BioBoss VX40S Especificaciones técnicas
USER MANUAL AND RECIPES
BOSS
VX40S - BioBoss
Whole Slow Juicer
O
ENGLISH 3
EN
FRANÇAIS 21
FR
DEUTSCH 41
DE
ESPAÑOL 61
ES
IT
ITALIANO 81
The information in this manual is intended
to help you to get the best results from
your BioBoss Whole Slow Juicer. Please
read and follow these instructions and
safeguards prior to use.
Please keep your manual handy for future
reference, warranty information and
support details
4
Safety Precautions
!Read all instructions.
!To protect against risk of electrical shock, do not put the body (motor) in
water or any other liquid .
!Close supervision is necessary when any appliance is used by children.
!Unplug from electrical outlet when not in use and before disassembly
for cleaning.
!Avoid contact with moving parts.
!Do not operate appliance with a damaged cord or plug.
!The use of attachments not recommended or sold by the manufacturer
may cause damage and will void warranty.
!Do not let cord hang over edge of counter.
!Make sure the motor has stopped completely before dissembling.
!Do not put your ngers or other objects into the juicer while it is in
operation. If food becomes lodged in the opening, use the provided
food plunger to push it down or press the button into reverse mode. If
ingredients are still lodged in the juicing drum, turn o and disassemble
to remove remaining food. You may need to cut produce smaller, or feed
ingredients slower into the chute to prevent this.
EN
5
Parts and Accessories
1 Hopper and
Feeding Chute
2 Bowl (drum)
3 Motor Base
4 Extra Fine, Fine,
Coarse & Sorbet
Strainers
5 Spinning Basket
6 Auger
7 Tamper
8 Silicone Cover
9 Pulp Container
10 Juice Container
11 Cleaning Brush &
Fine Cleaning Brush
1
2
3
4
5
6 9
7 10
11
8
EN
6
Step 5
Align the open yellow
triangles on the hopper
and twist the hopper
clockwise until the
lock position.
Step 1
If a silicone cover is not
already tted, place one
over spindle as shown.
Step 4
Insert auger into
strainer/spinning
basket. Wind clockwise
until it is sitting rmly in
the bowl.
Step 2
Ensure the yellow pulp
plug at the base of the
bowl has been inserted
rmly into the outlet.
Place the bowl onto
the base.
Step 3
Place the desired strainer
into the spinning basket
and then place these into
the bowl, aligning the
triangle on the strainer with
the triangle on the bowl.
Assembly Instructions
EN
7
Operating Instructions
Press the power switch into the ON position. Ensure that the safety switch
is unlocked and tap the door to open. Then push your larger round ingredients
into the chute allowing it to fall towards the auger. Insert other ingredients into
the smaller feeding chute individually. For best results add ingredients at an
even, slow pace to ensure maximum extraction is achieved.
CHOOSE YOUR STRAINER
Extra Fine Strainer
This strainer is half blank, and half has
small holes to create a smoother juice
with less pulp.
Fine Strainer
This strainer has small holes to create a
ne juice with a small amount of pulp.
Coarse Strainer
This strainer has larger holes to create
a whole-fruit juice (more pulp/bre
included).
Sorbet Strainer
This strainer is blank with no holes to
give you the option of making sorbets,
nut butters and more.
REVERSE FUNCTION
If you notice any ingredients have become stuck or are refusing to move
use the tamper to gently push ingredients downwards. The reverse switch is
specically for this reason. Press the reverse switch down for 3-5 seconds and
repeat 2-3 times if necessary.
Once the auger has come to a complete stop press the forward switch
to continue.
EN
8
JUICE OUTLET CAP
Close the juice outlet cap to mix your juice inside your juicer. Open the juice
outlet cap to dispense as required into the juice container.
CARING FOR THE SILICONE PULP PLUG
It is important to ensure that the pulp plug is always closed before juicing.
When you are cleaning the juicing drum (bowl) gently unplug the seal and
rinse under water.
Replace the seal after cleaning so your juicer is ready to use next time.
SILICONE COVER
Ensure the silicone cover is tted prior to use. It is another measure to ensure
that the motor is sealed from any juice overspill.
Clean after use by removing it from the motor base. Keep your spare silicone
covers handy in case of misplacement.
EN
9
Troubleshooting
My juicer
does not
operate when
the switch
is in the ON
position
1. Make sure the power cord is properly secured into
the power source and that the switch is turned to
the ‘ON’ position.
2. Check that the hopper is assembled correctly.
PLEASE NOTE: If the hopper has not been securely
locked in place with the arrows aligning, the
appliance will not work for safety reasons. This
is due to a magnetic safety strip located inside
the hopper which must align with the matching
magnetic strip inside the base.
3. Check the appliance has been assembled
according to the instructions in this manual.
My juicer
has stopped
during
operation
1. Reverse / REV to unwind any fibre that is caught
around the auger.
2. If your juicer has stopped during operation, please
check that the hopper is correctly aligned with the
base. If the alignment shifts during operation the
juicer will stop.
3. Turn your juicer off, reset the hopper and you should
be able to continue.
PLEASE NOTE: The BioBoss Whole Slow Juicer has an
automatic motor cut off safety feature that will
activate if the juicer is overloaded. This has been
designed to help prevent accidental damage and to
help extend the life of the machine.
4. To reset your juicer take off the hopper lid and
remove any ingredients in the juice bowl.
EN
10
The hopper
will not open
The hopper opens in an anti-clockwise way. If the
hopper will not open easily, try the following:
1. Allow your BioBoss Whole Slow Juicer to run without
adding more ingredients before turning off and
attempting to remove the hopper.
2. Switch your juicer into reverse for a few moments to
help dislodge any remaining ingredients around the
auger and feeding chute of the hopper.
PLEASE NOTE: The auger turns in a clockwise direction
which is opposite of the hopper. This may cause an
unintentional tightening of the hopper and result in
difficulty releasing the hopper from the juicing bowl.
3. After you have fed the last ingredients into the
hopper, let it run until all the juice and pulp has run
through the machine. Pour one or two glasses of
water down the hopper to flush out much of the left
over pulp.
4. Lift off the entire juicing section before trying to
separate.
The bowl
shakes when
squeezing
A slight shaking of the motor while in operation is
completely normal. Variations beyond this depend
on the bre content of the ingredients. Hard or tough
ingredients such as carrot and beetroots may cause
the bowl to shake more than soft and juicy ingredients.
EN
