Blackbe;rry 8700C WIRELESS HANDHELD - GETTING STARTED GUIDE FROM... Manual de usuario

Headset jack

USB port

Power button

Turn the device on/off

Notification LED

Backspace/Delete key

Enter key

Send key

Make a phone call

Symbol key

Open the symbol list

Alt key

Type the alternate

character on a key

Trackwheel

Select or click an item

Escape button

Exit a screen

Front Convenience key

Open a list of useful links or

set to open a selected program

End key

End a phone call

Return to the Home screen

Right shift key

Type a capital letter

Speakerphone/Currency key

Turn speakerphone on /off

during a call

Type a currency symbol

Side Convenience key

Open the profile list or set to

open a selected program

Mute button

Turn microphone on /off

during a call

Left shift key

Type a capital letter

BlackBerry 8700c Wireless Handheld™ from Cingular

Getting Started Guide

You must connect to the wireless network to begin using many BlackBerry device features. To connect to or disconnect

from the wireless network, click Turn Wireless On/Turn Wireless Off.

Indicators on the Home screen show the wireless coverage level for the area in which you are using your device. A low level

of wireless coverage might limit the use of some device features, as shown in the chart below.

Emergency calls

Phone

SMS messages

Email and PIN

Browser

Wireless network coverage

High-speed data

Emergency calls only

Wireless is turned off

No wireless coverage

Full wireless coverage

Full wireless coverage with

high-speed data

Bluetooth connection

LED

wireless coverage

LED

low battery LED

notification LED

system busy

SMS or MMS

message

message includes

attachment

filed message

unread message

read message

message not sent

message sending

sent message

received call

missed call

placed call

saved web page

Alt mode on

Shift (Cap) mode on

Bluetooth connection

Bluetooth radio on

voice mail message

alarm set

service book waiting

transmitting data

receiving data

Home zone

roaming

charging

Number mode on

low battery power

full battery power

Status indicators

Contents

Welcome to BlackBerry! 3

Where can I find more information? 3

Before getting started 3

Setting up your device 4

Step one: Insert your Cingular SIM card 4

Step two: Insert the battery 4

Step three: Charge the battery 5

Step four: Connect to the Cingular Wireless

network 5

Exploring your programs 7

Choosing your email solution 9

BlackBerry Internet Service email 9

BlackBerry Enterprise Server email 9

Setting up for email using BlackBerry Internet

Service 11

Set up email using the device 11

using the device 12

Set up email using a computer 12

using a computer 13

Install the BlackBerry Desktop Software for

personal data synchronization 14

Setting up for email using BlackBerry Enterprise

Server 17

Set up email using enterprise activation on the

device 17

Set up email using the BlackBerry Desktop

Software 17

How do I... 19

Navigate screens 19

Change values in fields 19

Make phone calls 19

Send email messages 19

Send PIN messages 19

Send SMS (text) messages 20

Add contacts directly to your address book 20

Add SIM card contacts to your address book 20

Add contacts from your computer 20

Go to web pages 20

Set a device password 21

Lock and unlock the device 21

Set the date and time 21

Enable profiles 21

Create new profiles 21

Turn on or off Bluetooth technology 22

Pair with another Bluetooth-enabled accessory 22

Set a Bluetooth-enabled accessory as trusted 22

Set Convenience keys 23

Find help with other features 23

Frequently asked questions 25

BlackBerry Internet Service - frequently asked

questions 27

getting_started.book Page 1 Tuesday, September 20, 2005 10:35 AM

getting_started.book Page 2 Tuesday, September 20, 2005 10:35 AM

Welcome to BlackBerry!

Whether you plan to use your BlackBerry 8700c

Wireless Handheld™ from Cingular for business or

personal productivity, you have made an excellent

choice! With push email delivery, phone, web,

organizer features and more, the BlackBerry®

solution is designed to keep you connected to the

people, data, and resources that you need every

day.

Take a moment to read this guide — it provides

important setup information to help you get the

most from your BlackBerry device. This guide

includes instructions on how to set up and turn on

the device, connect to the wireless network, and

set up your supported email accounts. You can

also choose to install the BlackBerry® Desktop

Software so that you can connect your device to

your computer for data synchronization and

charging.

Where can I find more information?

You can find a detailed user guide on the CD that

is included in the box with your BlackBerry device.

The user guide is also only a few clicks away on

your device. To view the user guide on your device,

on the Home screen, use the trackwheel to scroll

to the Help icon and click (press) the trackwheel

to select it. The trackwheel is located on the right

side of your device.

