VGA Video Splitters

VGA Video Splitter 10-Channel

MONITORTYPEPOWER

VGA Video Splitter 2-Channel

MONITORTYPEPOWER

FEDERAL COMMUNICATIONS COMMISSION

AND

INDUSTRY CANADA

RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio frequency energy

and if not installed and used properly, that is, in strict accordance with the

manufacturer’s instructions, may cause interference to radio communication.

It has been tested and found to comply with the limits for a Class A

computing device in accordance with the specifications in Subpart J of Part 15

of FCC rules, which are designed to provide reasonable protection against

such interference when the equipment is operated in a commercial

environment. Operation of this equipment in a residential area is likely to

cause interference, in which case the user at his own expense will be required

to take whatever measures may be necessary to correct the interference.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emission

from digital apparatus set out in the Radio Interference Regulation of Industry

Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de classe A prescrites dans le Règlement

sur le brouillage radioélectrique publié par Industrie Canada.

FCC AND IC STATEMENTS

VGA VIDEO SPLITTERS

NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,

cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,

etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales

que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como

sea recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más

allá a lo descrito en las instrucciones de operación. Todo otro servicio

deberá ser referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama,

sofá, alfombra o superficie similar puede bloquea la ventilación, no se

debe colocar en libreros o gabinetes que impidan el flujo de aire por

los orificios de ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes

de calor como radiadores, registros de calor, estufas u otros aparatos

(incluyendo amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo

del tipo descrito en el instructivo de operación, o como se indique en

el aparato.

NOM STATEMENT

12. Precaución debe ser tomada de tal manera que la tierra fisica y la

polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen

del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo

a las recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos

de las lineas de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo

no sea usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del

aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio

en su desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

VGA VIDEO SPLITTERS

Contents

Chapter Page

1. Specifications ............................................................................................. 5

2. Introduction ............................................................................................... 7

3. Installation .................................................................................................. 8

3.1 The Complete Package ....................................................................... 8

3.2 The Procedure .................................................................................... 8

3.3 Extending Your Distance .................................................................. 10

3.4 Cascading .......................................................................................... 11

4. Operation ................................................................................................. 12

5. Applications .............................................................................................. 13

6. Troubleshooting ...................................................................................... 14

6.1 Common Concerns ........................................................................... 14

6.2 Calling Your Supplier ....................................................................... 14

6.3 Shipping and Packaging ................................................................... 14

CHAPTER 1: Specifications

Approvals — FCC Part 15 Class A, DOC Class/MDC classe A

Standards — VGA, SVGA, XGA, XGA-2

Interface — IBM PC compatible video

Maximum

Resolution — 1600 x 1280 pixels; however, image quality and

attainable distance degrade relatively rapidly above

1280 x 1024 pixels

Maximum

Refresh Rate — 75 Hz

Maximum

Distance — See the table on page 12

Rise Time — Less than 1 ns

Bandwidth — 300 MHz (–3 dB)

User Control — (1) Front-mounted 4-position DIP switch for selecting

monitor type

Indicator — (1) Front-mounted POWER LED

Connectors — All rear-mounted:

All models:

(1) 5-pin mini-DIN female for power;

(1) DB15HD female for VGA input;

AC056 models: (2) DB15HD fem. for VGA output;

AC057 models: (4) DB15HD fem. for VGA output;

AC159A-R2: (6) DB15HD female for VGA output;

AC058A-R2: (8) DB15HD female for VGA output;

AC160A-R2: (10) DB15HD female for VGA output

1. Specifications

VGA VIDEO SPLITTERS

Power — AC056A-R2, AC057A-R2:

From wallmount power supply:

Input: 115 VAC, 60 Hz, 12 watts;

Output: ±5 VDC at 300 mA to 1 amp;

AC056AE-R2, AC057AE-R2:

From desktop power supply:

Input: 230 VAC, 50 Hz, 5 watts;

Output: ±5 VDC at 500 to 600 mA;

AC058A-R2, AC159A-R2, AC160A-R2:

