Blackhawk USB560v2

System Trace Emulator

Installation Guide

USB560v2-IG-01

APRIL 2012

USB560v2-IG-01

2XBlackhawk USB560v2 System Trace Emulator

Blackhawk USB560v2 System Trace Emulator

Installation Guide

IMPORTANT IMFORMATION

Reproduction, adaptation, or translation without prior written permission is prohibited,

except as allowed under the copyright laws.

EWA Technologies Document: USB560v2-IG-01

Warranty – this manual

The information contained in this document is subject to change without notice.

EWA makes no warranty of any kind with regard to this material, including, but not limited

to, the implied warranties of merchantability and fitness for a particular purpose.

EWA shall not be liable for errors contained herein or for incidental or consequential

damages in connection with the furnishing, performance, or use of this material.

About This Manual

This document represents the Installation Guide for the Blackhawk© USB560v2 System

Trace Emulator product (BH560v2). The BH560v2 is a device that attaches to a personal

computer or laptop to allow hardware engineers and software programmers to develop

applications with DSP’s via their computer's USB or Ethernet interfaces.

This guide contains some text paragraphs that are very important for proper device

functioning and for preventing the BH560v2 device and target board from being damaged.

These paragraphs are shaded as in the following example. Please read each of these

areas of text carefully.

Related Documents

1. Texas Instruments CCSv4 Wiki Page (tiexpressdsp Wiki - Updated: daily)

2. To get the latest documentation from TI, click: Get the latest DSP manuals from TI.

Trademarks

BLACKHAWK™ is a trademark of EWA Technologies, Inc. All other marks are trademarks of

their respective owners.

USB560v2-IG-01

XBlackhawk USB560v2 System Trace Emulator 3

Contents

1BH560v2 Overview..........................................................................................................................6

1.1BH560v2 Standard Features.....................................................................................................6 

2Hardware..........................................................................................................................................7

2.1Important Environmental Considerations..................................................................................7

2.1.1Other Hardware Requirments........................................................................................7

2.2BH560v2 Pod............................................................................................................................8

2.2.1LED Indicators...............................................................................................................9

2.3LED Modes of Operation.........................................................................................................10

2.4Target Interface Cable.............................................................................................................11

2.5Pin Converters.........................................................................................................................12

2.5.1MIPI 60 to TI 14 Pin Converter....................................................................................12

2.5.2MIPI 60 to compact TI 20 Pin Converter .....................................................................12

2.5.3MIPI 60 to ARM 20 Pin Converter...............................................................................13

2.6USB Cable...............................................................................................................................14

2.7Power Options.........................................................................................................................14

3Installation.....................................................................................................................................15

3.1Requirements..........................................................................................................................15

3.2Software..................................................................................................................................16

3.3Hardware.................................................................................................................................18

3.3.1Configuring the Emulator Cable Assembly..................................................................18

3.3.2USB Cable Assembly..................................................................................................18

3.4Configuration and Test............................................................................................................19

4JTAG Signal Definitions ...............................................................................................................20

5Using Code Composer Studio .....................................................................................................21

5.1Importing a Predefined Configuration......................................................................................21

5.2Using the Create Board Feature .............................................................................................23

Appendix A.Target Connection Specifications. ..........................................................................27

A.1.MIPI 60 Target Connection .....................................................................................................27

A.2.TI 14-pin Target Connection....................................................................................................28

A.3.Compact TI 20-pin Target Connection....................................................................................28

A.4.ARM® 20-pin (Multi-ICE)Target Connection...........................................................................29

A.5.TI 60-pin Trace Target Connection .........................................................................................30

Appendix B.Device Driver Installation..........................................................................................31

B.1.USB Plug n’ Play for Windows XP/Vista/7 ..............................................................................31

B.2.Linux Device Information.........................................................................................................33

B.3.Blackhawk Control Panel ........................................................................................................34

Appendix C.Support and Contact Information ............................................................................35

Mailing Address...............................................................................................................................35

Phone Numbers..............................................................................................................................35

FAX Number ...................................................................................................................................35

World Wide Web.............................................................................................................................35

E-Mail Address................................................................................................................................35

Corrections......................................................................................................................................35

USB560v2-IG-01

4XBlackhawk USB560v2 System Trace Emulator

List of Tables

Table 1.BH560v2 Standard Features..............................................................................................6

Table 2.BH560v2 LED Information.................................................................................................9

Table 3.MIPI 60 Connector Signals..............................................................................................27

Table 4.Standard TI 14-pin signal definitions .............................................................................28

Table 5.Compact TI 20 pin signal definitions..............................................................................28

Table 6.ARM® 20-pin (Multi-ICE) signal definitions ...................................................................29

Table 7.TI 60-Pin Trace signal definitions...................................................................................30

USB560v2-IG-01

XBlackhawk USB560v2 System Trace Emulator 5

List of Figures

Figure 1 - BH560v2 Pod and Target Cable............................................................................................8

Figure 2 - BH560v2 JTAG Cable End Panel..........................................................................................8

Figure 3 - BH560v2 Host Side End Panel..............................................................................................9

