4|User guide | OBD 1000 |en

574694 REV A | 11.2014 Bosch Automotive Service Solutions

Safety Precautions

For safety, read, under-

stand and follow all

safety messages and

instruction in manual be-

fore operating the Pock-

etScan™ Code Reader.

Always refer to and follow safety

messages and test procedures

provided by manufacturer of vehicle

and PocketScan Code Reader.

Signal Words and Symbols

DANGER!

Indicates a possible haz-

ardous situation that, if

not avoided, will result in

death or serious injury to

operator or bystanders.

WARNING!

Indicates a possible haz-

ardous situation that, if

not avoided, could result

in death or serious injury

to operator or bystanders.

CAUTION!

Indicates a possible haz-

ardous situation that, if

not avoided, may result in

moderate or minor injury

to operator or bystanders.

IMPORTANT

Indicates a condition that

may result in damage to

test equipment or vehicle

or lost information.

| OBD 1000 | User guide | 5

574694 REV A | 11.2014Bosch Automotive Service Solutions

Important Safety Messages

Always wear ANSI-ap-

proved goggles for eye

protection.

• Always operate vehicle in a

well-ventilated area.

• Always keep people, tools, and

test equipment away from all

moving or hot engine parts.

• Before testing a vehicle, make

sure the transmission is in PARK

(automatic transmission) or

NEUTRAL (manual transmission)

and the parking brake is set.

• Always block drive wheels and

never leave vehicle unattended

while testing.

• Always keep a fire extinguisher

suitable for gasoline/electrical/

chemical fires redily available.

• Never lay tools on the vehicle

battery.

• Always use caution when work-

ing around ignition coil, distribu-

tor cap, ignition wires, and spark

plugs. Components can produce

a High Voltage while engine is

running.

• Battery acid is caustic. If con-

tacted, rinse with water or neu-

tralize with a mild base (i.e.

baking soda). If in eyes, flush

with water and call a physician

immediately.

• Never smoke or have open

flames near vehicle. Vapors from

gasoline and battery during

charge are explosive.

• Never use the PocketScanTM

Code Reader if internal circuitry

has been exposed to moisture.

Internal shorts could cause a fire

and damage.

• Always turn ignition key OFF

when connecting or disconnect-

ing electrical components,

unless otherwise instructed.

Some vehicles are equipped with

safety air bags. Follow vehicle ser-

vice manual cautions when working

around air bag components or

wiring.

WARNING!

A vehicle airbag can open

for several minutes after

the ignition has been

turned off.

• Always follow vehicle manufac-

turer’s warnings, cautions, and

service procedures.

6|User guide | OBD 1000 |en

574694 REV A | 11.2014 Bosch Automotive Service Solutions

Tool Parts

Part Description

1LCD

display Single-line display with 8 char-

acters.

2ERASE

Used to Erase Trouble Codes and

I/M Monitor status from Vehicle’s

Computer Modules and scroll up

through screens. (I/M Monitors

are currently used for state emis-

sions tests.)

3READ

Used to view Read Codes, MIL

Status, I/M Readiness Status and

scroll down through screens.

4OBD II

Connector Used to communicate with OBD II

compliant vehicles.

PocketScan™ Code Reader

Features

Read Codes

Reading Diagnostic Trouble Codes

allows the PocketScan

Code Reader to read the codes

from the vehicle’s computer

modules.

• Diagnostic Trouble Codes:

Diagnostic Trouble Codes are

used to help determine the

cause of a problem or problems

with a vehicle. Diagnostic Trou-

ble Codes are set when a fault is

present for a sufficient amount

of time.

• Pending Codes:

Pending Codes are also referred

to as “continuous monitor

codes” and “maturing codes.”

Pending Codes occurs when the

code has not occurred a specific

number of times (depending on

vehicle,) causing the code to

mature.

MIL Conditions

MIL (Malfunction Indicator Lamp)

Status displays the

state of the vehicles computer

module(s).

