Blackweb BWA18AV007 Manual de usuario
6-Device
User Guide
v1.0 (2018)
BWA18AV007
with wireless audio transmitter
and stereo headphones
AMP
PROGRAM
AUX
INPUT
FAV
ENTER
123
456
7 8
0
9
+ +
CH
SAT/CBL STREAMTV
BRAY/DVD
GUIDE
VOL CH
MENU
BACK
APPS
EXIT
OK
A B C D
INFO
TABLE OF CONTENTS
UNIVERSAL REMOTE CONTROL
• GETTING STARTED (BATTERIES)
• IN THE BOX
• GETTING STARTED (BUTTONS)
• PROGRAMMING YOUR REMOTE (DIRECT CODE ENTRY)
• PROGRAMMING YOUR REMOTE (AUTO CODE SEARCH)
• FAVORITE CHANNELS
• VOLUME LOCK
• CHANNEL LOCK
• CODE IDENTIFICATION & FACTORY RESET
WIRELESS AUDIO TRANSMITTER
• ABOUT PRIVATE LISTENING
• GET TO KNOW YOUR AUDIO TRANSMITTER
• HOW TO SETUP YOUR AUDIO TRANSMITTER
• OTHER CONNECTION OPTIONS
• PRIVATE LISTENING THROUGH YOUR REMOTE
• TROUBLESHOOTING
• FCC INFORMATION
• LIMITED 90-DAY WARRANTY
02
03
04
06
09
10
11
12
13
14
15
16
18
20
23
25
26
01
GETTING STARTED BATTERIES
Thank you for choosing the Blackweb Universal Remote Control and
Wireless Audio Transmitter. This remote control can operate a wide range
of electronic devices, works across most brands and models, and comes
pre-programmed to operate many Samsung TVs (see the Programming
Your Remote sections if your device is not compatible). Your remote can
control up to 6 devices and is remarkably easy to set up. To get started,
please install two AA alkaline batteries (not included) as shown below.
Installing the Batteries
1. Remove the battery cover.
2. Insert the batteries as shown.
3. Snap the battery cover back into
place.
Battery Precautions
• Do not mix old and new batteries.
• Do not mix alkaline, standard
(carbon-zinc) or rechargeable
(nickel-cadmium) batteries.
• Always remove old, weak or worn-
out batteries promptly and recycle
or dispose of them in accordance
with local and national regulations.
Low Battery Indicator
If while using the remote, the
button’s red indicator light flashes
3 times, this indicates the batteries
need to be replaced. Please replace
the batteries as soon as possible
when this indication occurs.
Code Saver
When changing the batteries of your
remote, please do so quickly. You
have up to 20 minutes to change the
batteries in your remote without
losing the programmed codes.
Battery Saver
To conserve battery power, the remote will automatically turn off if any
button is pressed for more than 60 seconds (except during programming).
This feature is helpful in the event that the remote is stuck in a location
where the buttons remain depressed, such as between sofa cushions.
Battery Cover
Your remote control’s model number
can be found in the battery compartment
Two AA
alkaline
batteries
(not included)
Model: BWA18AV007 (PCL-1)
Customer Support: (877) 907-7010
Made in China
02
IN THE BOX
AMP
PROGRAM
AUX
INPUT
FAV
ENTER
123
456
7 8
0
9
+ +
CH
SAT/CBL STREAMTV
BRAY/DVD
GUIDE
VOL CH
MENU
BACK
APPS
EXIT
OK
REMOTE CONTROL
AUDIO TRANSMITTER
USER GUIDE RCA/3.5MM
AUDIO CABLE
STEREO HEADPHONES
USB CHARGER
6-Device
User Guide
v1.0 (2018)
BWA18AV007
with wireless audio transmitter
and stereo headphones
AMP
PROGRAM
AUX
INPUT
FAV
ENTER
123
456
7 8
0
9
+ +
CH
SAT/CBL STREAMTV
BRAY/DVD
GUIDE
VOL CH
MENU
BACK
APPS
EXIT
OK
A B C D
INFO
03
GETTING STARTED BUTTONS
NOTE: Some of the buttons on the remote may not be supported by your device.