Figure 4 - Normal Operating Mode LED States..................................................................................10

Figure 5 - BH560v2 End Panel LEDs (safe mode)3.............................................................................10

Figure 6 - Target Interface Cable (top view) .......................................................................................11

Figure 7 - Target Interface Cable drawing (side view).......................................................................11

Figure 8 - MIPI 60 to TI 14 Pin Converter (top/buffer board view) ....................................................12

Figure 9 - MIPI 60 to TI 14 Pin Converter (bottom/target view).........................................................12

Figure 10 - MIPI 60 to compact TI 20 Pin Converter (top/buffer board view)...................................12

Figure 11 - MIPI 60 to compact TI 20 Pin Converter (bottom/target view).......................................12

Figure 12 - MIPI 60 to ARM 20 Pin Converter (top/buffer board view) .............................................13

Figure 13 - MIPI 60 to ARM 20 Pin Converter (bottom/target view)..................................................13

Figure 14 - USB Y Cable.......................................................................................................................14

Figure 15 - Initial Welcome Screen......................................................................................................16

Figure 16 - Installation folder selection ..............................................................................................16

Figure 17 - Product Configuration.......................................................................................................16

Figure 18 - License Agreement Screen...............................................................................................16

Figure 19 - Custom Target Setup Screen............................................................................................16

Figure 20 - Custom Driver Setup Screen............................................................................................16

Figure 21 - Custom Setup Screen .......................................................................................................17

Figure 22 - Overall Installation Status.................................................................................................17

Figure 23 - Component Installation Status.........................................................................................17

Figure 24 - Completion Screen............................................................................................................17

Figure 25 - JTAG Cable + Pin Converter.............................................................................................18

Figure 26 - CCS v4.2 New Target Configuration Dialog ....................................................................21

Figure 27 - CCS v4.2 Main Application Window – Basic Tab............................................................22

Figure 28 - CCS v4.2 Main Application Window – Advanced Tab....................................................23

Figure 29 - Create Board display in CCSetup v4.2.............................................................................24

Figure 30 - CCSetup 4.2 Connection Properties Dialogs..................................................................25

Figure 31 - CCS v4.2 Create Board Dialog - Available Processors..................................................25

Figure 32 - CCS v4.2 Create Board Dialog - Current Processor.......................................................26

Figure 33 - Initial Windows PnP Detection .........................................................................................31

Figure 34 - Found New Hardware Wizard welcome dialog................................................................31

Figure 35 - Found New Hardware Wizard Automatic Install option .................................................32

Figure 36 - Copy Driver Files ...............................................................................................................32

Figure 37 - Driver Install Complete......................................................................................................32

Figure 38 - Windows Security Prompt – Signed Drivers...................................................................33

Figure 39 - Blackhawk Control Panel Dialog......................................................................................33

Figure 40 - Blackhawk Control Panel..................................................................................................34

USB560v2-IG-01

6XBlackhawk USB560v2 System Trace Emulator

1 BH560v2 Overview

This section contains a brief overview of the features available in the Blackhawk USB560v2

System Trace Emulators (BH560v2). Except where noted, information in this document applies

to both Windows and Linux operating systems.

This installation guide describes the fundamentals of the BH560v2 and how to use it with your

host machine and interface it to a target system.

The BH560v2 emulator target interface and connector are designed to be backwards compatible

with the XDS510 and XDS560-class emulators.

1.1 BH560v2 Standard Features

The following are standard features of the BH560v2.

Table 1. BH560v2 Standard Features

Development Environment and

Operating Systems Compatible with CCS v4.2 and later

Windows XP/Vista/7 & 2003 Server (32 and 64-bit editions)

Linux1

Debug Interfaces

(Blackhawk Enhanced Feature)

Supports IEEE 1149.1 (JTAG)

Supports IEEE 1149.72

System Trace Support

•Mobile Industry Processor Interface (MIPI)

•System Trace Protocol (STP)

•1-4 pin System Trace

•128 MByte System Trace Buffer

Bh560v2Config - Comprehensive Graphical Configuration

and Diagnostic Tool

TI Embedded Processor

Support C2000, C5000, C6000, ARM, ARM Cortex, Sitara, OMAP,

DaVinci, TMS470, TMS570, Stellaris and more

Compatible with CTools enabled devices

Target Physical Connections 60-pin MIPI

20-pin ARM Multi-ICE (via pin converter)

14-pin TI (via pin converter)

20-pin cTI (via pin converter)

Target Cable High-Speed Data Coax Ribbon Cable (8.0 inches) with

Native 60-pin MIPI HSPT target connection

Target Electrical and Signal

Interface Auto-sensing target voltage range from 1.2 to 4.1 volts

Auto-Adaptive Tesk Clock (TCK) up to 50 MHz

100MHz Export Clock compliant to MIPI STP

ESD Protection on target and host connections

Detection of target power loss and cable disconnects

1Linux Support requires CCS v5 and later

2IEEE Standard for Reduced-pin and Enhanced-functionality Test Access Port and Boundary Scan Architecture

USB560v2-IG-01

XBlackhawk USB560v2 System Trace Emulator 7

Auto -compensating calibration for edge jitter, channel skew

and duty cycle

Adaptive receiver for setup/hold times (up to 1.5ns)

Indicators

USB LED (bi-color red / green)

MODE LED (red / green)

Host Interfaces High-Speed USB 2.0 (480Mb/s)

Power Options

USB Cable (bus-powered)

2 Hardware

This section contains the hardware specifications for the BH560v2 pod, including external

attachments and indicators.

