BleBox Airsensor Manual de usuario

airsensor

AIR QUALITY INDICATOR

air quality sensor with μWiFi technology

        





        





        





2

1

3

4

You can also set the con guraon using the web browser

of your phone / tablet. Aer connecng to the wireless

network of the controller, turn on the browser and go

to: www.blebox.eu

Disconnect supply voltage circuit before installing the controller. Remember

that any mounng works should be carried out when the main voltage is

disconnected (switch o the mains fuse or disconnect the power supply from

the socket).

The device should be mounted in a place protected from direct adverse

environmental condions, in parcular atmospheric precipitaon. At the

same me, should be paid aenon to ensuring a good air exchange around

the device. Remember that metallic elements (wires, housing parts) have a

negave inuence on the range of the device, and consequently the comfort

of use. It is recommended that the device be mounted in a stable and 

xed posion, correctly oriented (according to the inscripons on the casing),

fastened with screws, wall plugs or by means of a doublesided assembly

tape.

Remove the cover of the device by liing it. Choose a power supply  a 5V

USB connector located on the le side of the device or a 1224V AC / DC

mains adapter connected via wires to a plugin connector located in the right

part of the PCB (polarizaon is irrelevant). Connect the power wire to the

USB connector or plugin connector. Bringing in the power wire outside the

housing through the aperture in the inferior part, replace the housing.

At the boom of the screen there is a table with numerical values of

parculate maer concentraons. Fields with concentraon values PM2.5

and PM10 change its color in relaon to the degree of exceeding the

standard in the color scale presented before, moreover, the percentage value

in relaon to the value of the standard is presented in brackets. For example,

a reading (50%) means that the current air polluon concentraons is only

half of the acceptable value, while the indicaon (300%) means a 3fold

exceedance of the standard. Next to the percentage, the change trend is

also calculated, compared to the average of the last hour of measurements.

The trend is indicated by an up, down arrow or a horizontal line in the case

that no changes have been registered, it is only displayed aer the sensor’s

working one hour.

At the very boom of the screen is presented the status of measurements

on the device. “”Last measurement”” means that the device displays

a measurement taken within a me not exceeding 10 minutes.

The device automacally performs another measurement every 10

minutes and displays the last air polluon concentraons value. This

behavior is dictated by the care of the sensor’s lifeme due to the fact the

air polluon slowly changes over the me. It is also possible to manually

force the measurement. To do this, press the “”Refresh”” icon (two arrows)

in the upper right part of the screen. Within the rst 20 seconds shows

the status “”Measurement in progress””, which next will be change to

“”Current measurement”” and the concentraon values will be updated.

To switch the device into connuous measurement mode, in which

measurements are taken every 1 second, hold down the “”Refresh”” icon for

over 3 seconds. The icon background will turn gray and the device will start a

connuous measurement, the device will start the connuous measurement,

which will last unl the moment it returns to the main screen of the

applicaon or the browser page is closed. Leaving the device in connuous

measurement mode, should remember about the lifeme of the measuring

system, esmated at approx. 8000 hours.

Historical measurement data are only available for sensors mounted outside,

congured in remote access mode, with a correctly set locaon and they are

stored only on BleBox servers. They are available by clicking on the diagram

icon in the upper right corner of the screen.They are also presented on the

map available on blebox.eu

Go to „Sengs” (icon in the upper right corner of the screen). In the “Main

sengs” secon, you can change the device name which is visible in the

wBox applicaon. The opon “Signal LED on” allows you to turn on the LEDs

built into the device.

In order to communicate with a device being out of the local WiFi network,

from anyplace in the World, via wBox applicaons, must be set to “”Yes”” the

opon “”Enable remote access””. Seng this opon to “”Yes”” also means

giving consent for the sending of the measurement data to a public map of

the air polluon available on the web page blebox.eu and the archiving of

this data together with its locaon. Seng the “”No”” opon will result in the

lack of the access to the controller when it is out of the local network and

the lack of access to historical data  only the current values will be visible.

Seng the “Enable event log” opon to “Yes” will cause the device to record

events (e.g. sending the nocaon set in the “Acons” secon) in the

BleBox cloud system. This allows the history of the events to be viewed later

also when the controller is oine.

