Binatone SPIRIT 710 Manual de usuario

SPIRIT 710

- When the instruction simply say 'press' a button, this means you should press it

briefly then release it.

- When the instruction say 'press and hold' a button, this means you should keep

it pressed until the display changes or you hear a tone.

Important:

Microphone -

For

speakerphone use

and answering

machine OGM &

Memo recording.

playback. Press and hold to switch

the answering maching ON or OFF.

With TAM ON is standby mode,

press to select OGM1 or OGM2.

- To access the caller

display records, and

UP-DOWN (CDS) Buttons

to scroll through lists

and options.

- Press to delete individual

messages, memos, stored

DEL (DELETE) Button

light - Turns ON

when using the

speakerphone.

SPEAKERPHONE

- Turns ON

when the TAM

is on. Flashes

when you

have new

TAM

messages.

MESSAGE light

numbers or Caller Display

records.

- Press to enter Options Menu

to set the Date, Time,Screen

(MENU) Button

Contrast,phone/TAM settings.

- Press to access the

Phonebook records.

(PHONEBOOK) Button

- Press to access the LNR lists

when in standby mode. Press to

insert a pause when dialing.

(REDIAL)/ P (PAUSE) Button

during a call to mute the microphone or

(MUTE) / STO(Store) Button - Press

- You may need this function if your

phone is connected to a PBX, or if

you use BT Calling Features.

R (RECALL) Button

- Press to make, answer, or end a call

using the speakerphone.

SPEAKERPHONE Button

- Press and hold to record your

outgoing messages. Press during

message playback to repeat the

current message or to go back

to the previous message(s).

OGM/ (REWIND) Button

- Press and hold to record a memo.

Press during message playback to

skip to the next message.

MEMO/ (SKIP) Button

- Press to play back messages and

memos. Press to pause playing of

a memo or message.

(PLAY/PAUSE) Button

Button - Press to stop recording or

(EXIT)/ (ANSWER ON/OFF)

- Used to adjust the volume

level of the Speakerphone.

SPEAKER Volume control

when the phone is ringing

for an incoming call.

Ringer light

- This flashes

mouthpiece. Press to store the (M1, M2

and M3)one touch memory dialing buttons

M1, M2, M3 one-Touch

Memory Buttons

The NEW icon only appears when viewing

New Caller Display records.

entry

with

2. Installation

1. Locating the Base unit

The Base unit should be placed on a level surface, in a position where:

the mains adapter plug will reach an easily accessible 230-V AC

switch mains supply socket - never try to lengthen the mains power cable.

the telephone line cable will reach your telephone line socket or

extension socket.

it is not close to a sink, bath or shower, or anywhere else where it

might get wet.

it is not close to other electrical equipment - fridges, washing

machines, microwave ovens, TVs, fluorescent lights, etc.

2. Plug the coiled handset cord into the Handset. Plug the other end into

the jack on the left side of the Base unit.

Note: The base unit doesn't

require a battery.

3. Place the Handset on

the Base unit.

4. Plug the telephone line cord into

the PHONE LINE jack at the back

of the Base unit. Plug the other

end into your telephone line socket 5. Plug the power supply cord

into the POWER jack at the

back of the Base unit. Plug

the other end to a 230V AC,

50Hz mains socket, with the

switch on the socket set to OFF

6.Switch ON the mains power at

the socket. Wait while the

7.Lift the Handset and check

for Dial tone in the earpiece.

The Spirit 710 Base unit must be used

only with the supplied mains adapter. Using

any other adapter may damage the unit.

Always use the telephone

line cord supplied with your

Spirit 710. Other telephone

line cords may not work.

Make sure the plugs click

into place.

or extension socket.

display shows INITIALISATION,

then the announcement

Answering machine on.

Announcement one before

the display changes to the

“

”

standby screen.

3. Desk/Wall mount installation

To place the Spirit 710 on a desk, connect

the stand to the bottom of the phone in the

slots near the rear of the base as shown below.

Desk Mount

Insert the rigid clips of the stand into the slots

on the bottom of the phone (nearer the centre of

the base). Press down firmly until the flexible

clips clicks into place.

To remove the stand, (1) pinch the flexible

clips, (2) pull back the stand, and then (3)

slide up and forward (3) as shown below.