2.1 Important Environmental Considerations

This equipment is designed to be operated under the following environmental conditions:

Temperature between 0°C –55°C. Relative Humidity of 20% - 70% non-condensing.

Operation of the unit outside of the above range may affect structural and mechanical integrity

and cause permanent damage.

Caution is necessary to minimize ESD (Electro-static Discharge) which can damage electronic

components. Use in a controlled environment where ESD materials and practices are employed

is highly recommended

2.1.1 Other Hardware Requirments

Target Board System - a self- powered board with a TI DSP and compatible JTAG header

connection conforming to IEEE 1149.1 Standard.

Copy of Code Composer Studio Version 4.2 or later

USB560v2-IG-01

8XBlackhawk USB560v2 System Trace Emulator

2.2 BH560v2 Pod

The following section contains figures that describe the BH560v2 pod, its connectors and

indicators. Figure 1 below shows the BH560v2 with its target cable.

Figure 1 - BH560v2 Pod and Target Cable

Figure 2 below shows the BH560v2 JTAG cable end panel, and Figure 3 below shows the

BH560v2 USB host connection on its host-side end panel.

This panel also includes two (2) bi-color LED indicators for status and activity, which are

described in Table 2.

MIPI 60

Connection

Figure 2 - BH560v2 JTAG Cable End Panel

USB560v2-IG-01

XBlackhawk USB560v2 System Trace Emulator 9

Figure 3 - BH560v2 Host Side End Panel

2.2.1 LED Indicators

The BH560v2 has eight (8) status and activity LEDs that can provide information during power

up, operation, and configuration. These LEDs are described below in Table 2. You can see the

LEDs and their respective labels in Figure 3.

Table 2. BH560v2 LED Information

LED COLOR Description

USB Green Unit is powered and has enumerated

USB Red Unit has power (powering up)

USB LED will blink during USB activity

MODE Green

Steady Green indicates unit has completed

boot cycle and is ready.

Blinking Green means unit is booting up (boot

time is ~20 seconds)

MODE Red Blinking Red indicates that unit is booting into

Safe Mode

USB560v2-IG-01

10 XBlackhawk USB560v2 System Trace Emulator

2.3 LED Modes of Operation

The BH560v2 is running an embedded version of the Linux operating system. Because the

BH560v2 is running an operating system, it maintains some of the OS characteristics, such as

boot modes. Similar to Microsoft Windows®, Linux has normal and safe boot modes. Safe

mode exists to prevent the device from being put into a state where it can’t boot or be restored to

a normal mode of operation.

Depending on certain events the BH560v2 may boot into safe mode. For example, if the device

does not complete a boot cycle into normal operating mode after ~5 tries, safe mode is activated.

This scenario is common if you power cycle the device too many times and don’t allow it to

complete the boot cycle. The following paragraphs describe how you can identify these

operating modes.

•Normal Operating Mode

Normal operating mode can be identified when the device completed its boot sequence,

which could take between 20 and 30 seconds, and both LEDs are on steady Green. See

Figure 4 for location and orientation of these LEDs on the BH560v2 end panel.

Figure 4 - Normal Operating Mode LED States3

•Safe Mode

Safe mode can be identified when the device is powered and the MODE LED is on blinking

Red. See Figure 5 for location and orientation of these LEDs on the BH560v2 end panel.

To clear safe mode, please refer to the section on the Bh560v2Config utility.

Figure 5 - BH560v2 End Panel LEDs (safe mode)3

3The USB cable must be connected to PC and BH560v2 for power, but has been omitted for better clarity.

Tabla de contenidos

Manuales populares de Equipo de laboratorio de otras marcas

Qiagen

Qiagen DML 3000 Manual de usuario

Queensgate

Queensgate NANOSCAN OP400 Manual de programación

Conviron

Conviron GEN1000-GE Manual de usuario

Parr Instrument

Parr Instrument 4560 Manual de instrucciones

IKA

IKA IC control Manual de usuario

Integra

Integra DOSE IT Manual de usuario

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manual de usuario

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manual de usuario

NI PXI-5422 Manual

Collomix

Collomix Aqix Manual de usuario

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manual de usuario

Ocean Insight

Ocean Insight FLAME-NIR+ Manual de usuario

Parker

Parker ALIGN-MG-NA Manual de usuario

BD 644787 Manual de usuario

DENTAURUM

DENTAURUM Compact Megaplus Manual de usuario

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manual de usuario

VWR

VWR SAS Super IAQ Manual de usuario

illumina

illumina MiSeqDx Manual de usuario
