Bentel Security EasyGate 3 Manual de usuario

BS EN ISO 9001

®®

BENTEL SECURITY srl. reserves the right to change the technical specifications of this product

without prior notice.

The EasyGate3 Digital

key and Door Control System

complies with the following normative laws:

Emission: EN 50081-1:1992

Immunity: EN 50130-4:1995+A1:1999

Low Voltage: EN 60950:2000

The Easygate3 Digital Key and Door Control system can be programmed via the EasyGate3 Software

Application 4.0 (or higher) contained in the Bentel Security Suite.

Installation of the EasyGate3 must be carried out strictly in accordance with the Instructions described

in this manual, and in compliance with the local laws and bylaws in force.

This product has been designed and made to the highest standards of quality, reliability and performance.

BENTEL SECURITY Srl. recommends that the entire system be completely Tested at least once a month.

The Test procedures depend on your Security system,

ask your Installer for the relevant instructions.

BENTEL SECURITY Srl. shall not assume the responsibility

for damage arising from improper application or use. The EasyGate3 has no user friendly components,

therefore, should be serviced and repaired by authorized personnel only.

®®

TABLE OF CONTENTS

INTRODUCTION ...................................................................................................................................... 5

System Specifications ...................................................................................................................... 5

About the system .............................................................................................................................. 5

Accessory Items ............................................................................................................................... 5

Technical Specifications ................................................................................................................... 7

PARTS DESCRIPTION ............................................................................................................................ 8

The Parts of the ECLIPSE reader and SAT key ................................................................................ 8

The Parts of the PROXI reader PROXI card ..................................................................................... 9

EasyGate3 Module Parts ................................................................................................................ 10

NC2TAST LEDs and Parts ............................................................................................................... 11

INSTALLING THE EASYGATE3 ............................................................................................................ 12

Installing the Peripherals ................................................................................................................. 12

The Terminal board .......................................................................................................................... 13

Setting up the EasyGate3 (via DIP Switches) ................................................................................ 14

Selecting the Operating Mode (via DIP Switches) ......................................................................... 14

Connecting ECLIPSE readers, Proximity readers and NC2TAST Keypads ................................... 15

Automatic Enrolling .......................................................................................................................... 16

Enrolling BPI Devices ...................................................................................................................... 16

Resetting Default ............................................................................................................................. 16

Outputs ............................................................................................................................................ 17

Inputs ............................................................................................................................................... 18

Connecting Security Panels ............................................................................................................ 19

Enrolling SAT Keys and PROXI-CARDS .......................................................................................... 19

Programming ECLIPSE and PROXI readers .................................................................................... 20

Programming NC2TAST Keypads and Codes ................................................................................ 20

OPERATING MODES ............................................................................................................................. 21

MODE 1 - 3 LED/Relay Proximity Control ........................................................................................ 21

MODE 2 - 1 LED/Relay Proximity Control and Door Control System .............................................. 23

MODE 3 - Door Control .................................................................................................................... 24

PROGRAMMING FROM PC ................................................................................................................ 25

Customer ......................................................................................................................................... 26

Status .............................................................................................................................................. 27

Configuration ................................................................................................................................... 28

ECLIPSE/PROXI Readers ................................................................................................................. 29

Keypads .......................................................................................................................................... 30

SAT Keys and PROXI Cards .......................................................................................................... 31

User Codes page ............................................................................................................................ 33

Buffer (Events) ............................................................................................................................... 34

Clock ................................................................................................................................................ 35

EasyGate3 - Digital Key and Door Control System

Timers .............................................................................................................................................. 36

OC Output configuration ................................................................................................................. 37

Language used on Printer .............................................................................................................. 38

Outputs ............................................................................................................................................ 39

Control ............................................................................................................................................. 40

Software PINs ................................................................................................................................. 42

File Menu ......................................................................................................................................... 43

Options ............................................................................................................................................ 44

Serial Port Menu .............................................................................................................................. 45

Manage Buffer Menu ...................................................................................................................... 45

Help Menu ........................................................................................................................................ 46

PROGRAMMING FROM THE KEYPAD ................................................................................................ 47

Accessing the Programming session ............................................................................................. 47

Programming User PINs at keypad .................................................................................................48

Programming the Date and Time of EasyGate3 .............................................................................. 48

Buffer Printout ................................................................................................................................. 49

Keypad Outputs .............................................................................................................................. 50

Enable Keypad ................................................................................................................................ 50

ECLIPSE/PROXI Reader Outputs ..................................................................................................... 51

Enable keypad ................................................................................................................................. 51

User Code Outputs ......................................................................................................................... 52

