Black & Decker HF100WD Manual de usuario

Black And Decker Purifry 2l Capacity Air Fryer Use Manual

Contents hide

1 SAVE THESE INSTRUCTIONS.

2 BEFORE FIRS T USE & PREP ARING F OR USE

3 USING THE APPLIANCE

4 COOKING TIPS:

5 RECIPES

6 MAKING HOMEMADE FRIES

7 CARE AND CLEANING

8 NEED HELP?

8.1 Documents / Resources

8.2 related articles：

HF100WD

HF100WCS

HF100WCA

HF110SBD

Product may vary slightly from what is illustrated.

Power indicator light1.

Preheat indicator light2.

60-minute Timer(Part# HF100-04 White /Part# HF110-04 Black )3.

Temperature control knob(Part# HF100-05 White /Part# HF110-05 Black )4.

2L capacity basket(Part# HF100WD-02 White /Part# HF110SBD-02 Black)5.

Basket separator (Part# HF100-03)6.

Basket release button7.

Release button cover8.

Pan (Part# HF100WD-01 White /Part# HF110SBD-01 Black)9.

Cool-touch handle10.

Reset button11.

Please Read and Save this Use and Care Book.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

safety features

OVERHEATING PROTECTION

This appliance is equipped with an overheating protection system. If the inner temperature

control system malfunctions, the overheating protection system is automatically turned on

and the appliance cannot be used. After this occurs, unplug the appliance, remove the food,

and allow at least 30 minutes for the appliance to cool.

Only after the appliance has been left to cool down completely, while on a stable surface,

carefully turn the appliance on its side to access the bottom. Locate the “RESET” button on

the bottom (see image) and using a pointed object, press the “RESET” button and hold two

seconds to return to normal operation. After this is done, the air fryer is operational again.

AUTOMATIC OFF-SWITCH

This appliance is equipped with a timer. Once the timer has counted down to off (O), a bell1.

will sound and the appliance will turn off automatically. To turn the appliance off manually,

simply turn the timer knob counterclockwise to off (O) until you hear the bell sound.

As a safety feature, this appliance will shut off power if the pan is removed, even partially,2.

during cooking. The timer will continue to count down but the cooking functions will not

operate. To resume cooking, insert the pan back into the appliance. Rapid heat technology

instantly reheats the appliance if you open it, so pulling the pan out briefly will not

drastically disturb the process.

POLARIZED PLUG (120V models only)

blade is wider than the other). To reduce the risk of electric shock, this plug isintended to fit

into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the

plug. If it still does not fit, contact a qualified electrician. Donot attempt to modify the plug

in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw to prevent removal of

the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the

outer cover. There are no user-serviceable parts inside. Repair should be done only by

authorized service personnel.

ELECTRICAL CORD

1) A short power-supply cord is provided to reduce the risk resulting from becoming

entangled in or tripping over a longer cord.

2) If a long detachable power-supply cord or extension cord is used,

a) The marked electrical rating of the extension cord should be at least as great as the

electrical rating of the appliance,

b) The appliance is of the grounded type, the extension cord should be a grounding-type 3-

wire cord, and

c) The longer cord should be arranged so that it will not drape over the countertop or

tabletop where it can be pulled on by children or tripped over unintentionally.

Note: If the power cord is damaged, please contact the warranty department listed in these

instructions.

BEFORE FIRS T USE & PREP ARING F OR USE

Remove all packaging materials.1.

Remove any stickers or labels from the appliance.2.

Please visit www.prodprotect.com/applica to register the appliance.3.

Wash all removable parts as instructed in care and cleaning section.4.

Choose a location appropriate for the device. Make sure there is enough space around the5.

appliance to prevent heat damage to cabinets or counters.

Always place on a stable, flat and level surface.6.

Slide the pan into the machine until it clicks into place. The appliance will not work unless7.

the pan is properly inserted.

Plug the unit into electrical outlet.8.

USING THE APPLIANCE

The air fryer can prepare a large range of foods, please refer to the “Cooking Guide” table

for additional cooking instructions.

Plug the appliance into an electrical outlet.1.

Turn the temperature control knob to the required temperature.2.

To switch the appliance on, turn the timer knob to 20 (twenty) and then to desired cooking3.

time, plus an additional 3-5 minutes for preheat. The power and heating lights will

illuminate.

Once the heating light is not longer illuminated, the appliance is preheated to the set4.

temperature.

To remove the pan, carefully push the release button cover on the handle forward with your5.

thumb while pulling the handle back to remove the basket.

Once the basket is out, make sure to cover the Basket Release button by pulling the release6.

button cover back over it to prevent accidental release of the basket from the pan.

Place the food in the basket and slide the pan back into the air fryer properly. You will hear7.

a click when the pan locks into place. If the pan is not inserted properly, the appliance will

not operate.

