Blomberg SSM 9450 Manual de usuario

Operating instructions

SSM 9450

Refrigerator

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in a 1st-class

manufacturing facility and checked under the most meticulous quality control

procedures, will provide you with years of good service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future reference.

This manual

• Will help you use your appliance quickly and safely.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

1 Your cooler/freezer 3

2 Warnings 4

Electrical Requirements .....................5

Warning! This Appliance Must Be

Earthed .............................................6

Energy Saving Tips............................7

Compliance with WEEE Directive and

Disposing of the Waste Product: .......7

Compliance with RoHS Directive: ......8

Package information..........................8

3 Installation 9

Points to be paid attention to when the

relocation of the cooler/freezer...........9

Before you start the cooler/freezer, ....9

Electrical connection..........................9

Disposing of the packaging .............10

Disposing of your old cooler/freezer.10

Placing and Installation ....................10

Replacing the interior light bulb .......11

4Preparation 12

Reversing the doors ........................13

5 Using your cooler/freezer 14

Setting the operating temperature ...14

The operating temperature is regulated

by the temperature control...............14

Using interior compartments............14

Cooling............................................14

Defrost ............................................15

6 Maintenance and cleaning 16

Protection of plastic surfaces ..........16

8 How To Obtain Service 21

9 Guarantee Details 22

C Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1Your cooler/freezer

1. Front plastic trim

2. Interior light

3. Thermostat knob

4. Movable shelves

5. Wine rack

6. Defrost water collection channel - Drain

tube

7. Crisper

8. Adjustable front feet

9. Dairy compartment

10. Adjustable door shelves

11. Egg compartment

12. Bottle shelf

2Warnings

• DO NOT connect

your appliance to the

electricity supply until

all packing and transit

protectors have been

removed.

• Leave to stand for at

least 4 hours before

switching on to allow

compressor oil to settle if

transported horizontally.

• If you are discarding an

old refrigerator with a

lock or latch fitted to the

door, disable the lock/

latch, ensure that it is

left in a safe condition to

prevent the entrapment

of young children.

• This appliance must only

be used for its intended

purpose i.e the storing of

edible foodstuff.

• Do not dispose of the

appliance on a fire.

At BLOMBERG, the

care and protection of

our environment is an

ongoing commitment.

This appliance which

is among the latest

range introduced is

particularly environment

friendly. Your appliance

contains non CFC /

HFC natural substances

in the cooling system

(Called R600a) and in

the insulation (Called

cyclopentane) which are

potentially flammable

if exposed to fire.

Therefore, take care

not to damage, the

cooling circuit / pipes

of the appliance in

transportation and in

use. In case of damage

do not expose the

appliance to fire or

potential ignition source

and immediately ventilate

the room where the

appliance is situated.

• We suggest you contact

your local authority for

disposal information and

facilities available.

• To obtain the best

possible performance

and trouble free

operation from your

appliance it is very

important to carefully

read these instructions.

• On delivery, check to

make sure that the

product is not damaged

and that all the parts

and accessories are in

perfect condition.

• Ensure that the

plug remains readily

accessible. Do not use

multiple adapter or

extension cable.

• Failure to observe

these instructions may

invalidate your right to

free service during the

guarantee period.

• Keep ventilation

openings, in the

appliance enclosure or

in the built-in structure,

clear of obstruction.

• Do not use mechanical

devices or other means

to accelerate the

defrosting process,

other than those

recommended by the

manufacturer.

• Do not damage the

refrigerant circuit.

• Do not use electrical

appliances inside

the food storage

compartments of the

appliance, unless

they are of the type

recommended by the

manufacturer.

• We suggest you keep

these instructions in

a safe place for easy

reference.

• This appliance can

be used by children

aged from 8 years and

above and persons

with reduced physical,

sensory or mental

capabilities or lack

of experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance

in a safe way and

understand the hazards

involved.

• Children should be

supervised to ensure

that they do not play with

the appliance.

Electrical

Requirements

Before you insert the plug

into the wall socket make

sure that the voltage and

the frequency shown on

the rating plate inside the

appliance corresponds to

your electricity supply.

Rating label is on the left

hand side of inner liner.

We recommend that this

appliance be connected

to the mains supply via a

suitable switched

and fused socket. The

appliance must be

positioned so that the plug

is accessible.

Should the mains lead

of the appliance become

damaged or should it need

replacing at any time,

it must be replaced by a

special purpose made

mains lead which can

only be obtained from a

BLOMBERG Authorised

Service Agent.

Warning! This

Appliance Must Be

Earthed

If the fitted moulded plug

is not suitable for your

socket, then the plug

should be cut off and an

appropriate plug fitted.

Destroy the old plug which

is cut off as a plug with

bared cord could cause

a shock hazard if inserted

into a socket elsewhere in

the house.

The moulded plug on this

appliance incorporates

a 13 A fuse. Should the

fuse need to be replaced

an ASTABEAB approved

BS 1362 fuse of the same

rating must be used. Do

not forget to refit the fuse

cover. In the event of losing

the fuse cover the plug

must not be used until a

replacement fuse cover

has been fitted. Colour

of the replacement fuse

cover must be the same

colour as that visible on

the pin face of the plug.

Fuse covers are available

from any good electrical

store.

Important! Fitting A

Different Plug

As the colours of the

wires in the mains lead

of this appliance may

not correspond with

the coloured markings

identifying the terminals

in your plug proceed as

follows: (See diagram).

