BMW R 1200 C Instrucciones de funcionamiento

BMW AG Motorcycle Division

After Sales

R 850 C

R 1200 C

Repair Manual

Published by: © BMW AG Motorcycle Division

After Sales

UX-VS-2

permission.

Errors and omissions excepted; subject to technical amendment.

Printed in Germany 3/99

Order number 01 50 7 654 051

Introduction

This repair manual will help you to perform all the main maintenance and repair work correctly and efficient-

ly. It should be consulted regularly by workshop personnel as an addition to the practical and theoretical

knowledge obtained in Training School courses. It is a contribution towards achieving even higher Service

quality.

A new issue of this repair manual will be published if amendments or additions (supplements) are needed.

The latest issue date is shown in the header of the microfiche. Microfiches rendered invalid by the new issue

should be destroyed without delay.

All information in both text and illustrations refers to motorcycles in standard condition or with Original BMW

accessories installed, and not to motorcycles which have been modified in any way to depart from the man-

ufacturer’s specification.

●The repair manual is structured in the logical sequence of the work to be performed: Removal, Disman-

tling, Repair, Assembly, Installation.

●The entire contents are divided into individual chapters, corresponding to the Construction Groups.

11 . 10

Chap. Page number within chapter

●Work to be performed during an Inspection is described in Group 00. The various Inspection routines

are numbered I, II, III and IV. This numbering is repeated in the work descriptions which follow, so that

work can take place without interruption.

●Use of the BMW special tools needed for certain tasks is described in the work instructions.

If the need arises, repair instructions are also issued in the form of Service Information. This information is

of course incorporated into the next issue of the repair manual. We also recommend you to consult the

detailed illustrations on the Parts microfiches as an additional source of information.

BMW AG Motorcycle Division

After Sales

Published by: BMW AG Sparte Motorrad

Hufelandstr. 6

D - 80937 München

permission.

Errors and omissions excepted; subject to technical amendment.

Produced in Germany

Order No. 01 71 0 008 872 UX-VS-2, 06.99 Printed in Germany

Customer Licence plate No.

Order No. Mechanic’s signature

BMW Inspection

at 1000 km

(600 miles)

BMW Service

every 10 000 km

(6 000 miles)

BMW Inspection

every 20 000 km

(12000 miles)

BMW

Annual Service

Read the fault code memory with the MoDiTeC

Change oil while at regular operating temperature and renew the oil filter element

if motorcycle is used only for short journeys or at outside temperatures under 0°C (32 °F), every

3 months, but at least every 3 000 km (1 800 miles) *)

Change oil in gearbox while at operating temperature

at least every 2 years*)every

2years

Change oil in rear wheel drive while at regular operating temperature;

if necessary, clean inductive sensor on rear wheel

every 40 000 km (24 000 miles) or at least every 2 years *)

40 000

(24 000)

every

2years

Renew fuel filter *)

normally every 40 000 km (24 000 miles), if fuel quality is poor every 20000 km (12 000 miles) 40 000

(24 000)

Check battery acid level, if necessary add distilled water

Clean and grease the battery terminals, if necessary

Renew intake air filter element

in very dusty or dirty operating conditions, renew the intake air filter element every 10 000 km

(6 000 miles) or even more often if necessary *)

Renew Poly-V belt *)

renew Poly-V belt every 60 000 km (36 000 miles); do not adjust 60 000

(36 000)

Check brake fluid level at front and rear and top up if necessary *)

Check operation of brake system and freedom from leaks; repair/replace items if nec. *)

Examine brake pads and discs for wear, renew if necessary *)

Change the brake fluid annually

Check clutch fluid level

Change the clutch fluid

every 40 000 km (24 000 miles) or at least every 2 years *)40 000

(24 000)

every

2years

Check tightness of rear wheel studs

Check rear wheel bearing play by tilting wheel

Check swinging arm bearings (zero play); adjust if necessary *)

Grease the side stand pivot

Check function of side stand contact switch

Check condition of spark plugs

Renew spark plugs *)

Check security of cylinder head nuts

Check/adjust valve clearances

Check throttle cable for free movement, abrasion and kinking; renew if necessary *)