Some foods require shaking halfway through the cooking process. To shake foods, pull the8.

pan out of the appliance by the handle and gently shake. Then slide the pan back into the air

fryer and continue to cook. Do not press the Release Button on the handle while shaking the

pan.

When you hear the timer bell, the set cooking time has finished. Pull the pan out of the9.

appliance and place it on a heat resistant surface and check if the foods are ready. If not,

simply put back into the appliance and set the time for a few extra minutes.

When the food is ready, push the clear tab forward on the handle, press the basket release10.

button and lift the basket out of the pan. Empty basket of food into serving bowl or plate.

For larger or fragile items, use tongs to lift the food out of the basket.

Once the food has been removed from the appliance, the fryer is ready for another batch.11.

If you want to cook two items at the same time, place the basket separator in the center of12.

the basket to divide foods and prevent the flavors from mixing

COOKING TIPS:

• To reduce the weight, you can remove the basket from the pan and shake the basket only.

To do so, pull the pan out of the appliance, place it on a heat-resistant surface and press the

Release Button on the handle to release the basket.

• If you set the timer to half the preparation time, you then will hear the timer bell when you

have to shake the food. Then just set the time again for the remaining cook time.

• You can pull out the pan at any time to check on the food. The power will automatically

shut off while the pan is out and resume when the pan is placed back in. The timer will

continue to countdown while the pan is out. Rapid heat technology instantly reheats the

appliance if you open it, so pulling the pan out briefly will not drastically disturb the

process.

• Smaller ingredients usually require a slightly shorter cook time than larger items.

• A larger amount of food only requires a slightly longer cook time, a smaller amount only

requires slightly less.

• Shaking smaller ingredients halfway through the cooking process will optimize the end

result and help prevent unevenly fried food.

• Add some oil to lightly coat fresh potatoes for crispy results. Fry your food in the air fryer

within a few minute after you’ve added the oil.

• Do not prepare extremely greasy food such as sausages in the air fryer.

• Snacks that can be prepared in an oven can also be prepared in the air fryer.

• The optimal amount for preparing crispy fries is 250 grams (8 oz.).

• You can also use the air fryer for reheating food. Place food in basket and set the

temperature to 150˚C (300˚F) for up to 10 minutes.

• Visit foodsafty.gov for more information on safe internal cooking temperatures.

RECIPES

KALE CHIPS

6 cups fresh kale leaves, torn into bite size pieces

1/2 Tbsp. olive oil

3 grinds of sea salt

Toss kale with olive oil and salt. Preheat Air Fryer to 160°C (320°F). Place kale in basket.

Cook 3-4 min., or until crisp, shaking basket halfway through cooking.

BUFFALO TURKEY BURGERS

1 lb, ground turkey

¼ cup bread crumbs

3-4 green onions, thinly sliced

¼ cup Buffalo Wing sauce

2 Tbs. crumbled blue cheese

In large bowl, mix all ingredients until well blended. Shape into 4 (3.5 inch

diameter) patties.

Preheat Air Fryer to 200/400°F Place 2 patties into basket; cook 10-15 minutes or until an

internal temperature of 165°F Let stand a few minutes before serving. Repeat with

remaining patties.

Makes 4 servings

TIPS:

• No need to turn patties during cooking

• Serve on buns with lettuce, tomato and mayonnaise or blue cheese dressing if desired.

• For sliders, shape turkey mixture into eight (2 oz.) balls. Flatten slightly. Place four patties

in a single layer in fryer basket. Cook at 200/400°F 10-12 min. or until 165°F.

MAKING HOMEMADE FRIES

Peel the potatoes and cut them into sticks.1.

Rinse the potato sticks thoroughly and dry them with paper towel.2.

Pour ½ tablespoon of olive oil in a large bowl, put the sticks on top and mix the sticks until3.

they are coated with oil.

Remove the sticks from the bowl so that excess oil stays in the bowl, and place them in the4.

air fryer basket.

Note: Do not pour the bowl with the oil and potato sticks into the basket. This prevents

excess oil from ending up on the bottom of the pan.

Fry the potato sticks according to the instructions in the Cooking Guide Table5.

CARE AND CLEANING

This product contains no user serviceable parts. Refer service to qualified service personnel.

Important: Before cleaning any part, be sure that the appliance is off, unplugged, and cool.

Removing the pan after use helps the air fryer cool down more quickly.

• Turn the unit off, unplug the appliance and allow time for the appliance to cool.

• Wipe the outside of the appliance with a moist cloth.

• Clean the pan and the basket with hot soapy water, using a non-abrasive sponge.

Note: The basket and separator are dishwasher-safe.

Tip: If residue sticks to the basket or the bottom of the pan, fill the pan with hot water and a

small amount of soap. Put the basket in the pan and let them soak for approximately 10

minutes.

• Clean the inside of the appliance with hot water and a non-abrasive sponge.

• Clean the heating element with a non-abrasive sponge to remove any food residues.