From desktop power supply:

Input: 95 to 250 VAC, 47 to 63 Hz, 10 watts;

Output: ±5 VDC at up to 2 amps

Temperature — 32 to 125˚ F (0 to 50˚ C)

Humidity — 5 to 95% noncondensing

Enclosure — Metal

Size — AC056A-R2, AC056AE-R2:

7.25"W x 1.5"H x 3.25"D (18.4 x 3.8 x 8.3 cm);

All models except AC056A-R2, AC056AE-R2:

7.25"W x 2.5"H x 3.25"D (18.4 x 6.4 x 8.3 cm)

Weight — 2- and 4-port (AC056, AC057) units: 2.5 lb. (1.1 kg)

6-port (AC159) units: 3 lb. (1.4 kg)

8-port and 10-port (AC058, AC160) units:

3.5 lb (1.6 kg)

CHAPTER 2: Introduction

Normally, computers are designed to drive their VGA (Video Graphics Array)

output to only one nearby monitor. Often, however, circumstances call for

VGA output to be driven to one or several monitors far away from the

computer. That’s where our family of VGA Video Splitters comes in.

A typical application for one of these Splitters involves a PC simultaneously

sending VGA output to its own monitor, usually placed nearby, and to as

many as nine remote monitors, located around the room or in another room

up to 250 feet (76.2 m) away. This makes your Splitter perfect for conference

rooms, classrooms, public information displays, show exhibits, and

demonstrations. For more about VGA Video Splitter applications,

see Chapter 5.

If you need to hook up more monitors than one Splitter can accomodate,

you can “cascade” Splitters by attaching one or more secondary units to the

MONITOR ports of the primary unit. See Section 3.4.

These VGA Video Splitters come in compact, attractive desktop enclosures.

They are powered by an external power supply and draw no power from the

sending computer. Each Splitter can be located up to 6 feet (1.8 m) away

from this computer.

With bandwidths of 300 MHz, these VGA Video Splitters can handle

resolutions of VGA, SVGA (Super VGA), XGA (Extended Graphics Array),

or XGA-2 as high as 1600 x 1280 pixels, at refresh rates as high as 75 Hz. They

support a variety of synchronization options, including H & V sync, composite

sync, sync-on-green, sync-on-RGB, and 75-ohm sync loads.

2. Introduction

VGA VIDEO SPLITTERS

3.1 The Complete Package

You should have received all of these things with your Splitter order:

• (1) VGA Video Splitter of the appropriate model

• (1) External transformer (power supply)

• (1) 6-ft (1.8-m) DB15HD-male-to-DB15HD-male video cable for

connecting the computer’s VGA output to the VGA Video Splitter

• (1) Copy of this manual

If any of these items are missing, call your supplier right away. If any of these

items are damaged, call your supplier and the shipping carrier immediately.

3.2 The Procedure

Follow these steps to install the VGA Video Splitter:

1. Place the VGA Video Splitter within 6 feet (1.8 m) of the computer.

2. Run the included video cable from the computer’s VGA output to the

connector marked VGA IN on the rear of the Splitter.

3. Connect your primary monitor (the one that was previously attached

directly to the computer) to the connector marked MONITOR 1 on

the rear of the Splitter.

4. Connect the additional monitor(s) to the remaining MONITOR

connector(s) on the rear of the Splitter. You can use VGA extension

cables to extend the distance you can run to as much as 250 feet

(76.2 m); see Section 3.3.

5. Plug the output cord of the included power supply into the jack marked

POWER on the rear of the Splitter.

6. Plug the power supply into an AC wall outlet. The Splitter’s front-panel

LED should glow red to show that the unit is properly powered.

3. Installation

CHAPTER 3: Installation

7. The four-position DIP switch marked MONITOR TYPE on the front

panel of the VGA Video Splitter tells the VGA adapter in your computer

what type of monitors you have connected when the computer boots up.