To place the Spirit 710 on a wall, connect

the stand to the bottom of the phone in the

slots near the front of the base as shown below.

Wall Mount

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

Desk/Wall mounting continue...

Insert the rigid clips of the stand into the slots

on the bottom of the phone (nearer the centre of

the base). Press down firmly until the flexible

clips clicks into place.

To remove the stand, (1) pinch the flexible

clips, (2) pull back the stand, and then (3)

slide up and forward as shown below.

Mark two points on the wall that are 92 mm

apart to lay the fixing centers as shown below.

BE CAREFUL to check that there are no

electrical wires hidden in the wall.

Fix two screws (supplied with the unit) at the

marked locations, leaving approximately 7mm

between the wall and the the screw head.

Hang the telephone on the screws using the

wall mount slots. You may need to remove the

telephone from the wall and tighten the

screws so that the Telephone is securely fixed and

does not wobble. Place the Handset on the

cradle with the parking hook on the cradle

arranged to fit in the parking recess under the

earpiece on the Handset.

92 mm

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

4. Setting up the Spirit 710

The following section details how to set up your telephone.

Press the MENU button to enter the Options menu and then use

the UP or DOWN buttons to cycle through the following options:

SET LANGUAGE

SET TIME/DATE

SET FLASH TIME

LCD CONTRAST

MESSAGE LENGTH

RINGS TO ANSWER

REMOTE ACCESS

TAM HD: ON/OFF

Note: The system will time out if you leave more than

10 seconds between key presses.

With the phone in standby mode;

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP button to go to the language setting.

ÖThe display shows

SET LANGUAGESET LANGUAGE

SET LANGUAGE

3 Press MENU button to confirm.

4 Press UP or DOWN button to select ENGLISH

(default), FRANCAIS, or DEUTSCH.

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

SET

LANGUAGE

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

SET TIME/DATESET TIME/DATE

SET TIME/DATE

3 Press MENU button to confirm.

ÖThe ‘year’ will be blinking.

SET TIME/

DATE

EXIT OPTION

ÖSet to ON is up to 8 minutes,

set to OFF is up to 20 minutes.

Note: if you subscribe to the caller display service

(see section 9) the time and date will be set

automatically,but the year may still need to be

adjusted to ensure the answering machine time

stamp gives the correct day.

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

Setting up continue...

4 Press UP or DOWN button to set the year.

5 Press MENU button to confirm.

ÖThe ‘month’ will be blinking.

6 Press UP or DOWN button to set the month.

7 Press MENU button to confirm.

ÖThe ‘date’ will be blinking.

8 Press UP or DOWN button to set the date.

9 Press MENU button to confirm.

ÖThe ‘hour’ will be blinking.

10 Press UP or DOWN button to set the hour.

11 Press MENU button to confirm.

ÖThe ‘minutes’ will be blinking.

12 Press UP or DOWN button to set the minute.

13 Press MENU button to confirm the TIME and

DATE setting.

14 Continue with programming, or press EXIT

button to return to standby mode.

1Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2Press UP or DOWN button until the display

shows

SET FLASH TIMESET FLASH TIME

SET FLASH TIME

3Press MENU button to confirm.

SET FLASH

TIME

You may need the Recall function if your phone is

connected to a PBX, or if you use BT Calling Features.

Flash is another name for the R (Recall) button,

4Press UP or DOWN button to select 100MS

(default), 300MS, 600MS or 1000MS.

When setting the 'hour' it is in 24 hour

mode only.

and the normal UK requirement is for 100ms, but

some PBX may need a longer time, in which case

you can change the setting from the Options Menu.

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

LCD CONTRASTLCD CONTRAST

LCD CONTRAST

3 Press MENU button to confirm.

4 Press UP or DOWN button to select your

comfortable display viewing level (1~5). The

default setting is 3.

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

To set the maximum recording time for each incoming

message or memo message on the Answering Machine.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

MESSAGE LENGTHMESSAGE LENGTH

MESSAGE LENGTH

3 Press MENU button to confirm.

4 Press UP or DOWN button to select 1 or 2

minutes. The default setting is 2 minutes.

5 Press MENU button to confirm the MESSAGE

LENGTH setting.

