Bosch B30BB935SS Manual de usuario

www.bosch-home.com/welcome

Fridge-freezer

Réfrigérateur / Congélateur combiné

Frigoríﬁco / congelador

B30BB935SS

en-us Installation instructions

fr-ca Instructions d,installation

es-mx Instrucciones de instalación

About these instructions

• Read and follow the operating and installation in-

structions. They contain important information on how

to install, use and maintain the appliance.

• The manufacturer is not liable if you disregard the

instructions and warnings in the operating and instal-

lation instructions.

• Have the appliance installed by the manufacturer,

customer service or a similarly qualified person only.

• Retain all documents for subsequent use or for the

next owner.

Risk of electric shock

Improper installations and repairs may put the user at

considerable risk.

• Never cut through or remove the third (ground) con-

ductor of the power cord.

• Never use extension cords or multiple plugs.

• Never use adapters.

• If the power cord is damaged:

Immediately disconnect the appliance from the power

supply and replace the power cord.

• Only use original parts supplied by the manufacturer.

Risk of suffocation

• Keep children away from the packaging and its parts.

Risk of injury

• Risk of tipping over! The appliance is very heavy/top-

heavy. The appliance should always be transported

and set up by at least 2 people.

• Risk of tipping over! The appliance is very heavy/top-

heavy. The appliance must be secured with the anti-

tip brackets supplied and continuously supervised

during this operation.

• Danger of cut injuries! Always wear protective gloves

while installing the appliance.

Damage

To prevent damage:

• Do not stand or support yourself on the base, runners

or doors.

• Keep plastic parts and door seals free of oil and

grease.

State of California Proposition 65 Warnings

This product may contain a chemical known to the

State of California, which can cause cancer or repro-

ductive harm. Therefore, the packaging of your product

may bear the following label as required by California:

T30

⁵⁄₁₆"

(8 mm)

½"

(13 mm) ∅

¼"

(6 mm)

∅

¹⁄₁₆"

(2 mm)

4' (1200 mm)

7/16"-24M 7/16"-24F

T30 T20

115° 90°

b ≥ 6

1/4"

b ≥ 160 mm

5/8" ≤ b < 6

1/4"

(16 mm ≤ b < 160 mm) a ≥ 1

3/16"

(a ≥ 30 mm)

b b

>65%

HEATKITB82

500 kg

1100 Ibs

7/16"-24M

84"... 85 ³⁄₁₆"

(2134 mm ... 2164 mm)

min. 24"

min. 610 mm

(25,4 mm)

max. 9"

max. 228,6 mm

min. 6"

min. 152,4 mm

min. 4"

min.100 mm

30"

(762 mm)

L1 = L 2

EN: If it is not possible due to the

construction to connect the appli-

ance to a power outlet next to it,

connect the appliance to a power

outlet behind the appliance. This

alternative position of the power

outlet is permissible only if you

can switch off the outlet with a

circuit breaker in the fuse box.

FR: S’il est structurellement impos-

sible de brancher l’appareil à une

prise située à côté de l’appareil,

branchez l’appareil à une prise

située à l’arrière de l’appareil.

Cette position de rechange de la

prise est uniquement permise si

vous pouvez désactiver la prise

avec un fusible dans un boîtier

de fusible.

ES: Si por motivos ediﬁcatorios no

es posible conectar el aparato

en una toma de corriente que

se encuentre al lado del apa-

rato, enchufe el aparato en la

parte posteior del aparato. Esta

posición alternativa de la toma

de corriente solo es admisible si

es que se puede desconectar la

toma de corriente mediante un

fusible en la caja de fusibles.

90°

115°

30"

762 mm

33"

830 mm

29 ¾"

756 mm

25"

635 mm

⅛"

3 mm

⅛"

3 mm

14 ⁵⁄₁₆"

364 mm

4x15 8x

5x60

6x31

4x15 6x

T30 T20

T20