For a standard application in which your remote monitor(s) are pretty

much interchangeable with your primary monitor (the one on

MONITOR 1), move all four switch positions to the “UP” setting; this

will cause the Splitter to pass the “ID bits” from the primary monitor

through to the VGA adapter. Moving all the positions to UP will not

work for applications in which:

• there is no monitor on MONITOR 1;

• the primary monitor is connected to MONITOR 1 with a VGA

extension cable that doesn’t carry the ID-bit leads;

• the primary monitor uses higher-grade video than one or more of the

remote monitors (for example, color VGA vs. monochrome VGA or

high-resolution XGA-2 vs. low-resolution VGA).

In these situations, set the MONITOR TYPE switch this way:

DIP Switch Positions Monitor Type

1234

DOWN UP DOWN UP Color VGA and XGA

DOWN DOWN UP UP Monochrome VGA

UP UP DOWN UP 8514/A

NOTE

If your monitors don’t belong to any of these three types, you must set

all four MONITOR TYPE switch positions UP and connect a

representative monitor to MONITOR 1 with cable that carries the

monitor’s ID-bit leads. If you don’t have such a cable, call your supplier

for a quote on a cable that carries all ID-bit leads.

8. Turn on the computer and the monitors. The monitors should now

display the computer’s output.

This completes the VGA Video Splitter installation. Once installed, the

Splitter shouldn’t require any adjustments; you can keep it out of sight.

It should now be ready for continuous operation.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Convertidor de medios de Black Box

Black Box

Black Box LGC135A Manual de usuario

Black Box

Black Box LGC320A-NPS Manual de usuario

Black Box

Black Box LMC200 Manual de usuario

Black Box

Black Box VS-2001-DEC Manual de usuario

Black Box

Black Box LPD500A Manual de usuario

Black Box

Black Box LRA1200A-1PS Manual de usuario

Black Box

Black Box AC1031A-2 Manual de usuario

Black Box

Black Box MT660A-MM Manual de usuario

Black Box

Black Box MediaCento AVX-VGA-RF Manual de usuario

Black Box

Black Box AC217A Manual de usuario

Black Box

Black Box IE GIGA MC TX/SFP Manual de usuario

Black Box

Black Box AC179A Manual de usuario

Black Box

Black Box LMC5207A Manual de usuario

Black Box

Black Box IC293A Manual de usuario

Black Box

Black Box 488 Controller Manual de usuario

Black Box

Black Box AVSC-VGA-HDMI-R2 Manual de usuario

Black Box

Black Box LGC220A Manual de usuario

Black Box

Black Box IC292A Manual de usuario

Black Box

Black Box DFCS 4Tx/L2 Manual de usuario

Black Box

Black Box LE7401A-R2 Manual de usuario

Black Box

Black Box LMC009A-R4 Manual de usuario

Black Box

Black Box LMC5118C Manual de usuario

Black Box

Black Box EMEX-HDMI -R2 Manual de usuario

Black Box

Black Box RS-422 Manual de usuario

Manuales populares de Convertidor de medios de otras marcas

SoundTraxx

SoundTraxx Blunami BLU-2200 Manual de usuario

SPROLINK

SPROLINK VA1 Manual de usuario

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manual de usuario

Nikon

Nikon AF-S TC-20E III Manual de usuario

Axis

Axis AXIS Q7406 Manual de usuario

Omega

Omega TAC80B-J Manual de usuario

Zoom

Zoom Thunderbolt TAC-2R Manual de usuario

OST

OST iConverter 10/100M Manual de usuario

Vertiv

Vertiv Netsure Manual de usuario

birddog

birddog MINI Manual de usuario

Roland

Roland GI-10 Manual de usuario

Wallenstein

Wallenstein WX310 Manual de usuario

Pace

Pace MSS 200-1 Manual de usuario

Solar Converters

Solar Converters EQ 12/24-50 Manual de usuario

CYP

CYP EL-7400V Manual de usuario

TIE

TIE MIDI 1i1o Manual de usuario

DCS

DCS Vivaldi Upsampler Manual de usuario

Westermo

Westermo MCW-211 SERIES Manual de usuario
