BGS technic KG

Bandwirkerstr. 3

D-42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

mail@bgs-technic.de

www.bgstechnic.com

© BGS technic KG, Copying and further use not allowed

BGS 67302

Pull and Press Sleeve Kit

INTENDED USE

This universal tool set is used for removing and installation of silent bushings, hydraulic bushings, ball

bearings, oil seals, rubber bushings, etc.. Ideal for different vehicles such as car, SUV, van, etc..

Used with spindle or hydraulic-workshop-press.

SAFETY ADVICE

•Read carefully the instructions before working with this tool set.

•Do not use this tool set for other purpose for which it is designed.

•Lifting of vehicles only allowed on the special lifting points.

•Before starting work under a car always ensure that it is adequately supported by axle stands or

ramps. Chock wheels and ensure that the hand brake is firmly applied.

•Always use approved eye protection, especially when working under vehicles.

•Ensure a secure and well-gripped stance during fitting.

•Ensure that tools are correctly mounted.

•Regularly check the condition of the tool and replace the damaged parts.

•Do not over tighten or use undue force as this can cause damage to both tool and component.

•The tool is not suitable for air impact wrenches. The use of an air impact wrench may lead to the

spindle bearing or other components bursting and fragments of components flying around may

lead to injuries.

•Always use workshop manual for detailed instructions.

•Always lubricate the screw threads before using the tool.

•Check & replace any damaged components as required.

•Keep children and unauthorized persons out of the working area.

Keep this tool out of children reach.

BGS technic KG

Bandwirkerstr. 3

D-42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

mail@bgs-technic.de

www.bgstechnic.com

© BGS technic KG, Copying and further use not allowed

CONTENTS

4 force screws:

M10 x 1.5 - M12 x 1.5 - M14 x 1.5 - M16 x 1.5 mm, 450 mm long

Plates and Sleeves can also be used in a standard workshop press

Sleeve wall thickness: 5 mm

Sleeve height: 94 mm

Sleeve outer diameter: 44, 46, 48, 50, 52, 54, 56, 58, 60, 62, 64, 66, 68, 70, 72, 74, 76, 78, 80, 82 mm

End Plates : Ø 83 x 20 mm

USE

ASpindle with Nut

BEnd Plates

CSleeves

DHousing (Bearings / Bushes)

EWheel Bearing / Bushes

A

C

D

E

B

C

B
