Blastrac 655DC Manual de usuario

Operating Instructions

655DC

MAN-655DC-EN

Technical data

Safety instructions

General

Transport

Initial operation

Operation

Maintenance

Electrical systems

Fault diagnosis

Spare parts

Design and specifications are subject to

change without notice - February 2005

Blastrac BV

Utrechthaven 12

3433 PN Nieuwegein

THE NETHERLANDS

T +31(0)30 - 601 88 66

F +31(0)30 - 601 83 33

E [email protected]

I www.surfacepreparation.com

Nieuwegein

655DC Operating Instructions

Technical data

Contents Chapter 1

1.1 Rating

1.2 Unit specifications

1.3 Operative range and correct usage

1.4 Stand-by power supply

1.5 Machine type designation

Operating Instructions 655DC

Technical data

1.1 Rating

Unit / designation: Blastrac dust collector

Machine type 655DC

Manufacturer

Blastrac BV

Utrechthaven 12

NL-3433PN Nieuwegein

THE NETHERLANDS

T +31(0)30 - 601 88 66

F +31(0)30 - 601 83 33

E [email protected]

I www.surfacepreparation.com

655DC Operating Instructions

Technical data

1.2 Unit specifications

Technical data

655DC

Dust collector 50 Hz 60 Hz

Power consumption

Screw conveyor

Power consumption

Fan / compressor

5,5 kW 6,4 kW

Power consumption

Dust collector

5,5kW 6,4kW

Input current Screw

conveyor

- -

Input current Fan /

compressor

max.11A max.11A

Input current Dust

collector

- -

Rated speed

Compressor

1080 min-1 1100 min-1

Rated speed Fan 4440 min-1 4530 min-1

Enclosure

Compressor

IP 54

Enclosure Fan IP 54

Connected loads 400V, 50Hz,

63A CEE Plug

440V, 60Hz,

60A UL Plug

Dust hose

connection

Ø 130 mm / Ø 150 mm

Dust hose length 20 m

Pressure adjusting

Compressor

6-7 bar

Pressure differential

Filter surface (MAX)

50-150 mm/WS

2-6 inch/ WG

Dedusting interval 15 s

Airflow 1250 m³/h

Connected loads (electrical system):

The indicated input current values correspond to the nominal current

values of the motors working under full load. These values are not

achieved under normal operating conditions.

Operating Instructions 655DC

Technical data

Dimensions:

Dust collector 655DC

Length 1730 mm

Width 800 mm

Height 1350 mm

Weight 650 kg

1.3 Operative range and correct usage

The dust collector 655DC is exclusively designed to

be used with Blastrac equipment only.

It is designed to vacuum dry dust specified to be

Class L. (E DIN IEC 61J/94 CD)

The Filter material FA 6176 is certified to DIN/EN

DUST CLASSIFICATION CLASS L and M.

Do not use this equipment on applications where

you expect dust that is classified to be harmful. If

you feel uncertain ask local authorities for

assistance.

The manufacturer will not be liable for damage

resulting out of from incorrect use.

In these cases the user assumes all risks.

Dust collector 655DC:

The dust collector 655DC is exclusively designed to be used with the

blast cleaning machines sizes 1-10, 1-15, 2-20, 350 and 350VH.

655DC Operating Instructions

Technical data

1.4 Stand-by power supply (Generator)

If the dust collector 655DC is operated using a

generator, this generator must be operated in

accordance with the current VDE directives (this

applies to the protective earth conductor in

particular) in order to ensure that all safety devices

are functioning and to eliminate possible damage to

electrical components.

1.5 Machine type designation

number of filter

5.5 kW motor powe

Dust Collecto

6 - 55 DC

Operating Instructions 655DC

Technical data
