BGS 950

Digital Torque Wrench

SPECIFICATIONS

Model Nr.

BGS 950

BGS 951

BGS 952

Accuracy

± 2 %

± 4 %

Square Driver

12.5 mm (1/2")

10 mm (3/8")

6.3 mm (1/4")

Torque Range

40-200 Nm

27-135 Nm

6-30 Nm

Resolution

0.1

Size

480 x 40 x 40 mm

380 x 35 x 35 mm

290 x 35 x 35 mm

Weight

1.05 kg

0.66 kg

0.4 kg

Memory

50 data sets of memory capacity

Operation Modes

Peak or Trace

Unit Selection

Kg-cm, Kg-m, Ib-in, Ib-ft, N-m

Battery

1.5V AAA (2 pcs)

Operation Temperature

-10°C ~ 60°C (13.9°F ~ 139.9°F)

Storage Humidity

-20°C ~ 70°C (-4°F ~ 157.9°F)

Operation Humidity

15% ~ 90%

Auto Shut Off

After 80 seconds of no use

IMPORTANT

Read this manual before operating the torque wrench. Failure to follow instructions listed in this guide

may result in damage of electrical system, wrong torque setting and/or serious injury

FEATURES

•50 data sets of memory capacity

•2 LEDs red / green for visual alerting

•72 gear teeth

•Standard functions: torque setting, measurement setting, mode setting

•Operation in both clockwise and counter-clockwise directions

•LCD display shows kg/cm, kg/m, lb-in, lb-ft, N/m

•Audible torque confirmation by means of buzzer

•Easy to set up Peak or Trace modes

•Anti-slip soft grip

WARNING

•Please use the torque wrench in a clean and dry place only.

•Do not use organic solvents to clean the torque wrench.

•Clean the torque wrench and LCD panel with a soft dry cloth only.

•Keep children and unauthorized persons out of the working area.

•Do not immerse the torque wrench in any liquids.

•Remove the batteries, when the torque wrench is not use for a longer period to avoid the

wrench damage.

•Do not disassemble the torque wrench and do not make any changes to the wrench.

•Do not shake or drop the torque wrench.

•Do not leave the wrench at place of over-heating, humidity or direct sun.

BGS 951

BGS 952

BGS technic KG

Bandwirkerstr. 3

D-42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

mail@bgs-technic.de

www.bgstechnic.com

DESCRIPTION

BATTERIES

•Do not mix old and new batteries with this torque wrench.

•Do not mix alkaline with carbon zinc or rechargeable lithium-ion (Li-ion) batteries.

•Do not install batteries backwards.

•Do not throw batteries into fire. Batteries can explode or leak causing personal injury.

•Remove batteries when storing the torque wrench for a long period. Batteries should be stored

at room temperature.

FUNCTION SETTINGS

•Battery

Install and change batteries: Open the end cap then insert two 1.5V AAA batteries (positive end

first) into compartment, tighten the cap.

•Switch on/off the power

Press the power button for 3 seconds will turn on the LCD screen and buzzer. There are two

modes trace (trACE) & peak hold (PtoP) to use, when switch is done. The LCD will show one of

the mode and digit 00.0.Pr. LCD will display both torque unit and value.

•Set Torque Unit Selection: kg/cm, kg/m, lb-in, lb-ft, N/m

Please press the button & at the same time and release them to select different torque unit.

•Set Torque Value. Press the or button to apply a right value then release it to set up

torque, the value will be memorized after flashing 10 seconds then LCD will show 00.0

automatically.

•Peak Hold Operation

In this mode, an acoustic and optical signal is output when the previously set torque value is

reached. Press & at same time then release it to get (PtoP) peak hold set up mode, then

press or button to set up the torque.

•Track Mode Operation

In this mode, the display shows the currently applied torque.

Press & in the same time again to get trace (trACE) mode then use or to to set up

torque.

UNIT

BUZZER

MEMORY

POWER

TRACE & PEAK

LED

LCD

BATTERY CAP

BGS technic KG

Bandwirkerstr. 3

D-42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

mail@bgs-technic.de

www.bgstechnic.com

FUNCTION SETTINGS

•Backlight function

When the power is on, press power button again to turn on/off the backlight.

•Auto shut off

The power will auto shut off after 80 seconds of on use.

•Memory function

Please stay at peak hold mode (PtoP) then press Mem for one second then release it to set

up the memory P01~P50 , there are 50 data of memory capacity cycling.

NOTE

If the battery capacity is low, a battery symbol will be displayed on the screen to remind you to change

new batteries. If the wrench not in use for a period of time, remove the batteries from compartment.

The battery life is not only decide by its quality but also the last of acting flash, buzzer and backlight.

ENVIRONMENTAL PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories

and packaging should be sorted, taken to a recycling centre and disposed of in a manner

which is compatible with the environment.

DISPOSAL

Do not dispose battery in household waste.

Batteries should be disposed of in a responsible manner, they must be disposed at

appropriate collection point.

Dispose of this product at the end of its working life in compliance with the EU Directive

on Waste Electrical and Electronic Equipment. Contact your local solid waste authority

for recycling information or give the product for disposal to BGS technic KG or to an

electrical appliances retailer.

NOTES
