Automatic grill & bake oven KH 1139
Operating Instructions
KH1139_IB_UK_Neu 13.01.2006 10:10 Uhr Seite 2
KH1139_IB_UK_Neu 13.01.2006 10:10 Uhr Seite 3
bifinett KH 1139
2 x
KH1139_IB_UK_Neu 13.01.2006 10:11 Uhr Seite 4
- 3 -
bifinett KH 1139
Automatic grill & bake oven Page
Safety precautions 4
Appropriate usage 5
Items delivered 5
Installation 6
Description 6
Starting to use the appliance 7
Switching off and storing away 7
Operation 8
Cooking tips and recipes 10
Cleaning 12
Disposal 12
Technical specifications 12
Warranty & customer service 12
Troubleshooting 13
Read the operating instructions carefully before using the appliance for the first
time and preserve this booklet for later reference. Also include the instructions if you
pass the appliance on to anyone else.
KH1139_IB_UK_Neu 13.01.2006 10:11 Uhr Seite 3
- 4 -
bifinett KH 1139
Automatic grill & bake oven
Safety precautions
Safety precautions
• When in use, never leave the
appliance unattended.
• Always make sure that the appliance
is kept out of the reach of children.
• We advise you not to open the casing
or undertake any repairs of the auto-
matic grill & bake oven. By failing to
observe this rule, you risk your safety
and the warranty may become inva-
lid. In case the grill & bake oven is
found to be defective, get it repaired
only by the shopkeeper’s service
personnel or an authorised technician.
• Do not use the appliance if you notice
any damage to the appliance or to
the power cord. In such a situation
get the appliance repaired by a
qualified technician.
• Make sure that no fluids enter into
the casing of your grill & bake oven.
Do not expose the appliance to
humidity and do not use it outdoors.
Moreover, do not keep any objects
filled with fluids such as vases on the
appliance. It may cause fire accidents
or electrical shocks. If any fluid
accidentally enters into the casing of
the appliance, remove the plug from
the power socket and get it repaired.
• When in operation, avoid placing the
automatic grill & bake oven directly
next to any easily inflammable
material, like kitchen towels, pothol-
ders and so on. Never attempt to dry
textiles or other objects on, above or
inside the appliance. This can lead to
fire hazards.
• Never touch the heating elements or
the glass door when the grill & bake
oven is still operating or before it has
cooled down completely. During the
operation do not touch anything
inside the grill & bake oven. Wait till
the appliance has cooled down,
otherwise you may sustain serious
burn injuries.
• When in use, the casing and the glass
door may become extremely hot.
Hence always use a potholder or
kitchen gloves to open the door of
the oven. Otherwise, you may sustain
serious burn injuries.
• After use, first allow your grill & bake
oven to cool down completely before
storing it away.
• Never touch the appliance, power
cord or plug with wet hands as this
may cause a severe electrical shock.
• Always hold the plug to pull it out of
the socket to remove the power cord
and not the power cord itself.
• Do not crease or crimp the power
cord.
KH1139_IB_UK_Neu 13.01.2006 10:11 Uhr Seite 4
- 5 -
• Place the power cord in such a
manner as to prevent anyone from
stepping on it or tripping over it.
• Do not use any extension cable with
the power cord.
• If you do not plan to use your grill &
bake oven for a considerable period,
disconnect it from the power supply.
There will be no electrical current,
only when the appliance is unplugged.
Explanations to safety precautions
The operating instructions include
different categories of safety
precautions as follows:
Danger
Any reference to the word DANGER
is a warning about possible hazard to
human life.
Caution
Any reference to the word CAUTION
is a warning about possible damage
to material or the environment.
This symbol indicates special tips for
the economical use of the grill &
bake oven.
Appropriate usage
Using the grill & bake oven, you can
heat, cook and grill foodstuffs. It may
only be used for this purpose. This also
implies the observance of all instructions
given in this manual, especially those
concerning safety. Any other form of
usage is considered as inappropriate and
it may have hazardous consequences on
material or on humans as well.
Kompernass is not liable for any dama-
ges resulting from the improper use
by its owner.
Items delivered
The package contains
• the automatic grill & bake oven
model KH 1139
• two metal grating
• a baking tray
• a handle
• warranty card
• Operating manual.
bifinett KH 1139
KH1139_IB_UK_Neu 13.01.2006 10:11 Uhr Seite 5
- 6 -
bifinett KH 1139
Installation
➩Place the appliance on a firm, flat and
heat-resistant base. Make sure that
the area surrounding the appliance is
adequately ventilated.
Fire hazard
There must be a clearance of at least
10 cm between the back of the
appliance and the wall, at least
10 cm above the top and 5 cm each
on the sides. Therefore, do not place
the appliance, for example, in a shelf
or a narrow space. Lack of sufficient
ventilation for the grill & bake oven
can cause a fire or damage the
appliance.