When using a particular program on the device,

you can click the trackwheel to view the menu,

and then click Help to see the help topics that are

associated with the program that you are using.

Before getting started

Please take a moment to look through your

BlackBerry 8700c™ sales package. Be sure that

the following components are included:

•BlackBerry 8700c

•Battery

•AC power adapter

•USB cable

•Hands-free headset

•BlackBerry 8700c holster

•BlackBerry Desktop Software CD (includes

user guide)

•

BlackBerry Safety and Product Information

booklet

•

BlackBerry Software License Agreement and

Warranty

booklet

A Cingular store representative will provide you

with a Cingular SIM card and activate your

BlackBerry data plan. BlackBerry data plan options

are available to support unlimited domestic and

international use.

getting_started.book Page 3 Tuesday, September 20, 2005 10:35 AM

Setting up your device

Step one: Insert your Cingular SIM

card

Your SIM card contains important information

about your wireless service. Your SIM card might

be inserted already if you did not obtain your

BlackBerry device from a retail store.

Warning: Turn off your device before you insert or

remove the SIM card. Do not scratch, bend, or

expose the SIM card to static electricity or wet

conditions.

1. Press the battery cover release button.

2. Slide off the battery cover.

3. If the battery is inserted, remove it.

4. Hold the SIM card with the metal contacts

facing down so that the notched corner of

the card is on the bottom right.

5. Slide the SIM card into the holder so that it

lies flat below the metal guide.

6. Continue to slide the SIM card into the

holder until it stops. One end of the SIM card

should be slightly hidden below the plastic

casing on your device.

Note: To remove the SIM card, press down lightly

on the SIM card and slide it out of the holder.

Step two: Insert the battery

Warning: Use only the battery that Research In

Motion® specifies for use with your BlackBerry

device. Using any other battery might invalidate

any warranty provided with your device and might

present a risk of fire or explosion. See the

BlackBerry Safety and Product Information

booklet that accompanied your device for more

information about using the battery safely.

1. Insert the battery so that the connectors on

the battery align with the connectors in the

battery compartment on your device.

getting_started.book Page 4 Tuesday, September 20, 2005 10:35 AM

About wireless network coverage

2. Replace the battery cover.

3. If the battery is charged, your device turns on

and the confirm date and time dialog box

appears.

•If the date and time are incorrect, click

Edit. See “Set the date and time” on

page 21 for more information.

•If the date and time are correct, click OK.

Step three: Charge the battery

1. Connect the small end of the AC power

adapter cord to your BlackBerry device.

2. Plug the AC power adapter into an electrical

outlet.

3. Charge the battery to full power. The battery

power level indicator is on the Home screen

in the top right corner.

Note: If you choose to install the BlackBerry

Desktop Software, you can also charge your device

by connecting it to your computer using the USB

cable. See “Can I charge my device by connecting

it to my computer?” on page 25 for more

information.

Step four: Connect to the Cingular

Wireless network

If the power is off, press the Power button on the

top left of your BlackBerry device. Your device is

designed to connect to the wireless network

automatically.

To connect to the wireless network successfully,

your Cingular BlackBerry data service plan must

be active, and you must be in a wireless network

coverage area.

To connect or disconnect from the wireless

network, on the Home screen, use the trackwheel

to scroll to the Turn Wireless On/Turn Wireless

Off icon and click (press) the trackwheel to select

it. When your device is not connected to the

wireless network, the word OFF appears in the top

right corner of the Home screen. You can continue

to use features that do not require a connection to

the wireless network. For example, you can type

and save draft email messages, manage tasks, or

use the calculator.

About wireless network coverage

Indicators on the Home screen show the wireless

coverage level for the area in which you are using

your BlackBerry device.

Full wireless coverage with high-

speed data

Full wireless coverage

No wireless coverage

Wireless is turned off

Emergency calls only

Emergency calls, phone, SMS

messages, email messages, PIN

messages, browser, high-speed data

Emergency calls, phone, SMS

messages, email messages, PIN

messages, browser

getting_started.book Page 5 Tuesday, September 20, 2005 10:35 AM

Emergency calls, phone, SMS

messages

Emergency calls, phone, SMS

messages

Emergency calls, phone, SMS

messages

getting_started.book Page 6 Tuesday, September 20, 2005 10:35 AM

Exploring your programs

Explore the many useful programs that your

BlackBerry 8700c has to offer. You can access the

frequently used programs listed in this section on

the Home screen of your device.

BlackBerry 8700c Home screen

Click Messages to view the messages

list, compose new email, SMS, or PIN

messages, and set options for messages.

