Bosch KIR Series Manual de usuario

en Instruction for Use

Refrigerator

KIR../KFR..

en Table of Contents

Safety and warning information ........... 3

Information concerning disposal ......... 5

Scope of delivery ................................... 6

Room temperature, ventilation and

cavity depth ............................................. 6

Installation location ................................ 7

Connecting the appliance .................... 7

Getting to know your appliance .......... 8

Switching the appliance on .................. 8

Setting the temperature ........................ 8

Usable capacity ...................................... 9

Refrigerator compartment .................... 9

Interior fittings ....................................... 10

Sticker “OK” .......................................... 10

Switching off and disconnecting

the appliance ........................................ 11

Defrosting .............................................. 11

Cleaning the appliance ....................... 11

Tips for saving energy ........................ 12

Operating noises ................................. 13

Eliminating minor faults yourself ....... 13

Customer service ................................. 14

enTable of Contents

enInstruction for Use

Safety and warning

information

Before you switch ON the

appliance

Please read the operating and

installation instructions carefully!

They contain important

information on how to install,

use and maintain the appliance.

The manufacturer is not liable if

you fail to comply with the

instructions and warnings.

Retain all documents for

subsequent use or for the next

owner.

Technical safety

The appliance contains a small

quantity of environmentally

friendly but flammable

refrigerant R600a. Ensure that

the tubing of the refrigerant

circuit is not damaged during

transportation and installation.

Leaking refrigerant may cause

eye injuries or ignite.

If damage has occurred

■Keep naked flames and/or

ignition sources away from the

appliance,

■thoroughly ventilate the room

for several minutes,

■switch off the appliance and

pull out the mains plug,

■inform customer service.

The more refrigerant an

appliance contains, the larger

the room must be in which the

appliance is situated. Leaking

refrigerant can form a

flammable gas-air mixture in

rooms which are too small.

The room must be at least 1 m³

per 8 g of refrigerant. The

amount of refrigerant in your

appliance is indicated on the

rating plate inside the appliance.

If the power cord of this

appliance is damaged, it must

be replaced by the

manufacturer, customer service

or a similarly qualified person.

Improper installations

and repairs may put the user

at considerable risk.

Repairs may be performed by

the manufacturer, customer

service or a similarly qualified

person only.

Only original parts supplied by

the manufacturer may be used.

The manufacturer guarantees

that only these parts satisfy the

safety requirements.

A extension cable may be

purchased from customer

service only.

Important information when

using the appliance

■Never use electrical

appliances inside the

appliance (e.g. heater, electric

ice maker, etc.). Explosion

hazard!

■Never defrost or clean the

appliance with a steam

cleaner! The steam may

penetrate electrical parts and

cause a short-circuit. Risk

of electric shock!

■Do not use pointed or sharp-

edged implements to remove

frost or layers of ice. You

could damage the refrigerant

tubes. Leaking refrigerant may

cause eye injuries or ignite.

■Do not store products which

contain flammable propellants

(e.g. spray cans) or explosive

substances in the appliance.

Explosion hazard!

■Do not stand on or lean

heavily against base

of appliance, drawers

or doors, etc

■For defrosting and cleaning,

pull the mains plug out or

switch off the fuse. Do not pull

out the mains plug by tugging

on the power cord.

■Store high-percentage alcohol

tightly closed and standing up.

■Keep plastic parts and the

door seal free of oil and

grease. Otherwise, parts and

door seal will become

porous.

■Never cover or block the

ventilation openings of the

appliance!

■Avoiding placing children

and vulnerable people at

risk:

At risk are children, people

who have limited physical,

mental or sensory abilities, as

well as people who have

inadequate knowledge

concerning safe operation of

the appliance.

Ensure that children and

vulnerable people have

understood the hazards.

A person responsible for

safety must supervise or

instruct children and

vulnerable people who are

using the appliance.

Only children from 8 years

and above may use the

appliance.

Supervise children who are

cleaning and maintaining the

appliance.

Never allow children to play

with the appliance.

Children in the household

■Keep children away from

packaging and its parts.

Danger of suffocation from

folding cartons and plastic

film!

■Do not allow children to play

with the appliance!

■If the appliance features a

lock:

keep the key out of the reach

of children!

General regulations

The appliance is suitable for

refrigerating food.

This appliance is intended for

use in the home and the home

environment.

The appliance is suppressed

according to EU Directive

2004/108/EC.

The refrigeration circuit has

been checked for leaks.

This product complies with

the relevant safety regulations

for electrical appliances

(EN 60335-2-24).

