BenQ W7000 Manual de usuario

Digital Projector

Quick Start Guide

W7000/W7000+

Quick Start Guide

Guide de démarrage rapide

Kurzanleitung

Guide rapida

Guía de inicio rápido

Guia de iniciação rápida

Snabbstartsguide

Краткое руководство

Snelgids

Skrócona instrukcja obsługi

Hızlı başlangıç kılavuzu

Průvodce rychlým používáním

快速使用指南

クイックスタートガイド

BenQ.com

1K101.001

P/N: 4J.J3901.001

Projection dimensions

<F>

<G>

<A>

<D>

<C> <E>

<E>

<F>: Screen <G>: Center of lens

<F>

<D>

<A>

<G>

The above numbers are approximate and may be slightly different from the actual measurements. Only the

recommended screen sizes are listed. If your screen size is not in the table above, please contact your

dealer for assistance.

<D>

<F>

<H>

<G>

<A>

<F>

<H>

<E>

<D>

<G>

<A>

Diagonal

<A>

[inch (mm)]

Height

<C>

[mm]

Width

[mm]

[cm]

Lowest/

Highest lens

position <E>

[mm]

Min distance

(with max

zoom)

Max distance

(with min

zoom)

Average

The screen aspect ratio is 4:3 and the projected picture is 16:9

The screen aspect ratio is 16:9 and the projected picture is 16:9

<C>

<C> <E>

<C>

Diagonal

<A>

[inch (mm)]

Height

<C>

[mm]

Width

[mm]

Max

distance

(with min

zoom)

Min

distance

(with max

zoom)

Average

Lowest/

Highest lens

position <E>

[mm]


height

<H>

[mm]

d d

[cm]

Timing chart

WXGA_85 84.880 71.554 122.500

SXGA_75 75.025 79.976 135.000

720 x 400 720x400 70.087 31.469 28.3221

640 x 480

VGA_60 59.940 31.469 25.175

VGA_72 72.809 37.861 31.500

VGA_75 75.000 37.500 31.500

VGA_85 85.008 43.269 36.000

800 x 600

SVGA_56 56.250 35.156 36.000

SVGA_60 60.317 37.879 40.000

SVGA_72 72.188 48.077 50.000

SVGA_75 75.000 46.875 49.500

SVGA_85 85.061 53.674 56.250

1024 x 768

XGA_60 60.004 48.363 65.000

XGA_70 70.069 56.476 75.000

XGA_75 75.029 60.023 78.750

XGA_85 84.997 68.667 94.500

1024 x 576

BenQ Notebook Timing

60.0 35.820 46.966

1024 x 600 64.995 41.467 51.419

1280 x 768 1280 x 768_60 59.870 47.776 79.5

1280 x 800

WXGA_60 59.810 49.702 83.500

WXGA_75 74.934 62.795 106.500

1280 x 1024

SXGA_60 60.020 63.981 108.000

SXGA_85 85.024 91.146 157.500

1280 x 960 1280 x 960_60 60.000 60.000 108

1280 x 960_85 85.002 85.938 148.500

1360 x 768 1360 x 768_60 60.015 47.712 85.500

1440 x 900 WXGA+_60 59.887 55.935 106.500

1400 x 1050SXGA+_60 59.978 65.317 121.750

1600 x 1200UXGA 60.000 75.000 162.000

1680 x 1050 1680x1050_60 59.954 65.290 146.250

1920 x 1080 1920x1080_60 59.939 / 60 67.432/ 67.5 148.35/ 148.5

640 x 480@67Hz MAC13 66.667 35.000 30.240

832 x 624@75Hz MAC16 74.546 49.722 57.280

1024 x 768@75Hz MAC19 74.93 60.241 80.000

1152 x 870@75Hz MAC21 75.06 68.68 100.00

FormatResolution Refresh rate (Hz) H. Freq. (KHz) Pixel Freq. (MHz)

HDMI(HDCP)

640 x 480

VGA_60 59.940 31.469 25.175

VGA_72 72.809 37.861 31.500

VGA_75 75.000 37.500 31.500

VGA_85 85.008 43.269 36.000

720 x 400 720x400 70.087 31.469 28.3221

800 x 600

SVGA_60 60.317 37.879 40.000

SVGA_72 72.188 48.077 50.000

SVGA_75 75.000 46.875 49.500

SVGA_85 85.061 53.674 56.250

1024 x 768

XGA_60* 60.004 48.363 65.000

XGA_70 70.069 56.476 75.000

XGA_75 75.029 60.023 78.750

XGA_85 84.997 68.667 94.500

XGA_120* (Reduce Blanking)

