A: 9300 S.W. Gemini Drive Beaverton, OR 97008 USA W: www.biamp.com

Desono™

Ceiling Loudspeaker Accessories

Black Grille

Installation Guide

SPA-GRB

Black Grille

Model Fits

SPA-GRB100 CM20DTS, CM30DTD

SPA-GRB200 CM60DTD

Biamp offers several sizes of Black Grilles (GRB) suitable

for the Desono CM ceiling loudspeakers. They are sold in

6-packs and can be installed on the ceiling loudspeaker by

substituting the black grille for the white grille included with

the unit. Please refer to the appropriate Installation and

Operation guide for full installation instructions.

Installation

1. Install the loudspeaker per the instructions in the

manual and adjust tap settings as necessary.

2. Attach the grille tether by inserting the tether plug in

the hole in the loudspeaker face.

3. Position the grille against the outside ring. The

magnets will hold the grille in place.

2

3

1

Typical installation (CM30DTD shown)

A: 9300 S.W. Gemini Drive Beaverton, OR 97008 USA W: www.biamp.com

SPECIFICATIONS

Typical Grille

585.0233 5NOV2021

CONTACT US

Email: [email protected]

Web: support.biamp.com

Warranty: biamp.com/legal/warranty-information

Material / Finish: Powder-coated perforated steel backed with acoustically transparent color

matched cloth. Color is RAL 9017.

Quantity per kit: Sold in 6-packs

Model Fits Ø Diameter mm [in]

SPA-GRB100 CM20DTS, CM30DTD Ø 221 mm (8.69")

SPA-GRB200 CM60DTD Ø 258mm (10.15")

Scan this QR-code and navigate to

your loudspeaker model to download

the appropriate installation guide

bia.mp/DesonoCeiling_pubs

Ø
