IP Camera 200 Series

NTC-265-PI

en Installation Manual

IP Camera 200 Series Table of Contents | en 3

Bosch Security Systems Installation Manual AM18-Q0610 | v1 | 2012.02

Table of Contents

1Safety 5

1.1 Safety precautions 5

1.2 Important safety instructions 6

1.3 FCC & ICES compliance 7

1.4 UL certification 8

1.5 Bosch notices 8

1.6 Copyrights 9

2 Introduction 10

2.1 Features 10

2.2 Unpacking 11

3 Installation 12

3.1 Assembly 12

3.2 Mounting 13

3.3 Network (and power) connector 14

3.4 Power connection 15

3.4.1 DC power connection 15

3.5 I/O connector 16

3.6 Audio connectors 17

3.7 Camera set-up 18

3.7.1 Camera positioning 19

3.8 Resetting the camera 20

4 Browser connection 21

4.1 System requirements 21

4.2 Establishing the connection 22

4.2.1 Password protection in camera 22

4.3 Protected network 22

5 Troubleshooting 23

5.1 Resolving problems 23

5.2 Customer service 23

4en | Table of Contents IP Camera 200 Series

AM18-Q0610 | v1 | 2012.02 Installation Manual Bosch Security Systems

6 Maintenance 24

6.1 Repairs 24

6.1.1 Transfer and disposal 24

7 Technical Data 25

7.1 Specifications 25

7.1.1 Accessories 26

IP Camera 200 Series Safety | en 5

Bosch Security Systems Installation Manual AM18-Q0610 | v1 | 2012.02

1Safety

1.1 Safety precautions

DANGER!

High risk: This symbol indicates an imminently hazardous

situation such as "Dangerous Voltage" inside the product.

If not avoided, this will result in an electrical shock, serious

bodily injury, or death.

WARNING!

Medium risk: Indicates a potentially hazardous situation.

If not avoided, this could result in minor or moderate bodily

injury.

CAUTION!

Low risk: Indicates a potentially hazardous situation.

If not avoided, this could result in property damage or risk of

damage to the device.

6en | Safety IP Camera 200 Series

AM18-Q0610 | v1 | 2012.02 Installation Manual Bosch Security Systems

1.2 Important safety instructions

Read, follow, and retain for future reference all of the following

safety instructions. Heed all warnings on the unit and in the

operating instructions before operating the unit.

1. Cleaning - Generally, using a dry cloth for cleaning is

sufficient but a moist, fluff-free cloth or leather shammy

may also be used. Do not use liquid cleaners or aerosol

cleaners.

2. Heat Sources - Do not install the unit near any heat

sources such as radiators, heaters, stoves, or other

equipment (including amplifiers) that produce heat.

3. Water - Never spill liquid of any kind on the unit.

4. Lightning - Take precautions to protect the unit from

power and lightning surges.

5. Controls adjustment - Adjust only those controls specified

in the operating instructions. Improper adjustment of

other controls may cause damage to the unit.

6. Power sources - Operate the unit only from the type of

power source indicated on the label.

7. Servicing - Unless qualified, do not attempt to service this

unit yourself. Refer all servicing to qualified service

personnel.

8. Replacement parts - Use only replacement parts specified

by the manufacturer.

9. Installation - Install in accordance with the manufacturer's

instructions and in accordance with applicable local codes.

10. Attachments, changes or modifications - Only use

attachments/accessories specified by the manufacturer.

Any change or modification of the equipment, not

expressly approved by Bosch, could void the warranty or,

in the case of an authorization agreement, authority to

operate the equipment.

IP Camera 200 Series Safety | en 7

Bosch Security Systems Installation Manual AM18-Q0610 | v1 | 2012.02

1.3 FCC & ICES compliance

FCC & ICES Information

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

– reorient or relocate the receiving antenna;

– increase the separation between the equipment and

receiver;

– connect the equipment into an outlet on a circuit different

from that to which the receiver is connected;

– consult the dealer or an experienced radio/TV technician

for help.