This appliance is intended for

use up to a maximum height of

2000 metres above sea level.

Information concerning

disposal

*Disposal of packaging

The packaging protects your appliance

from damage during transit. All utilised

materials are environmentally safe and

recyclable. Please help us by disposing

of the packaging in an environmentally

friendly manner.

Please ask your dealer or inquire at your

local authority about current means of

disposal.

*Disposal of your old

appliance

Old appliances are not worthless

rubbish! Valuable raw materials can be

reclaimed by recycling old appliances.

This appliance is labelled in

accordance with European

Directive 2012/19/EU concerning

used electrical and electronic

appliances (waste electrical and

electronic equipment - WEEE).

The guideline determines the

framework for the return and

recycling of used appliances as

applicable throughout the EU.



m Warning

Redundant appliances

1. Pull out the mains plug.

2. Cut off the power cord and discard

with the mains plug.

3. Do not take out the trays

and receptacles: children are

therefore prevented from climbing in!

4. Do not allow children to play with

the appliance once it has spent its

useful life. Danger of suffocation!

Refrigerators contain refrigerant

and gases in the insulation. Refrigerant

and gases must be disposed

of professionally. Ensure that tubing

of the refrigerant circuit is not damaged

prior to proper disposal.

Scope of delivery

After unpacking all parts, check for any

damage in transit.

If you have any complaints, please

contact the dealer from whom you

purchased the appliance or our

customer service.

The delivery consists of the following

parts:

■Built-in appliance

■Interior fittings (depending on model)

■Bag containing installation materials

■Operating instructions

■Installation manual

■Customer service booklet

■Warranty enclosure

■Information on the energy

consumption and noises

Room temperature,

ventilation and cavity

depth

Ambient temperature

The appliance is designed for a specific

climate class. Depending on the climate

class, the appliance can be operated at

the following temperatures.

The climate class can be found on

the rating plate. Fig. )

Note

The appliance is fully functional within

the room temperature limits

of the indicated climatic class. If

an appliance of climatic class SN

is operated at colder room temperatures,

the appliance will not be damaged up to

a temperature of +5 °C.

Ventilation

The air on the rear panel of

the appliance heats up. Conduction of

the heated air must not be obstructed.

Otherwise, the refrigeration unit must

work harder. This increases power

consumption. Therefore: Never cover

or block the ventilation openings!

Climate class Permitted ambient

temperature

SN +10 °C to 32 °C

N+16 °C to 32 °C

ST +16 °C to 38 °C

T+16 °C to 43 °C

Cavity depth

A cavity depth of 560 mm

is recommended for the appliance.

If the cavity depth is smaller – at least

550 mm – the energy consumption

increases slightly.

Installation location

Install the appliance in a dry, well

ventilated room. The installation location

should neither be exposed to direct

sunlight nor near a heat source, e. g.

a cooker, radiator, etc. If installation next

to a heat source is unavoidable, use

a suitable insulating plate or observe

the following minimum distances to a

heat source:

■3 cm to electric or gas cookers.

■30 cm to an oil or coal-fired cooker.

Connecting

the appliance

After installing the appliance, wait at least

1 hour until the appliance is switched on.

During transportation the oil in

the compressor may have flowed into

the refrigeration system.

Before switching on the appliance for

the first time, clean the interior of

the appliance (see chapter “Cleaning

the appliance”).

Electrical connection

The socket must be near the appliance

and also freely accessible following

installation of the appliance.

The appliance complies with the

protection class I. Connect the appliance

to 220–240 V/50 Hz alternating current

via a correctly installed socket with

protective conductor. The socket must

be fused with a 10 to 16 A fuse.

For appliances operated in non-

European countries, check whether the

stated voltage and current type match

the values of your mains supply. This

information can be found on the rating

plate. Fig. )

Getting to know your

appliance

Please fold out the illustrated last page.

These operating instructions refer

to several models.

The features of the models may vary.

The diagrams may differ.

Fig. !

Switching

the appliance on

Turn temperature controller, Fig. "/A,

from position “0”. The appliance begins

to cool. Light is switched on when

the door is open.

Operating tips

The refrigerator compartment

temperature rises:

■if the appliance door is opened

frequently,

■if large quantities of food are placed in

the refrigerator compartment,

■if the ambient temperature is high.

Setting

the temperature

Turn temperature controller, Fig. "/A, to

the required setting.

When the controller is at a medium

setting, the temperature drops

to approx. +4 °C in the coldest zone.

