Bosch MUZ5VL1 Manual de usuario

new device on

MyBosch now and

get free benefits:

bosch-home.com/

welcome

VeggieLove

MUZ5VL1

[en] User manual Slicer 8

[ms] Manual pengguna Penghiris 15

[zh-tw]   22

[zh]   28

[ar]   34

https://digitalguide.bsh-group.com?mat-no=8001226394

---

[en] Scan the QR code or visit the website to open the Further Notices for Use. You can find additional informa-

tion about your appliance or accessory here.

[ms] Imbas kod QR atau lawati laman web untuk membuka arahan penggunaan lanjut. Anda boleh

mendapatkan maklumat tambahan mengenai peranti anda atau aksesori di situ.

[zh-

tw]

掃描 QR-Code 或訪問網站，以開啟更詳細的使用說明。您可於此處找到有關電器或配

件的更多資訊。

[zh] 要打开更多与使用相关的提示，请扫描二维码或访问网站。您可以在那里查阅关于机

器或附件的更多详细信息。

[ar]         

      . 

     .

A B C

A B

4 5

6 7

8 9

10 11

12 13

14 15

16 17

18 19

20 21

22 23

en Safety

1 Safety

Observe the following safety instructions.

1.1 General information

¡Read this instruction manual carefully.

¡Observe the instructions for the base unit.

1.2 Intended use

Only use the accessories:

¡with a kitchen machine from the same series MUMS2, MUMS4,

MUM5.

¡With genuine parts and accessories.

¡for cutting up, shredding and grating food.

1.3 Safety instructions

WARNING‒Risk of cutting!

The cutting discs have sharp blades and edges.

▶Only take hold of the cutting discs by the edge.

▶Never touch the sharp blades and edges with bare hands.

WARNING‒Risk of injury!

Rotating drives, tools or accessory parts may cause injury.

▶Do not reach into the filling shaft.

▶Only use the pusher to push down ingredients.

Improper use may cause injuries.

▶Never assemble the accessories on the base unit.

▶Only attach and remove accessories once the drive has

stopped and the appliance has been unplugged.

▶The accessories should only be used in the intended operating

position.

Avoiding material damage en

2 Avoiding material dam-

age

ATTENTION!

Improper use may cause material

damage.

▶Do not process food that contains

hard components, e.g. bones,

gristle or stones.

▶Do not insert objects into the filling

shaft or housing, e.g. wooden

spoons.

▶Before use, check the filling shaft

and housing for foreign objects.

▶Do not apply great force with the

pusher.

3 Unpacking and check-

ing

Find out here what you need to note

when unpacking the appliance.

3.1 Unpacking the accessor-

ies and parts

1. Take the accessories out of the

packaging.

2. Take all other parts and the ac-

companying documents out of the

packaging and place them to

hand.

3. Remove any packaging material.

4. Remove any stickers or film.

3.2 Contents of package

After unpacking all parts, check for

any damage in transit and complete-

ness of the delivery.

→Fig. 1

Continuous-feed shredder

Cutting discs1

Accompanying documents

1Depending on the appliance spe-

cifications

3.3 Cleaning the accessories

before using for the first

time

1. Take the assembled accessories

apart.

→"Dismantling the continuous

feed shredder", Page12

2. Clean all parts that come into con-

tact with food before using for the

first time.

→"Cleaning and servicing",

Page12

3. Put the cleaned and dried parts

out ready for use.

4 Familiarising yourself

with the accessories

4.1 Components

You can find an overview of the parts

of your accessories here.

→Fig. 2

Housing

Disc holder

Lid with integrated filling shaft

Pusher and measuring jug

Reversible cutting disc, thick/

thin

1Depending on the appliance spe-

cifications

en Familiarising yourself with the accessories

Reversible shredding disc,

coarse/fine

Fine grating disc

Reversible slicing / shredding

disc1

Asia vegetables disc1

Coarse grating disc1

1Depending on the appliance spe-

cifications

4.2 Symbols

You can find an overview of the sym-

bols used on your accessories here.

Symbol Description

Follow the instructions in

the operating instructions.

Do not reach into the

filling shaft.

Attach the lid

Position marking housing

4.3 Overview of cutting discs

You can find an overview of the cut-

ting discs and their purposes here.

Designa-

tion

Use

Revers-

ible cut-

ting disc,

thick/thin

Cutting food into thick or

thin slices, e.g. fruit and

vegetables.

Marking:

¡1 = thick slices

¡3 = thin slices

Note:Not suitable for

processing hard cheese,

bread, rolls or chocolate.

Tip:Only cut up cooked

potatoes once they have

cooled down.

1Depending on the appliance spe-

cifications

Designa-

tion

Use

Revers-

ible

shredding

disc,

coarse/

fine

Shredding food coarsely

or finely, e.g. fruit, veget-

ables or cheese as

Gouda or Edam.

Marking:

¡2 = coarse side

¡4 = fine side

Note:Not suitable for

processing nuts or hard

cheese, e.g. Parmesan.

Tip:Shred soft cheese

with the coarse side

only.

Fine grat-

ing disc

Shredding food medium-

fine, e.g. raw potatoes or

hard cheese such as

Parmesan.

Note:Not suitable for

processing soft cheese

and cheese slices.

Coarse

grating

disc1

Grating food coarsely,

e.g. raw potatoes for

dumplings or potato

pancakes.

Revers-

ible sli-

cing /

shredding

disc1

Grating raw potatoes or

cutting into slices.

Note:Not suitable for

processing very fibrous

foods, e.g. leek or

mango.

Asia ve-

getables

disc1

For cutting food into thin

strips, e.g. fruit and ve-

getables.

1Depending on the appliance spe-

cifications
