Blaupunkt Voss Manual de usuario

CONTENTS

Content----------------------------------------------------------------------------------------------------------------------------1

Introduction-----------------------------------------------------------------------------------------------------------------------1

Safety Instructions------------------------------------------------------------------------------------------------------------- 2

Your VOSS----------------------------------------------------------------------------------------------------------------------3-4

Getting Started------------------------------------------------------------------------------------------------------------------5

Operating Instructions-------------------------------------------------------------------------------------------------------6-7

Troubleshooting/Technical Speciﬁcations----------------------------------------------------------------------------------8

Thank you for buying Blaupunkt VOSS.The following instructions will assist you in operating all the

features of this product.

snoitcurtsniehtdaerotemitehtekatesaelptub,tinuralimisagnisuhtiwrailimafebydaerlayamuoY

relevant for your model.

Your safety is very important, so please ensure you read the safety instructions before you operate

this unit.

This VOSS has been designed to give you many years of trouble -free service.In the unlikely

service engineers on thedeifilauqruofoenollacesaelp,yllamronkrowotsliaftcudorpruoytahttneve

free warranty line -1300 055 518 .

INTRODUCTION

Warranty---------------------------------------------------------------------------------------------------------------------------9

Safety Instructions

Please ensure that you read all of the safety instructions before using this unit.

Safety Considerations

Cleaning

Servicing

Position the power cable and other connected cables so that they are not likely to be walked

on, pinched or where items can be placed on or against them.

Do not use the unit in humid or damp conditions.

Do not allow the unit to get wet.

Never allow children to insert foreign objects into holes or slots on the unit.

The ventilation should not be impeded by covering the openings with items such as news-

papers, table cloths, curtains, etc. This may cause overheating.

No naked ﬂame sources, such as lit candles, should be placed on the unit.

Do not expose the unit to dripping or splashing, and no objects ﬁlled with liquids , such as

vases ,they should not be placed on the unit.

Do not place the unit in closed bookcases or racks without proper ventilation.

Disconnect the unit from the mains supply before cleaning.

Do not use any liquids or aerosol cleaners, as this may damage the unit. Use a soft, dust

free cloth.

There are no user serviceable parts in the unit. When servicing, refer to qualiﬁed service

personnel.

Consult your dealer if you are ever in doubt about the installation/operation/ safety of

the product.

AUX IN

Your VOSS

DC 5V OUT

1. POWER

Turn the unit on/oﬀ

2/3. VOL-/VOL+

Press to adjust the volume level.

4. MODE

Press to select Bluetooth/Aux In input.

5. DC 5V OUT

Connect an iPod/iPhone/iPad through an Apple USB cable (no supplied).

6. DC 10V IN

DC input jack.

7. AUX IN

Use 3.5mm audio cable(no supplied) to connect to audio device.

Your VOSS

1 2 3 4

Connections and Controls

MODE

AUX INDC 10V INDC 5V OUT

Connect to the power

Getting Started

1.Connect the power adaptor provided to the unit. The unit is in Standby mode, When

recharge the unit’s built-in batteries,the white LED is blinking on left side of unit’s top.

When fully charged, the white LED will turn oﬀ .

2.Press POWER button on the top to turn the unit on, the unit into bluetooth mode.

3.Bluetooth is pairing, and blue LED is blinking on right side of unit’s top, After successful

connection, the blue LED will be stayed without blinking.

4.After the unit is turn on, Press MODE button, the unit into AUX IN input mode. and red

LED is lighting on right side of unit’s top.

5.To turn the unit to standby again, press POWER button again.

MODE

When recharge the unit’s built-

in batteries, white LED is blinking.

When fully charged, the white

LED will turn oﬀ.

In bluetooth mode, When blue

LED is blinking, Bluetooth is pairing.

When into AUX IN mode, the red LED

is lighting.

After successful connection, the blue

LED will be stayed without blinking.

Operating Instructions

1. Connecting to A Bluetooth Device

Bluetooth

Devices

VOSSNot Connected

10M

Before playing your speaker it must be paired and connected to the Bluetooth source you are using.

This may be a mobile phone or Bluetooth equipped laptop etc.

Pairing with a Bluetooth device:

• Switch on the speaker.

If there is no Bluetooth source paired to the speaker, the Status indicator will blinking blue.

• Activate Bluetooth on the source.

If the source is a phone, Bluetooth will normally be activated in the connectivity section of the settings

menu.

If the source is a computer, Bluetooth settings should be found in the Control Panel.

• In the Bluetooth menu of the source, there should be an option to search for Bluetooth devices.

Select this option.

The source will now scan for other Bluetooth devices and should ﬁnd the speaker, identiﬁed as ‘VOSS’.

• Choose to pair with this.

If the device features Bluetooth technology earlier than V2.1, you will be asked for a password. If so,

enter 0000.