6 Continue with programming, or press EXIT

button to return to standby mode.

Setting up continue...

LCD

CONTRAST

MESSAGE

LENGTH

To set the number of rings before the machine

answers a call;

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

RINGS TO

ANSWER

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

2 Press UP or DOWN button until the display

shows

RINGS TO ANSWERRINGS TO ANSWER

RINGS TO ANSWER

3 Press MENU button to confirm.

4Press UP or DOWN button to select TOLL SAVER,

2, 3, 4, 5, 6, 7, 8, or 9 rings. The default setting is 5.

ÖUse ‘TOLL SAVER’ when checking your Spirit 710

for messages from a remote location using long

distance service or from a pay phone. The Answering

machine responds after the 2nd ring only if you have

a new message waiting. If there are no new messages,

the phone will answer after the 4th ring. You can then

hang up after the 3rd ring to avoid paying for the call.

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

The REMOTE ACCESS is a three-digit code you

your

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

REMOTE ACCESSREMOTE ACCESS

REMOTE ACCESS

3 Press MENU button to confirm.

ÖThe first digit of the code will be blinking.

4 Press UP or DOWN button to set the first digit

of the REMOTE ACCESS code.

Setting up continue...

REMOTE

ACCESS

5 Press MENU button to confirm.

ÖThe second digit of the code will be blinking.

6 Press UP or DOWN button to set the second

digit of the REMOTE ACCESS code.

7 Press MENU button to confirm.

ÖThe third digit of the code will be blinking.

need if you call away from home to check

messages.The default is 321. You can change it to

any three digits you want.

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

Tabla de contenidos

Otros manuales de Teléfono de Binatone

Binatone

Binatone iDECT Freedom Twin Manual de usuario

Binatone

Binatone 3488 Manual de usuario

Binatone

Binatone Reliant 510 Manual de usuario

Binatone

Binatone SPIRIT 221 Manual de usuario

Binatone

Binatone Trend Manual de usuario

Binatone

Binatone Smart 66 Manual de usuario

Binatone

Binatone CAPRICE 500 Manual de usuario

Binatone

Binatone IHOME PHONE - Manual de usuario

Binatone

Binatone DECT Solo Single Manual de usuario

Binatone

Binatone AC2000 Manual de usuario

Binatone

Binatone Speakeasy Combo 3865 Triple Manual de usuario

Binatone

Binatone Cliptel 50 Manual de usuario

Binatone

Binatone IHOME PHONE - Manual de usuario

Binatone

Binatone DECT Combo Plus Single Manual de usuario

Binatone

Binatone Lyris 710 Manual de usuario

Binatone

Binatone DSR-3716PA Manual de usuario

Binatone

Binatone CAPRICE CAPRICE 600 Manual de usuario

Binatone

Binatone LYRIS 310 Manual de usuario

Binatone

Binatone Caprice 670 Manual de usuario

Binatone

Binatone PB10 Manual de usuario

Binatone

Binatone Speakeasy 6 Manual de usuario

Binatone

Binatone Trend LCD Manual de usuario

Binatone

Binatone Spirit 110 Manual de usuario

Binatone

Binatone 2102 Manual de usuario

Manuales populares de Teléfono de otras marcas

GE 2-9480 Manual de usuario

Geemarc

Geemarc PHOTOPHONE 155 Manual de usuario

D-Link

D-Link DWR-720/PW Manual de usuario

Interquartz

Interquartz Gemini IQ333 Manual de usuario

SSS Siedle

SSS Siedle HT 840-0 Manual de usuario

Motorola

Motorola TITANIUM Manual de usuario

Panasonic

Panasonic ICX Manual de usuario

LG H870DS Manual de usuario

Samsung

Samsung GT-I9500 Manual de usuario

AT&T

AT&T Trimline 205 Manual de usuario

Selta

Selta zenyth 600 Manual de usuario

Doro

Doro AFTI 20 Manual de usuario

UNIQCELL

UNIQCELL A1 Manual de usuario

Panasonic

Panasonic KX Series Manual de usuario

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manual de usuario

BT Decor 425 Manual de usuario

NEC

NEC SV8500 Manual de usuario

Teledex

Teledex PEARL Manual de usuario