Enable User Code ........................................................................................................................... 52

Proximity Control Outputs ............................................................................................................... 53

Enable User Keys/Cards ................................................................................................................ 53

Enrolling User Codes ...................................................................................................................... 54

Deleting User Codes, Keys and Cards ........................................................................................... 54

Change Installer PIN ........................................................................................................................ 54

USER COMMANDS ............................................................................................................................... 55

MODE 1 - 3 LED/RELAY DIGITAL KEY ............................................................................................ 54

Arming and Disarming your Security Panel ............................................................................. 55

False key/card at reader .......................................................................................................... 55

Wrong PIN ................................................................................................................................. 55

Line Check ................................................................................................................................ 56

Tamper ...................................................................................................................................... 56

Partitioning ................................................................................................................................ 56

MODE 2 - 1 LED/RELAY PROXIMITY CONTROL AND DOOR CONTROL SYSTEM ........................ 56

EasyGate3 busy ....................................................................................................................... 57

Arming and Disarming Proximity Control .................................................................................. 57

Door Control .............................................................................................................................. 57

False Key .................................................................................................................................. 58

Wrong PIN ................................................................................................................................. 58

Tamper ...................................................................................................................................... 58

MODE 3 - DOOR CONTROL ............................................................................................................ 58

Door Control .............................................................................................................................. 59

False Key .................................................................................................................................. 59

Wrong PIN ................................................................................................................................. 59

Tamper ...................................................................................................................................... 59

®®

INTRODUCTION

Please read this section carefully to get an overall understanding of the steps involved

in installing the EasyGate3 System.

System Specifications

Manages 50 codes

Supports up to 100 SAT Keys/PROXI Cards

Supports up to 8 control devices: NC2TAST keypads (maximum 4), ECLIPSE/PROXI and readers

Serial port for PC (for system programming and management) or serial printer

Easy viewing of system status (no key/card required)

False key signal

‘Line Check’ Arming Inhibition

4 wire connection to reader

Houses 12 V - 1.2 Ah battery (97 x 52 x 43)

220 Vca power supply

About the system

The user-friendly EasyGate3 is at the forefront of Digital key and Door Control technology. It can be

simply and cost efficiently integrated with all advanced domestic or light commercial applications

small to medium sized installations. This no-fuss system enhancement tool provides a range of day-

to-day management functions that will allow the User to control several EasyGate3 enhanced

systems with the same key.

The Bentel Peripheral Interface (between the key readers and the EasyGate3) greatly increases the

level of security, and provides high EMI immunity.

Accessory Items

The EasyGate3 provides fast and secure control of Security systems that support an overall

composition of 8 of the following

control devices: NC2TAST keypads

(maximum 4), ECLIPSE or PROXI

readers (maximum 8).

All accessory items must be

ordered separately.

Figure 1 - The EasyGate3 Module

EasyGate3 - Digital Key and Door Control System

Following is a detailed description of the system accessories

and their functions.

ECLIPSE KEY READERS The ECLIPSE readers (Figure2a)

can be connected to the EasyGate3 by just 4 wires. The

system can be commanded by simply pushing the SAT key

(Figure 3b) into the ECLIPSE reader slot. The system status

can be easily viewed on the reader LEDs. The ECLIPSE/SAT

contactless system is highly resistant to oxidizing agents.

ECLIPSE key readers are available in different versions to fit

the most widely used outlet boxes (refer to Table 1).

PROXIMITY READERS The PROXI Readers (Figure2b) can

be connected to the EasyGate3 by just 4 wires. The system

can be commanded by simply holding the PROXI Card in the

vicinity of the sensitive field [14] of the PROXI Reader. The

system status can be easily viewed on the reader LEDs. These

readers can also function with SAT keys.

PROXI-CARD The PROXI Cards are programmed (at Factory)

with a 32 bit Random Serial Number (RSN).

Figure 2a - ECLIPSE Key Reader

Table 1 - Available outlet boxes

Figure 2b - Lettore di Prossimità

TICINO magic GEWISS

TICINO li ving GEWISS playbus

TICINO international GEWISS noir

TICINO li ght VIMAR light

TICINO ready magi c VIMAR idea

AVE

AVE noir

Figure 3a - PROXI-CARD

®®

SAT KEY All SAT Keys are programmed (at Factory) with a 4

byte Random Serial Number (RSN).

 SAT Keys and PROXI Cards can operate the

EasyGate3 System.

The programming instructions for the EASYGATE3, SAT Key

and ECLIPSE reader can be found in the “PROGRAMMING”

section.

NC2TAST Keypad EasyGate3 supports up to 4 NC2TAST

Keypads (Figure 4).