• MIL ON:

Indicates that the Malfunction

Indicator Lamp on vehicle should

be ON indicating a possible

emissions problem.

9If the MIL Status is ON and the

MIL is not illuminated with the

engine running, then a problem

exists in the MIL circuit.

• MIL OFF:

| OBD 1000 | User guide | 7

574694 REV A | 11.2014Bosch Automotive Service Solutions

Indicates the Malfunction Indica-

tor Lamp should be off and there

should be no emission problems.

9Some manufacturers will turn

the MIL off if a certain number

of drive cycles occur without the

same fault being detected.

9Diagnostic Trouble Codes

related to a MIL are erased from

the computer’s memory after 40

warm-up cycles if the same fault

is not detected.

Inspection/Maintenance Monitors

(I/M Monitors

The I/M Monitors (Inspection /

Maintenance) function displays a

SNAPSHOT of the operations for the

Emission System.

9After a specific amount of drive

time (each monitor has specific

driving conditions and time

required), the computer’s “moni-

tors” will decide if the vehicles

emission system is working

correctly.

9Some states MAY NOT require all

monitors listed to be “Ready” to

pass the emissions test. Check

with state testing site for exact

requirements. All states will fail

a vehicle that has the “MIL

Light” lit at time of test.

• Monitors Viewed:

Monitor Expanded Name

Misfire Misfire monitor

Fuel Fuel system monitor

Comp Comprehensive components monitor

Catlyst Catalyst monitor

Htd Cat Heated catalyst monitor

Evap Evaporative system monitor

Sec Air Secondary air system monitor

A/C Air conditioning refrigerant monitor

O2 Snsr Oxygen sensor monitor

O2 Htr Oxygen sensor heater monitor

EGR Exhaust gas recirculation

• Monitor Status:

Status Description

Ready Vehicle was driven enough under proper

conditions to complete the monitor.

Inc (Incomplete) Vehicle was not driven

enough under proper conditions to com-

plete the monitor.

• Monitors may be cleared by:

• Using the erase codes func-

tion.

• Disconnected or discharged

battery (on some vehicles.)

• Computer module losing

power (on some vehicles.)

Reading Diagnostic Trouble

Codes and Data

WARNING!

Avoid cooling fan. Fan

may turn on during test.

1. Turn ignition key to the OFF

position.

8|User guide | OBD 1000 |en

574694 REV A | 11.2014 Bosch Automotive Service Solutions

2. Locate and plug in data link

connector (DLC).

NOTE: The data link connector

should be located under the

dashboard on the driverside of

the vehicle. If the data link con-

nector is not located under the

dashboard as stated, a label

describing the location of the

data link connector should be

there.

3. Observe display toggles between

“Pocket” and “Scan”.

NOTE: For a correct reading for

diagnostic trouble codes and I/M

monitor status, ignition key must

be in the ON position and engine

does not require starting. To get

a correct reading for MIL status,

engine must be started.

4. Start engine.

5. Press and release key.

NOTE: If diagnostice trouble

codes (DTCs) are already being

displayed from a previous read

operation, press and hold

for 3 seconds and release.

6. Observe a moving * on display.

NOTE: If “No Link” message

displays, cycle ignition key to the

OFF position for 10 seconds,

then back ON and repeat “Read-

ing Diagnostic Data” procedure.

7. View codes on display.

NOTE: If

there are no codes present, the

tool will display “0 Codes” and

proceed to display MIL Status

when is pressed.

• To view codes, press and

release .

• If the code is a pending code,

pd will be displayed.

8. View MIL status:

• Press and release .

9. View I/M monitors that are

incomplete.

• Press and release .

| OBD 1000 | User guide | 9

574694 REV A | 11.2014Bosch Automotive Service Solutions

NOTE: If there are no more

I/M monitors that are incom-

plete, the tool will then

display ready monitors when

is pressed.

10.View I/M monitors that are

ready.

• Press and release .