Turn on the device by switching on the power supply voltage (switching on

the main power supply circuit fuse or connecng the power supply to the

socket). The device will turn on the LEDs on white color for a few seconds

and then will change into a color depending on the air quality. Connuous

lighng in white color indicates the sensor error, which is also signaled by the

red status visible in the wBox applicaon (more informaon about the wBox

applicaon later in the manual). In this case, check the wire connected to the

sensor circuit board.

Download thIf you have an Android mobile device,

you will  nd the applicaon in the Play Store. For iOS devices the applicaon

is in the App Store.

By using your mobile phone or tablet, connect it to the device wireless

network. To do this, enter to your smartphone or tablet sengs, then go

to seng of the WiFi network and nd the network named „airSensor

xxxxxxxxxx” where xxxxxxxxxx is the serial number of the device. Connect

to this network.

Open the wBox applicaon. A device will appear at the top of the screen. To

add it to the applicaon, click on “+” on the right side of the name. To pre

congure the controller, click on the default device name.

The main controller screen shows current informaon from the air quality

sensor. Air quality is determined based on the measurement of parculate

maer concentraons PM2.5 and PM10 and is shown the worst value of

both. The current state of air quality is displayed in the upper part of the

screen in a colored icon and also in word status, and is signaled by colored

LEDs built into the device and it shows in the following way:

WARNING!

Never connect at the same me power to the USB

connector and to the plugin connector. It may cause

damage to the device.

very good (intense green color)

good (light green)

moderate (light yellow)

sucient (orange color)

bad (bright red)

very bad (intensive red)

user manual

very good

good

moderate

sucient

bad

very bad

7





The “Make geolocaon coarse for sensor data” opon helps you maintain

privacy if you do not want your device to be located on the air polluon map

with high precision.

In the “”Sensor sengs”” secon, select the place of its installaon

 outside or inside the building (measurement of indoor air quality).

It is possible to turn o the table with the numerical values of parculate

maer concentraons on the main controller screen by seng the “Detailed

view” opon to “No”. Then only an icon with a descripon will be shown.

The controller allows you to send control commands to other controllers of

the wBox series via the WiFi network through the API. Each acon will be

deployed on parcular trigger, eg. change of air quality level.

When eding acons select “Control other device” as the “Acon type”,

select “Value greater/worse than or equal to”, “Value less/beer than or

equal to”, “Air quality level change” as the “Trigger”. Select “Value type”  a

specic value of parculate maer (PM1, PM2.5 or PM10) or air quality level

(for PM2.5, PM10 or worse of them). In the “Value” eld enter or select from

the list the border value aer which the acon is to be called once. Selecng

the “Trigger periodically” opon will trigger the acon every me specied

in the “Interval in minutes” eld for the enre period of the exceeded value.

Click on the “Select device” buon. The controller will search the network for

compable devices and display them in a list. Select the device you want to

control and click the “Select” buon. If the device is not listed you must use

the general API control method described further.

Then in the “Call API” eld enter the API command that the driver will call.

The most popular API commands for shuerBox and wLightBox are

presented below. It was assumed that the IP address of the device which will

be controlled is: 192.168.1.123

If the device was not on the found list or you want to control another device

in the network, select “Call URL” as “Acon type”.

In the “URL” eld, enter the API command preceded by the hp protocol

prex and the IP address of the wBox device which will be controlled. The IP

address can be found in the device sengs. Cauon! All the controllers must

be in the same subnet, usually the subnet of a home router.

Conrm the entry with the “Save” buon.

A detailed descripon of how to control other controllers of the wBox series

is available in the “Extended instrucons for wBox devices”, while all the

technical documentaon API of the wBox controllers is available at: hp://

technical.blebox.eu

The controller allows you to display a system nocaon on a phone with

the wBox applicaon installed on the parcular trigger, e.g. to change the

air quality level.

Nocaons are added similarly to “Acons”  as “Acon type” select

“Nocaon / Event log” ll in the remaining elds of the form and conrm

with the “Save” buon.

In order for the nocaon to be displayed on the phone it is necessary

to allow the controller to display nocaons. Go to the main menu of the

wBox applicaon, to the “Nocaons” tab. Then go to the sengs (the

“Sengs” icon in the upper right corner of the screen). Find the device on

the list and select “Acon nocaon” from the dropdown list next to the

device name. You can also select other types of available nocaons or

μPortal nocaons. Conrm the change of preferences with the “Save”

buon in the upper right corner of the screen.