119.989 97.551 115.500

1024x576

BenQ Notebook Timing

60.00 35.820 46.996

1024x600

BenQ Notebook Timing

64.995 41.467 51.419

1280x720 1280 x 720_60* 60 45.000 74.250

1280 x 720_120* 120 90.000 148.500

1280 x 768 1280 x 768_60 59.870 47.776 79.5

1280 x 800

WXGA_60 59.810 49.702 83.500

WXGA_75 74.934 62.795 106.500

WXGA_85 84.880 71.554 122.500

1280 x 1024 SXGA_60 60.020 63.981 108.000

SXGA_75 75.025 79.976 135.000

SXGA_85 85.024 91.146 157.500

1280 x 960 1280 x 960_60 60.000 60.000 108

1280 x 960_85 85.002 85.938 148.500

1360 x 768 1360 x 768_60 60.015 47.712 85.500

*Supported timing for non-3D and 3D signal with Frame Sequential format.

1440 x 900 WXGA+_60 59.887 55.935 106.500

1400X1050 SXGA+_60 59.978 65.317 121.750

1600x1200 UXGA 60.000 75.000 162.000

1680 x 1050 1680x1050_60 59.954 65.290 146.250

1920x1080

1920x1080_60 (CEA-861)

59.939 / 60 67.432 / 67.5 148.35 / 148.5

640x480@67Hz MAC13 66.667 35.000 30.240

832x624@75Hz MAC16 74.546 49.722 57.280

1024x768@75Hz MAC19 75.020 60.241 80.000

1152x870@75Hz MAC21 75.06 68.68 100.00

FormatResolution Refresh rate (Hz) H. Freq. (KHz) Pixel Freq. (MHz)

Video/S-Video

DETV/HDTV(via Component inputs)

*Supported timing for non-3D and 3D signal with Frame Packing and Top-Bottom format.

**Supported timing for non-3D and 3D signal with Frame Packing and Side-by-Side half format.

Format Resolution Refresh rate (Hz) H. Freq. (KHz) Pixel Freq. (MHz) Aspect

480i 720 (1440) x 480 59.94 15.73 27 16:9

480p720 x 480 59.94 31.47 27 16:9

576i 720 (1440) x 576 50 15.63 27 16:9

576p720 x 576 50 31.25 27 16:9

720/50p* 1280 x 720 50 37.5 74.25 16:9

720/59p* 1280 x 720 59.94 44.955 74.175 16:9

720/60p* 1280 x 720 60 45.00 74.25 16:9

1080/23P* 1920 x 1080 23.98 26.973 74.176 16:9

1080/24P* 1920 x 1080 24 27 74.25 16:9

1080/25P 1920 x 1080 25 28.13 74.25 16:9

1080/30P 1920 x 1080 30 33.75 74.25 16:9

1080/50i** 1920 x 1080 50 28.13 74.25 16:9

1080/59i** 1920 x 1080 59.94 33.716 74.175 16:9

1080/60i** 1920 x 1080 60 33.75 74.25 16:9

1080/50P 1920 x 1080 50 56.25 148.5 16:9

1080/60P 1920 x 1080 60 67.5 148.5 16:9

Format Resolution Refresh rate (Hz) H. Freq. (KHz) Pixel Freq. (MHz)

480i 720 x 480 59.94/60 15.734/15.75 13.5

480p 720 x 480 59.94/60 31.469/31.5 13.5

72526.5105675x027i675

7252.1305675x027p675

52.475.7305027x0821p05/027

720/60p 1280 x 720 59.939/60 44.955/45 74.175/74.25

1080/50i 1920 x 1080 50 28.125 74.25

1080/60i 1920 x 1080 59.939/60 33.716/33.75 74.175/74.25

1080/24P 1920 x 1080 23.976/24 26.973/27 74.175/74.25

1080/25P 1920 x 1080 25 28.125 74.25

1080/30P 1920 x 1080 29.97/30 33.716/33.75 74.175/74.25

5.84152.65050801x0291P05/0801

1080/60P 1920 x 1080 59.939/60 67.432/67.5 148.35/148.5

NTSC 3.58 - 59.94/60 15.734/15.753.58

NTSC 4.43 - 59.94/60 15.734/15.754.43

PAL-B/G - 50 15.625 4.43

PAL M - 59.94/60 15.734/15.753.58

PAL N - 50 15.625 3.58

PAL 60 - 59.94/60 15.734/15.754.43

SECAM - 50 15.625 4.25/4.41

Format Resolution Refresh rate (Hz) H. Freq. (KHz) Pixel Freq. (MHz)

Ceiling mount screws:

M6 x 8 (Max. L = 8 mm)

Unit: mm

128

151.2 173

106

211.7

424.4

364.4124.5

397.9

83.2

104 175

240

324.1

92.2

222.2

282.2