Check cable play

Check synchronisation and eliminate leaks *)

Final inspection with road safety and functional check:

– Condition of tyres and wheels, rims and spokes if applicable, tyre pressures

– Lights and signalling equipment

– Telltale and warning lights

– Clutch, gear shift

– Front and rear brakes, steering

– Instruments

– If necessary, test ride

*)Charged as an additional item

BMW AG Motorcycle Division

Maintenance schedule

R 1100 S / R 850/1200 C / R 1150 GS

Order No. 01 71 0 008 872 UX-VS-2, 06.99 Printed in Germany

Customer Licence plate No.

Order No. Mechanic’s signature

BMW

Pre-delivery check

Check the shipping crate for damage

Motorcycle:

– unpack

– install remaining items

– inspect for damage

– check that delivery is complete: tools

documentation

keys

correct optional extras

Fill and charge the battery (mark with charging date)

Check engine oil level when cold; add oil if necessary

Check clutch operating fluid level and brake fluid levels at front and rear

Check headlight beam angle, adjust if necessary

Check security of rear wheel studs

(comply with correct tightening torque)

Check tyre pressures

Fill fuel tank

Final inspection as functional check:

– Clutch, gear shift

– Front and rear brakes

– Lights and signalling equipment, telltale and warning lights, instruments

– Check operation of optional extras, ABS

– If necessary, test ride

Confirm pre-delivery check in Service and Technical Booklet

Final cleaning

Motorcycle handed over on:

BMW AG Motorcycle Division

Pre-delivery check

R 1100 S / R 850/1200 C / R 1150 GS

00 Maintenance and general instructions

11 Motor

12 Engine electrics

13 Fuel preparation and control

16 Fuel tank and lines

18 Exhaust system

21 Clutch

23 Gearbox

31 Front fork

32 Steering

33 Rear wheel drive

Contents

Group / Chapter

34 Brakes

36 Wheels and tyres

46 Frame

51 Equipment

52 Seat

61 General electrical equipment

62 Instruments

63 Lights

Group / Chapter

00.1

Contents Page

Tightening torques ......................................................................................................................3

Table of operating fluids ...........................................................................................................9

Key to maintenance intervals ..............................................................................................11

Reading out MoDiTeC fault memory ...............................................................................11

(Inspections I, II, III and IV)

Checking throttle cable play,

adjusting if necessary ..............................................................................................................11

(Inspections I and III)

Changing engine oil, renew oil filter element .............................................................12

(Inspections I, II, III and IV)

Changing oil in gearbox ..........................................................................................................13

(Inspections III and IV)

or at least every 2 years

Changing oil in rear wheel drive; cleaning inductive signal transmitter at

rear wheel .......................................................................................................................................13

(Inspections I, III and IV)

Every 40 000 km (24 000 miles) or at least every

2 years

Renewing fuel filter ...................................................................................................................14

(Inspection III)

In normal operating conditions every 40 000 km (24 000 miles); if fuel quality is poor every

20 000 km (12 000 miles)

Checking battery acid level/topping up if necessary, cleaning/greasing

battery posts .................................................................................................................................16

(Inspections III and IV)

Renewing intake air cleaner

element ............................................................................................................................................16

(Inspection III)

In very dirty and dusty operating conditions, renew every 10 000 km (6 000 miles) or even more fre-

quently if necessary

Renewing Poly-V belt ...............................................................................................................17

(every 60 000 km/36 000 miles)

(Inspection III)

Poly-V belt adjusting procedure:

Checking brake fluid level .........................................................................................................18

Front brake

00 Maintenance and general instructions

00.2

Contents Page

Rear brake

Checking brake pads and discs for wear/renewing ......................................................19

(Inspections II and III)

Checking front brake pad wear ..............................................................................................19

Checking rear brake pad wear ................................................................................................19

Checking brake disc wear ........................................................................................................19

Renewing brake pads Front brake ........................................................................................20

Renewing brake padsRear brake ..........................................................................................20

Renewing brake fluid and bleeding brake system ...................................................21

Renew the brake fluid annually

(Inspection IV)

