Bernina BERNETTE 50 Manual de usuario

Quick on your FEET

BERNINA

Walking

Foot #50

A Walk

in the Park

This quilt is done entirely with

Walking Foot #50. The blocks are

stitched individually, and then

seamed so that the raw edges are

to the front of the quilt. The edges

are covered with bias strips and

the quilt is finished with traditional

binding.

By Nina McVeigh

Draw diagonal lines

connecting the corners of

each block.

Construction

Attach the open-toe sole to Walking Foot #50;

this sole provides extra visibility. Attach Walking

Foot #50 to the sewing machine.

Insert a new #90/14

Embroidery needle into the

machine. Select an Isacord

thread color to complement

each of the 7 block fabrics.

Thread needle and bobbin

with the same thread color.

Select a decorative stitch

and quilt the block along

the diagonals. Choose open

stitches, avoiding satin-

based stitches.

Walking Foot #50 is a very helpful aid for working

with layers of fabric. It can be used with almost any

decorative stitch, making grid quilting much more

interesting! The ability to move the needle to any

position makes precision piecing a breeze. This quilt

is done entirely with Walking Foot #50. The blocks

are stitched individually, and then they are seam so

that the raw edges are to the front of the quilt. The

raw edges are covered with bias strips and the quilt

is finished with traditional binding.

Supplies

• ⅔yard of seven different fabrics

• 1¼ yards fabric for binding & strips between blocks

• 2¼ yards loft batting (or twin size batt)

• Isacord thread in eight colors to coordinate with

quilt fabrics (can use fewer colors if desired)

• Embroidery needle, size 90/14

• Denim needle, size 90/14

• Walking Foot #50 with Guides

• 1” Bias Tape Maker

• Water-soluble glue stick

• Spray starch

• Rotary cutting equipment

• 12½” square quilting ruler

• BERNINA Sewing Machine

Cutting Instructions

Using a rotary cutter, mat and ruler cut the 7 pieces

of fabric into 10¾” squares (8 from each piece).

Cut the batting into twenty-five 10¾” squares.

Preparation

Make 25 quilt sandwiches using the fabric and bat-

ting squares, layering the same print on the top and

bottom of each batting square.

You will have six extra fabric squares left over.

Attach the right hand

guide to Walking Foot

#50 and set it at 3”

from the needle.

Tighten the screw

to hold it in place.

Place the guide on

the previously stitched

line and sew the same

decorative stitch on

each side of the two

diagonal lines.

Stitch all blocks of

the same fabric with

the same thread,

choosing a different

decorative stitch for

each block. Choose

open decorative

stitches, avoiding the

satin-based stitches.

Repeat until you have stitched 25 blocks.

When all blocks are stitched, trim to 10” squares.

Arrange the blocks as desired in a 5 x 5 grid.

With wrong sides

(backs) together, sew

five blocks together in

a row. Guide the edges

with the ¼” seam mark

on the walking foot.

Make 5 rows.

Press seam allowances

open—they will be on

the right side of the quilt.

With wrong sides

(backs) together, stitch

the rows together to

make a square.

Press seam allowances

open.

Select a zigzag stitch

with length = 2mm,

width = 5mm. Zigzag

the seams open using

a thread that is comple-

mentary to all the blocks,

as it will show on the

back of the quilt.

Spray starch the binding fabric. To avoid seaming,

fold the fabric at a diagonal so that when you cut the

bias strips in the next step you will be cutting strips

as long as possible.

Cut eight 1¾”-wide bias strips that are at least 52”

long (seaming if necessary). Set aside the rest of the

fabric.

Load the bias tape

maker with a binding

strip. Pull the fabric

through the bias tape

maker and press as

the folded strip exits

the other end. (I found

that my strips were

more even and consistent when I pressed from the

top side of the fabric.)

Measure the width of

the pressed strip and

divide the measure-

ment in half. Measure

this distance out from

the seam and draw a

placement line for the

edge of the bias strip.

Position a folded bias strip over the seam, aligning

the edge with the marked line. Use a glue stick to

hold the strip in place.

Remove the guide from Walking Foot #50. Remove

the open-toe sole from the foot and attach the

standard sole. Since you will be stitching through

more layers of fabric you may want to change to a

#90/14 Denim needle.

Select a straight stitch

and move the needle

position 2 steps to the

right of center. Place

the quilt under the foot

with the edge of the

bias strip just inside

the right toe of the

foot. Stitch down the

side of the strip.

Repeat for the second

side of the strip.

Lay four strips in one

direction, then lay the

remaining four strips

in the other direction.

From the fabric left over from cutting the bias strips,

cut enough 2½”-wide bias strips to go around the

outer edge of the quilt—about 220”. Seam the bias

strips together. Press the long strip in half length-

wise, wrong sides together.

Place the folded bias

strip on the right side

of the quilt with the

raw edges even. Sew

the folded bias strip

to the quilt using a ⅜”

seam allowance. To

accomplish this, move

the needle position all

the way to the right and guide the raw edge of the

fabric along the outside edge of the foot.

When all of the binding is sewn to the front of the

quilt, press it out away from the quilt. Pull the binding

around to the back of the quilt and stitch along the

inner folded edge to hold the binding in place.

For additional information on Dual Sole

Walking Foot with Guides #50 and other

BERNINA presser feet, attachments, and

accessories, see Feetures, volumes 1-3.

Visit

www.berninausa.com

for additional projects and information.