Fig. #

Higher settings lower the temperature in

the refrigerator compartment.

1 Temperature controller/light

2 Light switch

3 Glass shelf in the refrigerator

compartment

4 Vegetable container

5 Door shelf

6 Shelf for large bottles

We recommend:

■Perishable food should not be stored

above +4 °C.

■Low setting for short-term

storage of food (energy-saving mode).

■Medium setting for long-term storage

of food.

■Select a higher setting only

temporarily, when the door is

frequently opened or large quantities

are placed in the refrigerator

compartment.

Refrigeration capacity

The temperature in the refrigerator

compartment may rise temporarily if

large amounts of food or a lot of drinks

are placed inside.

Therefore the temperature controller

should be set to a higher setting for

approx. 7 hours.

Usable capacity

Information on the usable capacity can

be found inside your appliance on

the rating plate. Fig. )

Refrigerator

compartment

The refrigerator compartment is the ideal

storage location for meat, sausage, fish,

dairy products, eggs, ready meals

and pastries.

Storing food

■Store fresh, undamaged food. The

quality and freshness will then

be retained for longer.

■In the case of ready-made products

and bottled goods, observe the best-

before date or use-by date specified

by the manufacturer.

■To retain aroma, colour

and freshness, pack or cover food

well before placing in the appliance.

This will prevent the transfer

of flavours and the discolouration

of plastic parts in the refrigerator

compartment.

■Allow warm food and drinks to cool

down before placing in the appliance.

Note

Avoid contact between food and rear

panel. Otherwise the air circulation will

be impaired.

Food or packaging could freeze to

the rear panel.

Note the chill zones

in the refrigerator

compartment

The air circulation in the refrigerator

compartment creates different chill

zones:

■Coldest zone is between the arrow

stamped on the side and the glass

shelf situated below. Fig. #

Note

Store perishable food (e.g. fish,

sausage, meat) in the coldest zone.

■Warmest zone is at the very top

of the door.

Note

Store e.g. hard cheese and butter

in the warmest zone. Cheese can then

continue to release its flavour and the

butter will still be easy to spread.

Vegetable container

Fig. !/4

A high air humidity keeps leafy

vegetables fresh for longer. Vegetables

and fruit should be stored at a slightly

lower air humidity.

The air humidity in the vegetable drawer

depends on the amount of stored food.

Note

If the air humidity is too high, drips may

form and cause decay.

Interior fittings

(not all models)

Glass shelves

Fig. $

You can reposition the inner shelves as

required: lift shelf, pull forwards, lower

and swivel out to the side.

Bottle shelf

Fig. %

Bottles can be stored securely on

the bottle shelf. The holder can be

adjusted.

Sticker “OK”

(not all models)

The “OK” temperature monitor

can be used to determine temperatures

below +4 °C. Gradually reduce

the temperature if the sticker

does not indicate “OK”.

Note

When the appliance is switched on,

it may take 12 hours until

the temperature is reached.

Correct setting

Otros manuales para KIR Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Refrigerador de Bosch

Bosch

Bosch KDN series Manual de usuario

Bosch

Bosch KIR51 series Manual de usuario

Bosch

Bosch KIV86 Series Hoja de especificaciones

Bosch

Bosch KAD Series Guía de configuración

Bosch

Bosch KIR24A65 Manual de usuario

Bosch

Bosch Refrigerator Operating and Hoja de especificaciones

Bosch

Bosch KGS SERIES Manual de usuario

Bosch

Bosch B36FD Series Manual de usuario

Bosch

Bosch B18IW50SRS Manual de usuario

Bosch

Bosch KIV87NFF0/04 Manual de usuario

Bosch

Bosch B22CS50 Series Manual de usuario

Bosch

Bosch KUR SERIES Manual de usuario

Bosch

Bosch KAD62V71 Manual de usuario

Bosch

Bosch KGV Series Manual de usuario

Bosch

Bosch KDN76 Series Manual de usuario

Bosch

Bosch KIR18V20FF Manual de usuario

Bosch

Bosch KFN96APEAG Manual de usuario

Bosch

Bosch B36CT Series Manual de usuario

Bosch

Bosch CTC29 DI Series Hoja de especificaciones

Bosch

Bosch KAD Series Guía de configuración

Bosch

Bosch KGV39VW31G Manual de usuario

Bosch

Bosch B36CT80SNS/01 Guía de configuración

Bosch

Bosch B36ET71SNS - 36" Built in Bottom-Free Manual de usuario

Bosch

Bosch GSD SERIES Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