NOTE: Pressing will

scroll up to review diagnostic

trouble codes and data.

Holding down for 3

seconds will read diagnostic

trouble codes and data again.

Erasing Diagnostic Trouble

Codes and Data

Erasing allows the PocketScan™

code reader to delete the codes and

IM monitor status from the vehicle’s

computer modules.

NOTICE

Only erase diagnostic data

after checking

system completely and

writing down results.

WARNING!

Avoid cooling fan. Fan

may turn on during test.

1. Turn ignition key to the OFF

position.

2. Locate and plug in data link

connector (DLC).

NOTE: The data link connector

should be located under the

dashboard on the driverside of

the vehicle. If the data link

connector is not located under

the dashboard as stated, a label

describing the location of the

data link connector should be

there.

3. Observe display toggles between

“Pocket” and “Scan”.

4. Turn ignition key to the ON

position leaving engine off.

NOTE: Make sure that the igni-

tion key is ON and NOT in the

accessory position.

10 |User guide | OBD 1000 |en

574694 REV A | 11.2014 Bosch Automotive Service Solutions

5. Press and hold for 3 sec-

onds and release.

6. Observe “ERASE?” displays.

7. Press and hold for 3 sec-

onds and release.

8. Observe a moving — on display.

NOTE: If a “NO LINK” message

displays, cycle ignition key to the

OFF position for 10 seconds,

then back ON, and repeat “Eras-

ing Diagnostic Data” procedure.

9. Observe “DONE” displays.

NOTE: If the problem causing

diagnostic trouble code(s) still

exists, the code will return. The

diagnostic trouble code may

return immediately or may

return after vehicle has been

driven.

NOTE: Pressing will read

diagnostic trouble codes and

data and holding will erase

results again.

Diagnostic Trouble Codes

This section contains the J2012

Diagnostic Trouble Codes (DTCs) as

defined by the Society of Automotive

Engineers (SAE).

DTCs are recommendations not a

requirement. Manufacturers may not

follow these, but most do.

Check vehicle’s service manual for

DTC meaning if the code(s) you are

getting does not make sense.

DTC definitions have been assigned

or reserved by the Society of Automo-

tive Engineers (SAE) to direct to

proper service area(s).

Codes not assigned or reserved by

the SAE are reserved for the manu-

facturer and referred to as Manufac-

turer Specific DTCs.

Remember:

• Visual inspections are important!

• Problems with wiring and connec-

tors are common, especially for

intermittent faults.

• Mechanical problems (vacuum

leaks, binding or sticking linkages,

etc.) can make a good sensor look

bad to the computer.

• Incorrect information from a

sensor may cause the computer

to control the engine in the

wrong way. Faulty engine opera-

tion might even make the com-

Tabla de contenidos

Idiomas:

Otros manuales de Lector de código de barras de Bosch

Bosch

Bosch KTS 530 Especificaciones

Manuales populares de Lector de código de barras de otras marcas

POSMicro

POSMicro Datalogic PowerScan D7100 Manual de usuario

Marson

Marson MT780 Guía de configuración rápida

NCR

NCR RealPOS Manual de usuario

Motorola

Motorola SE3300 Guía de configuración rápida

Element

Element P130BT Manual de usuario

Motorola

Motorola Symbol LS3008 Manual de instalación y operación

Meec tools

Meec tools OBD-II / VAG Manual de usuario

SICK

SICK CLP 100 Manual de usuario

Royal Tag SA

Royal Tag SA I-Read Manual de usuario

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manual de usuario

Meteor

Meteor 8310 Manual de usuario

Denso

Denso BHT-500B Manual de usuario

Datalogic

Datalogic Heron HD3130 Manual de usuario

Motorola

Motorola MP6000 Instrucciones de montaje

Newland

Newland NLS-HR15-BT Manual de usuario

ARTDEV

ARTDEV AS-1310 Manual de usuario

Aopos

Aopos AS290 Manual de usuario

ENS

ENS 367-5455 Manual de usuario
