Manual de usuario

Bosch

Bosch GardenPump18V-2000 Manual de usuario

Bosch

Bosch rexroth 11 Series Manual de usuario

Bosch

Bosch rexroth A4VSH Series Manual de usuario

Bosch

Bosch Universal Pump 18V Manual de usuario

Bosch

Bosch EasyPump Manual de usuario

Bosch

Bosch Rexroth A10VG Manual de usuario

Bosch

Bosch AGS10-2 Guía del usuario

Bosch

Bosch VPV 16 Manual de instalación y funcionamiento

Manuales populares de Bomba de agua de otras marcas

Neptun

Neptun NPHW 5500 Manual de usuario

Sensidyne

Sensidyne Gilian BDX-II Instrucciones de instalación y funcionamiento

Draper

Draper 47808 Manual de usuario

Trolla

Trolla 12820 Manual de usuario

Sunfab

Sunfab SVH Series Manual de usuario

WilTec

WilTec 50740 Manual de usuario

Fieldmann

Fieldmann FVC 5015 EK Manual de usuario

Everbilt

Everbilt EFSUB5-122HD Manual de usuario

Graco

Graco Husky 3300e Manual de usuario

esotec

esotec 101018 Manual de usuario

moyno

moyno 2000 CC Manual de usuario

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manual de usuario

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guía de solución de problemas

DUROMAX

DUROMAX XP WX Series Manual de usuario

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manual de usuario

Franklin Electric

Franklin Electric IPS Manual de usuario

Xylem

Xylem e-1532 Series Manual de usuario

Milton Roy

Milton Roy PRIMEROYAL Manual de usuario