Your Bluetooth source will now be connected to the speaker. Once connection has been established,

the Status indicator will light steady blue.

After pairing for the first time, the speaker will appear in the connection menu of your Bluetooth device.

Re-connecting:

Your device and the speaker should re-connect when next used if no other device has been connected

to the speaker.

NOTE: You cannot play phone calls via your speaker.

Operating Instructions

AUX IN

2. Play Music From Aux-in

3. Charging/powering mobile devices

The AUX IN jack may be used to connect sources that do not have Bluetooth connectivity. AUX

sources may include -

• Personal audio players

• Personal computers or laptops

Connecting to the AUX In jack:

• Connect the stereo 3.5mm jack cable (not supplied) between the headphone or LINE/AUX output

of the personal audio player and the AUX IN jack on the back panel of VOSS unit.

• Press the MODE button to switch to AUX mode.The Status indicator will light steady red.

• Set your personal audio player/computer to PLAY.

• Set the listening volume to the level you want with the volume control on the speaker.If there is no

sound or if the volume level is not loud enough, you may need to increase the volume setting on the

source.

• When you have ﬁnished listening to the AUX source, disconnect the source and the jack cable.

• Press the MODE button to switch back to Bluetooth mode.

You can charge or power mobile devices that have a USB charging cable from the USB port on the

back of your VOSS unit.

• Connect the charging cable (not supplied) from the mobile device to the USB port on the back

panel of the VOSS. The device will charge from the internal power in the speaker.

NOTE: It is not possible to play USB MP3 ﬂash players or ﬂash drives via the USB port.

CAUTION: Do not charge a mobile device when you are playing an AUX source.

The VOSS unit cannot charge a mobile device via USB port without connect AC adaptor.

DC 5V OUT

All electrical and electronic products must not be disposed of with household

waste. Please refer to the retailer from whom you purchase this item for

disposal instructions.

Packaging materials can be recycled using your local collection facilities.

Warning/Troubleshooting/Technical Specifications

If a fault occurs, first check the points listed below before taking the set for repair.

If you are unable to remedy a problem by following these hints ,consult you retailer or

service centre.

WARNING: Under no circumstances should you try to repair the set

yourself ,as this would void your guarantee.

Troubleshooting

Technical specification

PROBLEM POSSIBLE REMEDY

No power

No AUX input sound

1. AC adaptor in not connected.

2. The Bulit-in batteries no power.

1. Connect the AC adaptor properly.

2. Connect the AC adaptor to charge

1.Volume may not be adjusted.

2.Power is not correctly connected.

3.3.5mm cable not connected correctly.

1. Increase the volume level.

2.Connect the AC adaptor connect

properly.

3.Connect 3.5mm cable connect.

Unit not in Bluetooth mode.

Audio device not open Bluetooth mode.

3. Unable to pair with the unit.

1.turn unit into Bluetooth mode.

2.Open audio device Bluetooth mode.

3.Setthe speaker to Standby, and

close Bluetooth device’s Bluetooth

mode, then switch them on again.

Re-try connection.

No Bluetooth

1.The unitpower supply by built-in Batteris.

Charging cable is not correctly

connected.

1.Connect the AC adaptor properly.

2.Connect the charging cable properly

Bluetooth Standard :Bluetooth V3.0+EDR

Transmission Power: CLASS 2dBm

Bluetooth Frequency Range: 2.402GHz-2.480GHz

Wireless Transmission range: 10Metre

Supply Voltage: DC 10V 2A

Built-in Rechargeable Batteries: DC7.4V/1000mAh

Can not Charging other

devices via USB 5V out

PO BOX 6287

Silverwater NSW 1811

Warranty: 1300 055 518

www.bushaustralia.com.au

Warranty

Please keep your receipt as proof of purchase. This products is warranted for any defect in

materials or workmanship for 1year after the original date of purchase. This product is for

normal domestic & oﬃce use only.

This warranty does not cover damage from misuse or neglect, accidental damage, vermin

infestation,excessive voltages such us lightning or power surges or any alternation that

aﬀects the performance or reliability of the product.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.

You are entitled to replacement or refund for a major failure& for compensation for any other

reasonably foreseeable loss or damage. You are also entitled to

have the goods repaired or replaced if the goods fail to be of acceptable quality & the failure

does not amount to a major failure.

In the unlikely event that your product fails to work normally, please contact the Warranty on

1300 055 518 and have you receipt of purchase on hand.

This guarantee is subject to the following provisions:

It is only valid within boundaries of the country of purchase.

The product must be correctly assembled & operated in accordance with the instructions

contained in the manual.

This product must be use solely for domestic purposes.

The guarantee does not cover accidental damage.

The guarantee will be rendered invalid if the product is resold or has been damaged by

inexpert repair.

The manufacturer disclaims any liability for incidental or consequential damaged.

This guarantee is in addition to ,& does not diminish, your statutory or legal rights.