If nocaons are not displayed despite their conguraon check in the

phone system sengs (Android / iOS) whether the wBox applicaon is

authorized to display system nocaons.

5

6

Opening the window by the shuerBox: hp://192.168.1.123/s/u

Closing the window by the shuerBox: hp://192.168.1.123/s/d

Change LED strip color to red by the wLightBox: hp://192.168.1.123/s/

000000

Change LED strip color to yellow by the wLightBoxx:

hp://192.168.1.123/s/0000

Change LED strip color to green by the wLightBox: hp://192.168.1.123/

s/000000

Go to “Connect to WiFi network” secon, where you can connect the device

to the WiFi home network to be able to connect to it via it or from anyplace

in the world. To do this, select the network name from the list and press

“Connect”. If required, enter the WiFi network password. When connecng

the device to the home network, the phone / tablet may be disconnected

from the device’s network.

Aer compleng the WiFi network conguraon, you can disconnect from

the device network and connect the phone / tablet directly to your home

WiFi network. Control from the wBox applicaon will work in the same way

as when the phone / tablet is connected to the device’s network. If as a

user you leave the local network, eg leaving your home or enclosing mobile

data, the wBox applicaon will signal this status as “Remote mode”. In this

case, you will have access to the device data, but for security reasons sengs

opons will not be available.

In the “”Access point sengs”” secon, you can change the name and give

the password of the WiFi network emied by the device. Remember that

changing the network name or password can cause disconnecon with

the device immediately aer clicking the “”Save”” buon, so you should

reconnect to the WiFi network.



1224V AC/DC through a plug

in conector or 5V via micro USB

connector

 max 2W

 less than 1W



PM1: 0,31,0µm,

PM2.5: 1,02,5µm,

PM10: 2,510µm

 laser, PMS5003

 50% for parcles with a size of 0,3 μm,

98% for size parcles >=0,5 μm



 10 sec

 1 μg/m³

 every 10 minutes or on demand

 for PM2.5, 0500 μg/m³

 71 x 71 x 27 mm

 from 20 to + 50°C protect of the

direct sunlight

 screws, wall plug or doublesided

adhesive tape

 0.99%

 IP32, mounng in a place protected

from rain

 numeric and graphic indicator in wBox

applicaon, changing LED colors

 μWiFi, compable with WiFi, 802.11g



1224V AC/DC through a plug

in conector or 5V via micro USB

connector

 2.4 GHz

 bidireconal, encrypted

 open



direct connecon (as Access Point),

WiFi connecon via a standard router,

connecon with access from any loca

on in the world (requires only access

to the Internet)



Apple iPhone, Apple iPad, iPad Mini,

Android, computers and mobile devices

supporng HTML5

 WPA2PSK and authencated encryp

on with associated data (AEAD)









www.blebox.eu

made in Europe

For more informaon visit our website

Or send us an email to: info@blebox.eu

Support is available at support@blebox.eu

To be able to use historical air quality data, it is necessary to set the clock

and locaon of the device. Go to the “”Device me”” secon of the sengs

and then click “”Change zone””. Select your region and locaons from the

list, conrming your selecon with the “”Save”” buon. The device will

synchronize its me with the me server (if the controller is in a WiFi network

with Internet access) or it will download me from the phone/tablet.

Next, in the “Device locaon” secon, click “Set locaons”. The applicaon

/ browser will ask whether to share locaons  allow. In the “Coordinates”

eld, the approximate coordinates of your locaon should appear. If the “Set

locaons” buon blinks red with the word “error” or the “Coordinates” eld

did not change the value from “Not set” to numeric data, a failure occurred in

the locaon download. You should then make sure that the phone / tablet has

a GPS module and that the locaon sharing support is enabled on the phones

To update the soware in the controller, connect it to your home WiFi network

(see “”Access Point and WiFi sengs”” secon) which is connected to the

Internet. Go to “Sengs” (icon at the topright corner of the screen) and

click the “”Get new rmware”” buon in the nal secon on sengs. Wait about

1 minute, do not close the interface and don’t perform other acons. The

device will download the latest soware. The soware version number,

hardware version and device idener can be read at the boom of the

sengs screen.

Otros manuales de Accesorios de BleBox

BleBox

BleBox Tempsensorpro Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario

BleBox airsensor Manual de usuario

Manuales populares de Accesorios de otras marcas