Technical Specifications

Table 2 - Technical Specifications

Figure 4 - NC2TAST Keypad

Operating Voltage 230 V~50 Hz ±10 %

Maximum Current Draw from Mains 0.1 A~

PCB S Current Draw 120 mA_

Maximum available Supply Current to peripherals 450 mA_

NC2TAST Current Draw 50 mA_

ECLIPSE Current Draw 30 mA_

IP Rating II

Operating Temperature 0°C to 40 °C

Number of Relays 3 (Outputs) + 1 (AS)

Relay type Free Voltage Changeover

Contacts 30 V_/ 2 A

Dimensions (H x W x D) 180 x 220 x 60 mm

Battery 12 V / 1.2 Ah

Weight (wi thout battery) 1.5 Kg

Figure 3b - SAT Digital Key

OFF

ESC

ENTER

EasyGate3 - Digital Key and Door Control System

PARTS DESCRIPTION

This section describes the main parts of the EasyGate3, and the additional system devices: NC2TAST

keypads; ECLIPSE readers and SAT keys; PROXI readers and Proxi cards. The numbers in boldface

in the following tables refer to the parts illustrated in the various diagrams.

PART DESCRIPTION

1Reader Terminal board

2DIP Switch strip

34 DIP Switch ECLIPSE reader

45 DIP Switch ECLIPSE reader

5Jumper J1

6Jumper J2

7Red LED

8Amber LED

9Green LED

10 SAT key slot

11 Command button

12 SAT key

1234

11789 12

12345

12 345

The Parts of the ECLIPSE reader and SAT key

Figure 5a - ECLIPSE reader and SAT key

®®

Figure 5b - Proximity reader

PART DESCRIPTION

13 Frontplate

14 Sensitive field

Wire to be connected to the EasyGate3 BPI Bus:

Red Te r m i n a l " +" (Positive terminal)

White Te r m i n a l " C" (Call)

Blue Te r m i n a l " R" (Respond)

Black Te r m i n a l " –" (Negative terminal)

16 Frontplate screws

17 Weather Strip

18 Buzzer

19 Snatch Switch (not for EasyGate3)

20 Wire entry

21 Holes for backplate anchor screws (Ø = 4 mm)

22 Microprocessor

23 PROXI CARD

24 Locking tab

The Parts of the PROXI reader PROXI card

CNONC

1234

717

EasyGate3 - Digital Key and Door Control System

Figure 6 - EasyGate3 Module

PART DESCRIPTION

13 DIP Switch strip for hardware programming

14 Ta m p e r S w i t c h

15 Holes (4) for backplate anchor screws (Ø 5 mm)

16 Red LED

17 ENROLL Button (ACQ)

18 PROGRAMMING Button (PROG)

19 Microprocessor

20 Digital key Terminal board

21 Mains connection Terminal board (220 Vca)

22 Safety Fuse (250 V - 250 mA)

23 Battery 12V - 1.2 Ah (not included)

24 Wire Entry

25 Battery Connecti on Wire

26 DB9 Connector for PC or Printer Serial Link (not included)

12345678

NC1 C1 NA1 NC2 C2 NA2 NC 3 C3 NA3 AS BPI

+C RP1 P2 P3 AB ACAP

27 28 29 30 31

EasyGate3 Module Parts

Tabla de contenidos

Otros manuales de Sistema de control de Bentel Security

Bentel Security

Bentel Security BTEL-3G Manual de usuario

Manuales populares de Sistema de control de otras marcas

Pentair Pool Products

Pentair Pool Products Compool Manual de usuario

ComfortNET

ComfortNET CTK04 Manual de usuario

Fireye

Fireye InSight II 95DSS3 Manual de usuario

CAME

CAME G3000 Manual de usuario

Idemia

Idemia MorphoAccess VP MD Manual de usuario

Axis

Axis P1445-LE-3 Manual de usuario

HEIDENHAIN

HEIDENHAIN TNC 150 B Manual de usuario

CNC-Step

CNC-Step High-Z T-Series Manual de usuario

Doosan

Doosan DVF Series Manual de usuario

Honeywell

Honeywell KAP 140 Manual de usuario

Honeywell

Honeywell vk41 series Manual de usuario

AirBench

AirBench FPW Guía de instalación

Cypress

Cypress HHR-3160 Manual de usuario

CAME

CAME GLT40AOS Manual de usuario

Zonex

Zonex GEN II -VVT Guía del usuario

Altronics

Altronics K 9650 Manual de usuario

micro-trak

micro-trak RoadMaster Manual de usuario

micro-trak

micro-trak Calc-An-Acre II Manual de usuario