Fire hazard
Place the grill & bake oven only on
a firm, flat and heat-resistant base.
Failing to do so can cause fire
hazards or damage the appliance.
The appliance may leave permanent
marks, if placed on a soft surface.
Danger of electrical shock
Do not place the appliance directly
next to a water source, for example,
near washbasins, washtubs or in
humid cellars. Such locations can be
dangerous due to electrical shocks.
Do not lean or pla-
ce articles on the
glass door as this
would result in
damage to the
hinges.
Description
Using the grill & bake oven you can
warm, bake and grill different food-
stuffs. The provision for hot air convec-
tion ensures uniform and quick distribu-
tion of heat within the appliance.
Control knobs
Temperature control knob:
Variable temperature setting range
of 100°C to 250°C
Main switch for
OFF,
Upper heat,
Lower heat and
Upper & Lower heat.
Pilot light (Power)
is ON during the operation
Timer switch
for setting the desired baking /
grilling time range of 0 – 60 min.
Tappet switch for hot air convection
Glass door with handle
Metal grating
Baking tray
Grip for grating/baking tray
KH1139_IB_UK_Neu 13.01.2006 10:11 Uhr Seite 6
- 7 -
bifinett KH 1139
Starting to use the appliance
➩Remove the automatic grill & bake
electric oven and all the accessories
from the packing.
Danger of contusion
While opening or closing the door,
do not keep your hand at the door
hinges. Your hand may sustain
injuries due to contusion.
➩Before operating the appliance for
the first time, remove all traces of the
packaging material from the applian-
ce and all accessories. Wipe the
accessories clean using lukewarm
water and mild liquid soap solution
and wipe them dry.
➩Wipe the appliance casing gently with
a wet cloth and allow it to dry.
➩When the appliance is fully dry inside
and outside, connect the power plug
to an available wall socket
(230V AC, ~ 50 Hz).
➩Now switch the appliance on without
the accessories and without placing
any grilling or baking items in it. Keep
the appliance door fully open.
➩Set the temperature control knob
to 250°C. Set the main switch to
Upper or Lower or Upper & Lower
heat.
➩Set the timer switch to 15 minutes.
Because the new heating elements
are slightly greased, you may notice
an odd smell when the appliance is
used for the first time. This is harm-
less and will vanish after a while.
Open the window and ensure there
is enough ventilation.
➩Once the appliance has automatically
switched off, set the main switch to
OFF position.
➩Remove the power cord from the
socket and wait till the appliance has
cooled down completely.
➩Finally, clean the inside area with a
slightly wet cloth and wipe it dry.
Switching off and storing away
Switching off
➩Set the main switch and the timer
switch to OFF position. Pull the
mains plug out of the plug socket.
Transportation
➩If you wish to transport the grill &
bake oven to a different location, first
allow it to cool down.
➩Remove the power cord from the
socket.
➩Wind the power cord around the
bracing hooks at the back of the
appliance.
KH1139_IB_UK_Neu 13.01.2006 10:11 Uhr Seite 7
- 8 -
Operation
Grilling and baking
➩Remove the metal grating and the
baking tray from the oven. If
necessary, spread a wax paper on
them or apply butter or oil to the
baking tray .
➩Place the items to be grilled or baked
on the grating or the baking tray
and slide it into one of the railings.
Make sure that there is sufficient
distance between the grilling and
baking items as well as the inside
walls and the heating elements of the
appliance.
➩If you wish to use the grill & bake
oven in baking mode, close the glass
door .
➩If you wish to grill foodstuffs on the
grating , leave the glass door
slightly opened. When you close the
door slowly, it would stop at this posi-
tion before completely closing.
➩Using the temperature control knob ,
select the desired temperature. In the
grilling mode, always select the maxi-
mum temperature level (250 °C).
➩Finally, using the main switch select
Upper heat (for au gratin), Lower
heat (for cakes) or Upper & Lower
heat (for pizza). For grilling items,
turn the main switch to Upper
heat.
➩Using the timer switch set the
desired grilling or baking time.
Maximum grilling or baking time is
60 minutes.
➩If the cooking time for your grilling or
baking items is less than 25 minutes,
first set the timer switch to
60 minutes and then set it to the
desired grilling or baking time.
➩If you need to preheat the oven, add
this time to the actual cooking time.
The pilot light indicates that your grill
& bake oven is switched on. The timer
switch now moves in the anti-clockwi-
se direction to the OFF position (zero).
➩The appliance is automatically swit-
ched off when the set time runs out.
If you wish to switch off the appliance
earlier, turn the timer switch back
to the OFF position. Turn function
switch to the OFF position and pull
the mains plug out of the plug socket.
You will hear a bell tinkle and the pilot
lamp is turned off.
