Dryer

User Manual

TGU490RX0

TABLE OF CONTENTS

1 Important safety and

environmental instructions 4

1.1 General safety .....................................4

1.1.1 Electrical safety .............................5

1.1.2 Product safety................................6

1.2 Mounting over a washing machine......8

1.3 Intended use........................................9

1.4 Child safety..........................................9

1.5 Compliance with the WEEE regulation

and disposing of the waste product.........10

1.6 Compliance with RoHS Directive:......10

1.7 Package information..........................10

1.8 Technical specifications .....................10

2 Your Dryer 11

2.1 Overview............................................11

2.2 Package contents..............................12

3Installation 13

3.1 Appropriate installation location.........13

3.2 Removing the transportation safety

assembly .................................................13

3.3 Connecting to the drain .....................13

3.4 Adjusting the feet...............................14

3.5 Electrical connection..........................14

3.6 Transportation of the dryer ................14

3.7 Changing the illumination lamp ........14

4 Preparation 15

4.1 Laundry suitable for drying in the dryer15

4.2 Laundry not suitable for drying in the

dryer ........................................................15

4.3 Preparing laundry for drying ..............15

4.4 Things to be done for energy saving .15

4.5 Correct load capacity.........................16

5 Operating the product 17

5.1 Control panel .....................................17

5.2 Screen symbols.................................17

5.3 Preparing the dryer............................18

5.4 Programme selection.........................18

5.5 Programme selection and consumption

chart.........................................................19

5.6 Auxiliary functions..............................21

5.7 Warning symbols ...............................22

5.8 Starting the programme.....................23

5.9 Programme progress status ..............23

5.10 Child Lock........................................23

5.11 Changing the programme after it is

started......................................................24

5.12 Cancelling the programme ..............24

5.13 End of programme...........................24

6 Maintenance and cleaning 25

6.1 Cleaning Lint Filter / Loading Door Inner

Surface ....................................................25

6.2 Cleaning the sensor ..........................26

6.3 Draining the water tank......................26

6.4 Cleaning the condenser;....................27

7 Troubleshooting 28

Please read this user manual first!

Dear Customer,

Thank you for prefering a Blomberg product. We hope that your product which has been

manufactured with high quality and technology will give you the best results. We advise you to

read through this manual and the other accompanying documentation carefully before using

your product and keep it for future reference. If you transfer the product to someone else, give

its manual as well. Pay attention to all details and warnings specified in the user manual and

follow the instructions given therein.

Use this user manual for the model indicated on the cover page.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful

hints about usage.

AWarning for hazardous situations

with regard to life and property.

BWarning against electric shock.

Warning against hot surfaces.

Warning against fire hazard.

Packaging materials of the

product are manufactured

from recyclable materials in

accordance with our National

Environment Regulations.

Do not dispose of the packaging wastes with the domestic waste or other wastes, discard

them to the dedicated collection points designated by the local authorities.

EN / 4 Dryer / User Manual

1Important instructions for safety and

environment

This section contains safety instructions that will help protect

from risk of personal injury or property damage. Failure to

follow these instructions shall void any warranty.

1.1 General safety

• The dryer can be used by children at and above 8

years old and by persons whose physical, sensory or

mental capabilities were not fully developed or who

lack experience and knowledge provided that they are

supervised or trained on the safe usage of the product

and the risks it brings out. Children should not play with

the product. Cleaning and maintenance works should not

be performed by children unless they are supervised by

someone.

• Children of less than 3 years should be kept away unless

continously supervised.

• Adjustable feet should not be removed. The gap between

the dryer and the floor should not be reduced with

materials such as carpet, wood and tape. This will cause

problems with the dryer.

• Always have the installation and repairing procedures

carried out by the Authorized Service.Manufacturer

shall not be held liable for damages that may arise from

procedures carried out by unauthorized persons.

• Never wash the dryer by spraying or pouring water onto it!

There is the risk of electric shock!

Important instructions for safety and

environment

Dryer / User Manual EN / 5

1.1.1 Electrical safety

AElectrical safety instructions should be followed

while electrical connection is made during the

installation.

• Connect the dryer to a grounded outlet protected by a

fuse at the value specified on the type label. Have the

grounding installation performed by a qualified electrician.

