Blanco BFID3458X Manual de usuario
Dishwasher
Instruction
InstructionInstruction
Instruction Manual
Manual Manual
Manual
BFID3458X
CONTENTS
•Technical specifications …………………………………………………….. 4
•Conformity with the standards and Test data …………………………….. 4
Safety information and Recommendations………………………………….. 5
•Recycling .......………………………......................................................... 5
•Safety information …………………………………………………………… 5
•Recommendations …...……………………………………………………… 8
•Items not suitable for dishwashing ………………………………………… 9
Installing the machine ………………………………………………………….. 9
•Positioning the machine …………………………………………………….. 9
•Water connections …………………............................................................... 10
•Water inlet hose ….………………………………………………………….. 11
•Water outlet hose …..……………….............................................................. 12
•Electrical connection………………………………………………………… 13
•Fitting the machine undercounter …………………………………………. 14
1
•Prior to using the machine …………………………………………………. 16
•Detergent usage ……………………........................................................ 16
•Filling the detergent compartment…………………………………………. 16
•Combined detergent….……………………………………………………… 16
•Filling with rinse aid and making the setting………………………………. 17
Preparing the machine for use ………………………………………………… 16
Loading your dishwasher .……………………………………………………. 18
•Alternative basket loads …………………………………………………... 22
Switching on the machine and selecting a programme……………........ 27
•Switching on the machine…………………………………………………. 27
•Programme follow-up ……………………………………………………… 27
•Changing a programme …………………………………………………… 27
•Changing a programme with resetting …………………………………... 28
•Switching the machine off ….……………………………………………... 28
Maintenance and Cleaning ........................................................................ 29
•Filters ..……………………………………………………………………… 29
•Spray arms …………………………………………………………………. 30
•Hose filter …………………………………………………………………… 30
Failure codes and what to do in case of failure ………………………… 31
Practical and useful information……......................................................... 33
2
Programme descriptions .…………………………………………………….. 24
•Programme items ………………………………………………………….. 24
Getting familiar with your machine …………………………………………… 25
3
1. Upper basket with racks
2.
Upper spray arm
3. Lower basket
4.
Lower spray arm
5. Filters
6. Rating plate
7.
Control Panel
8. Detergent and rinse-aid dispenser
9.
10.
Upper basket track latch
Upper Cutlery Basket
1
2
3
4
5
6
7
8
9
10
Ceiling Spray Arm: It provides
better washing for the dishes at
upper basket.
11
12
Turbo Drying Unit: Thissystemprovides
better drying performance for your dishes.
4
Capacity 1 place settings
Height 820 mm - 870 mm
Width 598 mm
Depth 550 mm
Net Weight 38 kg
Electricity input 220-240 V, 50 Hz
Total Power 1900 W
Heating Power 1800 W
Pump Power 100 W
Drain Pump Power 30 W
Water supply pressure 0.03 MPa (0,3 bar)-1 MPa (10 bar)
Current 10 A
Technical specifications
5
SAFETYINFORMATIONANDRECOMMENDATIONS
Recycling
• Certain components and the packaging of your machine
have been produced from recyclable materials.
• Plastic parts are marked with international abbreviations:
(>PE< , >PS< , >POM<, >PP<, )
• Cardboard parts have been produced from recycled paper
and they should be disposed of into waste paper collection
containers for recycling.
• Such materials are not suitable for being disposed of into
garbage bins. They should be delivered to recycling centres
instead.
• Contact relevant centres in order to obtain information on
methods and points of disposal.
Safety Information
When you take delivery of your machine
• Check for any damage to your machine or to its packaging.
Never start a machine damaged in any way, make sure to
contact an authorised service centre.
• Unwrap the packaging materials as indicated and dispose
of them in accordance with the rules.
The points to pay attention during machine installation
•Choose a suitable, safe and level place to install your
machine.
• Carry out the installation and connection of your machine by
following the instructions.
•This machine should be installed and repaired by an
authorised service person only.
• Only original spare parts should be used with the machine.
• Before installing, be sure that the machine is unplugged.
6
according to the regulations.
on the rating plate.
stand on the electricity supply cable.
a connection. The plug should be comfortably accessible
after the machine has been installed.
for the first time.
In daily use
other purpose. Commercial usage of the dishwasher will void
the guarantee.
your machine anything other than those detergents and rinse
aids which are produced specifically for dishwashers.
Blanco will not be responsible for any damage that might
occur in your machine otherwise.
- Staff kitchen areas in shops, offices and other working
environments;
- Farm houses;
- By clients in hotels, motels and other residential type
environments;
- Bed and Breakfast type environments.
Do not stand on, sit on or place heavy loads on the open
door of this dishwasher, as it may fall over ordamage the door.
The waste water from this appliance is not drinkable.
7
• Do not put into your machine those items which are not
suitable for dishwashing. Also, do not fill any basket above its
capacity. Blanco will not be responsible for any scratch
or rust to form on the inner frame of your machine due to
basket movements otherwise.
• Because hot water may flow out, the machine door
should not be opened under any circumstances while the
machine is in operation. In any case, a safety devices
ensures that the machine stops if the door is opened.
• Please do not leave the door open as this will cause a
.
• Place knives and other sharp-ended objects in the cutlery
basket in blade-down position.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
• Due to danger of explosion, do not put into the machine’s
washing section any chemical dissolving agents such as
solvents.
• Check whether plastic items are heat-resistant before
washing them in the machine.
Young children should be supervised to ensure that they
do not play with the appliance.
•
•The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervised or instruction concerning the use of the
appliance by a responsible person for their safety.
8
For your children’s safety
packaging material is out of reach of children.
because there may still be residues of cleaning substances
inside the machine.
your children. Children are known to have gotten themselves
locked in old machines. To forestall such a situation, break
your machine's door lock and cut off the power plug.
In case of malfunctioning
by qualified persons. Any repair work performed by anyone
other than the authorised service personnel will cause your
machine to be left outside the scope of warranty.
machine is cut off from the mains.Switch off the power and
unplug the machine.Do not pull by the cable when unplugging.
Make sure to turn off the water tap.
Recommendations
your dishes before placing the dishes into the machine. Start
your machine after having fully loaded it.
opened at the end of the program. Do not force to close the
door to avoid damaging the auto door mechanism.
The door must be open during 30 minutes to get effective
drying.( in models with auto door opening system )
Warning: Do not stand in front of the door after the signal
sounds for the auto-open.
9
Items not suitable for dishwashing:
• Cigarette ashes, candle leftovers, polish, paint, chemical
substances, iron-alloy materials;
• Forks, spoons and knives with wooden or bone, or ivory or
mother-of-pearl handles; glued items,items soiled with abrasive,
acidic or base chemicals.
• Plastic items that are not heat-resistant, copper or tin-coated
containers.
• Aluminium and silver objects (they may discolour, become
dull).
•Certain delicate glass types, porcelains with ornamental
printed patterns as they fade even after the first wash; certain
crystal items as they lose their transparency over time,
adhered cutlery that is not heat-resistant, lead crystal glasses,
cutting boards, items manufactured with synthetic fibre;
• Absorbent items as sponges or kitchen rags are not suitable
for dishwashing.
Warning:Take care to buy dishwasher-proof sets in your
future purchases.
INSTALLING THE MACHINE
Positioning the machine
When determining the place to put your machine on, take
care to choose a place where you can easily load and unload
your dishes.
• Use the pre-wash programme only whenever necessary.
• Place such hollow items as bowls, glasses and pots into the
machine in such a way that they will face down.
• You are recommended not to load into your machine any
dishes different or more than indicated.