Click Enterprise Activation to set up for

email using BlackBerry Enterprise

Server™ if your system administrator

has provided you with a unique

enterprise activation password.

Click Individual Email Activation to set

up or log in to your BlackBerry® Internet

Service™ account.

Click Cingular Browser (Media Net or

mMode) to access content from the

Cingular portal or to download items

and visit web pages that are designed

for wireless browsers.

Click Internet Browser to visit HTML

web pages that you might normally visit

using your computer. You can also use

the Internet Browser to download items.

If you have an account that uses the

BlackBerry Enterprise Server, your

system administrator might enable the

BlackBerry Browser. Click BlackBerry

Browser to visit web pages on your

corporate intranet.

Click Applications to access the

MemoPad, Pictures, Search, and

Password Keeper programs.

Click Profiles to set and edit

notification preferences for email

messages, phone, calendar or task

reminders, and browser.

Click Settings to access the main list of

device options as well as settings for

Bluetooth™ technology, screen and

keyboard, network and more.

Click Help to view the main list of help

topics, shortcuts, and frequently asked

questions.

Additional programs appear on the

Home screen, including the Address

Book, Calendar, Tasks, and Calculator.

getting_started.book Page 7 Tuesday, September 20, 2005 10:35 AM

getting_started.book Page 8 Tuesday, September 20, 2005 10:35 AM

Otros manuales para 8700C WIRELESS HANDHELD - GETTING STARTED GUIDE FROM...

Tabla de contenidos

Otros manuales de Portátil de Blackbe;rry

Blackbe;rry

Blackbe;rry 7280 - MANUEL 2 Manual de usuario

Blackbe;rry

Blackbe;rry 8700C WIRELESS HANDHELD - GETTING STARTED GUIDE FROM... Manual de usuario

Blackbe;rry

Blackbe;rry 6230 Manual de usuario

Blackbe;rry

Blackbe;rry 8703e Version 4.1 Manual de usuario

Blackbe;rry

Blackbe;rry BlackBerry Wireless Handheld Manual de usuario

Blackbe;rry

Blackbe;rry 7730 Manual de usuario

Blackbe;rry

Blackbe;rry 6710 Manual de usuario

Blackbe;rry

Blackbe;rry 5820 Manual de usuario

Blackbe;rry

Blackbe;rry 7510 Wireless Handheld Manual de usuario

Blackbe;rry

Blackbe;rry 7230 Manual de usuario

Blackbe;rry

Blackbe;rry R6020GW Manual de usuario

Blackbe;rry

Blackbe;rry BlackBerry Wireless Handheld Manual de usuario

Blackbe;rry

Blackbe;rry 850 Manual de usuario

Blackbe;rry

Blackbe;rry BlackBerry Wireless Handheld Manual

Blackbe;rry

Blackbe;rry 850 Manual de usuario

Blackbe;rry

Blackbe;rry BlackBerry Wireless Handheld Manual de usuario

Blackbe;rry

Blackbe;rry 6750 Manual de usuario

Blackbe;rry

Blackbe;rry 6750 Manual de usuario

Blackbe;rry

Blackbe;rry 850 Manual de usuario

Blackbe;rry

Blackbe;rry 6710 Manual de usuario

Blackbe;rry

Blackbe;rry 7210 Manual de usuario

Blackbe;rry

Blackbe;rry 7750 Manual de usuario

Blackbe;rry

Blackbe;rry 7250 - MANUEL 4 Manual de usuario

Blackbe;rry

Blackbe;rry 6750 Manual de usuario

Manuales populares de Portátil de otras marcas

Honeywell

Honeywell Dolphin 9900 Manual de usuario

Honeywell

Honeywell CN75 Manual de usuario

MiTAC

MiTAC Mio 168 Manual de usuario

Wasp

Wasp WDT92 Manual de usuario

Texas Instruments

Texas Instruments TI-Nspire Manual de usuario

AXEM Technology

AXEM Technology MBS Manual de usuario

Armstrong

Armstrong Brain Wave Instrucciones de montaje

Unitech

Unitech TB128 Manual de usuario

Symbol

Symbol MC9000-G Manual de instalación y operación

Unitech

Unitech HT1 1D Batch Manual de usuario

Ingenico

Ingenico IWL220 GPRS Manual de usuario

Intermec

Intermec CK61 Manual de usuario

Symbol

Symbol c2000 Manual de usuario

Symbol

Symbol MC18 Manual de instalación y operación

Acer

Acer n20 Manual de usuario

Intermec

Intermec CK61 Manual de usuario

Docomo

Docomo F-04H Manual de usuario

Toshiba

Toshiba e350 Series Manual de usuario