This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions:

1. this device may not cause harmful interference, and

2. this device must accept any interference received,

including interference that may cause undesired operation.

Intentional or unintentional modifications, not expressly

approved by the party responsible for compliance, shall not be

made. Any such modifications could void the user's authority to

operate the equipment. If necessary, the user should consult

the dealer or an experienced radio/television technician for

corrective action.

8en | Safety IP Camera 200 Series

AM18-Q0610 | v1 | 2012.02 Installation Manual Bosch Security Systems

The user may find the following booklet, prepared by the

Federal Communications Commission, helpful: How to Identify

and Resolve Radio-TV Interference Problems. This booklet is

available from the U.S. Government Printing Office,

Washington, DC 20402, Stock No. 004-000-00345-4.

1.4 UL certification

Disclaimer

Underwriter Laboratories Inc. ("UL") has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested fire, shock and/or casualty

hazards as outlined in UL's Standard(s) for Safety for Closed

Circuit Television Equipment, UL 2044. UL Certification does not

cover the performance or reliability of the security or signaling

aspects of this product.

UL MAKES NO REPRESENTATIONS, WARRANTIES, OR

CERTIFICATIONS WHATSOEVER REGARDING THE

PERFORMANCE OR RELIABILITY OF ANY SECURITY OR

SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.

1.5 Bosch notices

More information

For more information please contact the nearest Bosch Security

Systems location or visit www.boschsecurity.com

Disposal - Your Bosch product was developed and

manufactured with high-quality material and components that

can be recycled and reused. This symbol means that

electronic and electrical appliances, which have reached the

end of their working life, must be collected and disposed of

separately from household waste material. Separate collecting

systems are usually in place for disused electronic and

electrical products. Please dispose of these devices at an

environmentally compatible recycling facility, per European

Directive 2002/96/EC

IP Camera 200 Series Safety | en 9

Bosch Security Systems Installation Manual AM18-Q0610 | v1 | 2012.02

1.6 Copyrights

The firmware 4.1 uses the fonts "Adobe-Helvetica-Bold-R-

Normal--24-240-75-75-P-138-ISO10646-1" and "Adobe-

Helvetica-Bold-R-Normal--12-120-75-75-P-70-ISO10646-1" under

the following copyright:

Permission to use, copy, modify, distribute and sell this

software and its documentation for any purpose and without

fee is hereby granted, provided that the above copyright

notices appear in all copies and that both those copyright

notices and this permission notice appear in supporting

documentation, and that the names of Adobe Systems and

Digital Equipment Corporation not be used in advertising or

publicity pertaining to distribution of the software without

specific, written prior permission.

This software is based in part on the work of the Independent

JPEG Group.

10 en | Introduction IP Camera 200 Series

AM18-Q0610 | v1 | 2012.02 Installation Manual Bosch Security Systems

2 Introduction

2.1 Features

The Bosch NTC-265-PI 720p infrared IP bullet camera is a ready-

to-use, robust network camera. This camera offers a cost

effective solution for a broad range of applications. The robust

aluminum camera body is IP66 rated, offering water and dust

proofing for demanding environments. The built-in active

infrared illuminator ensures effective vision under extreme low-

light conditions. The camera easily integrates with the Bosch

DVR 700 Series recorder and can also be used with an iSCSI

server connected via the network to store long-term recordings.

Features include:

– High performance active infrared illuminator inside the

camera for extreme low-light environments

– Tri-streaming: Two H.264 streams and one M-JPEG stream

– HD 720p Progressive scan for sharp images of moving

objects

– Robust IP66-rated camera design

– Two-way audio and audio alarm

– Power over Ethernet (IEEE 802.3af compliant)

– Tamper and motion detection

– Conforms to the ONVIF standard for wide compatibility