1. Connect the green-

yellow or green (Earth)

wire to the terminal in the

plug marked ‘E’ or with

the symbol or coloured

green and yellow or

green.

2. Connect the blue

(Neutral) wire to the

terminal in the plug

marked ‘N’ or coloured

black.

3. Connect the brown

(Live) wire to the terminal

in the plug marked ‘L’ or

coloured red.

4. With alternative plugs

a 13 A fuse must be

fitted either in the plug or

adaptor or in the main

fuse box. If in doubt

contact a qualified

electrician.

Energy Saving Tips

1. Ensure your appliance

is installed in a well

ventilated area.

2. Ensure the time

between buying chilled/

frozen food and placing

them in your appliance

is kept at minimum,

particularly in summer.

We recommend you use

a cool bag or a special

carrier bag to carry

perishable food.

3. Do not leave the door (s)

of your appliance open

longer than necessary

and ensure they are

closed properly after

each opening.

4. Defrost frozen food in

the fridge, so that frozen

food acts as an ice pack

to assist cooling in fridge.

Compliance with

WEEE Directive and

Disposing of the Waste

Product:

Thisproduct

complies with EU

WEEE Directive

(2012/19/EU).

This product

bears a classification

symbol for waste electrical

and electronic equipment

(WEEE).This product has

been manufactured with

high quality parts and

materials which can be

reused and are suitable

for recycling. Do not

dispose of the waste

product with normal

domestic and other

wastes at the end of its

service life. Take it to the

collection center for the

recycling of electrical and

electronic equipment. Please

consult your local

authorities to learn about

these collection centers.

Compliance with RoHS

Directive:

The product you have

purchased complies

with EU RoHS Directive

(2011/65/EU). It does

not contain harmful and

prohibited materials

specified in the Directive.

Package information

Packagingmaterialsofthe

product are manufactured

from recyclable materials

in accordance with our

National Environment

Regulations. Do not

dispose of the packaging

materials together with the

domestic or other wastes.

Takethemtothepackaging

material collection points

designated by the local

authorities.

3Installation

BIn case the information which are

given in the user manual are not

taken into account, manufacturer will

not assume any liability for this.

Points to be paid attention

to when the relocation of the

cooler/freezer

1. Your cooler/freezer should be

unplugged.Before transportation

of your cooler/freezer, it should be

emptied and cleaned.

2. Before it is re-packaged, shelves,

accessories, crisper, etc. inside your

cooler/freezer should be fixed with

adhesive tape and secured against

impacts. Package should be bound

with a thick tape or sound ropes

and the transportation rules on the

package should be strictly observed.

3. Original packaging and foam

materials should be kept for future

transportations or moving.

Before you start the cooler/

freezer,

Check the following before you start

to use your cooler/freezer:

1. Attach 2 plastic wedges as illustrated

below. Plastic wedges are intended

to keep the distance which will

ensure the air circulation between

your cooler/freezer and the wall.

(The picture is drawn up as a

representation and it is not identical

with your product.)

2. Clean the interior of the cooler/

freezer as recommended in the

“Maintenance and cleaning” section.

3. Connect the plug of the cooler/

freezer to the wall socket. When the

fridge door is opened, fridge internal

lamp will turn on.

4. When the compressor starts to

operate, a sound will be heard. The

liquid and gases sealed within the

refrigeration system may also give rise

to noise, even if the compressor is

not running and this is quite normal.

5. Front edges of the cooler/freezer

may feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Electrical connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

The connection must be in compliance

with national regulations.

• The power plug must be easily

accessible after installation.

• Electrical safety of your cooler/freezer

shall be guaranteed only if the earth

system in your house complies with

standards.

Tabla de contenidos

Otros manuales de Refrigerador de Blomberg

Blomberg

Blomberg BRFB 1042 WH Manual de usuario

Blomberg

Blomberg FRM1970A++ Manual de usuario

Blomberg

Blomberg KSM 9660 XA+ Manual de usuario

Blomberg

Blomberg FNT 9683 N Manual de usuario

Blomberg

Blomberg BRFD2650SS5VFLR Manual de usuario

Blomberg

Blomberg KND 9920 PD Manual de usuario

Blomberg

Blomberg BRSBS 2130 Manual de usuario

Blomberg

Blomberg KFI 1290 Manual de usuario

Blomberg

Blomberg KGM4530 Manual de usuario

Blomberg

Blomberg KND 9950 Manual de usuario

Blomberg

Blomberg KFD 9952 PXD Manual de usuario

Blomberg

Blomberg DSM 1510 Manual de lista de piezas

Blomberg

Blomberg BRFB1312SS Manual de usuario

Blomberg

Blomberg KWN 2400XN Manual de usuario

Blomberg

Blomberg KSM 9640 A Series Manual de usuario

Blomberg

Blomberg KWD 9440 X A+ Manual de usuario

Blomberg

Blomberg SOM 9673P Manual de usuario

Blomberg

Blomberg KGM 9690 Manual de usuario

Blomberg

Blomberg KND 9651 A Plus Manual de usuario

Blomberg

Blomberg KNM4563EI Manual de usuario

Blomberg

Blomberg DSM 1510 Manual de usuario

Blomberg

Blomberg DNE 9887 X A+ Manual de usuario

Blomberg

Blomberg SSM 9450 X A+ Manual de usuario

Blomberg

Blomberg SOM 9750 A+ Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