[ABS Inspection II and III]

Bleeding front brake circuit/renewing brake fluid ...........................................................21

Additionally with [ABS]

Bleeding rear brake circuit/renewing brake fluid ............................................................23

Additionally with [ABS]

Checking clutch operating fluid level .............................................................................24

(Inspections I, II and III)

Checking tightness of rear wheel studs ........................................................................25

(Inspection I)

Checking rear wheel bearing play by tilting wheel .................................................25

(Inspection III)

Checking swinging arm bearings, adjusting if necessary ...................................25

(Inspections I and III)

Greasing the side (prop) stand pivot ................................................................................25

(Inspections I, II and III)

Checking function of side (prop) stand contact switch ........................................25

(Inspections I, II, III and IV)

Tightening cylinder heads .....................................................................................................26

(Inspection I)

Checking/adjusting valve operating clearances ......................................................26

(Inspections I, II and III)

Checking/renewing spark plugs ........................................................................................27

(Inspection II)/renewing (Inspection III)

Check synchronising ................................................................................................................27

(Inspections I, II and III)

Final inspection with road safety and functional check .......................................28

(Inspections I, II, III and IV)

Road safety check

Roadworthiness check

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Motocicleta de BMW

BMW

BMW K 1200 S 2007 Manual de instalación y mantenimiento

BMW

BMW R65 Manual de instalación y mantenimiento

BMW

BMW R 1200 GS ADVENTURE Manual de usuario

BMW

BMW 1200 ST BROCHURE 2005 Manual de usuario

BMW

BMW R1200GS Manual de instalación y mantenimiento

BMW

BMW K 1600 GTL Exclusive Manual de instalación y mantenimiento

BMW

BMW R 1200RT Manual de instalación y mantenimiento

BMW

BMW F 800 ST Manual de instalación y mantenimiento

BMW

BMW R 1200 CL Manual de usuario

BMW

BMW F 650 GS DAKAR - Manual de usuario

BMW

BMW R 1200 GS 2014 Manual de instalación y mantenimiento

BMW

BMW C 650 GT Manual de instalación y mantenimiento

BMW

BMW R 1200 GS - Manual de usuario

BMW

BMW R 1200 RS 2016 Manual de instalación y mantenimiento

BMW

BMW 2008 R 1200 GS Manual de instalación y mantenimiento

BMW

BMW R 1200GS Adventure Manual de instalación y mantenimiento

BMW

BMW HP2 ENDURO Especificaciones técnicas

BMW

BMW R 1250 GS Adventure HP Manual de instalación y mantenimiento

BMW

BMW F 650 GS DAKAR - Manual de usuario

BMW

BMW K 1200 GT - Manual de usuario

BMW

BMW G 310 R Manual de instalación y mantenimiento

BMW

BMW MOTORRAD K 1200 R Sport Manual de usuario

BMW

BMW R 1200RS 2016 Manual de instalación y mantenimiento

BMW

BMW HP2 Megamoto 2007 Manual de instalación y mantenimiento

Manuales populares de Motocicleta de otras marcas

OHVALE

OHVALE GP-0 Manual de lista de piezas

Yamaha

Yamaha Star XV19CTSZ 2009 Manual de usuario

KTM

KTM 350 XCF-W USA Manual de usuario

HYOSUNG

HYOSUNG ST7 Manual de usuario

Husqvarna

Husqvarna FC 250 2016 Manual de usuario

Ducati

Ducati SCRAMBLER 800 Manual de instrucciones

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Manual de usuario

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manual de usuario

Yamaha

Yamaha 2006 YZF-R1V Manual de usuario

KTM

KTM Freeride E-XC 2021 Manual de usuario

Fantic

Fantic Enduro 125 Manual de usuario

Ducati

Ducati Supersport 750 desmodue Manual de usuario

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manual de instrucciones

Yamaha

Yamaha XVS650A Manual de usuario

Yamaha

Yamaha YZF-R6T(C) Manual

Ducati

Ducati 748 monoposto strada Manual de usuario

ATK

ATK 1988 250 Manual de usuario

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manual de usuario