AMP
PROGRAM
AUX
INPUT
FAV
ENTER
123
456
7 8
0
9
+ +
CH
SAT/CBL STREAMTV
BRAY/DVD
GUIDE
VOL CH
MENU
BACK
APPS
EXIT
OK
POWER INPUT
DEVICE
CATEGORIES
GUIDE
PROGRAM
MENU
APPS
3.5MM
HEADPHONE JACK
NAVIGATION
OK
BACK
MUTE
(HEADPHONES)
VOLUME
(HEADPHONES)
EXIT
A, B, C, D
BUTTONS A B C D
VOLUME
CHANNEL
MUTE
INFO
PREVIOUS
CHANNEL
VIDEO
PLAYBACK
CONTROLS
NUMBER
KEYPAD
FAVORITE
CHANNELS
INFO
04
POWER
Turns your device On/Off and also serves as an
indicator when the remote is being programmed
INPUT
Switches between the sources connected to your TV
DEVICE CATEGORIES
Use these buttons to select the device you want
to control
PROGRAM
Use to put your remote in programming mode
GUIDE
Use to access the guide of satellite and cable
set-top boxes
APPS
Use to access your smart TV’s apps (if supported)
BACK
Return to the previous menu or screen
A, B, C, D BUTTONS
Use to access device shortcuts for additional
features or custom apps on your device (if supported)
INFO
Use to access on-screen content description and
information
TV
BRAY/DVD
SAT/CBL
AMP
STREAM
AUX
PROGRAM
GUIDE
INPUT
BACK
A B
C D
APPS
INFO
05
PROGRAMMING YOUR REMOTE DIRECT CODE ENTRY
Press and hold the button
until the button lights up red.
The button’s red indicator light
remains on.
Programming your remote is as easy as 1, 2, 3
Before beginning, please make sure that the device you want to control
is powered on and follow these three simple steps.
NOTE: Press to exit at any time.
NOTE: The Blackweb universal remote comes pre-programmed to operate
many Samsung TVs.
1.
PROGRAM
PROGRAM
AMP AUX
SAT/CBL STREAMTV
BRAY/DVD
INPUT
FAV
ENTER
123
456
7 8
0
9
+ +
CH
GUIDE
VOL CH
MENU
BACK
APPS
EXIT
OK
PROGRAM
Red indicator light
INFO
06
Select the device you want to program
from the Device Categories:
The button’s red indicator light
blinks once and remains on.
2.
TV SAT/CBL STREAM
BRAY/DVD AMP AUX
AMP AUX
SAT/CBL STREAMTV
BRAY/DVD
INPUT
FAV
ENTER
123
456
7 8
0
9
+ +
CH
GUIDE
VOL CH
MENU
BACK
APPS
EXIT
OK
PROGRAM
Device Categories
Red indicator light
INFO
07
Enter the 4-digit code from the
included list for the category and
brand of your device.
The button’s red indicator light
shuts off if a valid code was entered.
If the button’s red indicator light
flashes and remains on after entering
four digits, that means an invalid code
was entered. In that case, check the
list again and re-enter the code.
NOTE: Test the remote with the device
to make sure the buttons work as
expected. If some of the buttons/
features don’t work, try a different code
on the list. Repeat this process for each
device you wish to control.
Code list and other helpful information
available at:
www.myblackwebremote.com
3. AMP AUX
SAT/CBL STREAMTV
BRAY/DVD
INPUT
FAV
ENTER
123
456
7 8
0
9
+ +
CH
GUIDE
VOL CH
MENU
BACK
APPS
EXIT
OK
PROGRAM
Enter the code
INFO
08
PROGRAMMING YOUR REMOTE AUTO CODE SEARCH
It’s recommended to program your remote by using the Direct Code
Entry method, however if with that method you were not able to find
a code that is compatible with your device, you may try the Auto Code
Search method below:
1. Power on the device that you want to control.
2. Press and hold the button until the button lights up red.
The button’s red indicator light remains on.
3. Select a device from Device Categories you would like to control.
The button’s red indicator light blinks once and remains on.
NOTE: Please refer to the list below if you are unsure about the device category.
• TV: TV, TV/DVD and other TV combinations
• SAT/CBL: Satellite, Cable, DVR, and other set-top boxes
• STREAM: Roku, Apple TV, Xbox, and other streaming media players*
• B-RAY/DVD: Blu-ray Players and DVD Players
• AMP: Sound Bars, Audio Receivers, and other audio devices
• AUX: VCRs, Digital Frames, and devices not found on the code list
*Compatible with Apple TV® and most Roku® devices; not compatible with Roku® Streaming Stick®,
Amazon® Fire TV and any voice-search features
4. Point the remote at the device you wish to control and then press and
hold the OK button until the device turns off. The button’s red
indicator light will blink as the codes are being tested.
5. When the device turns off, immediately release the OK button to lock
in the code. The button’s red indicator light will turn off. Test the
remote with the device to make sure all the buttons work as expected.
If some of the buttons/features don’t work, repeat the process or try
the Direct Code Entry method.
NOTE: It may take over 10 minutes to scan through all the possible codes for
your device. If during the Auto Code Search you have either accidentally or
deliberately released the OK button, you may repeat steps 1 through 5 above
to resume the code search where it left off.
After the Auto Code Search has exhausted all available codes for the selected
category, the remote’s button's red indicator light blinks three times and
turns off. If none of the codes worked with your device, try the Direct Code
Entry method.
PROGRAM
AMP AUX
SAT/CBL STREAMTV
BRAY/DVD
Device Categories
09