Our company shall not be liable for any damages that

will arise when the dryer is used without grounding in

accordance with the local regulations.

• The voltage and allowed fuse protection is stated on the

type label plate.

• The voltage specified on the type label must be equal to

your mains voltage.

• Unplug the dryer when it is not in use.

• Unplug the dryer from the mains during installation,

maintenance, cleaning and repair works.

• Do not touch the plug with wet hands! Never unplug by

pulling on the cable, always pull out by grabbing the plug.

• Do not use extension cords, multi-plugs or adaptors to

connect the dryer to power supply in order to decrease the

risk of fire and electric shock.

• Power cable plug must be easily accessible after

installation.

BDamaged mains cable should be changed notifying

the Authorized Service.

BIf the dryer is faulty, it must not be operated unless it

is repaired by an authorized service agent! There is

the risk of electric shock!

Important instructions for safety and

environment

EN / 6 Dryer / User Manual

1.1.2 Product safety

Points to be taken into consideration for fire

hazard:

Below specified laundry or items must not be dried

in the dryer considering fire hazard.

• Unwashed laundry items

• Items soiled with oil, acetone, alcohol, fuel oil,

kerosene, stain removers, turpentine, paraffin or

paraffin removers must be washed in hot water with

plenty of detergent before being dried in the dryer.

For this reason especially the items containing the

above specified stains must be washed very well, to

do this use adequate detergent and choose a high

washing temperature.

Below specified laundry or items must not be

dried in the dryer due to the fire hazard:

• Garments or pillows bolstered with rubber foam

(latex foam), shower bonnets, water resistant

textiles, materials with rubber reinforcement and

rubber foam pads.

• Clothing cleaned with industrial chemicals.

Items such as lighter, match, coins, metal parts,

needle etc. may damage the drum set or may lead to

functional problems. Therefore check all the laundry

that you will load into your dryer.

Never stop your dryer before the programme

completes. If you must do this, remove all laundry

quickly and lay them out to dissipate the heat.

Clothes that are washed inadequately may ignite on

their own and even may ignite after drying ends.

Important instructions for safety and

environment

Dryer / User Manual EN / 7

• You must provide enough ventilation in order to prevent

gases exiting from devices operating with other types of

fuels including the naked flame from accumulating in the

room due to the back fire effect.

AUnderwear that contains metal reinforcements

should not be dried in the dryer. Dryer may be

damaged if metal reinforcements come loose and

break off during drying.

CUse softeners and similar products in accordance

with the instructions of their manufacturers.

CAlways clean the lint filter before or after each

loading. Never operate the dryer without the lint filter

installed.

• Never attempt to repair the dryer by yourself. Do not

perform any repair or replacement procedures on the

product even if you know or have the ability to perform the

required procedure unless it is clearly suggested in the

operating instructions or the published service manual.

Otherwise, you will be putting your life and others’ lives in

danger.

• There must not be a lockable, sliding or hinged door that

may block the opening of the loading door in the place

where your dryer is to be installed.

• Install your dryer at places suitable for home use.

(Bathroom, closed balcony, garage etc.)

• Make sure that pets do not enter the dryer. Check the

inside of the dryer before operating it.

• Do not lean on the loading door of your dryer when it is

open, otherwise it may fall over.

• The lint must not be allowed to accumulate around the

tumble dryer

Important instructions for safety and

environment

EN / 8 Dryer / User Manual

1.2 Mounting over a washing machine

• A fixing device should be used between the two machines

when installing the dryer above a washing machine. The

fitting device must be installed by the authorized service

agent.

• Total weight of the washing machine and the dryer -with

full load- when they are placed on top of each other

reaches to approx. 180 kilograms. Place the products on a

solid floor that has sufficient load carrying capacity!

AWashing machine cannot be placed on the dryer.

Pay attention to the above warnings during the

installation on your washing machine.

Installation Table for Washing Machine and Dryer

Dryer

Depth

Washing Machine Depth

62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm

54 cm Can be installed Can be

installed Cannot be

installed

60 cm Can be installed Cannot be

installed

Important instructions for safety and

environment

Dryer / User Manual EN / 9

1.3 Intended use

• Dryer has been designed for domestic use. It is not

suitable for commercial use and it must not be used out of

its intended use.

• Use the dryer only for drying laundry that are marked

accordingly.

• The manufacturer waives any responsibility arisen from

incorrect usage or transportation.

• The service life of the dryer that you purchased is 10

years. During this period, original spare parts will be

available to operate the dryer properly.

1.4 Child safety

• Packaging materials are dangerous for the children. Keep

packaging materials away from children.

• Electrical products are dangerous for the children. Keep

children away from the product when it is operating. Do not

let them tamper with the dryer. Use the child-proof lock in

order to prevent the children to tamper with the dryer.

CChild-proof lock is on the control panel.

(See Child lock)

• Keep loading door closed even when the dryer is not in

use.

Important instructions for safety and

environment

EN / 10 Dryer / User Manual

1.5 Compliance with the WEEE regulation and disposing of the

waste product

This product complies with EU WEEE Directive (2012/19/EU). This product bears

a classification symbol for waste electrical and electronic equipment (WEEE).

This product has been manufactured with high quality parts and materials which

can be reused and are suitable for recycling. Do not dispose of the waste product

with normal domestic and other wastes at the end of its service life. Take it to the

collection center for the recycling of electrical and electronic equipment. Please

consult your local authorities to learn about these collection centers.

1.6 Compliance with RoHS Directive:

The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not

contain harmful and prohibited materials specified in the Directive.

1.7 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance

with our National Environment Regulations. Do not dispose of the packaging materials

together with the domestic or other wastes. Take them to the packaging material collection

points designated by the local authorities.

1.8 Technical Specifications

* Min. height: Height with adjustable feet are closed.

Max. height: Height with adjustable feet are opened maximum.

** Dry laundry weight before washing.

*** Type label is located behind the loading door.

CTechnical specifications of the dryer are subject to specification without notice to improve the

quality of the product.

CFigures in this manual are schematic and may not match the product exactly.

CValues stated on markers on the dryer or in the other published documentation accompanying

with the dryer are obtained in laboratory in accordance with the relevant standards. Depending

on operational and environmental conditions of the dryer, these values may vary.

Height (Min. / Max.) 84,6 cm / 86,6 cm*

Width 59,5 cm

Depth 60,9 cm

Capacity (max.) 9 kg**

Net weight (plastic front door usage) 39 kg

Net weight (glass front door usage) 41 kg

Voltage

See type label***

Rated power input

Model code

Tabla de contenidos

Otros manuales de Secadora de Blomberg

Blomberg

Blomberg TKF 7454 WE 30 Manual de usuario

Blomberg

Blomberg TKF 8451 SGC 30 Manual de usuario

Blomberg

Blomberg LTH 38420 W Manual de usuario

Blomberg

Blomberg TKF 8431 A Manual de usuario

Blomberg

Blomberg LTS2832W Manual de usuario

Blomberg

Blomberg DV 16540 Manual de servicio

Blomberg

Blomberg LTK2803B Manual de usuario

Blomberg

Blomberg DHP24404W Manual de usuario

Blomberg

Blomberg LTP 2832W Manual de usuario

Blomberg

Blomberg TAF 1330 Manual de usuario

Blomberg

Blomberg DV 17600 W Manual de usuario

Blomberg

Blomberg TROCKNER TKF 7330 A Manual de usuario

Blomberg

Blomberg TKF 7350 Manual de usuario

Blomberg

Blomberg TAF 7239 Manual de usuario

Blomberg

Blomberg LTS2932W Manual de usuario

Blomberg

Blomberg LTK 21003W Manual de usuario

Blomberg

Blomberg TKF 8439 Manual de usuario

Blomberg

Blomberg TKF 8451 Manual de usuario

Blomberg

Blomberg TKF 8451 AG 50 Manual de usuario

Blomberg

Blomberg TKF 8439 Manual de usuario

Blomberg

Blomberg TKF 7431 Manual de usuario

Blomberg

Blomberg DV 16540 NBL00 Manual de instrucciones

Blomberg

Blomberg TKF 8461 AGC Manual de usuario

Blomberg

Blomberg TKF 7451 AG 50 Manual de usuario

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
